Mach CM12 User manual

www.mach.dk
A Professional Product
C
M
12
A brilliant medium throw speaker in a compact design with high output and a
controlled dispersion pattern. The CM12 is a dedicated top box and is ideal for
applications in small to medium sized venues.
Featuring a rotatable horn and 18 flying points - four of which are fully adjustable
- the CM12 is an extremely versatile installation speaker allowing for full flexibility in
vertical and horizontal positioning.
The distinct new CM12 in the C-Range speaker series from MACH powerfully
projects every nuance of pure sound in any environment you choose.
Simple to fly
With a unique flexibility in mounting,
the innovative CM12 allows complete
versatility when setting aim points
in the application

CM12
•Brilliant medium throw speaker capable of reproducing
high SPL
•Dedicated top box holding a powerful 12" woofer and
1" compression driver with a constant coverage horn with
low distortion
•Rotatable horn with a 90 x 75 deg dispersion allowing for
complete versatility in vertical and horizontal mounting
•Innovative Passive and Active bi-amp solution with secure
access to switch and ultra quick change over between modes
•Designed specifically for small to medium size venues where
high output and low ceiling fixing points are required
SPECIFICATIONS
Power rating IEC268: ........................................... 325 watt
Power rating peak: .............................................1300 watt
Sensitivity 1w/1m: ........................................ 98.5 dB (avg.)
Max SPL, calculated long term: ...............................124 dB
Max SPL, peak: .....................................................130 dB
Frequency range +/-3dB: ............................ 70 Hz - 18 kHz
Dispersion angle avg: .......... H 90 x V 75 deg Rotatable Horn
Nominal impedance: ................................................ 8 ohm
Recommended High Pass filter: ........100Hz (24 dB/Octave)
Recommended Controller: .... Mach M20.06 or Mach M20.02
Recommended amplifier: ......................... 450 watt in 8 ohm
WEIGHT, MEASUREMENTS
AND PHYSICAL SPECIFICATIONS
Dimensions (HxWxD): ................................62 x 43 x 35 cm
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (24.4 x 16.9 x 13.8 inches)
Net weight: ........................................ 26.5 kg (53 pounds)
Finish: .......Black Safe Coat coating with other colors optional
Grille: ................................... 2 mm steel with foam backing
Input connectors: ................................ 2 x Speakon® NL 4
and barrier strip terminals
Rigging hardware: .......................Included U-bracket (fixed)
. . . . . . . . . . . . . . . . . . . . . . . . . . Included 3 x Eyebolt part no. 93940002
Optional: ........................... Multi Bracket part no. 93943040
WHAT IS THE C-RANGE?
•Powerful output in a compact design
•Innovative adjustable "spider bracket
system" for multiple horizontal and vertical
flying options
•Fast and easy mounting with 18 flying points
for complete versatility
•Flexible, easy connection in seconds with
recessed speakon and barrier strip terminals
•Customized u-bracket included as standard
• 3x10 mm Eyebolts included as standard
•
Trapezoidal cabinet design allows for flexible
and discrete fixing
•Safe coat scratchproof surface and extruded
aluminum profiles give an exceptionally
strong and robust cabinet
•Fast and easy access to all serviceable parts
360° of excellence. At every angle the C-Range brings you ergonomics
in design and functionality.
The speaker comes black as standard with any RAL code color
choice as optional.
The innovative C-Range spider bracket system allows multiple
positioning with ease.
A Professional Product
Mach Speakers A/S • Perspektivvej 2 • 9900 Frederikshavn • Denmark • Tel. [phone] • Fax [phone] • www.mach.dk
©November 2004 Martin Professional A/S Specifications are subject to change without notice.
