Mac Faucets AHD-3 User manual

Installaon Instrucons
User Manual
Automac Hand Dryer
Model: AHD-3 & Model: AHD-5
866 558 3200 310 919 3073 [email protected] www.macfaucets.com
MAC FAUCETS California, USA
D
E
S
I
G
N
E
D
&
A
S
S
E
M
B
L
E
D
I
N
T
H
E
U
S
A
Recommended Mounng Heights
Shell Allen wrench
Countersunk
screws
Electrical box locaon
7/8”
Use Allen wrench from
accessories bag to remove
2 countersunk screws from
body shell.
Pull the shell upward by
hands to remove.
Please avoid damage to
shell finish.
Drill hole
02
1. Use the template provided inside of the box.
2. Use a level to insure that the template is straight and
level, the electrical box must be a 7/8” from the edge
of template to the edge of the box.
3. Use painters tape to hold the template in place.
4. Drill holes for supplied plasc anchors.
Shell remove
03
01
Stainless Steel Front Cover
110 - 120V
11.7 Amps
550 - 1200W
Hardwire Connecon
HEPA Filter
All hardware necessary for sasfactory installaon
Specificaons
6-3/4”
Floor
Men 45” (114cm)
Women 43” (109cm)
Teenagers 42” (107cm)
Small childrens 34” (86cm)
Handicapped 38” (97cm)
From Floor to boom of Hand Dryer
12-1/4”
PAGE | 01
Tools Needed
Safety Glasses
Drill bit
Ø 1/4” Carbide
Drill for le
Cordless Drill
Hammer
Level
Phillips Screw Driver Tape
AHD-3 AHD-5
11-7/8”
12-1/4”
5. Place the
plasc anchors in
the holes and
push them with
the help of a lite
hammer.

D
E
S
I
G
N
E
D
&
A
S
S
E
M
B
L
E
D
I
N
T
H
E
U
S
A
Tab
Air Inlet Panel
866 558 3200 310 919 3073 [email protected] www.macfaucets.com
MAC FAUCETS California, USA
Place hands under sensor to acvate.
Dryer will shut off a few seconds aer hands are removed.
Daily Use and Maintenance
1. Remove Shell, see 06 above.
2. Open the air inlet panel, pull the air
filter out and clean it.
3. Install shell back on, see 06 above.
Cleaning cycle: semi-annually or as needed
Connect the hand Dryer
05
Mounng instrucons
04
Tighten the 2 countersunk screws on the shell.
Shell
Countersunk screws Allen wrench
Hand dryers MUST BE
grounded to avoid
personal injuries
All wire connecons MUST BE conducted by an experienced electrical
contractor. Connect to an independent 20 Amp circuit braker.
NOTE: 110V ONLY
Grounding device
Knock
out hole
Wire
Connectors
Shell installaon
External maintenance
06
01
Clean with a so dry cloth
or towel.
Please use standard glass
cleaner ONLY.
Please DO NOT use harsh
solvents of any kind.
Using the wrong cleaning
tools or supplies will
cause damage to the unit
and finish and WILL void
warranty.
Air filter maintenance
02
Operaon instrucons
01
Air filter
Sensing device
PAGE | 02
Electrical Box
6”-8” Long the
supply wire
Knock out hole
Install Electrical Box inside
the wall. Locaon is shown
in 02 page 1, point 2
Electrical Box must be
flush with the wall surface.
Pass the electrical cable
through the knock out hole
before mounng hand
dryer onto wall, leave 6”-8”
of wire inside of the hand
dryer.
Affix hand dryer onto wall
using the 4 supplied
screws, fasten securily Use the wire
connectors provided.
Connect Black to Line, White
to Neutral, Green to ground
Connect the electrical
cable to the cable of
the hand dryer
(pre-installed)
L
B
NW
GG
L
B
NW
GG
Connecng hand dryer to
higher voltage will damage
hand dryer and WILL void
warranty.
02
06
06
