Magnavox MBP5230 User manual

Owner’s Manual
MBP5230/F7
Blu-ray Disc™ / DVD Player with Built-in WiFi
© 2011 Funai Electric Co., Ltd.

EN-2
1. CONTENTS...................................................................................2
2. FEATURES.......................................................................................4
2.1 Features..............................................................................................4
2.2 Product Info..................................................................................... 6
2.3 Symbols Used in this Owner’s Manual............................ 6
3. FUNCTIONAL OVERVIEW.................................................7
3.1 Front Panel.......................................................................................7
3.2 Rear Panel......................................................................................... 7
3.3 Remote Control............................................................................ 8
3.4 Guide to On-Screen Display.............................................. 11
4. CONNECTIONS.....................................................................12
4.1 HDMI Video / Audio Connection.................................... 12
4.2 Standard Video + Standard Audio Connection ...... 12
4.3 Connection to an Audio System...................................... 13
4.4 Connection to the Network.............................................. 16
5. BEFORE YOU START.............................................................18
5.1 Finding the Viewing Channel / Source onYourTV..... 18
5.2 Initial Setup.................................................................................... 18
6. INFORMATION ON PLAYBACK...................................19
6.1 Information on Playback........................................................ 19
6.2 Guide to File List ....................................................................... 23
6.3 How to Insert a Disc.............................................................. 24
7. BASIC PLAYBACK...................................................................25
7.1 Playing Back a Disc................................................................... 25
7.2 Playing Back an SD Memory Card.................................. 26
7.3 Playing Back Video / Music / Photo from
DLNA Certified Home Media Servers...................... 27
7.4 Using the Title / Disc / Pop Menu................................... 28
8. SPECIAL PLAYBACK..............................................................29
8.1 Fast Forward / Fast Reverse ............................................... 29
8.2 Slow Forward Playback.......................................................... 29
8.3 Step by Step Playback............................................................. 29
8.4 Repeat Playback ......................................................................... 30
8.5 Slide Show..................................................................................... 30
8.6 PiP (BONUSVIEW™) Setting ........................................... 31
8.7 Enjoying BD-Live™ Discs Using Internet.................... 31
8.8 Title / Chapter Search............................................................ 32
8.9 Track Search................................................................................. 33
8.10 Time Search.................................................................................. 33
8.11 Switching Subtitles .................................................................... 33
8.12 Switching Audio Soundtrack............................................... 34
8.13 Switching Camera Angles..................................................... 35
8.14 Black Level..................................................................................... 35
8.15 Noise Reduction........................................................................ 36
8.16 Virtual Surround ........................................................................ 36
1. CONTENTS

EN
EN-3
9. BEFORE USING NETWORK FEATURES..................37
10.NETFLIX OPERATIONS......................................................38
10.1 Activating Netflix....................................................................... 38
10.2 Watching Streaming Movies ............................................... 39
11.FILM FRESH / BLOCKBUSTER OPERATIONS.......40
11.1 Activating Film Fresh / Blockbuster................................. 40
11.2 Guide to Film Fresh / Blockbuster Menu Screen... 41
11.3 Renting or Purchasing Movies / TV Episodes............ 41
11.4 Searching Movies / TV Episodes ....................................... 42
11.5 Watching Rented or Purchased Movies /
TV Episodes ................................................................................ 42
12.VUDU OPERATIONS...........................................................43
12.1 Activating VUDU........................................................................ 43
12.2 Guide to VUDU Menu Screen.......................................... 43
12.3 Renting or Purchasing VUDU Movies ........................... 44
12.4 Watching Rented or Purchased VUDU Movies...... 45
12.5 Using Internet Applications.................................................. 45
13.PANDORA OPERATION...................................................46
13.1 Activating Pandora.................................................................... 46
13.2 Adding Pandora User Accounts....................................... 46
13.3 Creating a New Pandora Station..................................... 47
13.4 Guide to the Player Screen................................................. 47
14.LIST OF SETTINGS................................................................48
15.SETUPS..........................................................................................51
15.1 Network Connection ............................................................. 51
15.2 fun-Link (HDMI CEC)............................................................. 57
15.3 HDMI Video Resolution......................................................... 57
15.4 Parental............................................................................................ 58
15.5 Software Update........................................................................ 60
15.6 Initialize ............................................................................................ 62
16.TROUBLESHOOTING.........................................................63
17.LANGUAGE CODE LIST....................................................67
18.SPECIFICATIONS ....................................................................68
19.NETWORK SERVICE DISCLAIMER..............................69
20.SAFETY INSTRUCTIONS...................................................70
21.MAINTENANCE......................................................................71
22.SUPPLIED ACCESSORIES...................................................72
23.TRADEMARK INFORMATION.......................................73
24.GLOSSARY..................................................................................75
25.ESPAÑOL .....................................................................................78
25.1 Mando a Distancia.................................................................... 78
25.2 Encontrar el Canal de Vídeo en su Televisor............. 80
25.3 Instalación Inicial......................................................................... 80
LIMITED WARRANTY ..............................................back cover

EN-4
2. FEATURES
2.1 Features
Blu-ray Disc™
You can enjoy Blu-ray Disc™ which is capable of storing five times more data than a conventional DVD.
BD-Java
With some Blu-ray™ discs which support Java applications, you can enjoy the interactive functions such as games or
interactive menus.
DVD upscaling for enhanced picture quality
Your current DVD will look even better than before thanks to video upscaling. Upscaling will increase the resolution
of standard definition DVD to high definition up to 1080p over an HDMI connection.The picture will be less jagged
and more realistic for a near high definition experience.
Enjoy your content on different kinds of media
Full backwards compatibility with DVD, CD and SD Memory Card ensures that you can continue to enjoy your
current audio-video collection. Additionally, you can enjoy AVCHD / MP3 / WMA / JPEG files.
Listen to rich multi-channel surround sound
Multi-channel surround sound, which realizes real-to-life sound and makes you feel that you are really there.
Easy and simple connection to your HDTV via HDMI
Connect this unit to your HDTV with one single HDMI (High-Definition Multimedia Interface) cable. It is recommended
to use a High Speed HDMI cable for better compatibility.The high definition video output signal will be transferred to
your HDTV without conversion to analog signals, so you will get excellent picture and sound quality, completely free from
noise.Thanks to other multiple outputs, you can also easily connect to your home theater system or amplifier.
fun-Link (HDMI CEC) (Consumer Electronics Control)
This unit supports fun-Link (HDMI CEC), which allows integrated system control over an HDMI cable and is part of
the HDMI standard.This function may not work properly on some devices.
PiP (BONUSVIEW™)
Some BD-videos have the PiP function which enables you to display the secondary video in the primary video.You can
call up the secondary video by pressing [MODE] whenever the scene contains the secondary video.
BD-Live™
BD-Live™ (BD-ROM version 2 Profile 2.0) that allows interactive functions to be used when this unit is connected
to the Internet in addition to the BONUSVIEW™ function.The various functions differ depending on the disc.
Pop menu
Some BD-videos have a pop menu which is a navigation menu that can be called up and be operated on the TV screen
without interrupting playback.You can call up the pop menu by pressing [POP MENU/MENU]. Contents in the pop menu
vary depending on the disc.
HDMI Deep Color
Deep Color reduces posterization (color banding) effect of the playback image.
Continued on next page.

EN
EN-5
HDMI 1080p/24 output (Blu-ray Disc™ only)
This unit is equipped with the feature which can provide smooth movement during playback of film originated material
with the frame rate of 24 frames per second with progressive. (Available only when the display device is connected by an
HDMI cable.) Refer to “HDMI Video Resolution” on page 57.
Playing back contents from an SD Memory Card
You can play back AVCHD / MP3 / WMA / JPEG files stored in an SD Memory Card. BD-ROM Profile 2.0 (BD-Live™)
and Profile 1.1 discs sometimes store picture-in-picture commentary, subtitles or other extras in the SD Memory Card
for use during playback with the BD-video.
Playing back AVCHD files
This unit supports playback of AVCHD format files (new format for high definition video camcorders) recorded on
disc / SD Memory Card.Your high definition personal archive is playable in HD quality.
x.v.Color
This unit supports playback of video contents on discs recorded with “x.v.Color” technology.To watch this video
content with the “x.v.Color” space, a TV or other display device supporting both video image reproduction using
“x.v.Color” standard and capability of manual switching of its color space setting is required. Please refer to the
owner’s manual of your display device for further information.
Enjoy contents stored on DLNA certified home media servers
This unit is a DLNA certified media player that can play video, music and photo files stored on DLNA certified
home media servers connected to your home network. (unwarranted for wireless environment)
Netflix
With this unit, you can enjoy movies and TV episodes streamed instantly from Netflix via the Internet. In order to
use this feature, you must visit netflix.com/Magnavox on your PC and become a Netflix member. (This feature is
available only in the United States.)
Film Fresh / Blockbuster
With this unit, you can enjoy movies and TV episodes streamed instantly from Film Fresh / Blockbuster via the
Internet. In order to use this feature, you must visit following website on your PC and become a Film Fresh /
Blockbuster member. (This feature is available only in the United States.)
- Film Fresh : filmfresh.roxionow.com/Login
- Blockbuster : www.blockbuster.com/auth/login
VUDU
This unit supports VUDU which is the leading HD on-demand video service.With VUDU, you can also enjoy
various kinds of Internet applications. In order to use this feature, you must connect this unit to the Internet. (This
feature is available only in the United States.)
Pandora
This unit supports Pandora Internet radio service.You can instantly listen to personalized radio stations streamed
over the Internet from Pandora. (This feature is available only in the United States.)

EN-6
2.2 Product Info
“Product Info” screen provides information about this unit’s software version.You can also download the latest software
from the Magnavox website and update it yourself if it is newer than the version currently on your unit.The current
version of software on your unit can be seen on the “Product Info” screen.
To access “Product Info”, follow the procedure below.
1. Press [HOME].
2. Use [Î/ ï/ Í/ Æ]to select “Settings”, then press [OK].
3. Use [Î/ ï]to select “Others”, then press [OK].
4. Use [Î/ ï]to select “Product Info”, then press [OK].
2.3 Symbols Used in this Owner’s Manual
To specify which media type each function is applicable to, we put the following symbols at the beginning of each
item to operate.
Symbol Description
Description refers to BD-video
Description refers to DVD-video
Description refers to audio CD / DTS-CD
Description refers to DVD-RW/-R and SD Memory Card with AVCHD files
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and SD Memory Card with MP3 files
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and SD Memory Card with Windows Media™
Audio files
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and SD Memory Card with JPEG files
Description refers to video files in the DLNA home server
Description refers to music files in the DLNA home server
Description refers to photo files in the DLNA home server
If you do not find any of the symbols listed above under the function heading, the operation is applicable to all
media.

EN
EN-7
3. FUNCTIONAL OVERVIEW
3.1 Front Panel
1 3 456 2*
78*9
(*) The unit can also be turned on by pressing these buttons.
DNote
• Due to new ENERGY STAR®requirements, this unit will automatically turn on the screen saver after 5 minutes
of inactivity and enter standby mode after 25 minutes of inactivity.
3.2 Rear Panel
12345
6
CCaution
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage
to the unit.
• This unit does not have a TV RF modulator.
1. Disc tray
2. OPEN/CLOSE flbutton*
3. Infrared sensor window
4. PLAY indicator
• Flashes while loading a disc.
5. STANDBY/ON indicator
• Flashes while getting ready to start.
6. STANDBY/ON .button
7. SD card slot
8. PLAY Æbutton*
9. STOP Êbutton
1. AC power cord
2. LAN terminal
3. HDMI OUT jack
4. AUDIO OUT jacks
5. DIGITAL OUT (COAXIAL) jack
6. VIDEO OUT jack

EN-8
3.3 Remote Control
1
3
6
8
12
5
4
17
18
20
21
25
13*
14
16
15
22
23
24
11
10
2
199
7*
(*) The unit can also be turned on by pressing these
buttons.
1. STANDBY/ON .button
Press to turn on the unit, or to switch the unit into
standby mode. (To completely turn off the unit, you
must unplug the AC power cord.)
2. RED / GREEN / BLUE / YELLOW buttons
Press to activate shortcut keys on some BD-video
functions.
When file list is shown, press to switch between
pages.
3. TOP MENU button
Blu-ray Disc™:
Press to display the top menu.
DVD:
Press to display the title menu.
4. Î/ ï/ Í/ Æbuttons
Press to select items or settings.
5. HOME button
Press to display the home menu.
6. ¢(reverse) button
During playback, press to fast reverse the playback.
7. Æ(play) button*
Press to start playback or resume playback.
8. H(skip) button
During playback, press once to return to the
beginning of the current title, chapter, track or file.
During playback, press twice to return to the
previous title, chapter, track or file.
During the JPEG playback, press to return to the
previous file.
9. Ê(stop) button
Press to stop playback.
10. Number buttons
Press to select a chapter during playback.
Press to enter numbers in the input field.
11. SEARCH button
Press to display the search menu.
Continued on next page.

EN
EN-9
12. NET APP button
Press to display the network application menu.
13. OPEN/CLOSE flbutton*
Press to open or close the disc tray.
14. POP MENU/MENU button
Blu-ray Disc™:
Press to display the pop menu.
DVD:
Press to display the disc menu.
15. OK button
Press to confirm or select menu items.
16. RETURN button
Press to return to the previously displayed menu or screen function.
17. ∫(forward) button
During playback, press to fast forward the playback.
When playback is in pause, press to slow forward the playback.
18. G(skip) button
During playback, press to skip to the next chapter, track or file.
When playback is in pause mode, press to forward the playback picture by picture.
19. Δ(pause) button
Press to pause playback.
20. DISPLAY button
Press to display the on-screen display menu.
21. REPEAT button
Press to select repeat mode.
22. SUBTITLE button
Press to select subtitles on a disc.
23. AUDIO button
Press to select the audio channel (such as audio languages) on a disc.
24. MODE button
During playback, press to display the play menu.
25. CLEAR button
Press to clear the information once entered.
DNote
• When the unit receives a signal from the remote control, STANDBY/ON indicator on the front panel flashes.
Continued on next page.

EN-10
■Installing the Batteries in the Remote Control
Install 2 AAA (1.5V) batteries matching the polarity indicated inside battery compartment of the remote control.
CCaution
Incorrect use of batteries can result in hazards such as leakage and bursting. Please observe the following:
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together. Although they may look similar, different batteries may have
different voltages.
• Make sure that the + and - ends of each battery match the indications in the battery compartment.
• Remove batteries from battery compartment, when the remote is not going to be used for a month or more.
• When disposing of used batteries, please comply with governmental regulations or environmental public rules
that apply in your country or area.
• Do not recharge, short-circuit, heat, burn or disassemble batteries.
■Using the Remote Control
Remote Control Usage Guidelines:
• Make sure that there are no obstacles between the remote control and the infrared sensor window on the unit.
• Remote operation may become unreliable if strong sunlight or fluorescent light is shining on the infrared sensor
window of the unit.
• Remote controls of different devices can interfere with each other. Avoid using a remote control of another
device which is located close to the unit.
• Replace the batteries when you notice a fall-off in the operating range of the remote control.
• The maximum operable ranges from the unit are as follows.
Line of sight : approx. 23 feet (7 m)
Either side of the center : approx. 16 feet (5 m) within 30°
Above : approx. 16 feet (5 m) within 15°
Below : approx. 10 feet (3 m) within 30°
30˚ 30˚

EN
EN-11
3.4 Guide to On-Screen Display
■Home Menu
When you turn on the unit, the home menu will appear automatically. Otherwise, press [HOME].
SD
SD
SD
Disc
“Disc” : Initiates playback of inserted disc, displays a list of tracks / files or the media filter menu
“NET APP” :To access the menu of network services
“SD Memory Card” : Displays a list of tracks / files on the inserted SD Memory Card or the media filter menu
“Home Network” :To access the home network server (DLNA)
“Settings” :To access the setup menu
“Network Setup” :To setup network settings
■Setup Menu
Video Out
Audio Out
Network
HDMI
Playback
Others
TV Aspect
Progressive Mode
Still Mode
: 16:9 Wide
: Auto
: Auto
1
2
1. Category
2. Menus / Options : Displays options for the highlighted item on the left whenever available.
■Play Menu
During playback, press [MODE] to display the play menu.
e.g.) Blu-ray Disc™
Search
Audio
Subtitle
Repeat
Black Level
Noise Reduction

EN-12
4. CONNECTIONS
4.1 HDMI Video / Audio Connection
(Supports up to 1080i, 1080p(*1), 1080p/24(*2) resolution.)
HDMI IN
HDMI cable (not supplied)
Your TV
HDMI OUT
No analog audio connection required.
(*1) 1080i/1080p : Outputs video data with a frame rate of 30 frames per second.
(*2) 1080p/24 : Outputs video data with a frame rate of 24 frames per second.
• Do not tilt the connector when inserting it into the HDMI jack, and make sure the shapes of the jack and the
connector are matched.
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• Use an HDMI cable with the HDMI logo (a certified HDMI cable) for this connection.
High Speed HDMI cable (also known as HDMI category 2 cable) is recommended for better compatibility.
4.2 StandardVideo + Standard Audio Connection
(Supports only 480i resolution.)
AUDIO IN
R
L
VIDEO IN
Your TV
VIDEO
OUT
L
R
AUDIO
OUT
Video cable (supplied)
Audio cable (supplied)
• Connect this unit directly to the TV. If the audio / video cables are connected to a VCR then the pictures may be
distorted due to the copyright protection system.

EN
EN-13
4.3 Connection to an Audio System
• When you change the connections, all devices should be turned off.
• When making connections with external devices, please refer to their user manuals for additional setup help.
■2-Channel Analog Audio Connection
AUDIO IN
R
L
Stereo system with
analog audio input jacks
Audio cable (supplied)
L
R
AUDIO
OUT
■Digital Audio Connection
COAXIAL
DIGITAL AUDIO INPUT
Digital audio coaxial cable
(not supplied)
AV receiver / amplifier with a
digital audio coaxial input jack
COAXIAL
DIGITAL OUT
PCM/BISTREAM
■Digital Output
“Digital Output”
setting →“Bitstream” “LPCM”
“BD Audio Mode”
setting →“HD Audio Output” “Mix Audio Output” “HD Audio Output” “Mix Audio Output”
Media
↓
Audio Source
↓Which audio format can be output depends on the compatibility of the connected device.
BD-video
Dolby Digital Dolby Digital DownMix 2ch LPCM
Dolby Digital Plus Dolby Digital DownMix 2ch LPCM
*1
DownMix 2ch LPCM
*2
Dolby TrueHD Dolby Digital DownMix 2ch LPCM
*3
DownMix 2ch LPCM
*4
DTS®DTS® DownMix 2ch LPCM
DTS-HD®DTS® DownMix 2ch LPCM
*1
DownMix 2ch LPCM
*5
LPCM DownMix 2ch LPCM DownMix 2ch LPCM
DVD-video
Dolby Digital Dolby Digital DownMix 2ch LPCM
DTS®DTS®DownMix 2ch LPCM
LPCM 2ch LPCM 2ch LPCM
DTS-CD DTS®DTS®DownMix 2ch LPCM
AVCHD Dolby Digital Dolby Digital DownMix 2ch LPCM
LPCM DownMix 2ch LPCM DownMix 2ch LPCM
Audio CD LPCM 2ch LPCM 2ch LPCM
MP3 MP3 2ch LPCM 2ch LPCM
Windows Media™
Audio WMA 2ch LPCM 2ch LPCM
Continued on next page.

EN-14
“Digital Output”
setting →“Bitstream” “LPCM”
“BD Audio Mode”
setting →“HD Audio Output” “Mix Audio Output” “HD Audio Output” “Mix Audio Output”
Media
↓
Audio Source
↓Which audio format can be output depends on the compatibility of the connected device.
DLNA Video
Dolby Digital Dolby Digital DownMix 2ch LPCM
MP2 2ch LPCM 2ch LPCM
LPCM DownMix 2ch LPCM DownMix 2ch LPCM
DLNA Music MP3 / WMA / LPCM 2ch LPCM 2ch LPCM
Netflix WMA 2ch LPCM 2ch LPCM
Film Fresh AAC 2ch AAC 2ch LPCM
Blockbuster AAC 2ch AAC 2ch LPCM
VUDU Dolby Digital Plus Dolby Digital
DownMix 2ch LPCM
*1
MP3 2ch LPCM 2ch LPCM
Pandora MP3 2ch LPCM 2ch LPCM
*1) Fully decoded.
*2) Only the independent substream is decoded.
*3) Dolby TrueHD stream is decoded.
*4) Only the Dolby Digital substream is decoded.
*5) Only the core substream is decoded.
DNote
• When playing back a BD-video which only contains the primary audio, the audio output will be the same case as
“HD Audio Output” even if “BD Audio Mode” is set to “Mix Audio Output”.
• If the connected device is not compatible with AAC (Advanced Audio Coding-often are protected by DRM
(Digital Rights Management)), audio will be output as LPCM depending on the capability of the connected device.
■HDMI Audio Connection
AV receiver/amplifier with an HDMI input jack
HDMI OUT
HDMI IN HDMI cable
(not supplied)
Continued on next page.

EN
EN-15
■HDMI Audio Output
“Audio Output”
setting →“Bitstream” “LPCM” “Off”
“BD Audio Mode”
setting →“HD Audio Output” “Mix Audio Output” “HD Audio Output” “Mix Audio Output” Regardless
Media
↓
Audio Source
↓Which audio format can be output depends on the compatibility of the connected device.
BD-video
Dolby Digital Dolby Digital Multi LPCM Mute
Dolby Digital Plus Dolby Digital Plus Dolby Digital Multi LPCM*1Multi LPCM*2Mute
Dolby TrueHD Dolby TrueHD Dolby Digital Multi LPCM*3Multi LPCM*4Mute
DTS®DTS®Multi LPCM Mute
DTS-HD®DTS-HD®DTS®Multi LPCM*1Multi LPCM*5Mute
LPCM Multi LPCM Multi LPCM Mute
DVD-video
Dolby Digital Dolby Digital Multi LPCM Mute
DTS®DTS®Multi LPCM Mute
LPCM 2ch LPCM 2ch LPCM Mute
DTS-CD DTS®DTS®Multi LPCM Mute
AVCHD Dolby Digital Dolby Digital Multi LPCM Mute
LPCM Multi LPCM Multi LPCM Mute
Audio CD LPCM 2ch LPCM 2ch LPCM Mute
MP3 MP3 2ch LPCM 2ch LPCM Mute
Windows
Media™
Audio
WMA 2ch LPCM 2ch LPCM Mute
DLNA
Video
Dolby Digital Dolby Digital Multi LPCM Mute
MP2 2ch LPCM 2ch LPCM Mute
LPCM Multi LPCM Multi LPCM Mute
DLNA Music
MP3 / WMA / LPCM 2ch LPCM 2ch LPCM Mute
Netflix WMA 2ch LPCM 2ch LPCM Mute
Film Fresh AAC 2ch AAC 2ch LPCM Mute
Blockbuster AAC 2ch AAC 2ch LPCM Mute
VUDU Dolby Digital Plus Dolby Digital Plus Multi LPCM*1Mute
MP3 2ch LPCM 2ch LPCM Mute
Pandora MP3 2ch LPCM 2ch LPCM Mute
*1) Fully decoded.
*2) Only the independent substream is decoded.
*3) Dolby TrueHD stream is decoded.
*4) Only the Dolby Digital substream is decoded.
*5) Only the core substream is decoded.
DNote
• If the connected device is not compatible with the HDMI BITSTREAM, audio will be output as multi LPCM or
2-channel down-mixed LPCM depending on the capability of the connected device even if you select “Bitstream”
in “Audio Output” setting.
• If the connected device is not compatible with AAC, audio will be output as LPCM depending on the capability
of the connected device.
• When playing back a BD-video which only contains the primary audio, the audio output will be the same case as
“HD Audio Output” even if the “BD Audio Mode” is set to “Mix Audio Output”.

EN-16
4.4 Connection to the Network
By connecting this unit to the Internet, you can update the software via the Internet, play contents stored on DLNA
home media servers or access BD-Live™, Netflix, Film Fresh, Blockbuster,VUDU and Pandora services.
- For more information about a software update, refer to “Network Update” on page 61.
- For more information about DLNA, refer to “Playing Back Video / Music / Photo from DLNA Certified Home
Media Servers” on page 27.
- For more information about BD-Live™, refer to “Enjoying BD-Live™ Discs Using Internet” on page 31.
- For more information about Netflix, refer to “NETFLIX OPERATIONS” on page 38.
- For more information about Film Fresh and Blockbuster, refer to “FILM FRESH / BLOCKBUSTER
OPERATIONS” on page 40.
- For more information about VUDU, refer to “VUDU OPERATIONS” on page 43.
- For more information about Pandora, refer to “PANDORA OPERATION” on page 46.
DNote
• Wired connection is recommended when using the following features. (Using the following features with a
wireless connection can be affected by other devices using radio frequencies.)
- Play contents from DLNA certified home media servers
- Video streaming services (Netflix / Film Fresh / Blockbuster / VUDU)
- Listening to Internet radio (Pandora)
- Network update
■Wired Connection
LAN WAN LAN
12345
LAN
LAN cable (not supplied)
Broadband router or hub
Networking equipment
(modem,etc.)
LAN cable (not supplied)
Internet
CCaution
• Do not insert any cable other than a LAN cable to the LAN terminal to avoid damaging the unit.
• Do not connect your PC directly to the LAN terminal of this unit.
Continued on next page.

EN
EN-17
DNote
• After you make a wired connection, set up necessary network settings. (For network setting of wired connection,
refer to “Wired” on page 51.)
• If your cable modem does not have router functions, connect a wired router.
• If your cable modem has router functions but there is no vacant port, add a hub.
• For a wired router, use a router which supports 10BASE-T / 100BASE-TX ETHERNET standard.
• Please purchase shielded LAN cables at your local store and use them when you connect to network equipment.
■Wireless Connection
LAN WAN
LAN cable (not supplied)
Internet
Networking equipment
(modem,etc.)
Wireless router
DNote
• After you made the wireless connection, set up necessary network settings. (For the network setting of wireless
connection, refer to “Wireless” on page 54.)
• For a wireless router, use a router which supports IEEE 802.11 b/g/n. (”n” type is recommended for stable
operation of the wireless network.)
• Set the wireless router to Infrastructure mode.This unit does not support Ad-hoc mode.
• Other radio devices or obstacles may cause interference to the wireless network connection.

EN-18
5. BEFOREYOU START
5.1 Finding the Viewing Channel / Source on Your TV
After you have completed all the connections, you must find the viewing channel (external input source) on your TV.
1. After you have made all the necessary connections, press [STANDBY/ON .]to turn on the unit.
2. Turn on your TV.
3. Press the button on the TV’s remote control that accesses the external input channel. It may be labeled
“SOURCE”,“AV”, ”AUX” or “SELECT” (refer to your TV’s user manual).
Please Wait...
This is the correct viewing channel (external input source).
• If the TV is connected by an HDMI cable, it may take a while for the opening picture to come up.
• If a certain amount of time has passed since you turned on the unit, welcome screen only appears for the first
time you turn on the unit.
5.2 Initial Setup
Please follow the instructions below to complete the initial setup.
1. While welcome screen is displayed, use [Î/ ï]to select “Next”, then press [OK].
2. Language setup screen will appear. Use [Î/ ï]to select your language, then press [OK].
Language
Please select your language for on-screen display.
English
Español
Français
3. “Quick Start Mode” screen will appear. Use [Î/ ï]to select the desired mode, then press [OK].
4. “Automatically check for latest software” screen will appear. Use [Î/ ï]to select the desired mode, then press
[OK].
5. Network setup screen will appear. Use [Î/ ï]to select the desired mode, then press [OK].
• If you select “Wired”, refer to “Wired” on page 51 for further information.
• If you select “Wireless”, refer to “Wireless” on page 54 for further information.

EN
EN-19
6. INFORMATION ON PLAYBACK
6.1 Information on Playback
■Playable Discs and Files
Playable discs Logos
Blu-ray Disc™
- BD-video
- BD-RE*(ver. 2.1)
(Recorded in BDMV format)
- BD-R*(ver. 1.1 / 1.2 / 1.3)
(Recorded in BDMV format)
(Disc that is not finalized may not be played
back.)
DVD-video
DVD-RW
(finalized video mode discs only)
DVD-R
(finalized video mode discs only)
CD-DA (audio CD)
CD-RW
CD-R
KODAK Picture CD
DTS-CD -
*Due to the intentional progression of the Blu-ray Disc™ format by its standard setting authority, the company
cannot guarantee or warrant the playability of future extensions of the Blu-ray Disc™ format with this product.
Playable files Media
AVCHD DVD-RW/-R, SD Memory Card,
miniSD Memory Card, microSD Memory Card,
SDHC Memory Card, miniSDHC Memory Card,
microSDHC Memory Card
MP3 BD-RE/-R, DVD-RW/-R, CD-RW/-R,
SD Memory Card, miniSD Memory Card,
microSD Memory Card, SDHC Memory Card,
miniSDHC Memory Card, microSDHC Memory Card
Windows Media™ Audio
JPEG
Continued on next page.

EN-20
Readable cards Playable files / data
SD Memory Card (8 MB - 2 GB)
AVCHD, MP3,WMA, JPEG, picture-in-picture
commentary, subtitles or other extras for
BD-ROM ver. 2 (Profile 2.0 / Profile 1.1)
miniSD Memory Card (16 MB - 2 GB)
microSD Memory Card (256 MB - 2 GB)
SDHC Memory Card (4 GB - 32 GB)
miniSDHC Memory Card (4 GB - 8 GB)
microSDHC Memory Card (4 GB - 16 GB)
■Recommended Specifications
AVCHD
This unit cannot play back standalone AVCHD files (*.m2ts, *.mts or *.m2t) written to a DVD or copied to an SD
Memory Card.The DVD or SD Memory Card containing AVCHD files must have a proper file and folder structure
meeting AVCHD format specifications.
Please use AVCHD compliant device / software to burn or copy AVCHD files to DVD or SD Memory Card.
(Please refer to user manuals of the device / software for more information.)
MP3 / WMA
• Sampling frequency : 32 kHz, 44.1 kHz or 48 kHz
• Constant bit rate : 112 kbps - 320 kbps (MP3),
48 kbps - 192 kbps (WMA)
JPEG
Resolution
• Upper limit : 2,560 x 1,900 dots (sub sampling is 4:4:4)
5,120 x 3,840 dots (sub sampling is up to 4:2:2)
• Lower limit : 32 x 32 dots
• Maximum file size of a picture : 12MB
■Folder / File Number Limitations
Blu-ray Disc™, DVD and SD Memory Card
• 999 folders (groups) and 9,999 files.
CD
• 255 folders (groups) and 999 tracks / files.
■Caution / Note for SD Memory Cards
CCaution
• Use the write-protect switch on the SD / SDHC Memory Cards to ensure your data is securely protected when
playing back contents from the card.
• Do not try to open or modify the card.
• Do not touch the terminal surface with your fingers or any metals.
• Do not attach additional labels or stickers to cards.
• Do not remove the label of the SD Memory Cards. Continued on next page.
