Mad Professor Snow White AutoWah User manual

MAD PROFESSOR AMPLIFICATION LTD
Finland
www.mpamp.com • [email protected]
This product is designed and manufactured by
Mad Professor Snow White AutoWah
ELECTRICAL SPECIFICATION:
• Current consumption approx. 15 mA
• Input impedance 500K Ohms
• Output impedance 1K Ohms
• Supply voltage 9VDC
• Max input -20 dBV
• Complete bypass and input of circuit
grounded when in bypass
NOTES:
SNOW WHITE AUTOWAH is protected
against wrong DC eliminator polarity.
Fuzzy sound is a sign of low voltage.
Maintain recommended voltage for best
results.
The manufacturer claims that the above
mentioned product fulfils the requirements as
set by EN 55013, EN 55020, EN 60555-2
and EN 60555-3, RoHS and WEEE.
Mad Professor pedals carry a 2 year limited
warranty.

MAD PROFESSOR - SNOW WHITE AUTOWAH - OWNER’S MANUAL
Thank you for buying
the nest and most
natural sounding auto-
wah pedal!
The New Snow White AutoWah (GB) is a
compination of the previous Snow White
AutoWah and the Snow White Bass
AutoWah. Now both of those fabulous
autowah sounds are in the same pedal
making the unit even more versatile.
SWAW (GB) has very fast tracking and
accuracy rarely found on autowah/envelope
lters. With four knobs you can have total
control of the effect.
You can ne-tune the SWAW (GB) to suit
your instrument, your playing style and your
taste of tone.
The controls are:
• GTR/BASS: Switch GTR for the guitar
and BASS for the bass or you can choose
which positions suits better for your
instrument.
• SenSiTiviTy:Sets the lter trigger level,
tune this carefully to fit your guitar/bass
output and your playing touch. You can
further change the sensitivity from
your guitar volume knob while playing.
• BiAS:Controls the filter resonance
frequency. When Sensitivity is turned fully off
the Bias can be used as a sweepable lter.
• RESONANCE: Controls the sharpness or
Q-factor of the lter.
• DecAy:Controls how fast the filter
frequency falls back to resting point (that is
set with the Bias control). This can be set
fast (CW) so you get the wah effect on
every note or slow for a more traditional
auto wah sound.
PLAyinG:
Please take time to get used to the con-
trols and as this is a voltage control lter it
will react to your playing touch. The enve-
lope control circuit is carefully designed to
follow the dynamics of guitar/bass and it
might take some time to master the Auto
Wah playing technics.
Try also adjusting instrument volume
between 8 and 10 to further expand use.
CAUTION!
Never operate the unit with its bottom
removed or damage will most likely occur.
POWER REqUIREMENTS:
6F22 9V battery or DC eliminator 2.1 mm
plug center negative and positive sleeve.
