Magellan Wireless Backup Camera User manual

Magellan Wireless Backup Camera
Installation Instructions
The following installation instructions are a general guide and
may
not apply to all vehicles.
We
strongly recommend you
have a qualified technician install this device. Improper instal-
lation may cause
damage
to
your
device and/or
your
vehicle.
Please consl:Jit
your
local
motor
vehicle laws on the use
of
this
product.
1.
Camera
2; :Transmitter
3.
Receiver
4. Vehicle
Power
Adapter (VPA)
5.
Quick
Slide T-Tap
connector (x2)
6. Quick
Disconnect
Terminal (x2)
3 6 o::([]
7.
Adapter cable (For use with RoadMate 1700)
4
7

Install the Camera
1.
Fasten the camera over the top
of
the rear license plate
using the existing license plate
screws. Take care not to pinch
or
strain the cable. Use the relief cut
out if necessary.
2.
Pass the camera cables through
the rear interior panel
of
the
vehicle.
Install the Transmitter
3.
Connect the transmitter's power and ground wires to the
vehicle's reverse light circuit.
+12voc
Backup Light
Use the supplied wire tap
Red
From
------
COnneCtOrS
to connect the
Transmitter _
__,
transmitter power wires to the
reverse light wires. Alternatively,
the transmitter can be wired directly
to the reverse circuit. Ensure
your
Black
connections did not cause
any
damage
to the wires
or
has any potential for shorts.

4. Connect the power cable and video cable of the
Transmitter to the corresponding cables
of the Camera.
Install the Receiver
5. Slide the receiver onto the back of the GPS device
cradle. The Back up Camera receiver has a "T" slot that
will slide onto the
back
of the cradle
supplied with
the GPS device.
Connect the 3.5
mm plug to the
AV-IN jack
of your
Roadmate GPS.

6. Connect the straight USB plug of the
VPA to the Receiver and the right
angle USB plug to your Roadmate
GPS. (The Magellan RoadMate
1700 requires the use
of the supplied
adapter cable.)
SPECIFICATIONS
CAMERA
Imaging Censor:
Resolution:
Vertical View Angle:
Horizontal View Angle:
Angle Adjustment Range:
Output Image:
Power Supply:
CMOS
640x480
Appx. 100°
Appx. 120°
45° Downward
Mirror Image
12V DC
Right angle USB
plug from VPA
Ingress Rating:
Dimensions (W X D X
H):
Weight:
Waterproof and dustproof
198mm x 27mm x 25mm
approx. 60 grams
Operating Temperature :
20°C- 75oC

TRANSMITTER
Frequency:
RF Output Power :
Power Supply:
Current Consumption:
Ingress Rating:
Operating Temperature:
Dimensions (W X D X H):
Weight:
RECEIVER
Receiver Sensitivity :
Power Supply :
Current Consumption:
Operating Temperature :
Dimensions (W X D X H):
Weight:
2400MHz-
2483.5MHz
18 dBm(typical)@ Max Power
10V-
32V DC
250mA
Water Resistant
0°C-
50°C
81mm x 55mm x 15mm
approx. 105 grams
-85 dBm
4.75V-5.25V DC
Max 150mA
0°C-
50°C
63mm x 17mm x 40mm
approx. 40 grams

FCC Interference Statement
This device complies with Part 15 of the FCC Rules. Op-
eration
is
subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate this equipment.
EU
Environmental Protection
Waste electrical products should not
be
disposed
of
with
any household waste. Please recycle where facilities ex-
ist. Check with your Local Authority or retailer for recycling
advice.

AGELLA
®
©2011 MiTAC International Corporation. The Magellan logo,
Magellan, and RoadMate are registered trademarks
of
MiTAC
International Corporation. All rights reserved.
605-0354-001 A
111111111111111111111111111111111111111111111111111111111111111111111111111111111111111111
5615N2870004
ROO

Federal Communications Commissi-on (FCC) Statement
WARNING
15. 21
You are cau.Uoned that changes or modifications not expressly approved by the part
re.spon.sible for compliance could void the users authority to operate the equipment.
15 . 105(b)
This e-quipment has been tested and found to compiy with the Hmits for a Class B
digital device.~pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential instaHation.
This
equipme - nt generates uses and can rad i.ate rad io frequency energy and . 1f n- ot
rnstaUed and used in accordance with the instructions. may cause harmful interference
to radio commtJnications. However. there ~ s no guarantee that interference will not
occur in a particular installation. U this equipment does ca\lse harmfu l interference
to radto or television reception , which can be determ i ned by turning th€ equipment
off and on , the user is encouraged to try to correct the interference by one or more
of the following measures:
• · Reorient or relocate the receiving antenna.
• increase the se parat ion betwHen the equipn1ent and receive r.
• Con n ee~ the eq uipment i, nto an .ou tlet on a d rc u. it different 'f rom that to w'tlich the
receiver is connect-ed.
• C
on sult the d ea ler or an ex.perienced r ad io/TV technici -a n f(Jf he ip .
This devi ce complies 'Ni th part 15 of the FCC Ru ies. Operation fSsubject to tl·;(~ following
two conditions:
1. Th ls devic e m ay not cause interference and
2. This d eV i Ce mus t accept any int f:; rferenc e. inc iuding inter fe rence t ha t rn;:1y cause
undesired
oper atio n of the d e · vic~.
