INSTRUCTIONS
INSTRUCTIONS
FOR USE AND MAINTENANCE
MADE IN SPAIN
SC100
“PORTABLE ELECTRICAL CHASER MACHINE”

The term “power tool”, “machine”, and “chaser machine” in all warnings below refers to mains-
operated MACROZA SC-100 wall chaser.
1. Keep your work area clean, tidy and well lit. Dirty, untidy and dark work areas increase the
risk of accidents.
2. Do not operate MACROZA SC-100 in explosive atmospheres such as in the presence of
flammable liquids or gasses. Power tools create sparks which may ignite fumes.
3. Do not expose MACROZA SC-100 to rain or wet conditions. Contact with water when using
a power tool will increase the risk of electric shock.
4. Keep bystanders, children and visitors away while operating MACROZA SC-100.
5. Tools with an earth or ground connection to the exposed metal parts must be connected to
a power outlet that has an earth or ground connection in accordance with all codes and
regulations. Check with a qualified electrician if you are in doubt as to whether the outlet is
properly earthed or grounded.
6. Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
7. Do not abuse the cord. Never use the cord to carry the MACROZA SC-100 or pull the plug
from an outlet. Keep cord away from heat, oil, sharp edges or moving parts. Replace damaged
cord immediately. Damaged cords increase the risk of electric shock.
8. When operating MACROZA SC-100 use only outdoor extensions cord marked “W-A” or “W”.
These cords are rated for outdoor use and reduce the risk of electric shock.
9. Stay alert; watch what you are doing when operating MACROZA SC-100. Use common
sense. Do not use the power tool when tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury. To reduce the risk of fatigue it is recommended to have a break of no less than 10
minutes after every hour of work
10. Use safety equipment. Always wear eye and ear protection and rubber gloves. Safety
equipment such as dust mask, non-slip footwear or hard hat used for appropriate conditions
will reduce personal injuries.
11. Dress properly. Do not wear loose-fitting clothing or jewellery. ong hair should be tied
back. Keep your hair, clothing and gloves away from moving parts as they can be caught in the
power tool.
WARNING! Read and understand all instructions before using the MACROZA SC-100. Failure
to follow all basic safety measures listed below may result in electric shock, fire and/or serious
personal injury.
2
GENERAL SAFETY RULES

3
12. Do not overreach. Keep a proper footing balance at all times. Proper footing and balance
enables better control of the tool in unexpected situations. Follow instructions in this book of
proper chasing positions.
13. Store idle MACROZA SC-100 in a dry safe place under lock and key and out of reach of
children. Do not allow persons unfamiliar with the chaser machine or these instructions to
operate the power tool. Tools are dangerous in the hands of untrained users.
14. Avoid accidental starting. Make sure the switch is off before plugging in. Do not carry
MACROZA SC-100 with your finger on the switch. In case an unexpected jam occurs, switch
the power tool off and unplug it from the mains socket.
15. Remove adjusting tools and attachments before turning MACROZA SC-100 on. A wrench
or a key that is left attached to a rotating part of the machine may result in personal injury.
16. Disconnect the plug from the power source before making any adjustments, changing
accessories or storing the MACROZA SC-100. Such preventive safety procedures will reduce the
risk of starting the machine accidentally.
17. Do not overload the MACROZA SC-100 as it will work more safely and efficiently within
the indicated power range. Do not use this wall chaser on extremely hard materials such as
concrete or stone.
18. Do not force the tool. Use the correct tool for your application. The correct tool will do the
job better and safer for which it is designed.
19. Do not use MACROZA SC-100 if the switch does not turn on and off. It must be repaired
immediately.
20. Maintain MACROZA SC-100 with care. Keep power tool clean and milling cutter sharp to
ensure perfect working condition.
21. All moving parts should be periodically inspected together with the cord and cutter
protective cover.
22. Keep handles clean and free from grease and oil. Properly maintained tools reduce risk of
personal injury.
23. Warning! Use only MACROZA original parts. Failure to do so may lead to personal injuries.
24. Before starting the job, check for damages or breakages and any other condition that may
affect the operation of the wall chaser or moving parts. If damaged, service the MACROZA SC-
100 before using it. Many accidents can be caused by poorly maintained tools.
25. Always use approved MACROZA service centres for maintenance. Have power tool service
by a qualified repair person. This will ensure safety of the machine is maintained.
26. MACROZA SC-100 is designed in accordance with these instructions and in the manner
intended for the particular type of job. All maintenance should carry out by a specialist and
using only MACROZA original spare parts.
27. The MACROZA SC100 chaser machine should not be used to perform work for which it has
not been designed (for example, to cut wood). Use of chaser machine for operations different
from those intended could result in a hazardous situation.

WARNING!
To reduce risk of injury, user must read instruction manual.
ELECTRICAL SAFETY
The installation voltage must be as stated on the MACROZA SC-100 specifications plate
E UIPMENT
1 MACROZA SC-100 chaser machine
1 Special fixed wrench for loosening the milling cutter
1 Fixed spanner for tightening the shaft
1 Box and case
1 Instructions manual
Model SC100 Model SC100
Class II Class II
Motor Single-phase Motor Single-phase
Voltage 220V AC Voltage 110V AC
Frequency 50 / 60 Hz Frequency 50 / 60 Hz
Power 2,800 W (at full load) Power 2,800 W (at full load)
Off-load rotating speed 1,900 r.p.m. Off-load rotating speed 1,900 r.p.m.
DESCRIPTION
1. On/Off switch 5. Brush holder
2. Rear handle 6. Front skid
3. Motor body 7. Ventilation slits
4. Front handle/cutter attachment housing 8. Mains power cord book
4
3
8
1
2
5
6
74
TECHNICAL INFORMATION
Acoustic power level: 110 dBA (± 3 dB)
Vibration level: 10 m/sec2.

5
STARTING JOB WITH MACROZA SC100
• Plug MACROZA SC-100 in the mains socket.
• Switch on MACROZA SC-100 before contact with the surface to verify its rotating
direction. Teeth must rotate forward as shown in Figure 1.
• ean MACROZA SC-100 lateral to the wall. Slowly insert the milling cutter into the wall
(Figure 4).
• Hold the machine firmly to avoid initial vibrations.
Figure 4
VERTICAL CHASES
• Vertical chases are done from top to bottom.
• Right hand should hold on to handle and switch while the left hand firmly grips on the
milling cutter cover (Figure 5).
• eft hand guides the chaser machine bearing most of the force.
• Once the cutter has entered the wall, pull down MACROZA SC-100 with both hands
producing a straight vertical cut.
• A difference in movement from one hand to the other will produce a curved cut.
Figure. 5
“Correct” “ eft hand incorrect”
fig. 5

6
HORIZONTAL CHASES
• Horizontal chases are done from right to left.
• The right hand holds the wall chaser by the right side of the milling cutter cover and
pushes leftwards (Figure 6).
• Right arm will lean on to the machine and push also leftward from the left hand side
(Figure 7).
• The left hand holds the rear handle and operates the switch (Figure 6).
Figure 6 “Correct” Figure 7 “Correct” “Right hand incorrect”
HORIZONTAL CHASES CLOSE TO THE FLOOR
• Horizontal chases close to the floor are done from left to right. (Figure 8)
• Right hand holds the machine by the rear handle and operates the switch. eft hand
holds the milling cutter cover from the left hand side and pushes to the right (Figure 8)
Figure 8 “Correct” “Both hands and the machine incorrect”

7
The MACROZA SC100 chaser machine’s cutting attachment is a widia-tipped (Carbide
Tungsten) milling cutter.
It is used with seven different types of milling cutters depending on the measure of chase
required (depth x width):
NOTES:
Cut width and depth might vary depending on milling cutter’s level of wear.
• For cuts wider than 50 mm, make two parallel cuts side by side
• For gear or switch boxes, make two additional parallel cuts on each side of the existing cut.
RZ-105: 30mm x 30mm RZ-125: 40mm x 40mm
RZ-10: 25mm x 25mm
RZ-150:
50mm x 50mm
RZ-11:
35mm x 25mm
RZ-12: 45mm x 15mm
RZ-115:
35mm x 35mm
MILLING CUTTERS

AFILADO DE LA FRESA
Antes de afilar la fresa,
emplearemos el comprobador de
afilado para verificar si sus
dientes necesitan ser afilados.
Comprobador de afilado
Do NOT use this
kind of machine
for sharpening.
Carbide Sharpness tester
8
Sharpening must
be done with this
grinding stone.

INSTALLING THE MILLING CUTTER
• There are several sizes of MACROZA milling cutter depending on the width and depth of the
chase.
• Only original MACROZA milling cutters should be used as they are designed specifically for
the MACROZA SC-100.
• Make sure that the MACROZA SC-100 is switched off and unplugged from mains power
before handling the milling cutter.
• Install milling cutter as shown in Figure 1, with teeth facing downwards in cutting position.
• Milling cutter shaft rotates to the left as indicated on arrow engraved on the milling cutter
cover (Figure1).
• Before installing the milling cutter it is very important to place a washer (supplied with the
machine and cutters) between the shaft and milling cutter. This will make it easier to remove
the milling cutter after use.
• To remove milling cutter, use the special wrench as shown on Figure 2.
• Fix the spanner between the shaft and milling cutter cover. Once the spanner is attached hit
the special wrench as shown in Figure 3. Do not hit the special wrench if the spanner it is
not fixed between the shaft and milling cutter cover.
VERY IMPORTANT: Check the following each time before using MACROZA SC-100
• Milling cutter does not have any widia (Carbide Tungsten) tip missing.
• Ensure all milling cutter teeth are sharpened.
9
“Direction of thrust”
“Rotation”
“Loosen
with the
special
wrench, ho-
oking it to
the lower
tooth and
the opposi-
te lip”
Fig. 3

To sharpen a milling cutter use an emery or grinding stone with the following specifications:
Carborundum, Grain 80, and Grade JK.
Milling cutter sharpening angle must be 5° (cutting angle A), as shown in Figure 9.
APROXIMATE MILLING CUTTER DURATION
The MACROZA SC100 chaser machine has been designed to work on the following materials:
• Bricks (both solid and hollow)
• Fireproof bricks
• Ytong blocks
• Cement blocks
• Plaster walls
Do not use the MACROZA SC100 chaser machine on concrete, stone or any other extremely
hard material.
The life figures (metres cut) of a milling cutter depends on the material it is used on:
MATERIALS LIFESPAN
Soft materials (plaster, Ytong, etc.) 15,000 m
Hollow brick 9,000 m
Solid brick 4,000 m
Cement block 3,000 m
∞
∞
∞
∞
Sharpen the milling cutter’s upper part.
Never sharpen the front part.
10

11
REPAIRING THE MILLING CUTTER (plate replacement):
Keep your milling cutter sharpened at all times and without any missing carbide widia tooth.
A milling cutter with a missing or broken widia tooth will be useless within a few hours of work
and may be a potential hazard. Repair immediately.
Widia tooth replacement:
1. Use a blowtorch to remove all old widia tooth remains.
2. Use a file to make the original gap. The gap should maintain the original position
3. New plate must welded with an autogenously filler weld. It should protrude 0.5 mm above
the milling cutter (figure 7).
4. Sharpen the new widia tooth following instructions above.
MAINTAINING THE MACROZA CHASER MACHINE:
All maintenance and repair jobs on the machine must be carried out at a MACROZA Technical
Service Centre.
MACROZA Wall Chaser Maintenance
We strongly recommend that all maintenance of Macroza Wall Chasers is done at an official
Macroza Technical Service Centre.
Regular maintenance should be done to ensure the best performance of your wall chaser.
DAILY MAINTENANCE.
Check the sharpness of the milling cutter approximately after each hour of use and change the
cutter when it becomes blunt.
After each day’s use, clean the machine so that there is no dust. If necessary, blow shots of
compressed air through the machine to remove the dust.
MONTHLY MAINTENANCE.
All MACROZA Wall Chasers used on daily basis should be checked at least once a month.
It is extremely important to check if there is any play in the bearings located in the milling
cutter shaft. At the slightest play we strongly recommend that the bearings are changed.
Failure to do so may lead to severe failures in the machine engine.
In normal working conditions and due to the harsh nature of chasing job, it may be necessary
to change the bearings each month.
ook through the lateral slots of the chaser to check whether sparks produced by the carbon
brushes in the commutator are stronger than normal. If necessary replace both carbon
brushes. Always replace the pair of carbon brushes.
AFTER-SALES SERVICE FOR YOUR MACROZA SC100:
MACROZA has an Official Technical Service Centre network to provide you with excellent service
and fast repairs.
The use of non original MACROZA spare parts could lead to machine damage.

S11 Milling cutter cover
S12 Motor casing
X13 Intermediate cover
X14 Complete rear handle
S15 Switch cover (handle)
X16 Intermediate cover seal
X18 Front skid
X20 Coil isolation cap
21 Cutter attachment shaft
23 Cutter attachment washer
24 Shaft dust-guard
25 Shaft grease retainer
X26 Shaft cover seal
27 RZ-11 Milling cutter
Ref. Descripción
28 RZ-12 Milling cutter
29 RZ-105 Milling cutter
30 RZ-10 Milling cutter
S115 RZ115 Milling cutter
S125 RZ125 Milling cutter
S150 RZ150 Milling cutter
31 Crown knuckle pin
32 Crown nut
34 Gear
35 Pinion
41 Motor bearing
43 Motor bearing
45 Shaft bearing
46 Shaft and motor bearing
Ref. Descripción
SPARE PARTS
13
20

47 O-ring
48 Motor bearing cover
49 Casing lower insulator
50 Interior insulator
S51 Complete armature
S52 Stator
53-54 Fan spacer & Fan
S58 Auto switch-off Brush
59 Brush plug
S61 Brush tube
62 Insulated bushing
M65 Switch
66 Cable exit rubber grommet
67 Cable with mains plug
Ref. Descripción
69 Capacitor
S70 Special cutter spanner
71 Fixed spanner
78 Flat washer
79 ock washer
82 Brush keeper
83 Allen screw
84 Allen screw
86 Allen screw
87 Bearing cover screw
88 Nut
89 Coil rod
90 Hard metal plate
M98 Overload chip
Ref. Descripción
13
