VLZ4 4•Bus 24-/32-Channel 4•Bus
FX Mixer with USB
Like us
Follow us
Watch our dang videos
2404VLZ4 and 3204VLZ4
In pursuit of the ultimate “do-it-all” Live Sound Mixer, we
threw in the kitchen sink and packed this bad boy with a full
set of processors allowing you to travel “rack free” while still
making professional sounding mixes.
For starters, we added not one, but TWO, of our patented
Running Man FX processors (RMFX+™) featuring 24 “gig-
ready” effects right into the board. This does not include
useless effects such as “the warbler” or the “insanity delay”,
but rather a suite of quickly accessible and useable reverbs,
choruses and delays that make coloring your mix a breeze.
Additionally, both FX processors feature a tap delay,
typically only available on an outboard rack. Delays may
easily be sync’d with the song at the tap of a finger. And
because we love flexible routing (hehe), the processed
signal may be sent direct to the mains and monitors from
the effects section or re-routed to the two stereo channels
to bring them through the EQ and aux section, utilizing the
60mm fader to draw them into the mix.
But wait, there’s more! The VLZ4 4•Bus has eight (yes,
eight!) single knob compressors to stop the dynamic signals
from poking out of the mix. Four compressors are located
on the last four mic inputs so that the most critical signals
(such as vocals, snare drum, the occasional jaw harp
or mountain goats) may be addressed. Plus, there are
single knob compressors on each of the four subgroups
so that grouped signals (such as a drum set or a choir
of didgeridoos) may be blended together for paramount
smoothness.
The VLZ4 4•Bus Series Mixers also feature a 4x2 USB
recording and playback function. This means that up to
four signals may be recorded simultaneously and a stereo
mix returned to the mixer for playback.
Bottom line? You have an awesome mixer with VLZ4 sound
quality, “built-like-a-tank” build quality and a recording and
processing feature set that is unparalleled. Congratulations...
and happy mixing!
APPLICATIONS:
Live sound mixing, houses of worship, clubs, gymnasiums,
banquet halls, conference rooms, boardrooms, multitrack
studio and field recording, video post-production,
multimedia applications, broadcast and many, many more.

2/6 PAGES
VLZ4 4•Bus 24-/32-Channel 4•Bus
FX Mixer with USB
VLZ4 4•Bus SPECIFICATIONS
Main Mix Noise
(20 Hz–20 kHz bandwidth, 1/4" main out, channel gains @ unity,
channel EQs flat, all channels assigned to main mix, odd channels
panned left, even channels panned right.)
Main mix fader unity, channel faders down:
–87.0 dBu (–91.0 dB Signal to Noise Ratio, ref +4 dBu) [2404VLZ4]
–84.5 dBu (–88.5 dB Signal to Noise Ratio, ref +4 dBu) [3204VLZ4]
Main mix fader @ unity, channel faders @ unity:
–81.5 dBu [2404VLZ4]
–80.0 dBu [3204VLZ4]
Total Harmonic Distortion (THD)
(1 kHz @ 15 dB gain, 20 Hz–20 kHz bandwidth)
Mic in to insert send <0.001%
Mic in to main out <0.005%
Attenuation / Crosstalk
(1 kHz relative to +10 dBu, 20 Hz–20 kHz bandwidth, mic in,
1/4" main out, gain @ unity)
Channel mute switch engaged –90 dBu
Channel fader down –88 dBu
Frequency Response
Mic input to main output (gain @ unity)
+0, –1 dB, 20 Hz to 50 kHz
+0, –3 dB, <10 Hz to >100 kHz
Equivalent Input Noise (EIN)
(Mic input to insert send out, max gain)
150 termination –128.5 dBu
20 Hz–20 kHz
Common Mode Rejection Ratio (CMRR)
1 kHz better than –70 dB
FEATURES:
■ 4•Busmixerfeaturingoursignature
 high-headroom,low-noisedesign
■Boutique-qualityOnyxmicpreamps
 •Ultra-wide60dBgainrange
 •128.5dBdynamicrange
 •+22dBulineinputhandling
 •Extendedfrequencyresponse
 •Distortionunder0.0007%[20Hz–50kHz]
■ImprovedRFrejection,perfectforbroadcast
 applications
■Phantompowerforcondensermics
■Dedicatedinlinechannelcompressionforcritical 
 inputs
■High-headroomlineinputswithdedicatedinserts
■3-bandEQwithsweepablemidrange
■18dB/oct100Hzlow-cutlteronmicinputchannels
■Level,pan,soloandoverload/muteLEDson
 eachchannel
■Foursubgroupsfeaturingdedicatedinline
 compressorsfortotaldynamiccontrol
■Sixauxsendswithinserts,pre/postfader
 andinternal/externalFXsendoptions
■Twostereoreturnsandfourgroupoutswithinserts
■Dual32-bitRMFX+™processorsfeaturing
 24“GigReady”reverbs,chorusesandtapdelay
 forliveapplications
■ Integrated4x224-bitUSBinterface
 •StreamsubgroupsormasterL/RtoyourPCorMac 
 forrecording
 •Useyourfavoriteplug-inliveviaauxes5/6
 •Convenientstereoreturntomainsformusic
 playbackorreturntochanneltoimplementEQ,
 auxesandmore
■PFL/AFLsolomodes
■60mmlong-wearinglog-taperfaders
■High-resolution12-segmentstereometers
■Sealedrotarycontrolsresistdustandgrime
■“Built-Like-A-Tank”ruggedsteelchassiswith
 powder-coatnish
■High-visibility,high-contrastcontrolsdeliver
 convenient“at-a-glance”visualfeedback
■Universalpowersupplyforworldwideuse

3/6 PAGES
VLZ4 4•Bus 24-/32-Channel 4•Bus
FX Mixer with USB
Maximum Levels
Mic in +21 dBu
All other inputs +21 dBu
Main mix XLR out +27 dBu
All other outputs +21 dBu
Impedances
Mic in 2.7 k
Channel insert return 2.5 k
All other inputs 10 k or greater
Tape out <10
All other outputs 120
3-Band EQ (mono channels)
High Shelving ±15 dB @ 12 kHz
Mid Peaking ±15 dB sweep 100 Hz – 8 kHz
Low Shelving ±15 dB @ 80 Hz
Low Cut Filter 18 dB/octave, –3 dB @ 100 Hz
4-Band EQ (stereo channels)
High Shelving ±15 dB @ 12 kHz
Hi Mid Peaking ±15 dB @ 2.5 kHz
Low Mid Peaking ±15 dB @ 400 Hz
Low Shelving ±15 dB @ 80 Hz
USB
Format USB 1.1
I/O Stereo Input, 4 Channel Output
A/D/A 24 bit, 44.1 kHz / 48 kHz
AC Power Requirements
Power Consumption 55 watts [2404VLZ4]
65 watts [3204VLZ4]
US, JP 100 – 120 VAC, 50 – 60 Hz
EU, UK, AU, CN 200 – 240 VAC, 50 – 60 Hz
Operating Temperature 0˚ – 40˚C
32˚ – 104˚F
Physical Properties (product)
Front Height 1.8 in / 46.3 mm [Both]
Rear Height 6.0 in / 153 mm [Both]
Depth 19.1 in / 486 mm [Both]
Width 29.4 in / 748 mm [2404VLZ4]
38.0 in / 964 mm [3204VLZ4]
Weight 31.0 lb / 14.1 kg [2404VLZ4]
39.0 lb / 17.7 kg [3204VLZ4]
Physical Properties (packaged product)
Height 10.6 in / 269 mm [Both]
Depth 23.0 in / 584 mm [Both]
Width 33.9 in / 861 mm [2404VLZ4]
42.5 in / 1080 mm [3204VLZ4]
Weight 37.0 lb / 16.8 kg [2404VLZ4]
44.0 lb / 20.0 kg [3204VLZ4]
Options
2404VLZ4 Mixer Cover P/N 093-008-00
3204VLZ4 Mixer Cover P/N 093-008-01
Ordering Information
2404VLZ4 24-Channel 4•Bus FX Mixer with USB, US P/N 2040769-00
2404VLZ4 24-Channel 4•Bus FX Mixer with USB, EU P/N 2040769-01
2404VLZ4 24-Channel 4•Bus FX Mixer with USB, AU P/N 2040769-04
2404VLZ4 24-Channel 4•Bus FX Mixer with USB, CN P/N 2040769-05
2404VLZ4 24-Channel 4•Bus FX Mixer with USB, BZ P/N 2040769-06
3204VLZ4 32-Channel 4•Bus FX Mixer with USB, US P/N 2040770-00
3204VLZ4 32-Channel 4•Bus FX Mixer with USB, EU P/N 2040770-01
3204VLZ4 32-Channel 4•Bus FX Mixer with USB, AU P/N 2040770-04
3204VLZ4 32-Channel 4•Bus FX Mixer with USB, CN P/N 2040770-05
3204VLZ4 32-Channel 4•Bus FX Mixer with USB, BZ P/N 2040770-06

4/6 PAGES
VLZ4 4•Bus 24-/32-Channel 4•Bus
FX Mixer with USB
THE INFORMATION CONTAINED
HEREIN IS PROPRIETARY AND
CONFIDENTIAL PROPERTY OF
LOUD TECHNOLOGIES, INC.
ALL RIGHTS RESERVED
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN INCHES
DUAL [MM] DIMENSIONS
FOR REF ONLY
TOLERANCE IN INCHES
LINEAR ± 0.13 in / ± 3.3 mm
ANGLES ± 1°
(X.XX) = REF DIMS
NO TOLERANCE IMPLIED
TSC = THEORETICAL SHARP CORNER
DIMENSIONS ACROSS CENTERLINES
TO BE SYMMETRICAL
THIRD ANGLE PROJECTION
2404VLZ4 NOTES:
1. WEIGHT APPROX. 31.0 lb [14.1 kg]
2. SHIPPING WEIGHT APPROX. 37.0 lb [16.8 kg]
3204VLZ4 NOTES:
1. WEIGHT APPROX. 39.0 lb [17.7 kg]
2. SHIPPING WEIGHT APPROX. 44.0 lb [20.0 kg]
19.1
[486]
38.0
[964]
29.4
[748]
6.0
[153]
1.8
[46]
6.0
[153]
1.8
[46]
19.1
[486]
VLZ4 4•Bus DIMENSIONS

5/6 PAGES
VLZ4 4•Bus 24-/32-Channel 4•Bus
FX Mixer with USB
L
R
PFL Solo
Main
PFL solo
AFL solo L
Monitor
Level
Insert
Level
Pan
L
R
Sub 1 Out (Sub 2-4 identical)
Phones
Monitor Out
L
R
Lsum
R sum
Sub 1 sum
1
2Sub
Aux 1 (pre)
Aux 1
Assign
Talkback
Assign
Hudson River Central Park
3-Band EQ
w/ Swept Mid
Aux 2 Aux 2 (pre)
FX 1
FX 2
FX1
FX 2
3
4
Internal FX 1
(Internal FX 2 identical except
returns to second stereo
channel)
Sub 1 level
Sub Assign To
Main Mix
L
R
Stereo Return 1 & 2
L
R
Main
1
2
Sub 3
4
L/R
1/2
3/4
L Insert R Insert
To Main Mix
Mute
Talkback
Level
Main Out
48V
Mono Channels 1-16(2404) 1-24(3204)
Mic +
-
Mic: 0 ~ +60dB
Line: -15 ~ +45dB
Stereo Channels 21/22 & 23/24 (2404) 29/30 & 31/32 (3204)
4-Band EQ
Level
Pan
Assign
L/R
1/2
3/4
Mute
Aux 5
PFL Solo
RUDE
SOLO
LED
Meter
Select
To Aux 1
Solo
Solo
LO MID
80 100~8K12K
HI
Line
Gain
Aux 1 Level
Preset select
FX
Preset
Display
Global 48v
Switch/LED
To Aux 2
Aux 6
Aux 3
Aux 4
Aux 5 Aux 6
Aux 1
Aux 2
HPF In
bypass
Solo Logic
Solo
USB Out
FX 1 Bypass
Logic
In
FX 1
Out L Out R
MID
Phantom Power (To All Mics)
Phantom Power
R
L
L
R
Int FX 1 Out L
FX 1
Line
LO MID MID
80 400 2.5K 12K
HI
LO MID MID
80 400 2.5K 12K
HI
Int FX 1 Out R
(FX2 on 2nd st ch.)
Tap
Solo
USB In
FX Mute Active
L R
Tape Out
Tape Input
L
R
2 track Input
Level
Main
level
+
-
+
-
+
-
+
-
Aux 3 (pre/post)
Aux 4 (pre/post)
Aux 1
Aux 2
post
pre
Aux 3
Aux 4
To Aux 3 To Aux 4
L-R
Aux1-4
Aux 3
Aux 4
USB
Tape
Solo
Phones
Level
Solo
Level
AFL solo R
AFL solo L
AFL solo R
Solo (2&4) Solo (1&3)
Solo
AFL Solo
Insert
Insert
Aux1
Aux2
Main
Mono Out
Mono level
-20dB pad
-20 Sig (flicker)
solo (on)
OL (flicker)
mute (on)
-20 Sig (flicker)
solo (on)
OL (flicker)
mute (on)
FX 1 master level
HPF
100Hz
Mono Channels
17-20(2404) 25-28(3204)
Mic +
-
Mic: 0 ~ +60dB
Line: -15 ~ +45dB
Line
GainHPF In
bypass
Phantom Power
HPF
100Hz
Comp
Comp
L R
AFL PFL
Solo mode
Mono Insert
Aux 1 sum
Aux 5
Aux 6
Aux 5 (post)
Aux 6 (post)
to USB 1-2
FX1
FX2
FX2 FX1
USB
(Second stereo
channel only)
Aux 1 Out (Aux 2-6 identical)
Sig/OL
L
R
(To first stereo channel)
post
pre
Gain
-20 ~ +20dB
Sub 1
Sub 4
Sub 3
Aux 6
to USB 3-4
Aux 5
Sub 2
Mono
Aux 5-6 Sub 3-4
Main L-R Sub 1-2
VLZ4 4•Bus BLOCK DIAGRAM

6/6 PAGES
VLZ4 4•Bus 24-/32-Channel 4•Bus
FX Mixer with USB
Part No. SW0996 Rev. A 08/13
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
PAN
L R
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
MID
200 2k
800
100 8k
FREQ FREQ FREQ FREQ FREQ FREQ FREQ FREQ FREQ FREQ FREQ FREQ FREQ FREQ FREQ FREQ
1
MUTE
PAN
L R
2
MUTE
PAN
L R
3
MUTE
PAN
L R
4
MUTE
PAN
L R
5
MUTE
PAN
L R
6
MUTE
PAN
L R
7
MUTE
PAN
L R
8
MUTE
PAN
L R
9
MUTE
PAN
L R
10
MUTE
PAN
L R
11
MUTE
PAN
L R
12
MUTE
PAN
L R
13
MUTE
PAN
L R
14
MUTE
PAN
L R
15
MUTE
PAN
L R
16
MUTE
PAD
-20dB
1
LOW CUT
100 Hz
GAIN
PAD
-20dB
2
LOW CUT
100 Hz
GAIN
PAD
-20dB
3
LOW CUT
100 Hz
GAIN
PAD
-20dB
4
LOW CUT
100 Hz
GAIN
PAD
-20dB
5
LOW CUT
100 Hz
GAIN
PAD
-20dB
6
LOW CUT
100 Hz
GAIN
PAD
-20dB
7
LOW CUT
100 Hz
GAIN
PAD
-20dB
8
LOW CUT
100 Hz
GAIN
PAD
-20dB
9
LOW CUT
100 Hz
GAIN
PAD
-20dB
10
LOW CUT
100 Hz
GAIN
PAD
-20dB
11
LOW CUT
100 Hz
GAIN
PAD
-20dB
12
LOW CUT
100 Hz
GAIN
PAD
-20dB
13
LOW CUT
100 Hz
GAIN
PAD
-20dB
14
LOW CUT
100 Hz
GAIN
PAD
-20dB
15
LOW CUT
100 Hz
GAIN
PAD
-20dB
16
LOW CUT
100 Hz
GAIN
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
1 2
SUBGROUPS
PUSH
TO TALK
MAIN
RIGHT
AUX 1-4
SOLO
STEREO
LEFT
RIGHT
SOLO
LEFT
RIGHT
SOLO
STEREO
LEFT
RIGHT
SOLO
LEFT
1 2 3 4 MAIN MIX
TALKBACK
OFF MAX
COMP
OFF MAX
COMP
OFF MAX
COMP
OFF MAX
COMP LEVEL
PHONES
TO AUX 1
TO AUX 2
SOLO
MONITOR
TAP
DELAY
MUTE
TO AUX 1
TO AUX 2
TAP
DELAY
MUTE
FX MASTERFX MASTER
TO LRTO LR
FX 2
SIG/OL
FX 1
SIG/OL
SOLO
SOLO
1
2
3
4
SOLO
SOLO MODE
SOLO
SOLO
SOLO
SOLO
SOLO PFL
AFL
AUX
AUX
AUX
AUX
CH 1-2 CH 3-4
AUX 5-6
PWR
RUDESOLO
48V
USB OUT
SUBS 3-4
20
10
7
4
2
0
2
4
7
10
20
30
LEVEL
SET
SUBS 1-2
MAIN
TO LR
TAPE
USB
2-TRACK RETURN
SUCK
SOLO
12V
0.5A
OFF MAX
COMP
OFF MAX
COMP
OFF MAX
COMP
OFF MAX
COMP
LOW CUT
100 Hz
LOW CUT
100 Hz
LOW CUT
100 Hz
LOW CUT
100 Hz FX 1 FX 2
USB
21
22
23
24
HI
12k
HI
MID
2.5k
LOW
MID
400Hz
HI
MID
2.5k
-15 +15
U
-15 +15
U
-15 +15
U
-15 +15
U
LOW
80Hz
LOW
MID
400Hz
LOW
80Hz
-15 +15
U
HI
12k
2
3
4
5
6
1
+15
U+15
U
+20
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U
+15
U+15
U+15
U
+15
U
+15
U
+15
U+15
U+15
U
+15
U
+15
U
+15
U
-15 +15
U
-15 +15
U
-15 +15
U
-20 +20
U
-20 +20
U
AUXMASTER
LR
STEREO RETURNS
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
FREQ
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
FREQ
MID
200 2k
800
100 8k
EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
FREQ
MID
200 2k
800
100 8k
EQ EQ EQ
HI
12k
-15 +15
U
-15 +15
U
LOW
80Hz
-15 +15
U
FREQ
MID
200 2k
800
100 8k
PAN
L R
17
MUTE
PAN
L R
18
MUTE
PAN
L R
19
MUTE
PAN
L R
20
MUTE
BAL
L R
21/22
MUTE
ALT 3-4
BAL
L R
0 dB=0dBu
LEFT RIGHT
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
1-2
3-4
LR
OL
-20
30
20
10
10
40
50
5
5
U
60
dB
OO
SOLO
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
FX
AUX5/6
PRE
PRE
FX1
FX2
PRE
1
2
+15
U
AUX
+15
U
3
4
5
6
+15
U
+15
U
+15
U
+15
U
23/24
MUTE
ALT 3-4
30
20
10
10
40
50
5
5
U
60
dB
OO
30
20
10
10
40
50
5
5
U
60
dB
OO
30
20
10
10
40
50
5
5
U
60
dB
OO
30
20
10
10
40
50
5
5
U
60
dB
OO
30
20
10
10
40
50
5
5
U
60
dB
OO
30
20
10
10
40
50
5
5
U
60
dB
OO
17
GAIN
18
GAIN
19
GAIN
20
GAIN LINE GAIN LINE GAIN
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
30
-20dB +40dB
U
60U
4020
50%
100%0%
25% 75%
POWER
ON
PHANTOM
ON
3 2 1 2 1
2 1
6 5 4
3 2 16 5 4
3 2 14
SUBGROUP OUTS
BAL / UNBAL
SUBGROUP INSERTS
TIP SEND, RINGRETURN
AUX INSERTS
TIP SEND, RING RETURN
AUX SENDS
BAL / UNBAL
3 2 14
L
R
MONO
L
R
MONO
STEREO RETURNS
BAL / UNBAL
21/22 23/24
BAL / UNBALBAL / UNBAL
MONITOR
MONO
MONITOR
L
R
100 - 240 V
50 - 60 Hz 55W
TALKBACK
MIC RIGHT MAIN OUT
INSERT LINE
LEFT MAIN OUT
INSERT LINE
MONO MAIN OUT
INSERT LINE
LEVEL
OUTPUT LUSB
R
L
R
TAPE
OUTIN
TIP SEND
RING RETURN
TIP SEND
RING RETURN
TIP SEND
RING RETURN
BAL / UNBAL BAL / UNBAL BAL / UNBAL
20
20
20
19
19
19
18
18
18
17
17
17
16
16
16
15
15
15
14
14
14
13
13
13
12
12
12
11
11
11
10
10
10
9
9
9
8
8
8
7
7
7
6
6
6
5
5
5
4
4
4
3
3
3
2
2
2
1
1
1
ONYX MIC PREAMPS
LINE (BAL / UNBAL)
INSERTS (TIP SEND, RING RETURN)
LINE (BAL / UNBAL)
INSERTS (TIP SEND, RING RETURN)
ONYX MIC PREAMPS
UNBALANCED
REVISION
SERIAL NUMBER
REPLACEWITH THE SAME TYPE FUSE AND RATING.
DISCONNECT SUPPLYCORD BEFORE CHANGING FUSE
UTILISE UN FUSIBLE DE RECHANGE DE MÊMETYPE.
DEBRANCHERAVANT DE REMPLACER LE FUSIBLE
WARNING: TO REDUCETHE RISK OF FIRE OR ELECTRIC
SHOCK,DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR
MOISTURE. DO NOT REMOVE COVER. NO USER SERVICEABLE
PARTSINSIDE. REFER SERVICINGTO QUALIFIED PERSONNEL.
AVIS: RISQUE DE CHOC ELECTRIQUE — NE PASOUVRIR
THIS DEVICE COMPLIESWITH PART 15 OF THE FCC RULES FOR THE U.S.AND THE ICES-003 FOR CANADA. OPERATION
IS SUBJECT TOTHE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAYNOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
+6
U
VLZ4 4•Bus FRONT AND REAR PANEL (2404VLZ4 shown)
Electronic files for this product are available at:
www.mackie.com
Specification Sheet VLZ4_4BUS_SS.PDF
Owner’s Manual VLZ4_4BUS_OM.PDF
www.mackie.com
16220 Wood-Red Road NE
Woodinville, WA 98072 USA
800-898-3211, Fax [phone]
LOUD Technologies Inc. is always striving to improve our products
by incorporating new and improved materials, components, and
manufacturing methods. Therefore, we reserve the right to
change these specifications at any time without notice.
“Mackie” and the “Running Man” figure are registered trademarks of
LOUD Technologies Inc. All other brands mentioned are trademarks
or registered trademarks of their respective holders, and are hereby
acknowledged.
©2013 LOUD Technologies Inc. All rights reserved.
