M-TI BPT Series User manual

Website: www.metertreater.com
Meter Treater Inc.: 1349 South Killian Drive • Lake Park, FL 33403
Sales: 561.845.2007 Toll: Free: 800.638.3788 Fax: [phone]
Email: [e-mail]
MT-BPTSERIES-3/18
The BPT Series is a Transient Protection System that provides heavy-duty
surge protection and ltering for industrial and commercial sites against the
harmful eects of transient energies induced on AC power lines. The BPT’s unique
construction allows it to deliver low clamping voltages while safely handling
large surge currents. Congured for parallel installation, units install quickly and
easily. All models are suitable for Type 1 or Type 2 service panel applications.
On-board diagnostics include a panel display equipped with LED indicators that
continuously monitor the operational status of the entire unit. An Audible
Alarm is standard with switch positions for test, disable and enable. A Surge
Counter and a set of NO/NC dry contacts are also standard. A Remote Monitor
and/or Filter are available as options.
Weather Resistant models available in a NEMA 4X housing with internal
diagnostics for harsh environments. Audible Alarm and Surge Counter are not
included with the NEMA 3R model.
Product Specications
In
Max Surge Current
Fusing
Short Circuit Current
Enclosure Ratings
10/20 kA
300kA per Phase
Coordinated Surge & Thermal
100kA RMS Symmetrical Amps
NEMA 4, 4X & NEMA 12
Model Number Service Voltage MCOV L - N L - G N - G L - L
BPTXXX/120-10-#-1
BPTXXX/120-SP-#-1
BPTXXX/120-3W-#-1
BPTXXX/120-3H-#-1
BPTXXX/240-3D-0-1
BPTXXX/220-3W-#-1
BPTXXX/230-3W-#-1
BPTXXX/240-3W-#-1
BPTXXX/277-3W-#-1
BPTXXX/480-3D-0-1
120 Volt Single Ø
120/240 Volt Split Ø
120/208 Volt 3Ø Wye
120/240 Volt 3Ø HL Delta
240 Volt, 3Ø Delta
220/380 Volt, 3Ø Wye
230/400 Volt, 3Ø Wye
240/415 Volt, 3Ø Wye
277/480 Volt, 3Ø Wye
480 Volt, 3Ø Delta
700V
700V
700V
700V
N/A
1000V
1000V
1000V
1000V
N/A
150Vac
150Vac
150Vac
150/320Vac
320Vac
320Vac
320Vac
320Vac
320Vac
520Vac
600V
600V
600V
600/1000V
N/A
1000V
1000V
1000V
1000V
N/A
600V
600V
600V
600/1000V
1000V
1000V
1000V
1000V
1000V
1800V
VPR
Mechanical/Environmental Specications
Diagnostics
Safety Standards
Operating Frequency
LED, Audible Alarm, Surge Counter
UL 1449 (most current)
50/60 Hz
N/A
1200V
1200V
1200/1500V
1200V
2000V
2000V
2000V
2000V
4000V
Dimensions Typical Installations
1. Replace XXX with: desired kA rating per phase: 100 for 100kA or 200 for 200kA or 300 for 300kA. 2. Replace # with: F if ltering is required (available option on WYE Models only).
3. Add: /RM at the end of the Model Number for the Remote Monitoring option. 4. ENCLOSURE HOUSING OPTIONS: Add /POL to the end of the Model Number for NEMA 4X
NonMetallic or /SS for NEMA 4 Stainless Steel or /WP for Weatherproof.
Commercial/Industrial Panel
Surge Protection Device
BPT Series
(Diagrams not drawn to scale)
All product dimensions provided are ± 0.125

BPT Series
SURGE PROTECTION DEVICES FOR
AC POWER APPLICATIONS
USER MANUAL AND
INSTALLATION GUIDE
WARRANTY INFORMATION
Meter-Treater, Inc. (MTI) warrants all BPT Series models
to be free from defects, and will at our option repair or
replace the product should it fail within fteen (15)
years from the rst date of shipment. This warranty is
limited to defects in workmanship or materials, and does
not cover customer damage, abuse or unauthorized
modication. If this product fails or does not perform as
warranteed, your sole recourse shall be repair or
replacement as described above. Under no condition
shall MTI be liable for any damages incurred by the use
of this product. Damages include, but are not limited to,
the following: lost prots, lost savings and incidental or
consequential damages arising from the use of or inability
to use this product. MTI specically disclaims all other
warranties, expressed or implied, and the installation or
use of this product shall be deemed an acceptance of
these terms by the user.
WARRANTY RETURNS
All warranty and non-warranty repairs must be returned
freight prepaid and insured to MTI. All returns must have
a Return Authorization (RA) number on the outside of the
shipping container. This number may be obtained from MTI
Warranty Department [phone]. Products returned
without an RA number will not be accepted.
IF UNIT(S) ARE RECEIVED DAMAGED,
NOTIFY THE SHIPPING COMPANY
IMMEDIATELY. RETAIN ALL SHIPPING
CONTAINERS AND PACKING MATERIALS
FOR INSPECTION.
Meter-Treater, Inc.
1349 South Killian Drive • Lake Park, FL 33403
Phone: [phone] • Fax: [phone]
Email: [e-mail]
Website: www.metertreater.com
Please Note:
There are no user serviceable parts inside.
MT-BPTINSTALL-10/2016
MOUNTING INFORMATION
NOTE: BEFORE STARTING THE INSTALLATION,
MEASURE THE LINE VOLTAGE WITH AN AC
VOLTMETER TO ENSURE THE CORRECT DEVICE
HAS BEEN SELECTED FOR THE APPLICATION. L-N/G
VOLTAGE SHOULD NOT EXCEED THE MAXIMUM
CONTINUOUS OPERATING VOLTAGE (MCOV) LISTED
ON THE SPD LABEL.
1. When mounting the BPT SERIES SPD, use the four
mounting holes.
2. Place the SPD as close as possible to the connection point
in the NEMA enclosure. Keeping the lead length short will
increase the performance of the unit.
3. Drill a hole in the BPT for the conduit to run the wires from
the distribution panel to the connecting lugs inside the SPD.
Installation is simplied if the wires enter the enclosure at the top
(see gure #2) of the enclosure.
4. Securely mount the TVSS unit using 1/4-20 bolts in the
four (4) mounting holes provided in the enclosure’s mounting
anges.
NOTE: IF YOU CHOOSE TO MOUNT THE BPT UNIT,
OBSERVE ALL SAFETY PROCEDURES APPLICABLE FOR
A LIVE METER SOCKET OR ELECTRICAL PANEL.
NOTE: SPLICING WIRES TO GAIN EXTRA LEAD LENGTH
IS NOT ADVISABLE AS THE EXTRA LEAD LENGTH WILL
DEGRADE THE PERFORMANCE OF THE DEVICE.
WORKING NEAR EXPOSED LIVE CONDUCTORS IS
HAZARDOUS. POWER SHOULD BE SECURED OR
APPROPRIATE ELECTRICAL SAFETY EQUIPMENT
SHOULD BE USED TO THE GREATEST EXTENT
POSSIBLE BEFORE CONNECTING.
STATUS INDICATORS:
GREEN LEDs: When the SPD is securely connected and
operating properly, the GREEN LEDs, under the headings “ØA”,
“ØB”, “ØC”, will be illuminated. No other indicator should be
illuminated if the unit is operating normally.
RED LED: If a problem develops with the internal monitoring
circuitry or in the unlikely event that there should be a loss or
reduction in the protection elements, the RED LED over the
words “SYSTEM FAULT” will illuminate.
YELLOW LED: If the YELLOW LED illuminates, at any time,
there could be a hazardous system wiring fault. The YELLOW
LED does not indicate a suppressor failure; however, it does
signal that there may be dangerous Neutral to Ground Voltages
present. Consult with a qualied electrician to verify the integrity
of the installation’s wiring. (Not present on Delta Congurations)
AUDIBLE ALARM: The alarm will sound if protection should
be lost on either the L-N or L-G modes. Control of the alarm
is managed with a switch located on the front panel next to the
alarm. The switch has three (3) settings: Up (momentary only)
for testing, which will sound the alarm; Center, this is the disable
position and turns the alarm o󰀨; And Down, this enables the
alarm and sets it for contact monitoring.
OPTIONAL COUNTER: The Optional Surge Counter will show
the number of transient events that the suppressor encounters.
Control of the Surge Counter is managed with a switch located to
the left of the counter display. The switch has three (3) settings:
Up (momentary only), for RESET; Center, this is the ENABLE
position and turns the Counter on and sets it for constant
monitoring; And Down (momentary only), this tests the Coun-
ter and will increase the count by 1 increment each time it is
activated.
TROUBLESHOOTING GUIDE:
There is little or no troubleshooting required for this series of
products.
PROBLEM:
1. No Front Panel Diagnostics or improper operations:
Ensure the SPD unit is properly connected to the AC Service
Panel and that all connections are secure.
Conrm that the breaker in the AC supply panel is in the ON
position.
2. If problem still persists: TURN OFF BREAKER, open the
SPD door and verify that all VISIBLE cable connections are prop-
erly secured, no loose wires. This is especially critical for the
connectors on the Sensor Cable as they interface with the RPM
Modules.
In the unlikely event that these measures have failed to correct
the problem, contact your dealer or the factory for additional
information.
COMMERCIAL APPLICATIONS
10.75”
(273mm)
11.50”
(292mm)
6.00”
(152mm)
Figure #1: BPT Front View
Construction (standard):
14 Gauge steel with continuous hinge.
UL50 Type 12 and Type 13.
NEMA/EEMAC Type 12 and Type 13.
JIC standard #EGP-1-1967.
CSA Type 12.
IEC 529, IP65.
Finish (standard):
ANSI 61 Gray polyester.
Powder coating inside and out over
phosphatized surfaces.
8 8 8 8 8 8
Ø A Ø CØ B
Front Panel Diagnostics:
Notes:
1. For Single Phase Models:
Only 1 Green LED, in the Phase
“B” positions, is provided.
2. For Split Phase Models: 2
Green LEDs, in Phase “A” and
“C” positions, are provided.
3. For Delta Models: There is no
Yellow, N-G, LED
Green=Protected O󰀨=No Protection
System Fault N-G Voltages
Reset
Enable
Test Event Counter
Status Indicators
Test
Disable
Enable
Audio Alarm
[Figure #11: 3 Phase Wye Conguration Shown]
Figure #2: BPT Top View
1.030”
(26.162mm)Dia.
4.00”
(101.6mm)
2.60”
(66.04mm)
8.94”
(227mm)

GENERAL
1. This document provides detailed information on how to install and operate the BPT Series of Surge Protection Devices (SPD)
2. Locate a position to mount the SPD that will minimize the length of connecting wires required. SPD’s should be
located as close as possible to the AC panel or service area. Mount the units using the mounting holes provided on the
enclosure as shown by the illustrations in these instructions. It is recommended that conduit, preferably metallic, be
utilized to accomplish this connection.
3. The BPT Series is installed and connected in parallel (“shunt”) across the AC supply to be protected. Connecting wires
do not carry the supply current, only the short duration currents associated with the suppression of a transient event.
4. Identied or indicated leads/wires must be connected exactly with respect to the AC Power feeding the SPD. Failure
to do so may result in damage to the device or post a danger to personnel.
5. Installation of this device should only be performed by a qualied licensed installer. Incorrect installation may
siginicantly impair the performance of the Surge Protection Device. It is particularly important that all installation
procedures and guidelines be followed exactly.
6. Before starting any installation procedures, verify service voltages with an AC voltmeter to ensure that the correct SPD
model has been selected.
7. Check to ensure that all connections are correct and secure before energizing.
8. Keep this manual in a safe, dry place for future reference.
INSTALLATION INSTRUCTION
Before starting the installation, measure the Line voltage with an AC voltmeter to ensure the correct device has been
selected for the current application. The MCOV (maximum continuous operating voltage) CANNOT exceed the
maximum limits for the following service voltages:
120VAC = 150MCOV
220VAC = 320MCOV
230VAC = 320MCOV
240VAC = 320MCOV
277VAC = 320MCOV
480VAC = 550MCOV
STANDARD ELECTRICAL CONFIGURATIONS
120 or 240VAC, Single Phase, 2 Wire + Ground
120 or 240VAC PHASE
NEUTRAL
GND
PHASE A
NEUTRAL
GND
PHASE B
PHASE A
GND
PHASE B
PHASE C
NEUTRAL
PHASE A
GND
PHASE B
PHASE C
NEUTRAL
PHASE A
GND
PHASE B
PHASE C
120 /240VAC, Split Phase, 3 Wire + Ground
240 or 480VAC, Three Phase Delta, 3 Wire + Ground
120/240VAC, Three Phase Delta, 4 Wire + Ground
120/208VAC, Three Phase Wye, 4 Wire + Ground
or
277/480VAC, Three Phase Wye, 4 Wire + Ground
Requires a 1 Pole Breaker [Figure #3]
Requires a 2 Pole Breaker [Figure #4]
Requires a 3 Pole Breaker [Figure #5]
Requires a 3 Pole Breaker [Figure #6]
Requires a 3 Pole Breaker [Figure #7]
120VAC
120VAC
240 OR 480
VAC
240 OR 480
VAC
240 OR 480
VAC
208 or 480
VAC
208 or 480VAC
208 or 480
VAC
240
VAC
240
VAC
208
VAC
120VAC 120VAC
(High Leg) “Orange”
120 or 277
VAC
120 or 277
VAC
120 or 277
VAC
NOTE:
Wye Conguration is
also applicable for:
220/380VAC
230/400VAC
240/415VAC
1. Connect the ground wire to the service panel ground buss.
2. Connect the neutral wire from the service panel neutral buss to the lug labeled neutral. (Not Applicable for Delta Applications)
3. Connect the phase (hot) wires from a 3 pole breaker to the SPD device connectors labeled phase “A”, “B”, and “C”, as appropriate.
4. Attach and crimp (supplied) lug connectors to each #8 or #10 AWG wire, as required, before inserting it into the terminal block.
5. Tighten the lug screw securely.
6. Check all connections to ensure they are correct and properly secured.
G
PHASE
FAULT
N-G
FAULT
TEST
DISABLE
ENABLE
PHASE PHASE
NOTE: BEFORE
ENERGIZING THE SPD:
ENSURE ALL
CONNECTIONS ARE
CORRECT. DO NOT
ENERGIZE WITH FRONT
COVER OPEN
3 POLE BREAKER
KEEP WIRES AS
SHORT AS POSSIBLE
[Figure #8: 3 Ø Phase
Wye Wire Hook-up]
[Figure #9: 3 Ø Phase Wye
Breaker Hook-up]
Notes:
1. For Single Phase Models, Phase “A” and Phase “C”
lines are left vacant.
2. For Split Phase Models, Phase “B” is left vacant.
3. For Delta Congurations, the Neutral position is left
vacant.
4. Use #10 to 1/0 Wire for installation.
BPT (100/200) Models:
The specic product you have in service may be congured
for any one of the following kA ratings: (100=100kA/Phase)
and (200=200kA/Phase)
120 or 240VAC, Single Phase
120/240VAC, Split Phase
240 or 480VAC, 3 Phase Delta
120/208VAC, 3 Phase Wye
120/240VAC, 3 Phase Delta
(High Leg)
277/480VAC, 3 Phase Wye
220/380VAC, 3 Phase Wye
230/400VAC, 3 Phase Wye
240/415VAC, 3 Phase Wye
[Figure #10: Internal Layout]
The device shall be fed from a 30 Amp breaker, in accordance
to the number of poles required.
Single Phase = 1 Pole Breaker
Split Phase = 2 Pole Breaker
Three Phase = 3 Pole Breaker
High Leg Delta = Phase “B” Orange
Delta Units have no Neutral
Because the SPD is installed in parallel or shunt with the load,
VA rating is not limited.
= 1 Pole Breaker
= 2 Pole Breaker
= 3 Pole Breaker
= Phase “B” Orange
