M-ti Secure plug User manual

SECURE PLUG™ PRODUCT MANUAL

Product Manual for

SECURE PLUG™

(PATENT PENDING)

DO NOT REMOVE PRODUCT MANUAL FROM STORE

Contents

1. Materials In Box 2

2. Warnings 2

3. Product Compatibility 3

4. Installation & Setup 4

5. Key Setup 5

6. Arming/Disarming the System 6

7. Silencing the Alarm 6

8. Deleting User Keys 6

9. LED Status Indicators 7

10. FCC and ISED Statement 10

For additional support, please reach out to

our Contact Center at 800-426-6844

CONTENTS

-CONTROLLED DOCUMENT- 063-00243 D-0 Status: Approved ECO-109326

ECO-109326

SECURE PLUG™ PRODUCT MANUAL

WARNINGS

MATERIALS IN BOX

Secure Plug Power Strip (Region-Speciﬁc)

Alarm Label Sheet Remote Access Module (Optional, Sold Separately)

UKEU

6 LED Indicators correspond

with the 6 positions on the

Secure Plug Power Strip.

6 positions correspond with

the 6 LED Indicators on the

Remote Access Module.

LED Ring will always mirror the

power strip’s system status.

1 6

2 5

3 4

LED Ring shows

system status.

DO NOT PLUG IN DEVICES

BEFORE LINKING AN

AUTHORIZATION CARD.

WARNING: No user serviceable parts inside. Please contact MTI for service.

CAUTION: To Reduce the Risk of Electric Shock – Use Only Indoors.

CAUTION: Risk of Electric Shock. Do not plug into another relocatable power tap or an extension cord.

CAUTION: Use Only in Dry Locations.

AVERTISSEMENT: Aucune pièce réparable par l’utilisateur à l’intérieur.

Veuillez contacter MTI pour le service.

ATTENTION: Pour réduire le risque de choc électrique - Utiliser uniquement à l’intérieur.

ATTENTION: Risque de choc électrique. Ne pas brancher sur une autre alimentation ou une rallonge.

ATTENTION: Utiliser uniquement dans des endroits secs.

-CONTROLLED DOCUMENT- 063-00243 D-0 Status: Approved ECO-109326

ECO-109326

EXAMPLES OF COMPATIBLE DEVICES

COMPATIBLE

EXAMPLES OF INCOMPATIBLE DEVICES

INCOMPATIBLE

Secure Plug supports up to 10 Amps per unit and DC power supplies up to 100W (per power supply).

Speaker:

Products with Detachable Power Supplies and or Power Cords: Products with Attached

Power Supplies:

Vacuum:

Headphones:

Hairdryer:

Tablets:

Value

Laptop:

Gaming Laptop:

SECURE PLUG™ PRODUCT MANUAL

PRODUCT POWER SOURCE COMPATIBILITY

PRODUCT COMPATIBILITY

Connect power cable

to power supply before

merchandising.

All devices merchandised on Secure Plug should

run demo loops/content, when possible.

-CONTROLLED DOCUMENT- 063-00243 D-0 Status: Approved ECO-109326

ECO-109326

2 3

SECURE PLUG™ PRODUCT MANUAL

INSTALLATION & SETUP

The Remote Access Module allows you to use the RFID cards

to control the Secure Plug when access to the unit is difﬁcult.

Initial setup of Secure Plug requires linking an Authorization Card to it. Please swipe the Authorization Card you intend to

use for that strip throughout the life of the position. If this card is lost please contact Customer Service.

The system registration and key setup processes can be done on the Secure Plug unit or through the Remote Access Module.

DO NOT PLUG IN DEVICES BEFORE

LINKING AN AUTHORIZATION CARD.

IF USING THE REMOTE ACCESS MODULE: Plug in to

the end of the Power Strip and afﬁx to surface, if desired.

Plug Power Strip into a wall outlet.

FOR SCREW MOUNT (OPTIONAL): Use three #6 (M3.5) wood screws (not included). Measure and install screws into

mounting surface leaving 1/4” (6.35mm) of the screw heads exposed. Align the Power Strip keyholes (circled in blue) and

hang onto the screws.

2.4 in

(62 mm)

7.9 in

(200 mm)

1.6 in

(42 mm)

-CONTROLLED DOCUMENT- 063-00243 D-0 Status: Approved ECO-109326

ECO-109326

SECURE PLUG™ PRODUCT MANUAL

MERCHANDISING

KEY SETUP

Swipe User Key you wish to setup.

If successful unit beeps 2 times

If unsuccessful unit beeps 4

times (retry)

Repeat process for all User Keys

until they are successfully added.

Swipe Authorization Card again to

end key setup.

Secure Plug will automatically exit

key setup mode 3 minutes after

the last User Key is added.

Swipe Authorization card.

Plug your device’s power cord and/

or power supply into the Secure

Plug power strip.

Note: If your device has a two-piece

power cord/power supply, connect

those pieces before merchandising.

The LED on the Secure Plug and

RAM will then ﬂash white and

single beep while calibrating, then

ﬂash green and double beep once

calibration has completed (this

can take up to 2 minutes).

Plug the power source into the

device any time after the Secure

Plug/RAM has ﬂashed green but

before arming.

Repeat this process for additional

devices.

The device end of the

power cord and/or power

supply must NOT be

connected to the device.

-CONTROLLED DOCUMENT- 063-00243 D-0 Status: Approved ECO-109326

ECO-109326

1 32

2 3

SECURE PLUG™ PRODUCT MANUAL

DELETING USER KEYS

ARMING/DISARMING THE SYSTEM

SILENCING THE ALARM

Place any User Key over the RFID

icon and the LED will change from

ﬂashing white to solid white to

silence the alarm.

After the problem has been ﬁxed,

place any User Key over the RFID

icon and the LED will change

from ﬂashing white to solid white,

arming the system.

Fix the problem that caused the

alarm.

Two causes of alarms

• The device was unplugged at either

end of the power cord.

• The device is still connected but has

completely shut down. Some devices

will generate alarms in this state and

some will not. If an alarm occurs

change the settings on the device

to prevent it from powering down or

run a demo loop or other content to

prevent it from powering down.

Arming Resolving Miscalibration

Place any User Key over the RFID icon and the LED

will change from ﬂashing white to solid white to indicate

Armed.

Secure Plug will beep for 5 seconds while verifying all

sockets have been calibrated and connected correctly.

If no errors have occurred, the LED will change from

ﬂashing white to white and the system is armed.

If an error occurred, the LED will blink red and the

system will emit a repeating series of four double beeps

and the RAM will indicate which

socket has an error.

For error resolution see the LED

Status Indications section of this

document.

Note: Any properly calibrated

position will still arm.

From an Armed state, place the

User Key over the RFID icon to

disarm the system. LED will be

ﬂashing white.

Hold down the Authorization Card

for 5 seconds, LED will be solid

yellow.

Place the Authorization Card over

the RFID icon AGAIN while LED is

yellow.

If successful unit beeps 2 times

and the LED will turn solid green

If unsuccessful unit beeps 4

times (retry)

-CONTROLLED DOCUMENT- 063-00243 D-0 Status: Approved ECO-109326

ECO-109326

SECURE PLUG™ PRODUCT MANUAL

LED STATUS INDICATORS

Visual Reference System Status Condition Solution

LED is solid white. Armed System is armed.

LED is ﬂashing white.

1.Disarmed - no beeps.

2.Merchandising Calibration -

continuous beeps

1.System is disarmed and needs to be re-

armed.

2.System is calibrating product, wait until

successful or unsuccessful merchandising

before proceeding.

LED is ﬂashing red and white. Alarm System is alarming and needs to be

attended to.

LED is ﬂashing red.

1.Mains Power Loss - 6

repeating double beeps

2.Merchandizing error - 4

continuous double beeps

Merchandizing error - causes

1. Strip armed with a device not plugged

into its power supply - plug device in to

clear error

2. Device was calibrated while plugged

into its power supply - unplug device from

power supply until socket LED goes white

and then red again. Plug device back into

power supply to clear error.

LED is solid green. Ready for Key Setup

System has an Authorization Card, but does

not have any User Keys added. Follow key

setup process.

-CONTROLLED DOCUMENT- 063-00243 D-0 Status: Approved ECO-109326

ECO-109326

SECURE PLUG™ PRODUCT MANUAL

Visual Reference System Status Condition Solution

1.LED ﬂashes twice and then

stops

2.LED is ﬂashing green

continuously.

1.Socket calibrated

2.Factory Reset

1.Plug in your device to the power supply.

2. Link an Authorization Card.

LED is solid blue.

1.Setup mode - no beeps.

2.Overcurrent - continuous

sequence of 5 double beeps.

1.System is in key setup mode. Follow key

setup process to add User Keys.

2.System has gone into overcurrent

protection. Unplug any product which

may be drawing too much power.

LED is ﬂashing yellow.

1.Ready to be Armed without

MTI Connect Mesh Connected

2.Merchandising Calibration

without MTI Connect Mesh

Connected

1.Add Secure Plug unit to Mesh network.

2.System is calibrating product, wait until

successful or unsuccessful merchandising

before proceeding.

LED is solid yellow.

1.Armed without MTI Connect

Mesh Connected

2.Delete Keys Mode (If using

Authorization Card)

1.Add Secure Plug unit to

Mesh network.

2.System is deleting associated keys. Wait

until complete.

LED STATUS INDICATORS

-CONTROLLED DOCUMENT- 063-00243 D-0 Status: Approved ECO-109326

ECO-109326

SECURE PLUG™ PRODUCT MANUAL

Visual Reference System Status Condition Solution

Individual LED is solid white

(not main LED)

Merchandising successful for

that socket port There is no issue in this state.

Individual LED is solid red

(not main LED)

1.Merchandising unsuccessful -

sequence of 4 double beeps.

2.Alarm - alarm tone

1. If you forgot to connect the device to

the power supply after the green ﬂash,

connect the device and Secure Plug will

self-heal.

If you had the device connected to

the power supply when the green ﬂash

appeared, disconnect the device from

the power supply, wait for Secure Plug to

recalibrate the socket, and then connect

your device before swiping the user key

to arm.

2. Swipe user key once to silence, hold

user key to disarm. If alarm is due to

miscalibration you will need to hold the

user key to the RFID sensor for a full 5

seconds to disarm.

LED is ﬂashing blue. 1.Provisioning Mode

2.Overcurrent/Disarmed

1. System has entered Mesh network

provisioning mode. If it’s within range

of a Hub that is also in provisioning

mode, it will join the Hub’s network

within 5 seconds and it will stop

ﬂashing blue.

2. System has gone into overcurrent

protection and user has disarmed the

system. Unplug any product which

may be drawing too much power. The

system will self-heal.

LED is ﬂashing multiple colors.

System has received an

“identify” command from a user

of the MTI Connect software.

LED STATUS INDICATORS

-CONTROLLED DOCUMENT- 063-00243 D-0 Status: Approved ECO-109326

ECO-109326

SECURE PLUG™ PRODUCT MANUAL

FCC AND ISED STATEMENT

This device complies with Innovation, Science and Economic Development Canada licence-exempt RSS standard(s). Operation is subject to the following

two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause

undesired operation of the device.

CAN ICES-3(B)/NMB-3(B)

Le présent appareil est conforme aux CNR Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.

L’exploitation est autorisée aux deux conditions suivantes:

(1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage

est susceptible de compromettre le fomctionnement du dispositif.

CAN ICES-3(B)/NMB-3(B)

The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain

Canadian information on RF exposure and compliance.

Le dispositif rencontre l’exemption des limites courantes d’évaluation dans la section 2.5 de RSS 102 et la conformité à l’exposition de RSS-102 rf,

utilisateurs peut obtenir l’information canadienne sur l’exposition et la conformité de rf.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated

with a minimum distance of 20 millimeters between the radiator and your body.

Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu’aucune autre antenne ou émetteur. Cet équipement devrait être installé et

actionné avec une distance minimum de 20 millimètres entre le radiateur et votre corps.

MTI declares that the radio equipment models 165-00460, 165-00470 and 165-00471 Secure Plug Power distribution units including the

models 165-00645 and 165-00670 Remote Access Modules in compliance with EU Directive 2014/53/EU.

The full text of the EU Manufacturer’s Declaration of Conformity is available at the following internet address: www.mobiletechinc.com

This device complies with Part 15 of the FCC Rules.

Caution: If any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the

equipment.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference

received, including interference that may cause undesired operation.

The grantee is not responsible for any changes or modiﬁcations not expressly approved by the party responsible for compliance. Such modiﬁcations could

void the user’s authority to operate the equipment.

The RF Exposure Compliance distance is 20 millimeters.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.
