COUNTERTOP DISHWASHER
User Manual
MODEL MCSCD6W3

11
14
20
23
25

IMPORTANT SAFEGUARDS
READ THIS MANUAL AND ALL INSTRUCTIONS BEFORE USE.
1. Do not use this appliance for other than its intended use.
2. Do not unplug your appliance by pulling on the power cord. Always grasp the plug !rmly and
pull it straight out from the outlet.
3. Do not operate your appliance in the presence of explosive fumes.
4. Do not add or mix any "ammable or explosive substances to wash.
5. Do not operate your appliance when parts are missing or broken.
6. Do not abuse, sit on or stand on the door or the dishwasher rack.
7. Do not use this appliance for commerical dishwashing purposes.
8. Do not wash plas#c items unless they are marked dishwasher safe or the equivalent. For
plas#c items without such markings, check the manufacturers recommenda#ons.
9. Do not operate this appliance unless all enclosure panels are properly in place.
10. Do not tamper with controls.
11. Do not touch the HEATING ELEMENT during or a$er immediate use.
12. Do not allow children to play in or on the appliance. To reduce risk of injury, close
supervision and observa#on of children is needed around the dishwasher.
13. Do not repair or replace any part of the appliance or a%empt any servicing unless speci!cally
recommended in the user repair instruc#ons that you understand and the necessary skills to
carry out such dishwasher servicing.
14. Do not use this dishwasher outdoors.
15. Do not use extension cords or adapters to connect the unit to any electrical power source.
-PAGE 2-

16. Use only detergents or we!ng agents recommended for use in a dishwasher and keep them
out of the reach of children.
17. When loading items to be washed:
A) Locate sharp items to prevent any damage to the door seal.
B) Load sharp knives with the handles up to reduce the risk of any personal injuries.
18. This appliance must be properly installed in accordance with the installa"on instruc"ons
before its use.
19. This appliance must be connected to a proper electrical outlet with the correct electrical
supply.
20. Proper grounding must be ensured to reduce the risk of shock and #re. DO NOT CUT OR
REMOVE THE GROUNDING PLUG. If you do not have a three-prong electric receptacle outlet
in the wall, have a cer"#ed electrician install the proper receptacle. The wall receptacle
MUST be properly grounded.
21. To reduce the risk of injury, immediately replace worn power cords, loose plugs and/or
power outlets.
22. Disconnect electrical power and water intake hose to dishwasher before cleaning and/or
servicing.
23. If your old appliance is not being used, we recommend that you store the unit out of the
reach of children or remove its door. This will reduce the risk of injury to children.
24. Hydrogen gas may be produced if the water heater has not been used in more than two
weeks. This could be explosive and can explode under certain circumstances. If this is the
case, before using this appliance, turn on all the hot faucets and let the hot water run for a
few minutes. This will let the trapped hydrogen escape. During this process do not turn on
an electric appliance, smoke, light a match or lighter, or use a $ame to avoid serious injury,
due to the highly $ammable nature of hydrogen gas.
-PAGE 3-

ELECTRICAL REQUIREMENTS
GROUNDING INSTRUCTIONS
This appliance must be plugged into at least a 15 AMP 120 Volt 60 Hz grounded outlet. This
appliance must be grounded. It is equipped with a 3-prong power cord with a grounding
plug. The plug must be plugged into an outlet that is properly installed and grounded.
Improper use of the grounded wire can result in the risk of electric shock.
Consult a quali!ed electrician if necessary. Do not a"empt to tamper or modify the plug in
any form.
Avoid the use of an extension cord because it may overheat and cause a risk of !re.
However, if it is necessary to use an extension cord:
A) Use only a 3-prong extension cord with a 3-prong grounding plug.
B) The marked ra"ng of the extension cord must be equal to or
greater than the ra"ng of this appliance.
C) The extension cord should be posi"oned such that it does not
drape over the counter or tabletop where it can be pulled by
children or tripped over.
ATTEMPTING ANY MAINTENANCE OR CLEANING
To minimize the possibility of electric shock, unplug this appliance from the power supply or
disconnect at the household electrical panel by removing the fuse or switching o# the circuit
breaker before a$emp"ng any maintenance or cleaning.
NOTE: Pressing the Power ON/OFF bu"on to an OFF posi#on does NOT disconnect the
appliance from the power supply.
Do not, under any
circumstances, cut,
remove, or bypass the
grounding prong.
Wall outlet with a
3-prong receptacle.
Power supply cord with
3-prong grounding plug.
WARNING
!WARNING !
-PAGE 4-

SPECIFICATIONS
PARTS AND FEATURES
CONTROL PANEL
FRONT VIEW
1) Power Light (ON/OFF) 5) Start/Reset Bu!on
2) Power Bu!on (ON/OFF) 6) Delay Feature
3) Wash Cycle Selector 7) Intake Warning Light
4) Delayed Start Bu!on 8) Rinse Aid Warning Light
1
23 4 5
6
7
8
-PAGE 5-

PARTS AND FEATURES
INSIDE VIEW BACK VIEW
฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀-PAGE 6-

INSTALLATION INSTRUCTIONS
UNPACKING AND PROPER PLACEMENT
UNPACKING
1. Inspect and remove all packing materials. This includes the foam
and any adhesive tape both inside and outside of the unit.
2. Inspect and remove any remains of packaging, tape, or printed
materials before powering on your appliance.
3. Check to see if you have all of the following parts:
Quick Faucet Adapter (1)
Instruc!on Manual (1)
Measuring Cup for Powdered Detergent (1)
Measuring Spoon for Liquid Rinse Aid (1)
Clip on Basket for 3-in-1 Tablets (1)
Rack (1)
Cutlery/Silverware Basket (1)
4. Clean the interior surface with lukewarm water using a so" cloth.
PROPER PLACEMENT
1. First determine the best countertop surface loca!on for your new
dishwasher. It must be close to a 120 Volt (15 Amp) outlet and a
sink with water supply and drainage system.
2. The minimum height clearance required to install your dishwasher
on a countertop surface with overhead cupboards or kitchen
cabinets is 17.8. This countertop dishwasher is 17.2 in height.
(Reference the diagram on the next page for more informa!on)
-PAGE 7-

THE QUICK FAUCET ADAPTER EASILY CONNECTS TO THE SINK FAUCET.
A) First remove aerator from your faucet nozzle and a!ach the quick connect threaded
adapter to the faucet. The quick connect faucet adapter allows easy snap-on/snap-
o" connec#on to standard (7/8 diameter) faucets.
B) Connect the dishwasher Quick Connect Faucet Adapter to the faucet $rst to ensure
the hose length $ts the dishwashers selected loca#on. Both hose and $%ngs must
be connected to the back of the dishwasher. The plas#c water intake and drain
$%ngs are unique to each design and are made to easily $t the dishwasher.
A hose that a!aches to a sink spray can burst if it is installed on the same
water line as the dishwasher. If your sink has a sink spray, it is recommended that the hose
be disconnected and the hole plugged.
C) Water Intake Hose: Connect to the rear of the dishwasher using the large, 4-corner
shaped wing nut.
D) Drain Hose: Connect to the rear of the dishwasher. It is suggested you use pliers to
#ghten but DO NOT over #ghten.
1) Drain Port Connec#on 5) Faucet Adapter 9) Locking Collar
2) Quick Connect Connec#on 6) Faucet Washer 10) Inlet Hose Connec#on
3) Inlet Port Connec#on 7) Pressure Relief Value 11) Drain Hose Connec#on
4) Quick Connect Connec#on 8) Faucet Adapter Connec#on
QUICK FAUCET ADAPTER CONNECTION
WARNING
!WARNING !
ghten but DO NOT over #ghten.
or
t
Co
nn
ec
#o
n
5
)
Fa
uc
et
A
da
pt
er
9)
L
oc
ki
ng
C
ol
la
r
-PAGE 9-

E) With both hoses connected, make sure you can plug the power cord into a 120 volt,
grounded AC outlet, then turn the dishwasher so it is facing forward.
F) Red Pressure Release Bu!on: This red bu!on, located on the Quick Release Faucet
Adapter, is used to release the water line pressure. When you "rst connect to the
water faucet, you can press the red bu!on to check the water is at the desired
temperature or to use the faucet normally without removing the whole Quick
Release Faucet Adapter.
G) With all the "#ngs connected, open the water tap to test to make sure there are no
leaks. Connect the A/C power cord and use the dishwasher as outlined in the
manual.
H) When "nished using the dishwasher, you need to close the water supply at the tap
and disconnect the power supply cord.
The water intake hose is now pressurized. Press the Red Pressure Release
Bu!on on the Quick Release Faucet Adapter, which will depressurize the water intake hose to
easily remove without squir"ng water, which can be very hot and cause scalding or personal
injury. The Quick Release Faucet Adapter should then be disconnected from the faucet and
stored for its next use.
CAUTION: Do not let children disconnect the dishwasher. Close supervision of children is
always important around the appliance.
F
auce
t
Ad
ap
te
r.
Faucet Adapte
r.
This part can be unscrewed
into two parts to adjust for di!erent
faucet sizes.
This end connects to
the sink faucet.
Red Pressure
Release Bu"on
WARNING
#WARNING #
Red Pressure
Release Bu!on
Water Hose
Drain Hose
-PAGE 10-

RECOMMENDATIONS FOR USE
WATER, PRESSURE, AND TEMPERATURE
DISHWASHING PREPARATIONS
For the best opera!ng results, the incoming water should be HOT and the pressure should
be between 0.03~1.00 Mpa. Incoming water supply for the dishwasher is controlled by a
low water switch applica!on, in the event your household water ceases, the dishwasher
will stop. We only recommend using HOT water for maximum e"ciency and op!mal results.
HOW IT WORKS:
Your dishwasher cleans by spraying a mixture of clean HOT water and detergent (under
pressure) against the soiled surface of your dishes. The water is pumped through a rota!ng
spray arm, drained through a #lter removing food and soiled par!cles, then pumped back
through the spray arm.
Soiled water is pumped out and replaced with clean water at the end of each cycle. For the
best cleaning results, the water temperature must be at least 120$F. To prevent damage to
your dishwasher, the temperature of the incoming water supply should not exceed 150$F
NOTE: Hard Water condi!ons will adversely a"ect the performance of your dishwashers
washing ability. Hard water condi!ons will also contribute to Lime (white #lm substance)
deposits, and/or Scaling on the stainless steel surface of the dishwasher tub and Heater
Element located in the sump underneath the removable #lter screen. To assist in minimizing
these condi!ons, it is recommended to periodically operate/rinse the inside of an empty
dishwasher using one cup of white vinegar (at least once a week) or special cleaning
products that clean calcium and lime deposits.
PREPARING TO WASH DISHES:
For best results, rinse dishware and perform the following steps before loading your dishes:
A) Discard any big chunks of food from the plate.
B) Remove any oils and grease.
C) Remove s!cky food residues and loosen burned-on residues.
D) Empty liquids such as soups and beverages from glassware and cups.
-PAGE 11-

LOADING DISHWASHER
TIPS TO AVOID STAINS AND FILMS:
The following sugges!ons are recommended to prevent stains and "lms from forming on
dishware and utensil items:
A) You must rinse all dishware, silverware, glassware, and food containers immediately a#er
use. Some citric based food products, co$ee, tea, and iron deposits in water can cause yellow
or brown "lming on the inside surfaces when le# on for long dura!ons.
B) Rinse o$ acid-based liquids, such as vinegar or lemon juice immediately. This may cause
discolora!on over !me to your plates, food containers, or internal cabinets.
C) Always check the manufacturers recommenda!ons prior to washing items.
D) You must check your water hardness to see whether you need to use more or less detergent
when washing. If your water is extremely hard then it may be causing stains on items. You
may need to use a water so#ener.
E) Do not overload the dishwasher.
F) Avoid improper loading by nes!ng plates together.
G) Do not use too li%le detergent.
H) Do not use old or damp powered detergent.
I) Make sure the water temperature is at the recommended level to wash your dishwares.
J) Do not load aluminum utensils improperly. Aluminum utensils can cause gray or black marks
to porcelain utensils if they touch during the washing cycle.
LOADING YOUR DISHWASHER:
The dishwasher is designed for a standard 6 place se&ng.
NOTE: The standard plate size is 10. For ease of loading/unloading larger sized dinner plates from
the dish rack, it may be necessary to (temporarily) remove the cutlery basket. When loading and
unloading is complete, a!ach the cutlery basket to its original posi"on.
CUTLERY BASKET:
Silverware should be placed in the basket with handles at the bo%om. If the rack has side
baskets, the spoon should be loaded individually into the correct slots. Excep!onally long utensils
should be placed in the horizontal posi!on on the cup shelf.
Do not let any item extend through the bo!om of the rack or cutlery basket.
Load sharp utensils with the sharp end pointed downward.
WARNING
!WARNING !
WARNING
!WARNING !
Do not let any items extend
through the basket.
ms extend
et.
-PAGE 12-

HOW TO LOAD ITEMS:
A) Locate sharp items so that they are not likely to damage the door seal.
B) Do not load plas!c items unless they are marked Dishwasher Safe or the
equivalent. For plas!c items without such markings, check the manufacturers
recommenda!ons.
C) Cups, glasswares, and bowls must have their openings facing downwards in the
dishwasher rack.
D) Do not load glasswares over the dish rack pins. Glasses loaded over dish rack pins
are not properly supported and are likely to get damaged. Certain types of glasses
can become dull a"er a large number of washes.
E) Arrange all items with recessed or curved sec!ons on a slant to drain water away
from the items.
F) Do not nest utensils together or overload the basket. They need to be evenly
distributed. Make sure any cutlery items have not fallen through the basket, which
can stop the spray arm from rota!ng.
G) Items with wooden or bone handles, and items joined together with glue are
unsuitable for the dishwasher, as they cannot withstand the hot water used.
H) Place silverware with handles facing down, with the excep!on of knives and other
poten!ally dangerous utensils which should have handles facing up. Do not load
silverware with steel construc!ons that are subject to rus!ng.
I) Do not load pewter or copper items, crystal glassware, wooden pla#ers, or items
made from synthe!c $bers.
J) Silver and aluminium parts have a tendency to discolor a"er washing.
K) Glazed pa#erns may fade over !me if they are frequently machine washed.
OPTIMUM CAPACITY:
1. Cups 6. Oval Pla!er
2. Serving Bowls 7. Dinner Plates
3. Glassware 8. Bread/Bu!er Plates
4. Saucers 9. Cutlery Basket
5. Fruit Bowls
Dishwasher Rack
-PAGE 13-

OPERATIONAL INSTRUCTIONS
DISHWASHING DETERGENT AND RINSE AID
NOTE: Use ONLY detergent speci!cally made for automa"c dishwashers. Check the product
packaging to be certain. Keep your detergent fresh and dry. Do not put powder detergent
into the dispenser un"l you are ready to wash dishes.
The amount of dishwashing detergent used is dependent on the condi!on of your
household water supply. Extra detergent is required for hard water condi!ons, while less
detergent is needed for so" water condi!ons. Your water u!li!es company should be able
to tell you the condi!on of your household water supply.
OPERATING YOUR DISHWASHER:
1) Ensure that all electrical, water, and drain connec!ons have been installed
correctly before proceeding.
2) Load the dishwasher (see the Loading Dishwasher sec!on).
3) Make sure that the water supply is turned on to full pressure.
4) Add the appropriate amount of dishwasher detergent to the dispenser
(see Dishwashing Detergent sec!on).
5) Close the door and ensure that the door latch has engaged.
6) Turn the dishwasher ON by pressing the ON/OFF bu#on.
7) Select the appropriate wash cycle/program (see Wash Cycle Sequence
sec!on).
8) Press the Start/Reset bu#on. The indiciator lights will $ash intermi#ently to
indicate the dishwasher is in RUN mode.
NOTE: When you press the Start/Reset bu#on to pause the unit during washing, the indica-
tor lights will stop blinking and the dishwasher will stop working un"l the Start/Reset bu#on
is pressed again.
ADDITIONAL RECOMMENDATIONS:
1) Consider purchasing utensils that are labeled dishwasher safe.
2) Use mild detergents that are labeled for dishwasher use. If necessary seek
further informa!on from detergent manufacturers.
3) For par!cular items, select a wash cycle with a low temperature se%ng.
4) To prevent any damage, do not take glassware and cutlery immediately out of
the dishwasher a"er the wash cycle has ended.
5) Excep!onally small items should not be washed in the dishwasher.
-PAGE 14-

For heavily soiled loads, use the HEAVY, NORMAL WASH cycle. Fill one or both of the interior
cups, depending on the hardness of your water, as well as the open cup on the dispenser lid.
For an easy guideline, use the informa!on in the table below to determine the amount of
automa!c dishwasher detergent to place into the dispenser:
To open the detergent storage cover, press the bu"on and the cover will #ip open. A$er you
%nish loading the detergent, securely close the cover. (See Figure 1 Below)
USING A RINSING AID AGENT
Using a specially formulated rinsing agent will help rinse away food and detergent residues
that can be le$ behind on your dishes during the %nal rinse. This helps to prevent unslightly
spots, %lms on dishes and glassware, and reduce drying !me. When used regularly, a rinse
agent will automa!cally provide you with cleaner dishes every !me you wash them. The
rinse aid will automa!cally be added during the %nal rinse, ensuring thorough rinsing, and
spot or streak free drying.
Always use a branded rinse aid for dishwashers, and never dilute or %ll the rinse aid
dispenser with any other substances (e.g. detergent), as it will damage the appliance.
RINSE AID SETTING
The amount of rinse agent released into the %nal wash can be adjusted. The dispenser has
four se&ngs (factory se&ng is at the midpoint; the recommended se&ng). If there are rings
of hard water (e.g. calcium) spots on dishes, try a higher se&ng.
TO ADJUST THE RINSE AID SETTING
Remove the dispenser cap, and then turn the adjuster counterclockwise to increase the
amount of rinse agent.
LOW RINSE AID LEVEL INDICATOR
As the rinse aid diminishes, the size of the black dot on the rinse aid level indicator will
change un!l the black do no longer appears in the rinse aid level indicator.
Number of Place Se&ngs Loaded Dishwasher Detergent Recommenda!ons
Fill compartment marked A (15g or 0.53 oz)
Fill compartment marked B (25g or 0.88 oz)
Less than 4
4 to 6
FIG. 1 FIG. 2
To open the detergent storage cover, press the bu"on and the cover will #ip open. A$er you
%nish loading the detergent, securely close the cover. (See Figure 1 Below)
USING A RINSING AID AGENT
Using a specially formulated rinsing agent will help rinse away food and detergent residues
FIG
FIG
FIG
FIG
FIG
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
. 1
F
FF
F
IG.
2
2
2
2
2
2
2
PUSH LATCH TO OPEN
AB
POWDER
TABLETS
DETERGENT TYPES:
FIG. 1
-PAGE 15-

FILLING THE RINSE AID DISPENSER
The rinsing agent dispenser holds 3.5 oz. of rinsing agent. Under normal condi!ons, this will
last approximately one month. Keep it full, but do not over"ll the dispenser. The dispenser is
located inside the door next to the washing detergent dispenser (See Figure 2).
1) To "ll the dispenser, turn the cap to the le# and li# it out.
2) Add rinse agent un!l the indicator level turns completely black.
3) Replace the dispenser cap and close the dishwasher door.
FIG. 2
CHECKING THE WATER TEMPERATURE
For the most e!ec"ve cleaning and to prevent damage to the dishware being cleaned, the
hot water supplied to the dishwasher should be at a temperature of at least 120#F (49#C)
and no more than 150#F (66#C).
-PAGE 16-

WASH CYCLE SEQUENCES
NOTE: Wash cycle !mes listed here are for reference use only as they can change based on
condi!ons such as inlet water temperature, whether the dishwasher is par!ally or fully
loaded, and the hea!ng element power ra!ng.
Cycle Water (Approx.) Time (Approx.) Sequence
Heavy
Normal
Light
Glass
Speed
Rinse
3.83 Gallons
3.17 Gallons
3.17 Gallons
2.56 Gallons
3.17 Gallons
1.32 Gallons
100 Minutes
85 Minutes
75 Minutes
70 Minutes
45 Minutes
24 Minutes
Pre-Wash
Pre-Wash
Pre-Wash
Pre-Wash
Wash
Pre-Wash
Pre-Wash
Pre-Wash
Pre-Wash
Pre-Wash
Wash
Wash
Wash
Pre-Wash
Wash
Wash
Rinse
Rinse
Rinse
Rinse
Rinse
Rinse
Rinse
Rinse
Rinse
Rinse
Dry
Dry
Dry
Dry
-PAGE 17-

USING THE DELAY FEATURE
PAUSING THE WASH CYCLE SEQUENCE
The start of the dishwasher can be delayed between 1 and 24 hours, using one hour increments.
To u!lize this feature:
1) Press ON/OFF bu"on to ON posi!on
2) Press PROGRAM bu"on
3) Press DELAY bu"on once for each hour of delay
(e.g. press bu"on 3 !mes to delay start by 3 hours)
To cancel the delay feature:
1) Press ON/OFF bu"on to OFF posi!on.
In order to make any changes to the selected wash cycle sequence, load addi!onal items, or
remove previously loaded items, the dishwasher must be put into PAUSE mode. The
dishwasher can be put into PAUSE mode at any !me during the wash cycle.
To temporarily pause the washing process:
1) Press and hold the START/RESET bu"on for approximately 3 seconds to cancel
the exis!ng program mode.
2) Make the necessary changes to the wash cycle sequence selec!on or
add/remove items from the dishwasher.
3) Ensure that the door is closed and the latch is fully engaged.
4) Press the START/RESET bu"on once.
5) The dishwasher will immediately resume opera!on using the most recently
selected wash cycle sequence.
NOTE: The dishwasher will automa!cally go into PAUSE mode if the door is opened. The door must
be closed and the latch engaged for the dishwasher to resume opera!on. Always use the above
steps.
-PAGE 18-

CHANGING THE WASH CYCLE SEQUENCE
END OF THE WASH CYCLE PROCEDURE
If you need to change the selected wash cycle sequence at any !me during the washing process,
then follow these steps:
1) Press and hold the START/RESET bu"on for approximately 3 seconds. (The
START/RESET indicator light turn on and the unit is now in PAUSE mode).
2) Select the desired wash cycle sequence by pressing the program bu"on.
3) Press the START/RESET bu"on again to resume opera!on using the newly
selected wash cycle sequence.
NOTE: If you change the wash cycle sequence a!er the detergent has been dispensed, or the
dishwasher has already drained the water, you will need to re"ll the detergent dispenser for the
newly elected wash cycle sequence, accordingly.
Once the dishwasher has completed the selected wash cycle sequence, a buzzer will sound for 8
seconds, indica!ng the end of they wash cycle.
1) Shut o# the water supply.
2) Turn the dishwasher OFF by pressing the ON/OFF bu"on.
3) Open the door ajar slowly to allow residual steam to escape.
4) Wait a few minutes (approximately 15 minutes) before unloading the dishwasher as
the dishes and cutlery will be hot. This also aids in the drying process.
5) The interior of the dishwasher will be wet, this is normal and will dry naturally.
It is dangerous to open the door when the dishwasher is in opera#on, as the hot
water may cause scalding or injury.
WARNING
!WARNING !
-PAGE 19-
