Magic Chef MCBR170W User manual

2
Important
¥ If you have bought this appliance to replace an old one equipped with a lock that
cannot be opened from inside (lock, bolt), make sure that the lock is broken.
This will make it impossible for children to lock themselves inside the appliance
and suffocate.
¥ The appliance must be correctly connected to the power supply. (See: How to
install)
¥ Do not touch the cooled surfaces while the appliance operates, especially not
with wet hands, because the skin may stick to the cold surfaces.
¥ Do not freeze bottles containing liquid, especially not soft drinks, such as
mineral water, sparkling wine, beer, cola etc., because liquid expands during
freezing and the glass bottle is very likely to blow up.
¥ Do not eat frozen food (bread, fruit, vegetables), because you can get
frostbites.
¥ If the food has strange smell or color, throw it away, because it is very likely
that it is spoiled and therefore dangerous to eat.
¥ Disconnect the appliance from the power supply before repairing it (only a
qualified technician should repair it), before cleaning.
¥ Do not defrost the appliance with other electric devices (hair dryer etc.) and
never scrape the ice or frost layer with sharp tools.
¥ The rating plate is inside the appliance or outside on the rear wall.
Before Putting Into Use
1
¥ Before connecting the appliance to the power supply, let it stand for about 2
hours, which will reduce a possibility of malfunctions in the cooling system due
to transport handling.
¥ Clean the appliance, and be thorough, especially in the interior (See Cleaning
and Maintenance).
¥ In case the interior accessories are not correctly placed, rearrange them as
described in chapter ÒNAME OF THE PARTSÓ.
Instructions for Use
These instruction for use are intended for the user. They describe the appliance
and its correct and safe use. They were prepared for various types/modes of
refrigerators therefore you may find in it description of some functions and
accesories that your appliance does not have.
Tips for Energy Savings
¥ Try not to open the door too often, especially when the weather is wet and hot.
Once you open the door, mind to close it as soon as possible.
¥ Every now and then check if the appliance is sufficiently ventilated (adequate
air circulation behind the appliance).
¥ Set thermostat from higher to lower settings as soon as possible (depends on
how loaded the appliance is ambient temperature etc).
¥ Before loading the appliance with packages of fresh foods, make sure they
are cooled to ambient temperature.
¥ Ice and frost layer increase energy consumption, so do clean the appliance as
soon as the layer is 1/8Ó thick.

43
NAMES OF THE PARTS
!Chiller
@Drain Pan
#Control Box
$Shelf
%Magnetic Door Seal
^Ice Cube Tray
&Rack
*Bottle Rack
(Bottle Rack for bottles, cans or jars.
) Crisper for vegetables fruits.
1 Crisper lid
MCBR170W
MCBR270W
MCBR440W

6
HOW TO CLEAN
Cleaners : Never use harsh, abrasive cleaners, heavy-duty cleaners, or solvents
on any surface.
Exterior : Wipe with damp, sudsy cloth, rinse and dry. For stubborn stains
and for periodic waxing, use silicon wax.
Freezer : When refrigerator needs defrosting turn thermostat dial to ÒOFFÓ.
Do not use sharp instruments to scrape off ice/frost.
Refrigeration Section : Wash shelves and other removable parts in warm
sudsy water, rinse and dry. Wash interior with baking soda solution (3
Tablespoons to 1 Liter of water) or warm sudsy water, rinse and dry.
Magnetic Door Seals : Wash with warm sudsy water.
The Finishing Touch : Replace all parts and return thermostat dial to desired
setting.
HOW TO INSTALL
§Install refrigerator in a convenient location away from extreme heat and cold.
Allow sufficient clearance between the refrigerator and side wall so the door
will open without obstruction. Refrigerator is not designed for recessed
installation.
§Select a space with strong level floor.
§Allow 5 inches of space between the
refrigeratorÕs side and the wall.
5
inches
POWER CORD REPLACEMENT
If the refrigeratorÕs power cord is damaged, have it replaced by a qualified
repair agent.
5
HOW TO OPERATE
Starting your new Refrigerator
1. Clean the refrigerator thoroughly. Wipe the outside with a soft dry cloth, the
interior with a clean moist cloth.
2. Insert the power supply cord into the socket.
3. Turn the thermostat dial to Ò7Ó. Close the door and let the refrigerator
operate for 15-20 minutes.
Temperature control
To control the internal temperature, adjust
the thermostat dial. The dial is numbered
from 1-7.
Number 1 is the warmest setting, number 7
the coldest.
The dial may be set any place on the scale.
It does not have to be set exactly on a
number.
To make ice cubes in the freezer
compartment, adjust the thermostat to the
coldest setting.
How to defrost
Defrost the refrigerator when the frost accumulated on the evaporator is about
5mm (1/5inch) thick.
Set the thermostat dial to ÒOFFÓ. Remove frozen or perishable foods. keep drip
tray in place. Defrosting usually takes a few hours. To defrost quickly remove all
foods from the refrigerator and leave the door open.
Never use a knife or other
metal instrument to scrape ice/frost from the evaporator. After defrosting,
empty water from drip tray and return the thermostat dial to the desired position.
NOTE: Wait 3-5 minutes before restarting if you unplug the refrigerator.
The unit may fail to operate properly if restarted too quickly.

7
WHAT TO DO...
When the fridge is not in use for a prolonged period:
¥ Remove the power plug from the power point.
¥ Remove all contents from the fridge.
¥ Dry the interior and leave the door open for a few days.
When you wish to move the fridge:
¥ Secure all movable parts and contents.
(Package them separately if necessary.)
¥ Transport the fridge only in an upright position. In any other position you
may damage the compressor.
Before calling service, please follow the checklist below.
This may save you an expensive service call.
WARNING-Improper use of the grounding plug can result in a risk of electric
shock. If it is necessary to use an extension cord, use only a 3-wire
extension cord that has a 3-blade grounding plug and a 3-slot receptacle that
will accept the plug on the appliance. The marked rating of the extension
cord should be AC115-120V, 10A, or more. If a grounding adapter is used,
make sure the receptacle box is fully grounded.
If the refrigerator seems too warm inside:
¥ Check that the door has not been opened too frequently or for too long.
¥ Check that the interior circulation is not obstructed by having too many
goods stored. (The fridge is overloaded)
¥ Did you store anything hot, without first cooling it to room temperature?
¥ Is there sufficient clearance around all sides and above the fridge?
If the fridge starts making any unusual noises:
¥ Is it wobbling? Re-level it and check if it now operates normally.
¥ Have any objects fallen behind the fridge? If so, remove them and check if
operation is now normal.
¥ Are any containers inside the fridge vibrating or resonating? If so, rearrange
them then check to see if operation has returned to normal.
8
CHANGING THE REVERSIBLE DOOR
This refrigerator has been built with the door hinges on the right.
If you wish to change the opening direction, follow the instruction below:
¥ Unplug the refrigerator from its electrical outlet.
¥ Empty everything in the refrigerator, including shelves, food, etc.
1. Remove the hinge cover on the right top
of the cabinet.
2. Remove the two screws (using a ratchet
tool with a 8MM socket) that hold the top
hinge to the cabinet. Keep these screws
for later use.
3. Lift the top hinge straight up to free the pin
from the socket on the top of the door.
4. Lift the door and place it on a padded
surface to prevent scratching it.
5. Remove the plug buttons from the upper
left holes as illustrated and transfer them
to the uncovered holes at the right side.
Be sure to press the plug buttons firmly
into the holes.
6. Lay the cabinet on its side down on the
floor. Remove the two screws that hold
the bottom hinge to the cabinet using a
10MM socket. Keep these screws and
washer for later use.
Top hinge
Hinge cover
Plug button
Bottom hinge

9
7. Insert the bottom hinge at the left side
using the two screws previously removed
in step 6.
NOTE:Do not tighten screws.
8. Stand the cabinet.
9. Replace the door making sure the bottom
socket enters the bottom hinge pin.
Be sure washer is in place.
10. While holding the door in the closed
position, secure the top hinge at the left
side using the two screws previously
removed at the beginning in step 2.
Do not tighten the screws until the top of
the door is leveled with the top cabinet.
11. Replace the hinge cover.
13. Tools required:
-8MM & 10MM socket-ratchet.
-Putty knife or thin-blade screwdriver.
12. Replace plugs.

Limited Warranty
DAEWOO ELECTRONICS CORPORATION OF AMERICA warrants the following
Refrigerators to be free from defective material and workmanship and agrees to remedy
any such defect or to furnish a new part (at the CompanyÕs option) in exchange for any
part of any unit of its manufacture which under normal installation, use and service
disclosed such defect, porvided the unit is delivered by the owner to us or to our
authorized distributor form whom purchased or authorized service station, intact, for our
examination with all transportation charges prepaid to our factory. To establish and
receive warranty service at our factory or authorized service facilities, a sales receipt or
bill of sales is required for proof of purchase.
Written authorization must be obtained before any merchandise is returnde to the factory.
This warranty does not extend to any of our electronic products which have been
subjected to misuse, neglect, accident, incorrect wiring not our own, improper installation,
unauthorized modification, or to use in violation of instructions furnished by us, nor units
which have been repaired or altered outside of our factory, nor to cases where the serial
number there of has removed, defaced, or changed.
This warranty is in lieu of all warranties expressed or implied and no representative or
person is authorized to assume for us any other liability in connection with the sales of our
electoronic products.
Over the counter exchange for units that are initially defective.
Initial defective is described as when the dealer opens the unit and finds that it is
inoperative or an individual customer opening a new unit and finding that it is initially
defective. This unit may be returned to the factory by the dealer for exchange. Under no
circumstances will an individual customer be permitted to return defective unit directly to
factory. Exchange must be directly with the dealer. When this unit is returned to dealer, a
copy of the purchase evidence stating the date of purchase is to be put in the individual
box for dealerÕs further control with the factory.
MODEL PARTS LABOR COMPRESSOR
Refrigerator 1 year 1year 5year
Model: MCBR170W, MCBR270W, MCBR440W
Note: For Service or Assistance, please call: 1-800-553-4355
REFRIGERATOR
INSTRUCTION MANUAL
Model No.: MCBR440W
MCBR270W
MCBR170W
§Before use, please read this manual carefully.
§Always remove the drain pan while this refrigerator is running.
§Removing the drain pan will enhance the cooling power and save your electric cost.
