M2M Smart Modem Operating manual


M2M Solutions
1 Stanger Avenue
Wierdapark, Centurion, 0154
South Africa
www.m2msolutions.co.za

User and Installation Manual
February 2019












M2M Smart Modem



Page 2/10
Table of content
Table of content
Overview
Hardware
Firmware
Connectors and indication
LED indicators
Status (Blue)
Tx (Red)
Rx (Green)
MicroSIM Card
GSM
RJ45
Power
RS232
RS485
GPIO
Power
Installation
Installing a SIM card
Installing the device
Mounting the device
Configuration
Technical Specification
 


Page 3/10
Overview
The M2M Smart Modem is a ready-to-deploy, standalone quad-band GSM/GPRS device that           
provides wireless data communication for IoT (Internet of Things) devices. The modem           
integrates seamlessly with virtually any application, and is useful for automated applications,           
such as remote diagnostics, remote monitoring and remote controlling. It is available with            
both RS232 and RS485 interface ports or a USB interface on request.
Hardware
●Quadband modem GSM 850/900/1800/1900MHz
●Internal power supply
●External SMA antenna
●MicroSIM or internal ChipSIM
●Status, Tx and Rx LED indicators
●RS232 interface
●RS485 interface
Firmware
●Private or public APN
●3 Simultaneous TCP/IP Sockets
●Client or Server mode
●Configurable connection interval
●SMS configuration
●Various device protocols integrated
●M2M Platform support for configuration, control and monitoring
 


Page 4/10
Connectors and indication
LED indicators
Status (Blue)
●Flashing fast twice per second – No
SIM card detected.
●Flashing slow 1 second on, 2 second
off – Searching for GSM signal.
●1 Flash every 2 seconds – Registered
on the GSM network, waiting for GPRS
attachment.
●2 Flashes every 2 seconds – GPRS
attached and modem ready.
●3 Flashes every 2 seconds – M2M
connection established and registered
online. Device is working normally.
Tx (Red)
Data is sent out on one of the modem
interface ports.
Rx (Green)
Data is received on one of the modem interface ports.
MicroSIM Card
Standard MicroSIM card. The modem has a push-push card holder. To insert the SIM push it               
in all the way until you feel a light click, then release it. To remove the SIM, push it in again                    
until you feel the light click, release it and the SIM card should come out.
Note: The modem does have onboard provisioning for a ChipSIM. Please contact us should             
you require this feature with your APN ChipSIM cards.
 


Page 5/10
GSM
SMA connector for and external antenna. The external antenna needs to be           
QuadBand-capable and equipped with a male SMA connector. External antenna is required           
for proper operation of the device.
RJ45
All the communication lines for the modem is available via the RJ45 connector as in the               
following table:

Pin
Power
RS232
RS485
GPIO
1
6 - 32 VDC
6 - 32 VDC
6 - 32 VDC
6 - 32 VDC
2
-
-
A (+)
-
3
-
-
B (-)
-
4
GND
GND
GND
GND
5
-
TX
-
-
6
-
RX
-
-
7
-
RTS
-
Output
8
-
CTS
-
Input
Power
The modem can be powered from 6 to 32V DC (10W) via the RJ45 connector pins 1 and 4.                  
When using this connector to power the modem, there is no need to connect the main power                
supply. This power connector is normally used when the end device already has a power              
supply capable of delivering 10W or more.
RS232
The RS232 port features a standard TIA-232-F Data Terminal Equipment (DTE) interface with            
hardware flow control.
Baud rate can be configured for 1200, 2400, 4800, 9600, 19200, 38400, 57600 or            
115200kbps with 9600kbps as default.


Page 6/10
Data bits can be configured as 5, 6, 7 or 8 data bits with 8 data bits as default
Frame format can be configured as None, Odd, Even, Space or Mark with None as default
Stop bits can be configured as 1, 2 or 1.5 with 1 as default
RS485
The RS485 port features a standard half duplex EIA-485 interface
Baud rate can be configured for 1200, 2400, 4800, 9600, 19200, 38400, 57600 or            
115200kbps with 9600kbps as default.
Data bits can be configured as 5, 6, 7 or 8 data bits with 8 data bits as default
Frame format can be configured as None, Odd, Even, Space or Mark with None as default
Stop bits can be configured as 1, 2 or 1.5 with 1 as default
GPIO
Two General purpose input/output (GPIO) pins are available on the RJ45 connector that can             
be used to control a output relay or as a input for pulse counting or trigger events.
Power
The modem has a built in power supply capable of powering directly from main supply via               
the 2 pin green terminal connector.
The internal power supply is rated at 85 - 264VAC 50Hz input and is protected by a PTC                 
resettable fuse and MOV.
For fixed installations it is recommended to install a fuse box inline with the live wire using a                 
1A slow blow fuse.

 


Page 7/10
Installation
Installing a SIM card
This model requires a MicroSIM card, which is supplied by your preferred service provider.             
To install the SIM card:
1. Locate the SIM card slot on the side of the modem. The slot is labeled SIM.
2. Push the MicroSIM card into the SIM card slot with the contact side facing down until               
you feel a light click.
3. Release the SIM card.
Installing the device
1. Connect a suitable antenna to the SMA connector.
2. Connect a RJ45 cable to the modem then connect the other end to the serial port on                
the application device.
3. Screw on the power cables into the power connection on the modem.
4. For a fixed installation, make sure the device is wired through a fuse box.
5. The blue status LED will start to blink according to the current state.
Mounting the device
The device can be secured under the meter terminal cover to limit possibility of theft and to                
protect from direct sunlight and moisture.
The devices should alternatively be mounted in a IP65 enclosure to protect it from direct              
sunlight and moisture.

 


Page 8/10
Configuration
The M2M Smart Modem can be configured via SMS messages. After the M2M Smart             
Modem is powered up, the user can send a configuration SMS with the following             
configuration parameters.
Parameters are delimited by a [ENTER] or semicolon [;]
Each configuration parameter consists of a key and value except for the RESET and INFO              
command. Key and values are separated by a colon [:]
Multiple parameters can be sent together in one SMS message.
For example
APN:internet
User:web
Pass:web
IP:www.google.co.za
Port:80
Mode:client
Baud:9600
Frame:8N1
Reset

This will set the APN to internet, username to web and password to web. It will also                
configure socket 1 to connect in client mode to www.google.co.za on port 80 and create a               
transparent link on interface port 1 with a baud rate of 9600 kbps and a frame format of 8                  
databits, none parity and 1 stop bits.
The Reset command doesn’t have a value, but instead saves the configuration and resets the              
modem. Some parameters can take an optional index denoted by [x]. This value can be 1 to 3                 
and indicates the socket index to configure. When no index is specified, it defaults to socket               
1.
The following parameters can be configured:




Page 9/10
Parameter
Description
Values
Default
APN
APN Name
String up to 64 characters
internet
USER
APN Username
String up to 64 characters
(blank)
PASS
APN Password
String up to 64 characters
(blank)
IP(1-3)
IP Address for TCP/IP connection
IP or DNS name
m2msolutions.co.za
PORT(1-3)
TCP Port for TCP/IP connection
2010
1 - 65535
MODE(1-3)
TCP/IP connection mode
CLIENT or SERVER
SERVER
BAUD(1-3)
Serial port baud rate
1200 to 115200
9600
FRAME(1-3)
Serial frame format
Databits, Parity, Stopbits
8N1
IDX(1-3)
Serial port index
1 - RS232, 2- RS485
1
RESET
Save configuration and restart
INFO
Reply with current configuration

Note: SMS message should not be longer than 160 characters. When your total            
configuration message is longer than 160 characters, it is advised to send multiple SMS             
messages with the RESET command only in the last message.
If the SIM card has credit or SMS bundle available, you will receive an acknowledge message               
back.
To retrieve the current configuration, you can send a SMS message with INFO. This will reply               
with the current modem configuration.
 


Page 10/10
Technical Specification

Category
Description
General
Performance
GPRS Class 12
Frequency Bands
Quad-band: GSM850, EGSM900, DCS1800, PCS1900
GPRS Speed
Up to 85.6 Kbps downlink and uplink
Connectors
SMA
Cellular 50 ohm Antenna
RJ45
RS232, RS485 and GPIO
Degson 5MM
AC Supply
Power Requirements
DC Supply
6 to 32V
AC Supply
85 to 264V, 50Hz
Consumption
10W max
Physical Description
Dimensions
78mm x 58mm x 21mm
Weight
86 grams
Environment
Operating Temperature
-35°C to +75°C
Humidity
Relative humidity 15% to 93% non-condensing
Certifications, Compliance, Warranty
EMC Compliance
ETSI EN 301-489-1
Radio Compliance
ETSI EN 301-511
Safety Compliance
IEC 60950-1
Warranty
12 Months


