Lyons Elite ETLxx663219 Series User manual

Subject to manufacturing tolerance of [+] or [-] 1/8"
Page 1
= Stud location
Left-hand drain shown—reverse layout for right-hand drain.
Elite™ Bathtub (ETLxx663219)
Above Floor Rough-in
6632 STUD LAYOUT. Lyons Elite™ 6632 Bathtub will t most
standard 32" x 66" bathtub walls.
IMPORTANT
• Read installation instructions carefully before starting project.
• Peel back protective lm to verify color before installation.
• Allow bathtub to reach room temperature before installation.
• Do not use plumber’s putty. Will cause product failure and void warranty.
Use a high grade silicone caulk for all necessary locations.
• Keep instructions for warranty information.
31⁄”
65⁄”
61⁄” 1”
19” 20”
26⁄”
13⁄”
51⁄”
33½"
66"
11" 15⁄"
6"
8¾" Drain C
L
Floor Cut Out (6" x 11")
DO NOT RETURN PRODUCT!
FOR QUESTIONS OR CONCERNS
please call or e-mail our customer support team
8:00am-4:30pm EST. Monday - Friday
1-800-458-9036
[email protected]
SUPPLIES YOU WILL NEED:
Screws, 1-5/8" Flathead
Shims
Construction Adhesive
Mortar Compound (Optional)
Drain & Overow Assembly with Extension
Silicone Caulk for Drain
TOOLS YOU WILL NEED:
Level
Jig Saw
Tape Measure
Pencil
Power Drill
Safety Glasses
(Additional models on next page)

31½"
54"
11" 14⁄"
6"
8¾" Drain C
L
Floor Cut Out (6" x 11")
31½"
60"
11" 14⁄"
6"
8¾" Drain C
L
Floor Cut Out (6" x 11")
Page 2
Elite™ Bathtub (ETLxx603019)
Above Floor Rough-in
Elite™ Bathtub (ETxx603016)
Standard Floor Rough-in
Elite™ Bathtub (ETxx543019)
Standard Floor Rough-in
29⁄”
59⁄”
55⁄” 1”
16” 17”
24⁄”
45”
13⁄”
29⁄”
53⁄”
49⁄” 1”
19” 20”
24⁄”
39”
13½”
29⁄”
59⁄”
55⁄” 1”
19”
20”
24⁄”
45”
13½”
Elite™ Bathtub (ETxx603219)
Standard Floor Rough-in
Left-hand drain shown—reverse layout for right-hand drain.
Left-hand drain shown—reverse layout for right-hand drain.
= stud location
= stud location
6030 STUD LAYOUT. Lyons Elite™ 6030 Bathtub will t most
standard 30" x 60" bathtub walls.
5430 STUD LAYOUT. Lyons Elite™ 5430 Bathtub will t most
standard 30" x 54" bathtub walls.
31⁄”
59⁄”
55⁄” 1”
19” 20”
26⁄”
45”
14½”
33½"
60"
11" 15⁄"
6"
8¾" Drain C
L
Floor Cut Out (6" x 11")
Left-hand drain shown—reverse layout for right-hand drain.
= stud location
6032 STUD LAYOUT. Lyons Elite™ 6032 Bathtub will t most
standard 32" x 60" bathtub walls.
LYONS INDUSTRIES, INC.
30000 M-62 West, Dowagiac, MI 49047
phone [phone] fax [phone]
lyonsindustries.com
e-mail [email protected]
11-04-15
Subject to manufacturing tolerance of [+] or [-] 1/8"
Subject to manufacturing tolerance of [+] or [-] 1/8"
Subject to manufacturing tolerance of [+] or [-] 1/8" Subject to manufacturing tolerance of [+] or [-] 1/8"

Page 3
FIGURE 1. Check to assure bathtub is level.
FIGURE 2. Apply construction adhesive to bathtub feet.
(Above oor rough-in feet shown)
FIGURE 3. Shim feet if needed using construction adhesive
to attach shims to bathtub feet and suboor.
FIGURE 4. Run a screw through bathtub ange at each stud
location.
A
Shims Sub-oor
1. Read and follow all instructions
2. DANGER: To reduce the risk of injury, do not permit children to use this unit unless they are closely supervised at all times.
3. Infants should not be permitted in the bathtub unit at water temperatures over 100˚ Fahrenheit and only with prior medical consultation and
permission from your doctor.
4. Pregnant women and persons suering from heart disease, diabetes, or high or low blood pressure should not enter the bathtub unit without prior
medical consultation and permission from their doctor
5. For your rst bath, start with a short duration of ve minutes. You can increase the time intervals as your body's tolerance adjusts. However, do not use
longer than 15 minutes at any one time.
6. High water temperatures and prolonged periods of use can raise internal human body temperature excessively and impair the body's ability to regulate
its internal temperature.
7. Check bathtub before use. Maximum safe temperature is 104˚ Fahrenheit (40˚ Celsius).
8. Observe reasonable time limits to avoid nausea, dizziness, and fainting.
9. Do not use bathtub while under the inuence of alcohol or narcotics.
10. Enter and exit the bathtub unit slowly.
11. Do not use electrically connected devices such as televisions, radios, stereo speakers, lights, cooking devices, hair dryers, telephones, or other electrical
appliances within ve feet of the bathtub unit.
12. Use this bathtub unit only for its intended use as described in this manual. Do not use attachments not recommended by the manufacturer.
READ BEFORE INSTALLATION AND/OR USE
IMPORTANT SAFETY INSTRUCTIONS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRICAL SHOCK OR INJURY TO
PERSON  CONTINUED
INSTALLATION INSTRUCTIONS
STEP 1. PREPARING ALCOVE
a. Strip alcove to bare studs.
b. Stud pocket should be constructed as shown above. Studs should be plumb and square to
sub-oor.
c. Floor must be clean, smooth, and level (check with level). Sub oor must be installed in the
stud layout. Do not install bathtub on open oor joists.
d. Cut hole in sub oor as shown above to accommodate drain (Not included).
STEP 2. TRIAL FIT BATHTUB
a. Trial t bathtub in prepared alcove. With bathtub sitting at on oor, check with level on top
of bathtub (Fig 1).
b. Use shims to level bathtub if needed (Fig 3).
c. Remove bathtub from alcove.
OPTIONAL: If sub-oor is not level, use a leveling compound (smooth mortar) or a similar
quick-setting compound specically made for leveling oors. This fully supports and levels
the bathtub.
STEP 3. INSTALLING BATHTUB
a. Connect overow assembly per manufacturer's instructions
b. Apply construction adhesive to all feet and install bathtub into alcove (Fig 2).
c. If needed, level bathtub with shims into construction adhesive under feet (Fig 3).
d. If needed, shim between bathtub and studs to create a tight t.
e. Once leveled, screw bathtub ange to all studs (Fig 4).
IMPORTANT
• Failure to screw ange to all studs will void warranty.
• If installing a door, make sure walls are plumb to accommodate jambs
CLEANING
• Do not use any abrasive cleaners or metal scrapers.
• If drywall mud or plaster gets on your bathtub, it may be carefully removed with a wooden
scraper made from a piece of scrap wood.
• Adhesive may be removed with mineral spirits.
• Ideal cleaners are Soft Scrub Gel® or Comet Gel®.
WARNING: Some cleaning products are not suitable for use. Read all labels carefully.
DO NOT USE if they say“not suitable for use with ABS, acrylic, or polystyrene."

Page 4
LYONS BATHING FIXTURE — LIMITED WARRANTY
5-YEAR CONSUMER, 2-YEAR COMMERCIAL
Lyons Industries, Inc. warrants to the original purchaser that this Lyons bathing xture will be free of manufacturing defects, which aect its performance
as a bathing or showering xture, under the following conditions and subject to the limitations contained in the ”Remedies”and ”Warranty Limitations”
sections. The Limited Warranty applies for 5 years from the date of purchase if the xture is used in a residential owner-occupied building for non-
commercial purposes; or for 2 years from the date of purchase if it is used in any other building, including any building used for rental, commercial, or
business purposes. This Limited Warranty is void if the xture is not installed in accordance with the installation instructions supplied by Lyons, or local
building codes and ordinances, or if the care and cleaning instructions supplied by Lyons are not followed. This Limited Warranty is also void if the xture
is moved from the location of its initial installation, or is subjected to accident, abuse, or misuse. The Limited Warranty excludes normal wear and tear,
and does not cover damage that can be repaired by following the Scratch Removal Instructions. This Limited Warranty shall be void unless any failure or
non-conformance is discovered before the expiration of this warranty, and is reported to Lyons, in writing, accompanied by the original proof of purchase,
within 30 days of discovery, to: Lyons Industries, Inc., 30000 M-62 West, Dowagiac, Michigan 49407
REMEDIES — The original purchaser’s remedy under this Limited Warranty is limited to the repair, replacement, or refund of the purchase price of the
xture, at Lyons sole option, of any part of the xture which has failed or does not conform to the manufacturer’s specications. In no event shall Lyons
be liable for lost prots, loss of use, incidental, special or consequential damages including, but not limited to, damage to or loss of use of the building or
its contents, arising out of any defect in the xture; nor shall Lyons be liable for any amount in excess of the original purchase price of the xture. Lyons
reserves the right to require the return, at purchaser’s expense, of the damaged xture for repair or exchange before providing services under this Limited
Warranty. If Lyons elects to replace the xture, its obligation is limited to supplying a replacement unit or component part of comparable size and style, and
does not include the cost of removal, installation, or transportation, which must be borne by the purchaser. Replacement parts provided under this Limited
Warranty are warranted for the remainder of the original warranty period applicable to the xture, as if such parts were original components of that x-
ture.
WARRANTY LIMITATIONS — THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IMPLIED WARRANTIES,
INCLUDING THOSE OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY DISCLAIMED. LYONS DISCLAIMS ANY AND ALL
LIABILITY FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow limitations of incidental or consequential damages,
so the above limitations and exclusions may not apply to you. In such states, Lyons’ liability shall be limited to the extent permitted by state law. ANY
IMPLIED WARRANTIES ARISING BY WAY OF STATE LAW, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR ANY IMPLIED WARRANTY OF
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION AND IN SCOPE OF COVERAGE TO THE TERMS OF THIS LIMITED WARRANTY, UNLESS
A SHORTER PERIOD IS ALLOWED BY LAW.
SCRATCH REMOVAL INSTRUCTIONS
1. For eective scratch removal and polishing, you will need to purchase these items.
1 sheet 1000 grit 3M® wet-dry sandpaper
1 sheet 1500 grit 3M® wet-dry sandpaper
1 sheet 2000 grit 3M® wet-dry sandpaper
1 small container of 3M® rubbing compound #05933
These items can be purchased at most auto supply stores that provide supplies to professional paint and body shops. Call
before you go. Not all auto supply stores will have these items.
2. Start sanding with 2000 grit paper. Use small squares of paper about 2" x 2" for all sanding, and use lots of water. The water
serves as both a lubricant and to prevent residue buildup on the paper. Residue buildup shortens the eective life of the paper
and may scratch the surface you’re trying to polish.
3. 2000 grit paper is the nest grit available (the higher the number, the ner the grit). If you can’t remove all of the scratches
with 2000 grit, switch to 1500 grit. Remember to wash the paper frequently with water as you sand.
4. If all of the scratches can’t be removed with 1500 grit, switch to 1000 grit. This should remove most ne scratches. If you have
deep scratches or a gouge, coarser paper may have to be used (see chart to right). Be careful! Using grit that is too coarse may
actually put in more scratches than it removes.
5. Once you have removed all of the scratches, by sanding with the nest paper possible, repeat the sanding process using
successively ner grits of paper until you’ve once again sanded with 2000 grit.
6. Now use 3M® rubbing compound #05933 on a soft, damp cloth. Polish using considerable pressure to produce a
smooth, shiny nish.
LIGHT SCRATCH
1500 – 2000 grit
MEDIUM SCRATCH
1000 – 2000 grit
DEEP GOUGE
600 – 2000 grit
SUPERFICIAL SCRATCH
2000 grit
SCRATCH / SANDPAPER GUIDE
13. Never drop or insert any object into any opening.
14. Keep all breakable objects out of area.
15. Prolonged immersions in hotter water may induce hyperthermia.
16. The causes, symptoms and eects of hyperthermia may be described as follows: Hyperthermia occurs when the internal temperature of the
body reaches a level several degrees above the normal body temperature of 98.6˚ F. The symptoms of hyperthermia include an increase in the
internal temperature of the body, dizziness, lethargy, drowsiness and fainting. The eects of hyperthermia include:
a) Failure to perceive heat
b) Failure to recognize the need to exit the hydromassage bathtub
c) Unawareness of impending hazard
d) Fetal damage in pregnant women
e) Physical inability to exit the hydromassage bathtub
f) Unconsciousness resulting in the danger of drowning
WARNING - The use of alcohol, drugs or medication can greatly increase the risk of fatal hyperthermia.
17. SAVE THESE INSTRUCTIONS.
