Magic Chef DU4J User manual

DISHWASHING GUIDE (DU4J)
O_FSTART
SCRUB WASH HEAT OFF
DRY
RINSE &HO_D
How to Operate YourNew Dishwasher
STEP1.Load the dishwasher according to the instructions on pages 5-7.
STEP 2. Add detergent to the detergent dispenser. See page 4. Use rinse aid to help prevent spotting and filming
and to improve drying results. See page 5.
STEP 3. Select the appropriate cycle. Refer to the chart below for additional information.
STEP 4. Select/deselect heating options. Press the door until it latches and start the dishwasher. The cycle will
begin with a drain prior to filling.
CYCLE DESCRIPTIONS
Super Scrub Cycle ] _ I [ i I I i ] I H_ I _ I _ ] I i I I _ [ ] OIF-CT-I__[---ff_F-Z2--]_[---_-I_C--ff-I_F---ffT_F------I_F----_
For heavily soiled dishes, pots and pans.
Cycle Time: Approx. 66 minutes
Water Usage: Approx. 11 gallons
For normally soiled dishes.
Cycle Time: Approx. 56 minutes
Water Usage: Approx. 9.5 gallons
Short Wash
For turnaround of lightly soiled dishes. _____]_]__
Select a Normal Wash Cycle and turn dial
to Short Wash.
Cycle Time: Approx. 36 minutes
Water Usage: Approx. 4.5 gallons
Rinse&Hold ____--_
For rinsing a few dishes until full.
Cycle Time: Approx. 13 minutes
Water Usage: Approx. 3 gallons
Heating Options:
DRYING HEAT. Available on all cycles except Rinse & Hold. Add 30 minutes to the cycle times listed above.
HEAT OFF. Drying Heat is turned off.

CONTENTS Write your model and serial numbers in the spaces
provided below. You'll find them on the data label
Cycle Description .............................................................. 1 located on the upper left corner of the door frame.
For Future Reference ......................................................... 2 Use this information for any correspondence or
service calls concerning your dishwasher.
Energy Saving Tips ........................................................... 2 ModelNumber
Safety Instructions ............................................................. 3
Using Your Dishwasher ................................................... 4
Hot Water .................................................................... 4 SerialNumber
Detergent ..................................................................... 4
Rinse Aid ..................................................................... 5
Preparing the Dishes .................................................. 5 Date ofPurchase
Loading the Dishwasher ....................................... 5-7
Convertible Dishwasher Connection ............................. 7 WARNING- To avoid possible electrical
What Can and Cannot be Washed .................................. 8 shock, check with the installerto make
sure the appliance has been praperly
Care and Cleaning ............................................................. 9 grounded. In addition, be sure to read
Storing Your Dishwasher ................................................. 9 the IMPORTANT PERSONAL SAFETY
INSTRUCTIONS on page 3before starting
Changing Color Panels ..................................................... 9 to usethis dishwasher.
The Problem Solver ................................................... 10-12
If You Need Service ......................................................... 12
Warranty ...........................................................................13 ENERGY SAVING TIPS
• Operate the dishwasher only when it's full. Running
a half-full dishwasher uses the same amount of
electricity and hot water as a full dishwasher.
FOR FUTURE •Always select the shortest cycle possible for the
REFERENCE... amount of food soil. See page 1.
•Load correctly for best results. See pages 5-7.
Before operating your dishwasher, please read this
book carefully. It is designed to help you operate and * Use your dishwasher during off-peak hours. Ask
maintain your new dishwasher properly. Keep it your local utility company for off-peak rates.
handy for answersto your questions.

IMPORTANT PERSONAL SAFETY INSTRUCTIONS
Products with a (_) label have been listed with the 9. Use only detergents and rinse additives designed
Underwriters' Laboratories, Inc.--those with a CSA for an automatic dishwasher. Never use soap,
tag have been listed with Canadian Standards laundry detergent, or hand washing detergent in
Association. Nevertheless, as with any other your dishwasher. Keep these products out of the
equipment using electricity and moving parts, there is reach of children.
a potential hazard. When using your dishwasher, 10. Do not sit, stand on or abuse the door or dish
follow basic precautions, including the following: racks of the dishwasher.
1. Read all instructions before using the dishwasher. 11. Under certain conditions, hydrogen gas may be
2. Use the dishwasher only for its intended function, produced in a hot water system that has not been
used for two weeks or more. Hydrogen gasis
3. Disconnect electrical power to dishwasher before explosive. If the hot water system has not been
attempting to service, used for such a period, turn on all hot water
4. To avoid electrical shock hazard, the sides and faucets and let the water flow from each for
back must be enclosed, and the front panels must several minutes. This will release any accumulated
be attached before electrical power is applied to hydrogen gas. As the gas is flammable, do not
the dishwasher. Refer to the installation smoke or use an open flame during this process.
instructions for proper grounding procedures. 12. Do not wash plastic items unless marked
5. Connect to a properly rated, protected and sized "dishwasher safe" or the equivalent. For plastic
power supply circuit to avoid electrical overload, items not so marked, check the manufacturer's
recommendations.
6. Children should never be permitted to operate, or
play in, with, or around this dishwasher. 13. Do not tamper with controls.
7. To reduce the risk of injury when loading items to 14. Always remove the door to the washing
be washed, sharp or pointed items should be compartment when removing an old dishwasher
located with the handles up. Also, load sharp from service or discarding it.
items so they are not likely to damage the door
seal.
8. Be careful not to touch the heating element on the
bottom of the tub during or at the completion of a
cycle. It may be hot.
SAVE THESE INSTRUCTIONS
3

USING YOUR DISHWASHER
Hot Waterfresh detergent and store it in a cool, dry place (not
under the .kitchen sink).
For proper performance, hot water is necessary. For
best cleaning and drying results, set your water heater Amount to Use
to deliver 140°F (60°C) water to the dishwasher. If, for
any reason, the temperature of the water entering the The amount of detergent to use depends on the water
dishwasher is below 140°F, select the option (if hardness (measured in grains per gallon-gpg) and the
available) to have your dishwasher heat the water, amount of soil on the dishes. Generally detergent
amounts should be increased for harder water and
To check water temperature, turn on the hot water heavier soil.
faucet nearest the dishwasher. Let the water run into a
glass until it is as hot as possible, then check with a A basic guideline is one teaspoon of detergent for each
candy or meat thermometer. If the temperature at the grain of water hardness (gpg). Use a minimum of
faucet is below 140°F, have a qualified person raise the three teaspoons (one tablespoon) in soft water.*
water heater thermostat setting. If the water hardness is 15 grains or harder, it will be
Helpful hints: virtually impossible to get good results with any
dishwasher. The only solution is a mechanical water
•If outside temperatures are unusually low, or if your softener to improve water quality.
water travels a long distance from the water heater
to the dishwasher, you may need to increase your Adding Detergent
water heater's thermostat. There are two detergent dispensers on the inside door
• If you have not used hot water for some time, the of your dishwasher. Longer cycles have two washes
water in the pipes will be cold. Turn on the hot and need detergent in both cups, while shorter cycles
water faucet at the sink and allow it to run until the
water is hot. Then start the dishwasher, have only one wash and need detergent placed in the
covered cup.
• If you've recently done laundry or run hot water for After adding detergent to the Main Wash cup always
showers, give your water heater time to recover
before operating the dishwasher, snap the lid closed. Detergent placed in the Pre°Wash
cup (open cup) will be dispensed immediately.
Detergent Refer to the Detergent Usage Guide below for
detergent amounts and placement for each cycle. Your
Use only powder or liquid detergents specifically dishwasher may not feature all the cycleslisted.
made for use in automatic dishwashers. Other types
(laundry, hand soap, etc.) will cause oversudsing. Use
Detergent Usage Guide (powder orliquid)
SOFT WATER MEDIUM WATER HARD WATER
(0-3 grains hardness) (3-7 grains) (7-12 grains)
CYCLES Main Cup Open Cup Main Cup Open Cup Main Cup Open Cup
SUPER SCRUB
NORMAL WASH 1 Tbsp. 1 Tbsp. 2-3 Tbsp. 2-3 Tbsp. 3-4 Tbsp. 3-4 Tbsp.
ENERGY SAVER minimum minimum (2nd Line) (2nd Line) (3rd Line) (3rd Line)
CHINA/CRYSTAL
SHORT WASH 1 Tbsp. None 2-3 Tbsp. None 3-4 Tbsp. None
minimum (2nd Line) (3rd Line)
RINSE & HOLD Use no detergent Use no detergent Use no detergent
*Note: When using ultra dishwashing detergents, use the amount recommended on the package.
4

Rinse Aid Loading the Dishwasher
Using a rinse aid makes water flow off the dishes Helpful Hints:Always load items on the racks so
better. This lessens water spotting and filming and they are separated and face the center to insure the
improves drying. For best dishwashing performance, water spray will reach the soiled surfaces. Do not
using a rinse aid is recommended, allow items to extend out of the racks.
Rinse aids come in either solid or liquid form. When Make sure the movement of the upper and lower
using a solid rinse aid such as Jet Dry, fasten it to the spray arms is not blocked by items hanging below the
back right corner of the lower rack. Purchase new lower rack or tall articles in the upper rack. Do not
rinse aid when the solid material dissolves and the block the center area of the lower rack. A center wash
container is empty, tower extends through this area to improve cleaning.
When using a liquid form, the rinse aid dispenser Insure the free flow of water to the detergent cups by
(Select Models) automatically releases a measured not blocking with large items.
amount of rinse aid into the final rinse. On the following pages are illustrations showing
To fill, turn the dispenser cap counterclockwise to various loading possibilities.
open. Remove the cap and pour the liquid rinse aid
into the opening. Depending on how often the Adding a Forgotten Item:
dishwasher is used, it should last about three months.
The level of the rinse aid should be checked For best cleaning, the forgotten item(s) should be
added early in the cycle.
periodically. An 'E' appearing in the bottom of the
reservoir indicates the dispenser is empty and needs 1. Unlatch the door and wait until the sound of the
to be refilled, circulating water stops.
Prenarinn the Dishes 2. Open the door and add the item(s).
3. Pause before latching the door. The cycle will
If this is your first dishwasher, or if you're replacing a continue at the point it was interrupted.
much older model, you may wonder how much
preparation your dishes need. Actually very little. Pre-
rinsing of normal food soils is not necessary. With
common sense and a little practice, you'll soon know
what foods to remove. Here are some guidelines:
1. Scrape off bones, skins, toothpicks and other hard
or large food solids. Remove excessive quantities of
oil or grease.
2. Remove large quantities of any food. Your
dishwasher has a built-in soft food disposer that
chops soft food bits and flushes them away. It can
handle small amounts of soft foods, but large
amounts will be difficult to handle. You may hear
chopping noises during the cycle. This is normal.
3. For burned-on soil, it may be necessary to pre-soak
or lightly scour the item before loading. Remember
to use the Rinse & Hold cycle (Select Models) for
small "holding" loads.
4. Since certain foods such as mustard, mayonnaise,
vinegar, lemon juice and other acidic foods can
cause discoloration on stainless steel, it is
recommended to rinse these soils off susceptible
flatware.

UpperRack LowerRack
The upper rack is designed to hold glasses, cups, small Large dinner plates and other dishes may be placed in
plates, bowls, etc. any convenient location in the lower rack with soiled
Bowls fit securely in the back right half of the top rack. surfaces facing the center. The back half of the lower
rack is designed to accommodate either large dinner
Small plates, such as salad plates, can be loaded in plates or two parallel rows of smaller plates. When
front of the bowls, facing the center. Glasses and cups loading large dinner plates, use the wide tine spacing
of varying sizes can be loaded in the center and left
side. If additional space is needed for loading small to center the plates.
plates, the center left set of rack tines can also be used. The lower rack is also a good place to load large or tall
items such as bakeware and serving platters or bowls.
When loading glassware, leave a small space between The back left side of the lower rack has an area
each piece so they do not touch each other during the without tines and is suited for wide items (muffin tins,
wash cycle. Do not place glasses over the tines. casserole dishes, etc.)
Instead, rest them against the side of the rack or tines. Small items such as plates, saucers or shallow bowls
may be loaded in the elevated area behind the wash
tower.
G

Utensil Tray (Select Models) Press down on the thumb release. Lift the connector
up onto the faucet and release your thumb pressure so
The removable utensil tray sits on top of the upper the connector is held firmly in place.
rack and holds long, awkward items such as spatulas,
serving spoons, knives, etc. When using the tray, be Turn the hot water faucet on full force.
sure items do not block the upper wash arm. Be sure the sink drain is open so that water from the
dishwasher will drain properly.
FlatwarePull the electric cord from the back of the dishwasher
Put flatware in the removable silverware basket by and plug it into a properly grounded electrical outlet.
mixing knives, forks and spoons. To prevent them
from nesting together, place some handles up and Follow the operating suggestions listed on the cover of
some down. However, sharp or pointed items should this book.
always be loaded with the handles up. _ ......
I! t
Pressure
Release
Button
_N_ To disconnect the dishwasher:
Turn the hot water faucet off.
Press the water release button to release any water
pressure.
Press down on the thumb release and remove the
connector from the faucet.
Convertible DishwasherReplace the connectorinto the recess on the back of
Connection the dishwasher.
Turn on the hot water faucet and allow the water to
run until it is hot. Then, shut off the water faucet.
Pull the faucet connector from the recess in the back of
the dishwasher as shown.

WHAT CAN AND CANNOT BE WASHED
Remember: It is the user's responsibility to determine if the item should be washed in a dishwasher.
Usually
Material Safe Exceptions (not safe) Special Instructions
Aluminum YES Some colored anodized Some darkening or spotting possible.
aluminum can fade. Remove by scouring with soap-filled
steel wool pads.
China/YES Antique, metal-trimmed, hand- If in doubt, check with the
Stoneware painted or over-the-glaze patterns manufacturer. Or test wash one piece
fade. ,daily for at least a month. Compare
Gold leaf will discolor, with the rest of the set.
Crystal YES Antique, metal-trimmed or hand- Load securely to prevent movement.
painted patterns fade. Check manufacturer's instructions for
Gold leaf will discolor, your crystal.
Non-dishware NO Do not wash in dishwasher. Damage
items--such as to dishwasher and discoloration or
electronic air cleaner staining of dishwasher may result.
filters, furnace filters,
paint brushes, etc.
Glass YES Milk Glass may yellow.
Iron NO Iron will rust.
Pewter NO Pewter tarnishes.
Plastics YES If it doesn't say DISHWASHER SAFE,
test one piece before dishwashing an
entire set.
Stainless steel YES Rinse if not washing immediately.
Salty or acidic foods can stain if left on.
Sterling Silver and YES Don't put in same silverware Rinse if not washing immediately.
Silver plate basket with stainless steel. Salty or acidic foods can stain if left
Contact between metals can on. Dry detergent can cause difficult-
damage silver, to-remove black spots. Place in back
Don't wash copper utensils in the section of silverware basket to avoid
same load. Silver may get a exposure to detergent from the
brown film. detergent cup.
Adhesive used to attach some
hollow-handle knives can loosen.
Non-stick coatings YES
Tin NO Tin can rust.
Wood NO Wood can warp, crack or lose its
finish with any type of washing.

CARE AND CLEANING each cycle with a drain for touch control models,
press the Drain/Off pad. (See page 1.)
Clean the control panel with a lightly dampened • Disconnect the electrical supply and prop open the
cloth. Dry thoroughly. Do not use abrasives or sharp door.
objects on the panel. They can damage it.
To care for a wood top ona convertible dishwasher,
first wipe the top with a damp cloth to remove surface CHANGING COLOR
dust, then dry. Next, saturate a cloth with mineral oil
and apply a heavy coat to the wood top. Let it stand PANELS
overnight. The next day apply a thin coat of mineral
oil and rub with a soft dry cloth. Repeat these steps If you are redecorating, you can change your
every few months to maintain the appearance of the dishwasher's front panels to match or blend with your
wood top. new colors.
Two panels are held in place by the door trim and the
The inside normally takes care of itself.Occasionally trim on the panel below the door. Each side of each
check the tub bottom forany large pieces which may panel is adifferent color. Oryoucan paint a panel
have collected. Periodically clean the bottom edge of with the color of your own choice.
the doorliner ifanyspillsorfood soils arenoticed
after a cycle. How to change the door panel inserts:
To remove any odor,try one of the following: I. Take out the three trim screws oneither side of the
dishwasherdoor. Removethe side trim.
1. Put baking sodainboth cups. Select the Normal2. Slide out both of the insertpanels at once.
cycle andlet the watercirculate forabout 10
minutes. Stopthe dishwasherby unlatching the 3. Put the panel with the coloryou want in front.
door. Let itsit overnight. Then restartthe (Handle the panels carefully. Edges may be sharp.)
dishwasherby latching the doorand letting it 4. Replace the side trim and screws.
completethe cycle. How to change the lower panel inserts:
2. Selectthe Normal cycleand let the dishwasherfill
with water. Thenopenthe door and pour 1/4cup of 1. Removethe four panel attachment screws. (Two
chlorine bleach into the bottom of the dishwasher,abovepanel,two below.)
Latch the door andletitcompletethe cycle. 2. Removethe entirepanel.
3. Tryusingalemonscent detergent and/or rinseaid 3. Take out the three screwsand removethe toptrim.
to helpperiodically freshen a dishwasherinterior.
It is also recommended that youswitch detergents 4. Slide out both of the insert panels atonce.
if you notice a strong chemical or chlorine odor 5. Replace the panels with the coloryou want in front.
from your present detergent. 6. Replace the toptrimandscrews.
4. Runthe dishwasher more frequently. Use the Rinse 7. Replace the entirepanel and four attachment
&Hold cycle(if available)to removeany food soil
thatmay cause an odor. screws.
Color insertpanels for thedoor andpanelcan be
STORING YOUR replaced by 1/4" thick wood inserts to match your
kitchen cabinets. Get them from your nearest cabinet
DISHWASHER dealer.
If your dishwasher will be in storage or an unheated Dimensions for 1/4'*wood inserts:
area exposed to freezing temperatures, please follow Door Panel: 181/4'' H x 231/2'' W.
these recommendations: Lower Panel: 411/16''H x 231/2'' W.
• Clean the dishwasher inside and out as explained in
the Care and Cleaning section. (Also clean the door Note: Do not operate the dishwasher while changing
gasket), the panels or when the lower access panel is
removed. When installing wood panels, you may
•Operate the drain portion twice to ensure most of need to check with your dealer for advice and/or
the water will be removed. Most dishwashers begin assistance.

THE PROBLEM SOLVER
Check the Problem Solver Chart if you have a problem. It may be something minor you can correct. Simply locate
your problem on the chart and follow the suggested remedy.
PROBLEM POSSIBLE CAUSE AND REMEDY
DISHWASHER •A fuse in your home may be blown or the circuit breaker tripped. Replace fuse or
WON'T RUN reset circuit breaker. Remove any other appliances from the circuit.
•Be sure the door is tightly closed and latched.
UNUSUAL NOISE • Make sure everything is securely placed in the dishwasher. Water may cause
utensils to rattle,
• Something small may have dropped fromthe rack.
• Wash arm may be hitting an item when rotating. Load the items so nothing blocks
the wash arms.
• Chopping noises may be heard during the cycle due to the built-in disposer. This is
normal.
DISHES DON'T DRY • Check the rinse aid dispenser to see that it's not empty. (See page 5.)
• Select the Drying Heat option.
• Make sure the inlet water temperature is correct. (See page 4.)
• Check for improper loading. Dishes shouldn't nest together. Avoid overloading.
• Unload the bottom rack first. Waterfrom dishes in the top rack may be spilling into
the bottom rack.
• Plastic items have a porous surface and tend to hold water. Towel drying may be
required.
• Glasses, cups, etc., with concave bottoms will hold water.
UNCLEAN DISHES • Check the inlet water temperature. 140°F water is recommended. (To test, see page 4.)
AND FLATWARE • Select the Water Heat option if available.
• Use the amount of detergent recommended for your water hardness and be sure it
is placed in the detergent dispenser properly. (See page 4.)
• Select the proper cycle for soil level of dishload. (See page 1.)
• Load the rack correctly. (See pages5-7.)
DETERGENT LEFT IN • The dispenser cover may not be opening or may be blocked by improperly loaded
DISPENSER CUPS items. Move any dishes that may be blocking the detergent cup. If you used a
powder detergent, open the cup and remove any caked-on detergent. If the cup still
doesn't open automatically, call for service.
• Detergent may be old. If the powder detergent is hard or caked in the box, throw it
away. Be sure to store detergent in a cool, dry place.
• The detergent may not be working well. Try another brand.
Continued on next page
10
