magic clean MCLD24WI User manual

INSTRUCTION MANUAL
Model Number: MCLD24WI
CLOTHES DRYER
CAUTION:
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
Magic Clean has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.
MAGIC CLEAN
3265 Meridian Pkwy # 114
Weston, FL 33331

2
TABLE OF CONTENTS
Help Us Help You
3
Parts and Features
4
Important Safety Instructions
5
Installation Instructions
5
Before Using Your Dryer
5
Wall Mounting Instructions
6
Leveling Legs
7
Electrical Connection
7
Control Panel
7
Operating Your Appliance
8
Temperature Control
8
Dry Mode Selector
8
Drying Time Reference
8
Sorting Fabrics
9
Fabric Care Sheet
10
Care and Maintenance
11
Cleaning Your Appliance Exterior
11
Cleaning the Filters
11
Troubleshooting Guide
12
Service for Your Appliance
12
Your Magic Clean Warranty
13
Registration Information and Registration Card
15

3
HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and maintain
your new appliance properly.
Keep it handy to answer your questions.
If you don't understand something or your
need more help, please call:
Magic Clean Customer Service
800-220-5570
Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.
Write down the model and serial numbers.
You'll find them on a plate located on the back
wall of the appliance.
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
Serial Number
Use these numbers in any correspondence or
service calls concerning your appliance.
If you received a damaged appliance,
immediately contact the dealer (or builder) that
sold you the appliance.
Save time and money. Before you call for
service, check the Troubleshooting Guide. It
lists causes of minor operating problems that
you can correct yourself.
IF YOU NEED SERVICE
We're proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are some
steps to follow for further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased. In
most cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send to:
Customer Service
MAGIC CLEAN
3265 Meridian Pkwy # 114
Weston, FL 33331

4
PARTS AND FEATURES

5
Important Safety Instructions
~
WARNING
~
To reduce the risk of fire, electrical shock, or injury when using
your appliance, follow these basic precautions:
•Read all instructions before using the appliance.
•DANGER or WARNING: Risk of child entrapment.
•Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous. . . even if they will “just sit in the garage a few days.”
•Before you throw away your old appliance: Take off the door so that children may not
easily climb inside.
•Never allow children to operate, play with, or crawl inside the appliance.
•Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or
explosion.
•Do not place the dryer in steamy rooms or where the dryer is directly exposed to rain. Moisture
may destroy the electrical insulation causing an electrical shock hazard.
•During
spinning, don’t put your hand in the spin basket: Because the spin basket is
rotating at high speed, rotating parts may injure your hand.
•Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
-Save these instructions-
INSTALLATION INSTRUCTIONS
ØBefore Using Your Appliance
•Remove the exterior and interior packing.
•Check to be sure you have all of the following parts:
•Instruction Manual
•Allow at least 5 inches of space between the sides of the appliance.
•Put your laundry into the dryer evenly. Uneven laundry may cause noise or vibration.
•Before drying, check all pockets. If nails or pins remain in pockets, they may damage the dryer
or clothes.
•Never splash water on the control panel.
•Plug the dryer into an exclusive properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and or grounding should be directed toward a certified electrician or an
authorized Magic Clean Products service center.
ØSelecting a Location
Before you install the dryer, select a location with the following characteristics:
•A hard level surface (if the surface is uneven, see “Adjusting the Leveling Legs”).
•If you are going to wall mount your dryer using the wall mounting kit included (see “Wall
Mounting Instructions”).
•Away from direct sunlight. Direct sunlight may affect the acrylic coating, plastic and electrical
components.
•Adequate ventilation
•Room temperature that will not fall below 0º C.
•Away from sources of heat such as coal or gas. Make sure that the dryer does not stand on its
power cord. Ventilation openings must not be obstructed by carpeting when the dryer is installed
on a carpeted floor.

6
ØWall Mounting Instructions
** It is recommended to complete the following procedure with at least 2 people **
Tools Required
Tools and parts
required for Plaster
and or Wood
Installation
Drill & Drill Bit
1
Phillips Head Screw Driver
1
Wood screws 2” long
4
Wall Mounting Kit Includes the following:
Description
Wall Hanging Bracket
2
Wall Hanging Hook
2
Plastic Spacers
2
Exhaust Pipe
1
a)
Determine the position where you will be installing the mounting bracket.
(This dryer is not designed to sit directly on top of your washing machine).
(A minimum of 2 inches in required between the top of the dryer and the ceiling to allow easy
installation and adequate space for exhaust).
(If mounting above a washing machine, allow sufficient spacing to open the lid of the washer or
breathing room in the case of a front-loading washer).
b)
c)
Affix the wall mounting bracket (included)
securely to the wall (directly to the stud).
(If a stud is not available, use a wooden slat
between the studs to mount the bracket)
Install the Wall Hanging Hooks as shown in
illustration (Fig. 2).
Fig 2:
d)
Install the exhaust pipe as shown in
illustration (Fig. 3). (Align the Exhaust pipe
to the Exhaust Vent and turn Clockwise)
•The exhaust vent can be locked into the
position that best fitsyourneeds.
(Upward, Downward or venting to
either side left or right).
Fig 3:
e)
Mount the dryer on the wall bracket as
shown in illustration (Fig. 4).
** It is recommended that this step be done
by two (2) or more persons **
Fig 4:

7
ØAdjusting the leveling legs
Your dryer is shipped with the legs in the bag containing your user’s guide.
To install and adjust the leveling legs see the illustration to the right.
If the floor is uneven adjust the legs (do not insert pieces of wood, or any
other objects under the legs)
•Adjust the height level of the legs accordingly.
Place the dryer on a sturdy flat surface.
If the dryer is placed on an uneven or weak surface, noise or vibration will occur. (Allowable is 1º)
ØElectrical Connection
This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the
possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power cord supplied.
Use of extension cord is not recommended.
This appliance requires a standard 115/120-volt, 50Hz electrical outlet with three-prong ground.
The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidental injury.
ØCONTROL PANEL
~Warning~
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Magic Clean Products service center.

8
ØOPERATING INSTRUCTIONS
ØDRY MODE SELECTOR
This unit is designed with an automatic moisture sensor to
monitor the moisture level of the clothes for optimistic
performance. It provides you both Auto Dry and Timed
Dry modes for your best drying performance.
Auto Dry Mode:
When the selector button is up, unit works at automatic drying mode. Please set the timer to
200 minutes and unit will start drying process till the moisture reaches setting degree, (unit
will cut off the heating element inside and terminate the drying automatically), but unit will
continue the wrinkle guard process till the timer runs to “OFF” position.
Note: For heavy items like jeans, blankets, covers, towels, etc., recommended mode is timed
dry.
Timed Dry Mode:
When the selector button is pressed down, unit will work under timer controlled mode. Set the
timer with the following references:

9
ØDRYING TIME REFERENCE
** LOAD WEIGHTS AND RESPECTIVE DRYING TIMES ARE APPROXIMATE **
Drying Capacity
Drying Times
High Heat
Low Heat
3 (Three) Lbs
30 Minutes
55 Minutes
5 (Five) Lbs
60 Minutes
110 Minutes
7 (Seven) Lbs
120 Minutes
9 (Nine) Lbs
200 Minutes
Sorting Fabrics
For the best drying results, clothes should be sorted properly. Separate the lint shedders (chenille
and terry cloth) from the lint collectors (synthetics, flannel and fabrics with a nap, such as velveteen
and corduroy). Separate non-colorfast from light colored items, heavy fabrics from light weight fabrics
and permanent press from heavy, bulky items.
Do not tumble dry
Read all permanent care labels carefully. If a garment’s care label says “Drip Dry”, Line Dry” or “Dry
Flat”, do not dry in the dryer. Certain materials will melt or become dangerously flammable if heated,
while others may lose their shape. Other items that should not be tumble dried are:
•Items that have been dry-cleaned at home.
•Wool (unless the garment’s manufacturer recommends it)
•Fiberglass
•Laminated or rubber coated items
•Vinyl or plastic
•Do not use fabric softeners or products to eliminate static unless recommended by
manufacturer of the fabric softener or product.
WARNING:
To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY
INSTRUCTIONS before operating this appliance.
Drying Time
Drying time depends on many factors, such as the amount of washing, how damp it is, the type of fabrics, rated
power of the machine and the temperature of the room. It also, of course, depends on how dry you want the
washing when you take it out of the machine.
Shrinkage
Knitted fabrics in particular are liable to shrink. Do not use the extra dry program for these materials, and always
stretch them out directly after drying.
Dryer Added Fabric Softeners
Because some dryer added fabric softeners may cause damage to automatic dryers, use only ones that the
manufacturers give a written assurance that their softeners can safely be used in your dryer.
Single Items
Use the timed program when there is only one item to be dried. This is because the automatic program may turn
off the heating too early, so that the item is not properly dried.
If The Washing Is Not Dry After Tumble-Drying
When using the automatic programs, it can happen that not all of the washing is properly dry. This may be due

10
to such reasons as very heavy fabrics or thick seams. To dry these items, give a further 10 minutes or so in the
timed program. Also do not overload the dryer. If the dryer is overloaded, its efficiency is lessened and clothes
may not dry evenly.
Do not over-dry
When using the timed program, it is possible to over-dry fabrics, if too long a time has been set. This can cause
the fabrics to wrinkle, shrink or feel harsh. Synthetic materials can also become charged with static electricity.
Fabric Care Chart

11
CARE AND MAINTENANCE
ØCleaning the Exterior
•Wipe the dryer surfaces, including the control panel, with a soft cloth and non-abrasive
household detergents.
•Use a soft cloth to dry the surfaces.
•Do not pour water on the dryer.
ØCleaning the Filters
Unplug the power cord prior to any cleaning.
Cleaning the Lint Filter:
a)
Removing the Lint Filters:
Remove by pulling outward using the
four (4) grip holes in the filter assembly.
ALL FILTERS MUST BE IN PLACE WHEN DRYING
FILTERS MUST BE CLEANED BEFORE AND
AFTER EACH USE.
b)
The filter assembly consists of three (3)
parts
(See illustration)
a) Exhaust Vent Shroud
b) Lint Filter
c) Exhaust Filter
c)
Separate each of the above parts and
clean the individual pieces
using a
SOFT brush or vacuum cleaner. DO
NOT damage the filters
d)
Re-install the filter assembly
Reassemble the filter assembly in order
Exhaust Filter – Lint Filter – Exhaust
Shroud
Align the entire assembly with the
recessed position in the back
of the
drum and press firmly until the entire
assembly is secure.
Cleaning the Air Intake Filter
a)
Removing the Air Intake Filter:
Remove by pulling outward holding the filter
housing by the top and bottom.
b)
Remove the filter inside the housing and
clean using a SOFT brush or vacuum
cleaner.
c)
Replace the filter housing by pushing
upwards with your thumb until the latch is
secure.

12
PROBLEMS WITH YOUR DRYER?
You can solve many common appliance problems easily, saving you the cost of a possible service
call. Try the suggestions below to see if you can solve the problem before calling the servicer.
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
Timer knob will not rotate
Dryer does not operate.
Drum does not rotate
Not plugged in.
The circuit breaker tripped or blown fuse.
Door is not closed.
Laundry not completely dry
Clean the Filter
Reduce the amount of clothing loaded in the
dryer.
Re-dry the loaded items
Ensure items are not knotted or bulked together.
Dryer is not located in a well ventilated area.
SERVICE FOR YOUR DRYER
We are proud of our customer service organization and the network of professional service technicians
that provide service on your Magic Clean appliances. With the purchase of your Magic Clean dryer, you
can have the confidence that if you ever need additional information or assistance, the Magic Clean
Products Customer Service team will be here for you. Just call us toll-free.
MAGIC CLEAN PRODUCTS CUSTOMER SERVICES
Product Information
800-323-5029
Whatever your questions are about our products,
help is available.
Part Orders
800-220-5570
You may order parts and accessories that will be
delivered directly to your home.
You may order these items by personal check,
money order, Master Card, or Visa.
In-Home Repair Service
800-220-5570
An Magic Clean Products authorized service
center will provide expert repair service,
scheduled at a time that is convenient for you.
Our trained servicers know your dryer inside and
out.

13

14
YOUR MAGIC CLEAN PRODUCTS
WARRANTY
Staple your sales receipt here. Proof of original
purchase date is needed to obtain service under
warranty.
WHAT IS COVERED – LIMITED ONE-YEAR WARRANTY
Magic Clean Products warrants that the product is free from defects in materials and/or workmanship for a
period of twelve (12) months from the date of purchase by the original owner. The foregoing timeline begins
to run upon the date of purchase, and shall not be stalled, tolled, extended, or suspended for any reason
whatsoever unless described in detail in the warranty document. For one year from the date of purchase by
the original owner, Magic Clean products will, at its option, repair or replace any part of the product which
proves to be defective in material or workmanship under normal use. Magic Clean Products will provide you
with a reasonably similar product that is either new or factory refurbished. During this period Magic Clean
Products will provide all parts and labor necessary to correct such defects free of charge, so long as the
product has been installed and operated in accordance with the written instructions in this manual. In rental or
commercial use, the warranty period is 90 days. All Magic Clean appliances of 4.1 cubic feet capacity or less
must be brought/sent to the appliance service center for repair.
LIMITED FIVE YEAR WARRANTY ON PLASTIC TUB (CLOTHES WASHERS ONLY)
After one year and until five years from the date of purchase, Magic Clean Products will furnish a replacement
plastic tub, for one which is defective in material or workmanship. All labor and transportation charges are the
responsibility of the consumer.
LIMITED SEVEN YEAR WARRANTY ON STAINLESS STEEL TUB (Clothes Washer And Dryer)
After one year and until seven years from the date of purchase, Magic Clean Products will furnish a
replacement tub, for one which is defective in material or workmanship. All labor and transportation charges
are the responsibility of the consumer.
WARRANTY EXCLUSIONS / WHAT IS NOT COVERED:
The warranty coverage described herein excludes all defects or damage that are not the direct fault of Magic
Clean Products, including without limitation, one or more of the following:
•A failure to comply with any applicable state, local, city, or county electrical, plumbing and/or building codes,
regulations, or laws, including failure to install the product in strict conformity with local fire and building
codes and regulations.
•Any external, elemental and/or environmental forces and factors, including without limitation, rain, wind,
sand, floods, fires, mud slides, freezing temperatures, excessive moisture or extended exposure to
humidity, lightning, power surges, structural failures surrounding the appliance, and acts of God.
•Incidental or consequential damages
•Parts and labor costs for the following will not be
considered as warranty:
•Inner door panels, door shelves, door rails,
and/or door supports.
•Light bulbs and/or plastic housing.
•Plastic cabinet liners.
•Failure of the product if it is used for other than it
intended purpose.
•Shipping and handling costs associated with the
replacement of the unit.
•Repairs performed by unauthorized servicers.
•Service calls that are related to external problems,
such as abuse, misuse, inadequate electrical
power, accidents, fire, floods, or any other acts of
God.
•Surcharges including but not limited to, any after
hour, weekend, or holiday service calls, tolls, ferry
trip charges, or mileage expense for service calls
to remote areas.
•The warranty does not apply outside the
Continental USA.
In no event shall Magic Clean Products have any liability or responsibility whatsoever for damage to
surrounding property, including cabinetry, floors, ceilings, and other structures and/or objects around the
product. Also excluded from this warranty are scratches, nicks, minor dents, and other cosmetic damages on
external surfaces and exposed parts; Products on which the serial numbers have been altered, defaced or
removed; service visits for customer education, or visits where there is nothing wrong with the product;
correction of installation problems (you are solely responsible for any structure and setting for the product,
including all electrical, plumbing and/or other connecting facilities, for proper foundation/flooring, and for any
alterations including without limitation cabinetry, walls, floors, shelving etc., as well as the resetting of breakers
or fuses.
OUT OF WARRANTY PRODUCT
Magic Clean Products is under no obligation, at law or otherwise, to provide you with any concessions,
including repairs, pro-rates, or product replacement, once this warranty has expired.
Warranty – Laundry Products

15

16
Registration Information
Thank you for purchasing this fine Magic Clean product. Please fill out this card and return it within
100 days of purchase and receive these
important benefits:
ØProtect your product:
We will keep the model number and date of purchase of your new Magic Clean product on file
to help you refer to this information in the event of an insurance claim such as fire or theft.
ØPromote better products:
We value your input. Your responses will help us develop products designed to best meet
your future needs.
-----------------------------------------------------------(detach here)----------------------------------------------------------
Magic Clean Registration Card
__________________________________ _____________________________________
Name Model # Serial #
__________________________________ _____________________________________
Address Date Purchased Store/Dealer Name
__________________________________ ______________________________________
City State Zip Occupation
__________________________________ As Your Primary Residence, Do You:
Area Code Phone Number £Own £Rent
Did You Purchase An Additional Warranty: Your Age:
£Extended £None £under 18 £18-25 £26-30
Reason For Choosing This Magic Clean Product: £31-35 £36-50 £over 50
Please indicate the most important factors Marital Status:
that influenced your decision to purchase £Married £Single
this product. Is This Product Used In The:
£Price £Home £Business
£Product Features How Did You Learn About This Product:
£Magic Clean Reputation £Advertising £Product Features
£Product Quality £In Store Demo £Personal Demo
£Salesperson Recommendation £Other______________________________
£Friend/Relative Recommendation Comments____________________________
£Warranty _____________________________________
£Other_______________________ _____________________________________

17
MCLD24WI - 12032021 PRINTED IN CHINA
