Magic Chef MCBR445B1 User manual

REFRIGERATOR
INSTRUCTION MANUAL
Model No.: MCBR445W1
MCBR445B1
MCBR445S1
zTo ensure proper use of this appliance and your safety, please read the following
instructions completely before operating this appliance.

1
TABLEOFCONTENTS
Before Putting Into Use………………………………………………………………….. 2
Tips For Energy Savings………………………………………………………………….. 2
Important Safety Instructions……………………………………………………………. 3
Name Of The Parts……………………………………………………………………….. 4
Specifications……………………………………………………………………………… 4
How To Operate:
Starting Your New Refrigerator………………………………………………….. 5
Temperature Control………………………………………………………………. 5
How To Defrost…………………………………………………………………….. 5
How To Clean……………………………………………………………………….……… 6
How To Install………………………………………………………………………….…… 6
Care And Maintenance
What To Do……………………………………………………………………….… 7
Changing The Reversible Doors………………………………………………….……… 8-9
Refrigerator Warranty……………………………………………………………………… 10

2
Before Putting Into Use
zBefore connecting the appliance to the power supply, let the unit stand upright for 4 hours,
which will reduce the possibility of the cooling system malfunctioning due to improper
handling.
zClean your unit thoroughly before putting into use. (See How to Clean)
zUse the parts diagram on page 4 to insure proper positioning of internal components.
Tips for Energy Savings
zKeep the refrigerator and freezer doors closed as much as possible, particularly in warm /
humid conditions.
zMaintain adequate ventilation around the back and sides of the unit.
zMaintain a thermostat setting of between “3” and “5” under normal use.
zAllow warm food to cool to room temperature before placing in the refrigerator or freezer.
zExcessive ice build up will increase energy consumption. Defrost the unit when ice / frost
is1/4” thick.

3
Important Safety Instructions
DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer:
zTake off the doors.
zLeave the shelves in place so that children may not easily climb inside the unit.
zThe appliance must be correctly connected to the power supply. (See: “HOW TO INSTALL”).
zDo not use an extension cord as this can negatively affect the performance of the unit.
zDo not touch the cooled surfaces while the appliance operates, especially not with wet hands,
because the skin may stick to the cold surfaces.
zDo not freeze bottled liquids such as carbonated soft drink, beer, wine, etc. Doing so can
cause glass bottles and aluminum cans to rupture.
zIf the unit fails to cool properly, dispose of spoiled food as needed.
zAll repairs should be made by a qualified service technician. Repairs made by non-qualified
personnel will void the warranty.
zDo not defrost the appliance with other electric devices (hair dryer, etc.) and never scrape the
ice or frost layer with sharp tools.
zThe rating plate is inside the appliance or outside on the rear wall.

4
NAMEOFTHEPARTS
Model No.: MCBR445W1 / MCBR445B1 / MCBR445S1
Evaporator
Drain Pan
Temperature Control Box
Shelves
Door Liner
Ice Cube Tray
Rack
Bottle Rack
Crisper
Can Dispenser
Temperature Control Dial
Defrost Button
SPECIFICATIONS
Product Description Magic Chef Refrigerator with Glass Shelves
Model No. MCBR445W1 / MCBR445B1 / MCBR445S1
Capacity 4.4 Cu. Ft.
Width Height DepthUnit Dimensions
( inches ) 19.09” 32.91” 21.38”
Net Weight ( lbs ) 66.14 ( lbs )

5
HOW TO OPERATE
Starting Your New Refrigerator
1. Clean the refrigerator thoroughly. Wipe the outside with a soft dry cloth, the interior with a
clean moist cloth.
2. Insert the power supply cord into the socket.
3. Turn the thermostat dial to “7”. Close the doors and let the refrigerator operate for 15-20
minutes.
4. Reduce the thermostat to a mid-range setting between “3” and “5” on the thermostat control.
Temperature Control
To control the internal temperature, adjust the
thermostat dial. “1” is the warmest setting. “7”
is the coldest.
The Dial may be set any place on the scale. It
does not have to be set exactly on a number.
To make ice cubes in the freezer
compartment, adjust the thermostat to the
coldest setting.
Note: Wait 3-5 minutes before restarting if you unplug the refrigerator. The unit may fail to
operate properly if restarted too quickly.
How To Defrost
Defrost the refrigerator when the frost accumulated on the evaporator is about 1/4” thick.
To defrost, simply push the defrost button. Be sure to keep the drain pan in place. Defrosting
usually takes a few hours. The refrigerator will restart automatically when defrosting ends. Empty
water from the drain pan after defrosting.
Never use a knife or other sharp metal instrument to scrape ice / frost from the inside of the
unit.
Defrost Button

6
HOWTOCLEAN
Cleaners: Never use harsh, abrasive cleaners, heavy-duty cleaners, or solvents on any surface.
Exterior: Wipe with damp, sudsy cloth, rinse and dry. For stubborn stains and for periodic
waxing, use silicon wax.
Freezer: When refrigerator needs defrosting press defrost button. Do not use sharp
instruments to scrape off ice/frost.
Refrigeration Section: Wash shelves and other removable parts in warm sudsy water, rinse and
dry. Wash interior with baking soda solution (3 tablespoons to I liter of water) or warm
sudsy water, rinse and dry.
Magnetic Door Seals: Wash with warm sudsy water.
The Finishing Touch: Replace all parts and return thermostat dial to desired setting.
HOWTOINSTALL
zInstall the refrigerator in a convenient
location away from extreme heat and cold.
Allow sufficient clearance between the
refrigerator and side wall so the door(s)
will open without obstruction. Refrigerator
is not designed for recessed installation.
zSelect a space with strong level floor.
zAllow 5 inches of space between the
refrigerator’s side and the wall.
zThe appliance must be correctly
connected to the power supply.
POWER CORD REPLACEMENT
If the refrigerator’s power cord is damaged, have it replaced by a qualified repair agent.

7
CARE AND MAINTENANCE
WHAT TO DO …
When the fridge is not in use for a prolonged period:
zRemove the plug from the outlet.
zRemove all contents from the fridge.
zDry the interior and leave the door open for a few days.
When you wish to move the fridge:
zSecure all movable parts and contents. (Package them separately if necessary.)
zTransport the fridge only in an upright position. In any other position you may damage the
compressor.
Before calling service, please follow the checklist below.
This may save you an expensive service call.
If the refrigerator is not cooling properly:
zCheck to see that the door is closing properly and the door seal is not damaged.
zCheck that the interior circulation is not obstructed by having too many goods stored. (The
fridge is overloaded)
zDid you store anything hot, without first cooling it to room temperature?
zIs there sufficient clearance around all sides and above the fridge?
If the fridge starts making any unusual noises:
zIs it wobbling? Re-level the unit and check if it now operates normally.
zHave any objects fallen behind the fridge? If so, remove them and check if operation is now
normal.
zAre any containers inside the fridge vibrating or resonating? If so, rearrange them then check
to see if operation has returned to normal.
WARNING – Improper use of the grounding plug can result in a risk of electric shock. If it is
necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade
grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The marked
rating of the extension cord should be AC 115-120V, 10A, or more. If a grounding adapter is
used, make sure the receptacle box is fully grounded.

CHANGINGTHEREVERSIBLEDOORS
CAUTION: To avoid personal injury to yourself and/or property, we recommend
someone assist you during the door reversal process.
This refrigerator has been built with the door hinges on the right. If you wish to change the opening direction, follow
the instruction below:
zUnplug the refrigerator from its electrical outlet.
zEmpty everything in the refrigerator, including shelves, food, etc.
1. Remove the hinge cover on the right top of the cabinet.
2. Remove the two screws (using a ratchet tool with a
7/16” socket) that hold the top hinge to the cabinet.
Keep these screws for later use.
3. Lift the top hinge straight up to free the pin from the
socket on the top of the door.
4. Lift the door and place it on a padded surface to prevent
scratching it.
5. Remove the plug buttons from the upper left holes as
illustrated and transfer them to the uncovered holes at
the right side. Be sure to press the plug buttons firmly
into the holes.
6. Lay the cabinet on its side down on the floor. Remove
the three screws that hold the bottom hinge to the
cabinet using a 7/16” socket. Keep these screws and
washer for later use.
8

9
7. Insert the bottom hinge at the left side using the two
screws previously removed in step 6.
NOTE: Do not tighten screws.
8. Stand the cabinet.
9. Replace the door making sure the bottom socket
enters the bottom hinge pin. Be sure washer is in
place.
10. While holding the door in the closed position, secure
the top hinge at the left side using the two screws
previously removed at the beginning in step 2. Do not
tighten the screws until the top of the door is leveled
with the top cabinet.
11. Replace the hinge cover.
12. Replace plugs.
13. Tools Required:
- 7/16” socket-ratchet.
- Putty knife or thin-blade screwdriver.

10
Refrigerator Warranty
MC Appliance Corp. warrants each new Refrigerator to be free from defects in material and
workmanship and agrees to remedy any such defect or to furnish a new part(s) (at the company’s
option) for any part(s) of the unit that has failed during the warranty period. Parts and labor expenses
are covered on this unit for a period of one year after the date of purchase. In addition, MC Appliance
Corp. warrants the compressor (parts only) to be free from defects in material and workmanship for a
period of 5 years. The consumer is responsible for all labor and transportation expenses related to the
diagnosis and replacement of the compressor after the initial one- year warranty has expired. If in the
event the unit requires replacement or refund under the terms of this warranty the consumer is
responsible for all transportation expenses to return the unit to our factory prior to receiving a
replacement unit or refund. A copy of the dated sales receipt / invoice is required to receive
warranty service.
This warranty covers appliances in use within the continental United States, Puerto Rico and Hawaii.
The warranty does not cover the following:
Damages due to shipping damage or improper installation.
Damages due to misuse or abuse.
Content losses due to failure of the unit.
Inside components such as door panels, door shelves, racks, light bulbs, etc.
Punctures to the evaporator system due to improper defrosting of the unit.
Repairs performed by unauthorized service agents.
Service calls that do not involve defects in material and workmanship such as instruction
on proper use of the product, door reversal or improper installation.
Replacement or resetting of house fuses or circuit breakers.
Failure of this product if used for other than its intended purpose.
Disposal costs of failed units not returned to our factory.
Any delivery costs incurred as the result of a unit that fails to perform as specified.
The consumer is responsible for a $35.00 delivery charge for all replacement units
provided under warranty.
This warranty is in lieu of all warranties expressed or implied and no representative or person is
authorized to assume for us any other liability in connection with the sale of this product. Under no
circumstances is the consumer permitted to return this unit to the factory without prior written consent
from MC Appliance Corp.
Model Parts Labor Compressor (Part Only) Type of Service
MCBR445W1 One- Year One- Year Five Years Carry In
MCBR445B1 One –Year One- Year Five Years Carry In
MCBR445S1 One- Year One- Year Five Years Carry In
For Service or Assistance please call 888 775-0202 or visit us on the web at
www.mcappliance.com.
