Lynk 430221 User manual

Using tool provided, securely tighten finger nuts.
Attach dividers to base using finger nuts.
Divider (4)
Base
Finger Nut (8)
Finger Nut (8)
Tool
Dividers (4)Base
Glide Frame
Discard (4)
Parts Bag
Finger Nut (8)
Tool
Instructions
Alignment Guide
Mounting
Screw (4)
Wood
Screw (4)
Parts Bag Includes
© 2016 Lynk, Inc. 8241 Melrose Dr. Lenexa, KS 66214
430221 Roll Out Bakeware Organizer R2 1
Roll Out Bakeware Organizer #430221
Tighten
3
Assemble
2
1Unpack

Set assembled dividers back onto glide
frame with mounting holes in dividers
and glide frame aligned.
Attach dividers to glide frame
using mounting screws.
Only gently tighten.
Remove assembled dividers from glide frame.
Move inner glide rails slightly forward as shown.
Mount glide frame into cabinet using
wood screws found in parts bag.
•The use of a power screwdriver
•Drill 4 starter holes using a 1/8”
diameter drill bit.
Recommended:
Install front
screws rst
Base
mounting
hole
Move glide
rails forward
Set the assembled dividers and base
onto glide frame with mounting
holes aligned.
Check for adequate
cabinet & door clearance.
Adjust glide frame
position if needed.
2 ” min.
50.8mm 2 ” min.
50.8mm
2 ” min.
50.8mm
Make sure arrows
are pointing to the
front of the cabinet
Alignment
Guide
Align glide frame in cabinet as shown using
alignment guide found in parts bag.
2 ” min.
50.8mm 2 ” min.
50.8mm
2 ” min.
50.8mm
4 5
Aligning Glide Frame Checking Cabinet Clearance
6Mounting Glide Frame
Attach Dividers
7
