Magnavox MDV540VR - Dvd/vcr Player Operating manual

REAR OF TV
(EXAMPLE ONLY)
ANTENNA IN
RF COAXIAL CABLE
OR
IN OUT
CABLE BOX
2
3
ANTENNA or
CABLE TV SIGNAL
ANTENNA or
CABLE TV SIGNAL
1Disconnect all equipment from the power outlets. Connect the equipment to the power outlets only after you
have finished hooking up everything. Never make or change connections with equipment connected to the power outlet.
2If you do not have a Cable Box, simply connect your Antenna or Cable TV signal directly to the ANT-IN jack
on the rear of the DVD/VCR.
If you do have a Cable Box (or Satellite Receiver), first connect the Cable TV (or Satellite) signal to the IN
jack on the Cable Box/ Satellite Receiver. Then, use an RF coaxial cable (like the one supplied) to connect
the OUT jack of the Cable Box/ Satellite Receiver to the ANT-IN jack on the DVD/ VCR.
3Connect the supplied black RF coaxial cable to the DVD/VCR’s ANT-OUT jack and to yourTV’s ANTENNA
IN jack. The TV’s ANTENNA IN jack could be labelled 75-ohm,TV IN, or RF IN. Check your TV manual for details.
4Plug the power cords of the DVD/VCR and the TV into an active power outlet.
5Turn on the TV power. Set the TV to channel 3 or 4. (If you cannot use channel 3 at your TV, you can use
channel 4 instead. However, you must set the DVD/VCR’s output channel to 4. See the accompanying DVD/VCR
owner’s manual for details.)
6Press the STANDBY-ON yybutton on the DVD/VCR or its remote to turn on the DVD/ VCR. The first
time you turn on the DVD/VCR, you should complete the VCR setup. See the other side of this Quick-
Use Guide for details.
MDV540VR SMART. VERY SMART.
-
-
There are many ways to connect your new DVD / VCR to your Television and other equipment.This Quick-
Use Guide shows the easiest, most common connection between the DVD/ VCR and a TV.
Higher quality connections are explained in the owner’s manual and will provide better sound or picture if
your TV and/or audio system is compatible.
MDV540VR/17 QUG_feb26.qx4 04.4.14 4:49 PM Page 1

Setting Up the VCR the First Time
1Turn on the TV and set it to channel 3 or 4.
2Press VCR, then press STANBDY-ON yyto turn
on the DVD / VCR. This display will appear.
3Press KKor LLto select English, French, or Spanish
as the language for VCR displays and menus.
Then, press B.
4The AUTO SET UP message will appear. Press Bto set
up TV channels for the VCR. When setup is
complete, the lowest TV channel will appear on the TV.
LANGUAGE SELECT
BENGLISH [ON]
FRANCAIS
ESPAÑOL
PUSH B
Quick-Use Guide (cont’d)
Quick-Use Guide (cont’d)
Detailed playback features and additional functions are described in the
accompanying owner’s manual.
Playing a Disc
1With the TV and DVD/VCR on, press the DVD
button to put the DVD / VCR in DVD mode.
2Press OPEN/ CLOSE Ato open the disc tray.
Put a Disc in the tray with the label facing up and the
shiny side facing down.
Press OPEN/ CLOSE Aagain to close the tray.
3Playback may start automatically. If not, press
PLAY B.If a DVD Disc menu appears, use the s , B ,K,
L,OK, or Number buttons to select features or start
playback. Follow the instructions in the menu.
4To stop playing the Disc, press STOP C.
MDV540VR / 8239 300 31732
OVMN04141A / H9660UD****
Printed in China
Playable Discs
The DVD Player of the DVD/VCR will play the following Discs.
DVDs must have a Region Code of ALL regions or Region 1.
DVDs must be recorded in either the NTSC or PAL color
system.Your TV must also have the NTSC or PAL color system.
1
ALL
Recordable
ReWritable
TIMER SET
SETUP SUBTITLEAUD IO
MODE
DISPLAY
TITLE
SKIP/
CH
SKIP/
CH
RETURN
A-B
DVD
PLAYSTOP
FF
PAUSE
SPEED
NA508
REW
VCR
DISC
REPEAT
C-RESET
CLEAR
REC REPEAT
ANGLE
STANDBY-ON
2 31
SLOW
5 64
VCR/TV
8 97
SEARCH MODE
ZOOM
0 +10
MENU
OK
Turn on the TV to
channel 3 or 4.
2
2
TIMER SET
SETUP SUBTITLEAUD IO
MODE
DISPLAY
TITLE
SKIP/
CH
SKIP/
CH
RETURN
A-B
DVD
PLAYSTOP
FF
PAUSE
REW
VCR
DISC
REPEAT
C-RESET
CLEAR
REC REPEAT
ANGLE
STANDBY-ON
MENU
OK
4
CHANNEL STOP PLAYRECORDREW
– AUDIO –
LR
VIDEO
POWERON
STANDBY-ON
F.FW D ST OP/EJECT PLAY
VCR
SOURCE
OPEN/
CLOSE
DVD
PROGRESSIVE SCAN
DVDVIDEO/VCR COMBI MDV540VR
ONETOUCH RECORDING • LONG PLAY
4 HEAD HI-FI STEREO
1
2
1
3
AUTO SET UP
3-4
MDV540VR/17 QUG_feb26.qx4 04.4.14 4:49 PM Page 2
