MACROZA M80 User manual

Portable
electric wall chasers
Wall Chasers
Original User Guide
MADE IN SPAIN

2
Portable
electric wall chaser
Mac oza
SSCC200
Mac oza
M80
Mac oza
M95

3

GGEENNEERRAALL SSAAFFEETTYY RRUULLEESS
1. eep your work area clean, tidy and well lit.
Dirty, untidy and dark work areas increase the
risk of accidents.
2. Do not operate your MACROZA Wall Chaser
in explosive atmospheres such as in the
presence of flammable liquids or gasses.
Power tools create sparks which may ignite
fumes.
3. Do not expose your MACROZA Wall Chaser
to rain or wet conditions. Contact with water
when using a power tool will increase the risk
of electric shock.
4. eep bystanders, children and visitors away
while operating MACROZA Wall Chasers.
5. Tools with an earth or ground connection to
the exposed metal parts must be connected
to a power outlet that has an earth or ground
connection in accordance with all codes and
regulations. Check with a qualified electrician
if you are in doubt as to whether the outlet is
properly earthed or grounded.
6. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is earthed or
grounded.
7. Do not abuse the cord. Never use the cord to
carry the MACROZA Wall Chaser or pull the plug
from an outlet. eep cord away from heat, oil,
sharp edges or moving parts. Replace damaged
cord immediately. Damaged cords increase the
risk of electric shock.
8. When operating your MACROZA Wall Chaser
use only outdoor extensions cord marked “W-
A” or “W”. These cords are rated for outdoor
use and reduce the risk of electric shock.
9. Stay alert; watch what you are doing when
operating MACROZA Wall Chasers. Use
common sense. Do not use the power tool when
tired or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury. To reduce the risk of fatigue it is
recommended to have a break of no less than 10
minutes after every hour of work
10. Use safety equipment. Always wear eye and
ear protection and rubber gloves. Safety
equipment such as dust mask, non-slip
footwear or hard hat used for appropriate
conditions will reduce personal injuries.
11. Dress properly. Do not wear loose-fitting
clothing or jewellery. Long hair should be tied
back. eep your hair, clothing and gloves
away from moving parts as they can be
caught in the power tool.
RECOMENDED
¡WARNING! Read and understand all instructions before using MACROZA Wall
Chasers. Failure to follow all basic safety measures listed below may result in electric
shock, fire and/or serious personal injury.
The term “power tool”, “machine”, and “chaser machine” in all warnings below refers to
mains-operated MACROZA wall chasers.
4

12. Do not overreach. eep a proper footing
balance at all times. Proper footing and
balance enables better control of the tool in
unexpected situations. Follow instructions in
this book of proper chasing positions.
13. Store idle your MACROZA Wall Chaser in a
dry safe place under lock and key and out of
reach of children. Do not allow persons
unfamiliar with the chaser machine or these
instructions to operate the power tool. Tools
are dangerous in the hands of untrained
users.
14. Avoid accidental starting. Make sure the
switch is off before plugging in. Do not carry
MACROZA Wall Chaser with your finger on
the switch. In case an unexpected jam
occurs, switch the power tool off and unplug
it from the mains socket.
15. Remove adjusting tools and attachments
before turning MACROZA Wall Chaser on. A
wrench or a key that is left attached to a
rotating part of the machine may result in
personal injury.
16. Disconnect the plug from the power source
before making any adjustments, changing
accessories or storing the MACROZA Wall
Chaser. Such preventive safety procedures
will reduce the risk of starting the machine
accidentally.
17. Do not overload the MACROZA Wall Chaser
sas it will work more safely and efficiently
within the indicated power range. Do not use
this wall chaser on extremely hard materials
such as concrete or stone.
18. Do not force the tool. Use the correct tool for
your application. The correct tool will do the
job better and safer for which it is designed.
19.
19. Do not use MACROZA Wall Chasers if the
switch does not turn on and off. It must be
repaired immediately.
20. Maintain MACROZA Wall Chasers with care.
eep power tool clean and milling cutter
sharp to ensure perfect working condition.
21. All moving parts should be periodically
inspected together with the cord and cutter
protective cover.
22. eep handles clean and free from grease
and oil. Properly maintained tools reduce risk
of personal injury.
23. Warning! Use only MACROZA original parts.
Failure to do so may lead to personal
injuries.
24. Before starting the job, check for damages or
breakages and any other condition that may
affect the operation of the wall chaser or
moving parts. If damaged, service the
MACROZA before using it. Many accidents
can be caused by poorly maintained tools.
25. Always use approved MACROZA service
centres for maintenance. Have power tool
service by a qualified repair person. This will
ensure safety of the machine is maintained.
26. MACROZA Wall Chasers are designed in
accordance with these instructions and in the
manner intended for the particular type of
job. All maintenance should carry out by a
specialist and using only MACROZA original
spare parts.
27. The MACROZA chaser machine should not
be used to perform work for which it has not
been designed (for example, to cut wood).
Use of chaser machine for operations
different from those intended could result in a
hazardous situation.
5

ELECTRICAL SAFETY
The installation voltage must be as stated on the MACROZA wall chasers’
specifications plate
WARNING! To reduce risk of injury, end-user must read instruction manual carefully.
E UIPMENT
DESCRIPTION
1. On/Off switch
2. Rear handle
3. Motor casing
4. Front handle/Milling cutter cover
5. Brush holder
6. Front skid
6
3
8
1
2
74
5
6
9
Modelo SC200
Class II
MotorSingle-phase
Voltage220V/240V AC or
110V/130V AC
Frequency50 / 60 Hz
Power2,800 W (at full load)
Off-load rotating speed
1,400 r.p.m.
Modelo M95
Class II
MotorSingle-phase
Voltage220V/240V AC or
110V/130V AC
Frequency50 / 60 Hz
Power2,400 W (at full load)
Off-load rotating speed
1,200 r.p.m.
DATOS TÉCNICOS M80 M95 SC200
Acoustic power level: 89 dBA (± 3 dB) 96 dBA (± 3 dB) 102 dBA (± 3 dB)
Vibration level: 7 m/sec2. 8 m/sec2. 10 m/sec2.
Modelo M80
Class II
Motor Single-phase
Voltage 220V/240V AC or
110V/130V AC
Frequency 50 / 60 Hz
Power 2,000 W (at full load)
Off-load rotating speed
1,000 r.p.m.
10
7. Ventilation slits
8. Mains power cord
9. Led lights. Only for SC 200
10. Dust extraction outlet
1 MACROZA wall chaser machine
1 Special fixed wrench for loosening the milling cutter
1 Fixed spanner for tightening the shaft
1 Box and case
1 Instructions manual

7
“Direction of thrust” “Support the
shaft on the
casing fixed
spanner”
INSTALLING THE MILLING CUTTER
• There are several sizes of MACROZA milling cutter depending on desired width and
depth of the chase.
• Only original MACROZA milling cutters should be used as they are specifically
designed for MACROZA Wall Chasers.
• Make sure MACROZA Wall Chasers are switched off and unplugged from mains
power before handling the milling cutter.
• Install milling cutter as shown on Figure 1, with teeth facing downwards in cutting
position.
• Milling cutter shaft rotates to the left as indicated on arrow engraved on the milling
cutter cover (fig.1).
• Before installing the milling cutter it is very important to place a washer (supplied with
the machine and cutters) between the shaft and milling cutter. This will ensure perfect
seating on the shaft and will make it easier to remove the milling cutter after use.
It is also recommended to grease the thread shaft with oil or lubricant
• To remove milling cutter, use the special wrench as shown on Figure 2.
Fix the spanner between the shaft and milling cutter cover. Once the spanner is
attached hit the special wrench as shown in Figure 3. Do not hit the special wrench if
the spanner is not fixed between the shaft and milling cutter cover.
VERY IMPORTANT: Check the following each time before using MACROZA wall
chasers
• Milling cutter does not have any Tungsten Carbide plate missing.
• Ensure all milling cutter teeth are well sharpened.
“Rotation”
Figu e 1
Figu e 2
Figu e 3
“Loosen with
the special
wrench, hooking
it to the lower
tooth and the
opposite lip”

8
figure. 5
figure. 4
“Correct” “Left hand incorrect”
VERTICAL CHASES
• Vertical chases are done from top to bottom.
• Right hand should hold on to handle and switch while the left hand firmly grips on the
milling cutter cover (Figure 5).
• Left hand guides the chaser machine bearing most of the force.
• Once the cutter has entered the wall, pull down MACROZA wall chaser with both
hands producing a straight vertical cut.
• A difference in movement from one hand to the other will produce a curved cut.
• Plug MACROZA wall chaser in the mains socket.
• Switch on the machine before contact with the surface to verify its rotating direction.
Teeth must rotate forward as shown in Figure 4.
• Lean your MACROZA wall chaser lateral to the wall. Slowly insert the milling cutter
into the wall (Figure 4).
• Hold the machine firmly to avoid initial vibrations.
STARTING JOB

9
figure. 6
figura. 7
HORIZONTAL CHASES
• Horizontal chases are done from right to left.
• The right hand holds the wall chaser by the right side of the milling cutter cover and
pushes leftwards (Figure 6).
• Right arm will lean on to the machine and push also leftward from the left hand side
(Figure 7).
• The left hand holds the rear handle and operates the switch (Figure 6).
“ “Correct”
“Right hand incorrect”
figure. 7

10
HORIZONTAL CHASES CLOSE TO THE FLOOR
• Horizontal chases close to the floor are done from left to right. (Figure 8)
• Right hand holds the machine by the rear handle and operates the switch. Left hand holds
the milling cutter cover from the left hand side and pushes to the right (Figure 8)
OVERLOAD CIRCUIT
If the milling cutter gets blocked with the wall chaser switched on in model MACROZA
SC200 a red light will lit up and the machine will switched off automatically.
After a few seconds a green light will be lit instead and the wall chaser will be able to carry
on working.
““Correct” ”
figure. 8

11
DUST COLLECTION OPTION FOR MACROZA M95 & Sc200
MACROZA M95 and SC200 come with optional dust collection outlet if needed.
• Remove milling cutter cover cap as shown on Figure 9
• Insert dust collector adaptor. Figure 10
• Attach dust collector adaptor on dust collection system as shown on figure 11
figure. 9
figure. 10
figura. 11
To avoid dust & debris we recommend use our
own dust collector MACROZA MCV1

MACROZA wall chasers’ cutting device is a Tungsten Carbide tipped milling cutter.
There are seven different types of milling cutters depending on required cutting
measure (depth x width):
12
NOTES
Cutting width and depth might vary depending on
milling cutter’s level of wear.
• For cuts wider than 50 mm, make two parallel cuts
side by side
• For gear or switch boxes, make two additional parallel
cuts on each side of the existing cut.
STANDARD SERIES RZ
RZ Standard milling cutters
are able to work on softer
materials such as hollow clay
bricks, AAC blocks, limestone
blocks or semi-hard solid
clay bricks and hollow
cement blocks
PREMIUM SERIES RD
RD Premium series have been designed to work
on the hard building material with the exception
of concrete, pre-cast concrete or stone.
Working on standard masonry materials,
MACROZA RD Premium series increase
productivity in up to 40% as opposed to the RZ
standard cutters.
MILLING CUTTERS
RZ1-RD25 RZ-RD12 RZ-RD150
RZ-RD105 RZ-RD11 RZ-RD115 RZ-RD10
RZ or RD 10: 25 mm x 25 mm (suitable for all Macroza models)
RZ or RD 105: 30 mm x 30 mm (suitable for all Macroza models)
RZ or RD 11: 35 mm x 25 mm (suitable for all Macroza models)
RZ or RD 12: 45 mm x 15 mm (suitable for all Macroza models)
RZ or RD 115: 35 mm x 35 mm (suitable for M95 and SC200 only)
RZ or RD 125: 40 mm x 40 mm (suitable for M95 and SC200 only)
RZ or RD 150: 50 mm x 50 mm (suitable for SC200 only)

MILLING CUTTER
SHARPENING
Use the MACROZA Carbide
Tester before sharpening the
milling cutter to check
whether the carbide teeth
need to be sharpened.
“Do NOT use this
kind of machine for
sharpening.”.”
“Sharpening must be
done with this kind of
grinding stone
machine.”<
Sharpening must be
carried out with
bench grinder.
Carbide
Sharpness
tester
13

Only the milling cutter upper
side should be sharpened.
Do not sharpen the front
part.
MILLING CUTTER PERFROMANCE TABLE MACROZA wall chasers machine
has been designed to work on the following materials:
Do not use the MACROZA chaser machines on concrete, pre-cast concrete, stone
or any other extremely hard material.
14
MILLING
CUTTERS
RZ y RD
Hollow brick 400 metres 4-6 hours 12,000 -14,000 metres
Solid brick 200 metres 2-4 hours 4,000-6,000 metres
Cement block 150 metres 1-3 hours 3,000-5,000 metres
Mortar-rendering wall 300 metres 2-4 hours 5,000 – 7,000 metres
Aerated concrete 500 metres 4-6 hours 16,000 m-18,000 metres
MATERIAL
* Life of milling cutters will depend greatly
on the kind, quality & abrasion degree of
the materials used
figura. 12 To sharpen a milling cutter use an
emery or grinding stone with the
following specifications: Silicone
Carbide, Grain 80, and Grade J .
Milling cutter sharpening angle
must be 5° (cutting angle A), as
shown in Fig. 12
Metres before
sharpening
HOURS
BEFORE
SHARPENING *
MILLING
CUTTER
LIFESPAN*
- Bricks (both solid and hollow)
- Fireproof bricks
- Aerated concrete (AAC) blocks
- Cement blocks
- Limestone blocks
- Fly Ash blocks
- Mortar-rendered walls

15
MILLING CUTTER TUNGSTEN PLATE REPLACEMENT
eep your milling cutter sharpened at all times and without any missing Tungsten Carbide plate.
A milling cutter with a missing or broken Tungsten Carbide plate will be useless within a few hours
of work and may be a potential hazard. Repair immediately.
Tungsten Carbide plate replacement:
1. Use a blowtorch to remove all old plate remains.
2. Use a file to make the original gap. The gap should maintain the original position
3. New plate must welded with an autogenously filler weld. It should protrude 0.5 mm above the
milling cutter (figure 7).
4. Sharpen the new following instructions above.
MAINTAINING THE MACROZA CHASER MACHINE:
All repair & maintenance work on the machine must be carried out at a MACROZA Technical
Service Centre.
MACROZA Maintenance
We strongly recommend that all maintenance of Macroza Wall Chasers is done at an official
Macroza Technical Service Centre.
Regular maintenance should be done to ensure the best performance of your wall chaser.
DAILY MAINTENANCE
Check the milling cutter sharpeness approximately after each hour of use. Change milling cutter
when blunt.
After each day’s use, clean the machine to remove all traces of dust. If necessary, blow shots of
compressed air through the machine’s lots to remove dust.
MONTHLY MAINTENANCE
All MACROZA Wall Chasers used on daily basis should be checked at least once a month.
It is extremely important to check if there is play in the bearings located in the milling cutter shaft. At
the slightest play we strongly recommend that bearings are changed. Failure to do so may lead to
severe failures in the machine engine. Always change the pair of bearings.
In normal working conditions and due to the harsh nature of chasing job, it may be necessary to
change bearings each month.
Look through the lateral slots of the chaser to check whether there are sparks produced by the
carbon brushes in the commutator. If necessary replace both carbon brushes. Always replace the
pair of carbon brushes.
AFTER-SALES SERVICE FOR YOUR MACROZA WALL CHASER
MACROZA has an Official Technical Service Centre network to provide you with excellent service
and fast repairs.
The use of non original MACROZA spare parts
could lead to machine damage..
Hollow brick 400 metres 4-6 hours 12,000 -14,000 metres
Solid brick 200 metres 2-4 hours 4,000-6,000 metres
Cement block 150 metres 1-3 hours 3,000-5,000 metres
Mortar-rendering wall 300 metres 2-4 hours 5,000 – 7,000 metres
Aerated concrete 500 metres 4-6 hours 16,000 m-18,000 metres

E02 Fan E03 Fan spacer
E08 Carbon brush E09 Brush plug
E11 Brush holder tube E14 Insulated socket
E15 Switch E17 Capacitor E19 Switch insulator
E21 Rubber cable bushing
E22 Cable with plug (3 m.)
E25 Bottom case insulator
E301 Armature complete E304 Stator E306 Stator insulation tube F10 Bearing cover F301 Milling cutter cover F302 Motor casing F303 Middle cover F304 Handle cover F305 Switch cover F308 Front skid J03 O-ring J101 Middle cover
J302 Shaft cover joint L01 Special double tool
L03 17 mm milling cutter tool M01 Milling cutter shaft
M03 Ring gear knuckle pin
M04 Ring gear nut M05 Ring gear M06 Motor pinion
R03 Shaft bearing
R04 Shaft bearing shielded
R10 Lubricant seal
R11 Shaft dust guard R12 Seal front
R13 Seal rear
R301 Motor bearing (front)
R302 Motor bearing (rear)
T01 Switch screw
T02 Brush holder tube screw T03 Screw (T04, T05 and T06)
T07 Coil screw
T11 Washer T20 Milling cutter washer T31 Nut
Ref. Des rip ión Ref. Des rip ión
16
Model M80

17

E02 Fan E03 Fan spacer
E06 Stator insulation tube E08 Carbon brush E09 Brush plug
E11 Brush holder tube E14 Insulated socket
E15 Switch E16 Protection chip E17 Capacitor E19 Switch insulator
E21 Rubber cable bushing
E22 Cable with plug (3 m.)
E25 Bottom case insulator
E101 Armature E104 Stator F07 Milling cover plug F09 Vacuum tube F10 Bearing cover F101 Milling cutter cover F202 Motor casing F203 Middle cover F104 Handle cover F105 Switch cover F108 Front skid
J03 O-ring
J101 Middle cover O-ring
L01 Special double tool
L03 17 mm milling cutter tool M01 Milling cutter shaft
M02 Shaft tube M03 Ring gear knuckle pin
M04 Ring gear nut
M05 Ring gear M06 Motor pinion R03 Shaft bearing
R04 Shaft bearing shielded
R10 Lubricant seal
R11 Shaft dust guard R12 Seal front
R13 Seal rear
R101 Motor bearing (front)
R102 Motor bearing (rear)
T01 Switch screw T02 Brush holder tube screw T04 Screw (T05, T06)
T07 Coil screw T21 Milling cutter washer T31 Nut
Ref. Des rip ión Ref. Des rip ión
18
Model M95

19

E01 Armature E02 Fan E03 Fan spacer
E04 Stator E06 Stator insulation tube E08 Carbon brush E09 Brush plug
E11 Brush holder tube E14 Insulated socket
E15 Switch E16 Protection chip E17 Capacitor E19 Switch insulator
E21 Rubber cable bushing
E22 Cable with plug (3 m.) E23 Leds it E25 Bottom case insulator E27 Green and red leds F01 Milling cutter cover F02 Motor casing F03 Middle cover F04 Handle cover F05 Switch cover F07 Milling cover plug F08 Front skid F09 Vacuum tube
F10 Bearing cover
J03 O-ring
J101 Middle cover O-ring
L01 Special double tool
L03 17 mm milling cutter tool M01 Milling cutter shaft M02 Shaft tube
M03 Ring gear knuckle pin M04 Ring gear nut
M05 Ring gear
M06 Motor pinion R01 Motor bearing (front)
R02 Motor bearing (rear)
R03 Shaft bearing
R04 Shaft bearing shielded
R10 Lubricant seal
R11 Shaft dust guard R12 Seal front
R13 Seal rear
T01 Switch screw T02 Brush holder tube screw T04 Screw (T05, T06)
T07 Coil screw T21 Milling cutter washer T31 Nut
Ref. Des rip ión Ref. Des rip ión
20
Model M200
