Magnum Energy ME-ARTR User manual

ME-ARTR
Advanced Router
Owner’s Manual
(Version 4.0)

© 2017 Sensata Technologies Page i
Disclaimer of Liability
This manual provides detailed installation and operation information for the ME-ARTR router
and is intended for the system installer and operator. The use of this manual and the conditions
or methods of installation, operation, use and maintenance of the ME-ARTR are beyond the
control of Sensata Technologies. Therefore, this company does not assume responsibility and
expressly disclaims liability for loss, damage, or expense whether direct, indirect, consequential
or incidental that may arise out of or be any way connected with such installation, operation, use,
or maintenance.
Due to continuous improvements and product updates, the images shown in this manual may not
exactly match the unit purchased.
Restrictions on Use
The ME-ARTR may only be used in life support devices and systems with the express written
approval of Sensata Technologies. Failure of the ME-ARTR can reasonably be expected to cause
failure of that life support device or system, or to affect the safety or effectiveness of that device
or system. If the ME-ARTR fails, it is reasonable to assume the health of the user or other persons
may be endangered.
Copyright Notice
Copyright © 2017 by Sensata Technologies. All rights reserved. Permission to copy, distribute,
and/or modify this document is prohibited without express written permission from Sensata
Technologies.
Document Information
Description – ME-ARTR Owner’s Manual
Part Number and Revision – 64-0091 Rev A
Date Published – December 2017
This is a comprehensive manual and much of it is fairly technical. Terms may be used
throughout the manual that are unfamiliar to you. Refer to the glossary in Appendix B for
clarification. This manual is printed without color for cost savings. However, this entire manual
is available for download—with many of the figures available in color—online at our website at
www.SensataPower.com.
Contact Information
For Magnum Energy Products:
Sensata Technologies
Phone: [phone]
Fax: [phone]
Web: www.SensataPower.com
Thank you from all of us at Sensata Technologies for purchasing this ME-ARTR (also known as the
“advanced router”). The ME-ARTR is a product under the Magnum Energy brand from Sensata
Technologies. We understand that you have many purchasing options in the marketplace, and we
are pleased that you have decided on this product.
At Sensata, we are committed to providing you with quality products and services, and hope that
your experience with us is pleasant and professional.

Safety Information
Page ii © 2017 Sensata Technologies
Important Product Safety Instructions
This manual contains safety instructions that must be followed during the installation and
operation of this product. Read all instructions and safety information contained in this manual
before installing or using this product.
Safety Symbols
To reduce the risk of electrical shock, fire, or other safety hazard, the following safety symbols
have been placed throughout this manual to indicate dangerous and important safety instructions.
WARNING: Indicates that failure to take a specified action could result in physical
harm to the user.
CAUTION: Indicates that failure to take a specified action could result in damage to
the equipment.
Info: Indicates information that emphasizes or supplements important points of the
main text.
Remedy: Provides possible solutions for related issues.
Product Safety Alerts
All electrical work must be performed in accordance with local, state, and federal electrical codes.
WARNINGS:
• All electrical work must be performed in accordance with local, state and federal
electric codes.
• This product is designed for indoor/compartment installation. It must not be exposed
to rain, snow, moisture, or liquids of any type.
• Use insulated tools to reduce the chance of electrical shock or accidental short
circuits.
• Remove all jewelry such as rings, watches, bracelets, etc., when installing or
performing maintenance on the inverter.
• Always disconnect the batteries or energy source prior to installing or performing
maintenance on the inverter. Live power may be present at more than one point
since an inverter utilizes both batteries and AC. Turning off the inverter may not
reduce this risk on some Magnum inverters. As long as AC power is connected, it
passes thru the inverter regardless of the power switch on the inverter or the ON/
OFF INVERTER button on the router.

© 2017 Sensata Technologies Page iii
Table of Contents
1.0 Introduction ...........................................................................................1
2.0 Installation.............................................................................................3
2.1 Pre-Installation .............................................................................................. 3
2.1.1 Inverter Requirements .................................................................................. 3
2.1.2 Installation Guidelines .................................................................................. 3
2.1.3 Unpacking and Inspection ............................................................................. 3
2.1.4 Tools Required............................................................................................. 3
2.2 Installation Overview ...................................................................................... 4
2.3 Router Dimensions.......................................................................................... 5
2.4 Communications Cables – Provided ................................................................... 6
2.4.1 Network Cable ............................................................................................. 6
2.5 Communications Cable Routing......................................................................... 7
2.6 Mounting the Router on a Wall.......................................................................... 8
2.7 Connecting the Communication Cables .............................................................. 8
2.7.1 Connecting the Remote/Network Cables .......................................................... 9
2.7.2 Connecting the Parallel Stack Cables..............................................................10
2.8 Installing the Router’s Front Cover ...................................................................10
2.9 Wiring the Auxiliary (Aux) Relay ......................................................................11
3.0 Setup.................................................................................................... 12
3.1 Power-up Routine ..........................................................................................12
3.2 Navigating the Router ....................................................................................12
3.3 Router Buttons and Menu Items ......................................................................13
3.3.1 PORT Button and Menus...............................................................................13
3.3.2 CTRL (Control) Button and Menus..................................................................14
3.3.3 METER Button and Menus.............................................................................18
3.3.4 SETUP Button and Menus .............................................................................23
3.3.5 TECH Button and Menus...............................................................................43
4.0 ME-ARTR Menu Maps ............................................................................ 48
5.0 Operation ............................................................................................. 54
5.1 Front Panel ...................................................................................................54
5.1.1 LED Indicators ............................................................................................54
5.1.2 LCD Display................................................................................................54
5.1.3 ON/OFF Buttons..........................................................................................55
5.1.4 Menu Buttons .............................................................................................55
5.1.5 Rotary SELECT Knob....................................................................................55
5.1.6 Aux Relay LED Indicator...............................................................................55
5.2 Operating the Inverter/Charger .......................................................................56
5.2.1 Inverter Mode.............................................................................................56
5.2.2 Charger Mode .............................................................................................56
5.3 System Status Messages ................................................................................56
5.3.1 Inverter Mode Status Messages.....................................................................57
5.3.2 Charger Mode Status Messages.....................................................................58
5.3.3 Secondary Scrolling Status Messages.............................................................63
5.3.4 Fault Mode Messages ...................................................................................66
5.3.5 LED Indicator Guide.....................................................................................74

Page iv © 2017 Sensata Technologies
Table of Contents (Cont.)
6.0 Troubleshooting ................................................................................... 75
6.1 Troubleshooting Tips ......................................................................................76
6.1.1 Inverter Problems .......................................................................................76
6.1.2 Charger Problems........................................................................................76
6.2 Performing an Inverter Reset ..........................................................................77
6.3 Powering Down the Inverter............................................................................77
7.0 Updating the ME-ARTR Router’s Firmware............................................ 78
8.0 Using an AGS Module............................................................................ 79
8.0.1 Software Differences Between AGS Versions ...................................................79
8.1 ME-AGS-N Setup (with the ME-ARTR) ...............................................................81
8.1.1 ME-AGS-N Functional Tests using the ME-ARTR ...............................................93
8.2 ME-AGS-N Operation/Monitoring (with the ME-ARTR)..........................................94
8.2.1 Controlling the AGS using the ME-ARTR..........................................................94
8.2.2 Enabling the ME-AGS-N................................................................................95
8.2.3 Monitoring the AGS using the ME-ARTR ..........................................................95
8.2.4 Starting and Stopping the Generator..............................................................98
8.2.5 ME-ARTR Router’s AGS Menu Maps ................................................................99
8.2.6 ME-AGS-N Router Status Messages ............................................................. 102
8.3 ME-AGS-N Router Troubleshooting (with the ME-ARTR)..................................... 105
8.3.1 AGS Fault Message Screens for the Router ................................................... 105
8.3.2 Resolving AGS Faults using your Router ....................................................... 106
9.0 Using a BMK .......................................................................................108
9.1 ME-BMK Setup (with the ME-ARTR) ................................................................ 108
9.1.1 Adjusting the Charge Efficiency Setting ........................................................ 108
9.2 ME-BMK Operation/Monitoring (with the ME-ARTR)........................................... 109
9.2.1 How does the ME-BMK Battery Monitor Operate? ........................................... 109
9.2.2 BMK METER Menu Items (with ME-ARTR)...................................................... 110
9.2.3 ME-ARTR Router’s BMK Menu Maps.............................................................. 112
9.2.4 BMK Status Messages (with the ME-ARTR) .................................................... 114
9.3 ME-BMK Troubleshooting (with the ME-ARTR) .................................................. 115
9.3.1 BMK Fault Message Screens for a Magnum Router ......................................... 115
9.3.2 Resolving BMK Faults using the Router......................................................... 115
10.0 Attaching a Remote Control................................................................ 116
11.0 Using an ACLD .................................................................................... 117
11.1 Setting Up the ACLD using the ME-ARTR ......................................................... 117
11.2 Monitoring the ACLD using the ME-ARTR ......................................................... 117
11.2.1 ME-ARTR’s ACLD METER Button Menus......................................................... 117
11.2.2 ME-ARTR Router’s ACLD-specific TECH Menus ............................................... 118
11.2.3 ACLD Menu Maps ...................................................................................... 118
11.2.4 ACLD Router Status Messages..................................................................... 119
11.3 ACLD Troubleshooting using the ME-ARTR....................................................... 120
11.3.1 ACLD Fault Message Screens ...................................................................... 120
11.3.2 Resolving ACLD Faults using the ME-ARTR .................................................... 120
12.0 Using a PT Charge Controller .............................................................. 121
12.1 Setting Up the PT Controller using the ME-ARTR............................................... 121

© 2017 Sensata Technologies Page v
Table of Contents (Cont.)
12.2 Operating/Monitoring the PT Controller using the ME-ARTR................................ 130
12.2.1 Operating the PT Charge Controller ............................................................. 130
12.2.2 Monitoring the PT Charge Controller............................................................. 133
12.2.3 PT Charge Controller Menu Maps ................................................................. 137
12.2.4 PT Charge Controller Router Status Messages ............................................... 142
12.3 PT Controller Troubleshooting using the ME-ARTR ............................................ 146
12.3.1 PT Controller Fault Message Screens............................................................ 146
12.3.2 Resolving PT Faults using the ME-ARTR ........................................................ 146
Appendix A – Router Display Abbreviations................................................. 151
Appendix B – Router Feature to Inverter Compatibility ............................... 156
Appendix C – Using the Router with Non-stacked Inverters ........................ 163
C-1 Using Router to Control Multiple Unconnected Inverters .................................... 163
Appendix D – Using the ME-ARTR in an AC Coupled Application .................. 164
D-1 What is an AC Coupled System...................................................................... 164
D-2 Configure the Router to use in an AC Coupled System ...................................... 164
Appendix E – Warranty and Service Info ..................................................... 165
E-1 Limited Warranty......................................................................................... 165
E-2 How to Receive Repair Service ......................................................................165
Index .......................................................................................................... 166
List of Figures
Figure 1-1, Front Panel Features ...................................................................................... 1
Figure 1-2, Router Features (front cover removed)............................................................. 2
Figure 2-1, System Overview .......................................................................................... 4
Figure 2-2, Router Dimensions (with Front Cover).............................................................. 5
Figure 2-3, Router Mounting Holes and Cutout Sections (back) ............................................ 5
Figure 2-4, Remote (RJ14) Communication Cable .............................................................. 6
Figure 2-5, Parallel Stack (RJ45) Communication Cable ...................................................... 6
Figure 2-6, Concealed Mounted Remote/Network Cables..................................................... 7
Figure 2-7, Surface Mounted Remote/Network Cables......................................................... 7
Figure 2-8, Router Front Cover’s Cable Connection Cutouts ................................................. 7
Figure 2-9, Mounting the Router to a Wall ......................................................................... 8
Figure 2-10, Connecting the Parallel Stack and Remote Cables to an Inverter ........................ 9
Figure 2-11, Connecting the Parallel Stack Cables to the Router..........................................10
Figure 2-12, Installing the Router’s Front Cover................................................................10
Figure 2-13, Wiring the Auxiliary Relay ............................................................................11
Figure 3-1, System Home Screen ...................................................................................12
Figure 3-2, Up and Down Arrows for Hidden Lines.............................................................12
Figure 3-3, PORT Button................................................................................................13
Figure 3-4, CTRL (Control) Button and Menus...................................................................14
Figure 3-5, METER Button and Menus..............................................................................18
Figure 3-6, Current Flow – Inverter Mode ........................................................................21
Figure 3-7, Current Flow – Standby Mode ........................................................................21
Figure 3-8, Current Flow – Load Support Mode .................................................................21
Figure 3-9, ALL Ports vs Port-specific METER Menus ..........................................................22
Figure 3-10, Accessing Port-specific METER Menus ............................................................22
Figure 3-11, SETUP Button ............................................................................................23

Page vi © 2017 Sensata Technologies
List of Figures (Cont.)
Figure 3-12, CV Charge Done Time/Amps Charge Stages ...................................................35
Figure 3-13, Hold CV Charge Volts CC/CV Charge Stages ...................................................36
Figure 3-14, Final Charge Stage – Multi-Stage..................................................................41
Figure 3-15, Final Charge Stage – Float ...........................................................................41
Figure 3-16, Final Charge Stage – Silent..........................................................................41
Figure 3-17, TECH Button ..............................................................................................43
Figure 3-18, Port-Specific TECH Menus ............................................................................44
Figure 3-19, Inverter Fault History (first and second screens) .............................................45
Figure 3-20, AGS Fault History .......................................................................................45
Figure 3-21, PT Controller Fault History (first and second screens) ......................................45
Figure 4-1, PORT/CTRL Button Menu Maps .......................................................................48
Figure 4-2, METER Button (ALL Ports & Port-specific) Menu Map..........................................49
Figure 4-3, SETUP Button (System and Inverter Setup – ALL Ports) Menu Map......................50
Figure 4-4, SETUP Button (Charger Setup – ALL Ports) Menu Map .......................................51
Figure 4-5, TECH Button (ALL Ports) Menu Map ................................................................52
Figure 4-6, TECH Button (Single Ports) Menu Map.............................................................53
Figure 4-7, Legend Key for Menu Maps ............................................................................53
Figure 5-1, ME-ARTR Front Panel Controls and Indicators ...................................................54
Figure 5-2, Aux Relay LED .............................................................................................55
Figure 5-3, SYSTEM Status Home Screens .......................................................................57
Figure 5-4, Empty ........................................................................................................57
Figure 5-5, Inverting Mode ............................................................................................57
Figure 5-6, Inverter Standby Mode .................................................................................58
Figure 5-7, Off Mode.....................................................................................................58
Figure 5-8, Searching Mode ...........................................................................................58
Figure 5-9, Unknown Mode ##.......................................................................................58
Figure 5-10, Absorb Charging Mode ................................................................................59
Figure 5-11, Bulk Charging Mode....................................................................................59
Figure 5-12, Charger Standby Mode................................................................................59
Figure 5-13, Charging Mode...........................................................................................59
Figure 5-14, Constant Current Mode ...............................................................................60
Figure 5-15, Constant Voltage Mode................................................................................60
Figure 5-16, Equalizing Mode .........................................................................................60
Figure 5-17, Float Charging Mode ...................................................................................61
Figure 5-18, Full Charge Mode........................................................................................61
Figure 5-19, Load Support AAC Mode ..............................................................................62
Figure 5-20, Load Support VDC Mode..............................................................................62
Figure 5-21, Silent Mode ...............................................................................................62
Figure 5-22, AC In – Disabled Mode ................................................................................63
Figure 5-23, Gen Cooldown Mode ...................................................................................63
Figure 5-24, Gen Warm-up Mode ....................................................................................63
Figure 5-25, Inv Max Charge Time Mode..........................................................................64
Figure 5-26, PT Max Charge Time ...................................................................................64
Figure 5-27, Reminder to EQ Mode .................................................................................65
Figure 5-28, SOC Connect Mode .....................................................................................65
Figure 5-29, Time Connect Mode ....................................................................................65
Figure 5-30, VDC Connect Mode .....................................................................................65
Figure 5-31, AC Backfeed Mode ......................................................................................66

© 2017 Sensata Technologies Page vii
List of Figures (Cont.)
Figure 5-32, AC Overload Fault.......................................................................................66
Figure 5-33, Breaker Tripped Fault ..................................................................................67
Figure 5-34, Dead Battery Charge Fault ...........................................................................67
Figure 5-35, FET Overload Fault......................................................................................67
Figure 5-36, High Battery Fault ......................................................................................68
Figure 5-37, High Battery Temperature............................................................................68
Figure 5-38, High Speed Bus Fault ..................................................................................68
Figure 5-39, High Volts AC Fault .....................................................................................69
Figure 5-40, Low Battery Fault .......................................................................................69
Figure 5-41, No Inverter Found! .....................................................................................69
Figure 5-42, Overcurrent Fault .......................................................................................70
Figure 5-43, Overtemp Fault ..........................................................................................70
Figure 5-44, Stuck Relay Fault........................................................................................70
Figure 5-45, Tfmr Overtemp Fault...................................................................................71
Figure 5-46, Unknown Fault ##......................................................................................71
Figure 5-47, StackClock Fault.........................................................................................72
Figure 5-48, Stack Mode Fault ........................................................................................72
Figure 5-49, StackPhase Fault ........................................................................................72
Figure 5-50, Internal Bridge Fault ...................................................................................73
Figure 5-51, Internal Charger Fault .................................................................................73
Figure 5-52, Internal NTC Fault ......................................................................................73
Figure 5-53, Internal Relay Fault ....................................................................................73
Figure 6-1, Performing an Inverter Reset .........................................................................77
Figure 7-1, ME-ARTR Router’s Firmware SD Card Slot ........................................................78
Figure 8-1, ME-ARTR’s AGS Configuration Access Buttons...................................................79
Figure 8-2, AGS PORT, CONTROL, METER, and TECH Menu Maps.........................................99
Figure 8-3, AGS SETUP Menu Maps (Section 1)............................................................... 100
Figure 8-4, AGS SETUP Menu Maps (Section 2)............................................................... 101
Figure 8-5, ME-AGS-N Fault Message – Router Screens.................................................... 105
Figure 9-1, Ending Battery Voltage Versus Time.............................................................. 110
Figure 9-2, BMK SETUP Menu Maps............................................................................... 112
Figure 9-3, BMK METER Menu Maps (ALL Ports) .............................................................. 113
Figure 9-4, BMK METER Menu Map (Port-specific) ...........................................................113
Figure 9-5, ME-BMK Fault Message – Router Screens....................................................... 115
Figure 10-1, Accessing the RC Setup Menu .................................................................... 116
Figure 11-1, ACLD METER Menu Map............................................................................. 118
Figure 11-2, ACLD Fault Message (Example) ..................................................................120
Figure 12-1, CV Charge Done Time/Amps (PT Controller)................................................. 123
Figure 12-2, Hold CV Charge Volts (PT Controller)........................................................... 124
Figure 12-3, Multi-Stage Charging (PT Controller) ........................................................... 125
Figure 12-4, PT Charge Controller CTRL Menu Map.......................................................... 137
Figure 12-5, PT Charge Controller METER Menu Map ....................................................... 138
Figure 12-6, PT Charge Controller Data History Matrix Menu Map ...................................... 139
Figure 12-7, PT Charge Controller SETUP1 Menu Map ...................................................... 140
Figure 12-8, PT Charge Controller SETUP2 Menu Map ...................................................... 141
Figure 12-9, PT Controller Fault Message (Example) ........................................................ 146

Page viii © 2017 Sensata Technologies
List of Tables
Table 3-1, Battery Type to Charge Voltages ......................................................................33
Table 3-2, Battery Amp/Hrs Capacity to Suggested Absorb Time .........................................37
Table 3-3, Inverter/Charger Default Settings on ME-ARTR ..................................................47
Table 5-1, LED Indicator Guide .......................................................................................74
Table 6-1, Router Troubleshooting Guide..........................................................................75
Table 8-1, Software Differences Between AGS Versions......................................................80
Table 8-2, ME-ARTR Autostart/Autostop Matrix .................................................................81
Table 8-3, AGS Router Operational Statuses ................................................................... 102
Table 8-4, AGS Router Start Statuses ............................................................................ 103
Table 8-5, AGS Router Fault Statuses ............................................................................ 103
Table 8-6, AGS Default Settings on ME-ARTR.................................................................. 104
Table 9-1, BMK Router Operational Statuses................................................................... 114
Table 9-2, BMK Router Fault Statuses ............................................................................ 114
Table 11-1, ACLD Router Operational Statuses................................................................ 119
Table 12-1, PT Default Settings on ME-ARTR................................................................... 137
Table 12-2, PT Controller Router Operational Statuses ..................................................... 142
Table 12-3, PT Router Relay Statuses ............................................................................ 142
Table 12-4, PT Router Fault Statuses ............................................................................. 143
Table 12-5, PT Router Charge Modes ............................................................................. 144
Table 12-6, PT Router Power Statuses ........................................................................... 145
Table A-1, Abbreviations on Router Display .................................................................... 151
Table B-1, ME-ARTR (Version 4.0) Compatibility Matrix .................................................... 156

Introduction
© 2017 Sensata Technologies Page 1
LCD
Display
Inverting
FacFault Gen Off
29.3VDC -99.0ADC
ALL System Home
The ME-ARTR is equipped with the following features:
• Status LEDs (x4) –At-a-glance LEDs that provide the inverter/charger’s status in a
straightforward way.
• LCD Display –A 20 x 4 line (80 characters total) alphanumeric display used for setting up the
inverter/charger operation, as well as viewing current status or fault messages.
• ON/OFF Buttons (x2) –ON/OFF buttons that allow all the connected inverters or chargers
to be quickly enabled or disabled.
Info: The router’s ON/OFF INVERTER and ON/OFF CHARGER buttons function normally
when a ME-ARC is connected through the router in a parallel system.
• Rotary SELECT Knob –A rotary encoder knob that is similar to a car dash radio knob and
is used to quickly scroll through Ports 1-6, or to select various menu items and settings.
Pressing this rotary knob allows you to select a menu item or to save a setting, once it is
displayed on the LCD.
• Comm LEDs (x6) – At-a-glance LEDs that provide the connection statuses of the
communication ports.
• Front Cover – Removable front frame cover, allows access to the cable connections and
mounting holes.
Figure 1-1, Front Panel Features
1.0 Introduction
The ME-ARTR (or “advanced router”) has many of the same features as the ME-ARC, with
the added functionality required to parallel Magnum MS-PAE or MS-PE inverter/chargers. The
advanced router is designed to easily and quickly connect multiple inverter/chargers in parallel
without the need to program each inverter. The ME-ARTR can accommodate up to: four MS-PAE
or MS-PE inverter/chargers in parallel, two AGS modules, six BMKs, and one remote control.
Info: This manual is for the ME-ARTR with version 4.0 or higher; see the TECH: 02 Port
Vers section on page 44 for information on how to determine your version level.
Rotary
SELECT
Knob
Comm
LEDs
PORT, CTRL, METER,
SETUP, TECH Buttons
Front
Cover
Status
LEDs
ON/OFF
Buttons

Introduction
Page 2 © 2017 Sensata Technologies
• Menu Buttons (x5) – Allow the inverter or charger to be configured to your specific system
preferences. These buttons also allow simple access to menu items that can help with
monitoring and troubleshooting your inverter/charger system.
PORT Button –This button accesses the six communication and accessory ports to display
information on the connected devices.
CTRL Button –This button is used to select inverter, charger, and AGS functions previously
set up using the SETUP button.
METER Button – This button is used to access ‘read only’ DC, AC, Timer, AGS, and BMK
meters.
SETUP Button –This button is used to access setup menus for the inverter, charger, AGS,
and BMK. The SETUP button may be password protected to keep unauthorized users from
accessing the SETUP menus.
TECH Button –This button is used to access technical information, fault history, and to set
a password for the SETUP button.
• Auxiliary (Aux) Relay – The ME-ARTR provides an Auxiliary Relay (Item G below) that can
be programmed to work either as a voltage-controlled relay (stays opened or closed based
on VDC, and activates either as an active high or active low type relay with an adjustable
time delay), a SOC-controlled relay (stays opened or closed based on the battery’s state of
charge*), or used as an inverter fault detection relay (opens if an inverter fault occurs). See
Section 2.9 for more information on this relay, as well as instructions on how to wire and set
up the Aux Relay (using the CTRL button’s 04 ARTR Aux Relay menu).
*Requires the optional ME-BMK (Battery Monitor Kit) to be installed.
• SD Card Slot – Allows you to download and install updated firmware from the Magnum
Energy product website—using a standard SD memory card. See Section 7.0 for more info.
Figure 1-2, Router Features (front cover removed)
B
F
ED C
G
A
H
A
B
C
D
E
G
H
I
I
F
Mounting tabs for front cover
Parallel stack ports (x4)
Six LEDs for communication (P1-P6)
LED for future use (not functional)
LED for Aux Relay operation
Mounting screw holes (x4)
Aux Relay 2-wire terminal
Six Comm ports (P1-P6)
SD Card Slot

Installation
© 2017 Sensata Technologies Page 3
2.0 Installation
Review this section and the important safety information on page ii before proceeding with the
installation of your router.
WARNING: Installations should be performed by qualified personnel, such as a licensed
or certified electrician. The installer determines which safety codes apply and ensures
all applicable installation requirements are followed. Applicable installation codes vary
depending on the specific location and application.
CAUTION: When connecting battery power to the inverter, all battery negative
connections must be connected prior to the battery positive connections. When removing
battery power from the inverter, the battery positive should be removed before any
battery negative connections are disconnected. This prevents any communication chips/
lines from becoming the DC return path to the battery—causing permanent damage to
all connected accessories.
Summation: Ensure all battery negative circuits are always connected before connecting
or disconnecting battery positive.
2.1 Pre-Installation
Before proceeding, read the entire Installation section to determine how you are going to install
your ME-ARTR router. Save time and avoid common, costly mistakes by thoroughly planning the
installation before you start.
2.1.1 Inverter Requirements
The router is used to control multiple Magnum inverters that are normally connected in parallel.
Each connected inverter must: be the same model (i.e., two MS4024PAEs), use the same settings,
and be connected to the same battery bank. If the inverters are not stacked, see Appendix C.
2.1.2 Installation Guidelines
• Before connecting any wires, determine the router’s cable route throughout the home or
vehicle/boat—both to and from the inverter.
• Always check for existing electrical, plumbing, or other areas of potential damage BEFORE
drilling or cutting into walls to mount the router.
• Make sure all wires have a smooth bend radius and do not become kinked.
• If installing this router in a boat, RV or truck, ensure the conductors passing through walls,
bulkheads, or other structural members are protected. This minimizes insulation damage
(such as chafing) which can be caused by vibration or constant rubbing.
2.1.3 Unpacking and Inspection
Carefully remove the ME-ARTR router from its shipping container and inspect all contents. Verify
the following items are included:
• ME-ARTR router (with removable front cover)
• Two 6’ RJ14 remote cables (see Figure 2-4)
• Two 6’ RJ45 stack cables (see Figure 2-5)
• Four #8 x 3/4 Phillips screws (for wall mounting)
• ME-ARTR Owner’s Manual
If items appear to be missing or damaged, contact an authorized Magnum Energy dealer or
Sensata Technologies.
IMPORTANT: Save your proof-of-purchase as a record of your ownership; it is needed if the unit
should require in-warranty service.
2.1.4 Tools Required
Installing the router is simple and requires the following tools:
• Phillips screwdriver • Level • Drill
• Cut-out tool (knife/saw) • Pencil • Drill bit (7/64”)

Installation
Page 4 © 2017 Sensata Technologies
Figure 2-1, System Overview
REMOTE cables (x4) from
router to each inverter’s
REMOTE Port (blue)
Network or
Remote cable
from
ME-AGS-N to
Network Port
(green)
Cables from router to ME-BMK and
ME-ARC, or to ME-AGS-N
#3
MS-PAE
INVERTER
(SLAVE 2)
#2
MS-PAE
INVERTER
(SLAVE 1)
#4
MS-PAE
INVERTER
(SLAVE 3)
#1
MS-PAE
INVERTER
(MASTER)
MA
SL1
SL2
SL3
P1 P2 P3 P4 P5 P6
ME-AGS-N
ME-BMK
ME-ARC
Stack cables
(x4) from
router to each
inverter’s
Stack Port
(red)
2.2 Installation Overview
The simplified system diagram shown in Figure 2-1 should be reviewed to assist you with planning
and designing your installation. This drawing is not intended to override or restrict any national
or local electrical codes, nor should it be the determining factor as to whether the installation is
compliant—that is the responsibility of the electrician and the onsite inspector.

Installation
© 2017 Sensata Technologies Page 5
FRONT
VIEW
8 15/16"(22.7 cm)
RIGHT
SIDE
1 9/16"
(4 cm)
6 5/8"
(16.8 cm)
BOTTOM
VIEW 5/8"
(1.6 cm)
1 9/16"
(4 cm)
15/16"
(2.4 cm)
7 1/16"(17.9 cm)
15/16"
(2.4 cm)
1 1/8 "
1 3/4 ”
5/16"
2 1/4 ”
5/8"
1
5/16 "
1 3/8 "
3/8"
1"
1
1/16 "
(2.7 cm)
2 11/16 "
(6.8 cm)
1 3/16 "(3 cm)
2 3/4 "
(7 cm)
6 7/16 "
(16.4 cm)
3/8"
(0.9 cm)
8" (20.3 cm)
8
3/4 " (22.2 cm)
1/2"
(1.3 cm)
7/16"
(1.1 cm)
5 1/2 "
(14 cm)
(2.5 cm)
(3.3 cm)
(5.7 cm)
(4.5 cm)
(2.9 cm)
(0.8 cm) (1.6 cm)
(3.5 cm)
3/8"
(0.9 cm) 3/8"
(0.9 cm)
A
BCD
2.3 Router Dimensions
Figure 2-2, Router Dimensions (with Front Cover)
Figure 2-3, Router Mounting Holes and Cutout Sections (back)

Installation
Page 6 © 2017 Sensata Technologies
2.4 Communications Cables – Provided
The ME-ARTR router comes with four six-foot, yellow communication cables. These cables—
shown below—are provided to make connections between the router and your inverter easier and
code compliant. Two of the communications cables are remote (RJ14) cables, and the other two
are parallel stack (RJ45) cables.
Most systems that use the router will also use an enclosure that includes the components required
in a parallel inverter system (i.e., Magnum Energy panels). The NEC/CEC requires the insulation
of all conductors inside the enclosure to be rated for the highest voltage present. The router is
designed to work with 120/240 VAC inverters, therefore, the voltage rating of the communications
cables inside the enclosure must be rated for 300 volts or higher to be code compliant. These
communications cables have 300-volt rated insulation, to meet NEC/CEC requirements DO NOT
substitute for the supplied cables—most cables do not have the properly rated insulation.
Info: These cables carry less than 30 volts and are thus considered a “limited energy
circuit”, which is normally not required to be installed in conduit.
Info: Additional stack cables are available with the purchase of a MPX Series enclosure.
Stack cables are not sold separately. If NEC/CEC requirements do not apply, a CAT 5
cable (RJ45/8P8C) can be used. However, this CAT 5 cable must be no longer than 6
feet—this ensures there is no communication issue as these cables transmit/receive
high speed data.
Figure 2-4 shows a ‘REMOTE’ cable (two are
supplied). This cable is 6’ (1.83m), with a RJ14
6P4C (6-position/4-conductor) telephone-type
male connector and a blue REMOTE label on
each end. It comes with 300-volt rated, yellow
insulation. One end of this cable is connected to
one of the communication ports (P1-P6) on the
router (see Figure 2-6 or 2-7), and the other
end is connected to the inverter’s Remote port
(normally routed inside the MP enclosure) as
shown in Figure 2-10. Figure 2-4, Remote (RJ14)
Communication Cable
Figure 2-5, Parallel Stack (RJ45)
Communication Cable
Figure 2-5 shows a ‘STACK’ cable (two are
supplied). This cable is 6’ (1.83m), with a RJ45
8P8C (8-position/8-conductor) connector on
each end. It comes with 300-volt rated, yellow
insulation. One end of this cable is connected to
one of the stacking ports (MA-SL3) on the router
(see Figure 2-11), and the other end is connected
to the inverter’s Stack/Accessories port (normally
routed inside the MP enclosure) as shown in
Figure 2-10.
2.4.1 Network Cable
A network cable is not supplied with the router, but is included with the purchase of our networked
accessories (i.e., ME-AGS-N, ME-BMK). If stacking inverters on Magnum Energy’s MP Series
enclosures, the regular network cable must be replaced with a high voltage network cable, which
is included with the purchase of the MP Series enclosure. This cable has 300-volt rated yellow
insulation, is 6’ (1.83m) long, and has a RJ14 6P4C (6-position/4-conductor) telephone-type
male connector on each end. One end of this cable is connected to the accessory, and the other
end is connected to the router’s Comm port or the inverter’s Network port (see Figure 2-11). This
cable is wired similar to the remote cable, and can be substituted for the remote cable, if needed.

Installation
© 2017 Sensata Technologies Page 7
BOTTOM VIEW – ROUTER COVER
Remote and network cable cutouts (x9)
RIGHT SIDE VIEW – ROUTER COVER
Stack cable cutouts (x4)
Figure 2-8, Router Front Cover’s Cable Connection Cutouts
Info: If the cables are installed on the surface, the router’s front cover has cutout
sections to accommodate the cables (see Figure 2-8). These cutout sections are made
thinner to allow them to be easily broken or cut. Only remove those cutout sections
needed for the number of cable connections you are installing.
Figure 2-6, Concealed Mounted
Remote/Network Cables
2.5 Communications Cable Routing
Before mounting the router on a wall, determine whether to surface mount or to conceal the cable
connections to the router. The cables can be flush-mounted (concealed) through an opening in a
wall (Figure 2-6); or, if there is insufficient room behind the wall or no desire to cut into the wall,
the cables can be surface-mounted (Figure 2-7).
Info: If the router is being installed on a Magnum Energy panel enclosure (MP), a
router mounting bracket is provided with the panels. This bracket can be attached to
either the left or right-hand side. Refer to the MP Owner’s manual (PN: 64-0028) for
information on mounting the router on a MP panel.
Figure 2-7, Surface Mounted
Remote/Network Cables

Installation
Page 8 © 2017 Sensata Technologies
A
BCD
Figure 2-9, Mounting the Router to a Wall
2.6 Mounting the Router on a Wall
CAUTION: The router must be located close to the inverter/chargers (within six feet).
The router is designed to exchange data from the master inverter with one or multiple
slave inverters. The high speed communication data between the stack ports on the
router and the inverter ensure the slave inverters are synchronized to the master
inverter. To ensure those communications are not impacted, DO NOT exceed the 6-foot
stack cable distance between the router and each connected inverter.
Info: If a more distant monitoring location is required (more than six feet), a ME-RC50
or ME-ARC50 remote control may be connected and acts as a remote on/off switch to
assist in monitoring the system. See Section 10.0 for more information.
To mount the router on the surface of a wall:
1. Select an appropriate location to install the router (see Figures 2-2 & 2-3 for the router’s
dimensions).
2. Remove the router’s front cover, and then use the router bezel as a template to mark the
screw holes and the sections of the wall (or mounting surface) to remove to accommodate the
routing of the communication wires (Sections A-D on Figure 2-9).
Note: If you are not routing the communication wires thru the wall, there is no need to cut
sections from the wall.
3. Once the screw holes have been drilled and the optional wall sections are removed, mount the
router bezel to the wall using the 4 screws that are provided.
2.7 Connecting the Communication Cables
The stack and remote communication cables are used to connect each inverter/charger directly
to the router. A network cable is used to connect any accessories to the router.
Each paralleled inverter/charger requires a high speed parallel stack cable connected to a stack
port on the router—marked MA (Master), SL1 (Slave 1), SL2 (Slave 2), and SL3 (Slave 3)—see
Figure 2-1. One inverter/charger will always be designated the “Master”, and subsequently any
other connected inverter/chargers are designated as “Slaves”. You can stack up to four MS-
PAE or MS-PE Series inverter/chargers using one router. It is recommended that you set up the
Master inverter as the first unit on the left, and Slave 1 as the second unit, etc.

Installation
© 2017 Sensata Technologies Page 9
Connect the parallel stack cable to the top
port (red) marked “Stack/Accessories.”
Connect the remote cable to the port (blue)
marked “Remote.”
Connect the network cable to the port (green)
marked “Network.”
Figure 2-10, Connecting the Parallel Stack and Remote Cables to an Inverter
2.7.1 Connecting the Remote/Network Cables
To connect the remote cables:
1. Connect a remote cable to the Remote port on every inverter installed in parallel (see Figures
2-1 & 2-10), using the supplied cables.
2. Route the inverter-connected remote cables from each inverter/charger to your router. Follow
the same route you used for the stack cables.
3. Connect each remote cable to its respective communication port on the router (P1-P6 per the
number of inverters installed in parallel). Refer to Section 2.4 and Figures 2-6 & 2-7.
4. Connect any accessories to the remaining open communication ports on the router using a
network cable.
Info: A maximum of four inverters can be connected to a router to work in parallel with
each other. If the maximum number of inverters are connected, two open ports remain.
If a ME-ARC or ME-RC remote is connected to a router, it must be connected directly to
a remote communication port on the router. If there are still open communication ports
on the router, connect any accessories—i.e., an ME-AGS-N or ME-BMK—directly to the
router first. Then, if all the router’s communication ports are being used and there are
additional accessories, they may be connected to the Network ports on the inverters.
Info: Any accessory connected directly to the Network port on an inverter displays as
an accessory on the router port to which that inverter is connected.
Example: A ME-AGS-N connected to the Network port on the master inverter (P1)
displays as P1A on the router.
Info: Multiple accessories of the same type may be connected to the system, but there
are limitations to the number of accessories. You may connect a maximum of one ME-
RC or ME-ARC remote, two ME-AGS-N modules, and up to six ME-BMK/ME-BMK-NS
accessories.
Once the stack cables are connected, coordinate the remote cables to the communications ports
so that the Master inverter is connected to Port 1 and the Slave 1 inverter is connected to Port
2 (the remote and stack cables are connected to the inverters in order from left to right—MA
(Master), SL1, SL2, and SL3). This configuration makes it easy to keep track of which inverter is
displayed on each port, and allows you to identify the master and slave units without having to
trace the wires from the router to each inverter.

Installation
Page 10 © 2017 Sensata Technologies
2.8 Installing the Router’s Front Cover
Once all the wiring is completed, you are ready to re-install the front cover (if using the router’s
Aux Relay, refer to Section 2.9 before re-installing the front cover). If you have surface mounted
your router, you must first remove those cutout sections from the front cover that are needed for
the number of cable connections you have installed (see Figure 2-8).
Tip the top of the front cover down and hook it over the router top (protruding horizontal tabs
on inside top of the front cover go under corresponding mounting tabs at top of router), and
then drop the front cover down (cover the router’s bottom vertical tabs). Install the two flathead
Phillips screws into the bottom tabs to hold the front cover in place (see Figure 2-12).
Figure 2-12, Installing the Router’s Front Cover
MA
SL1
SL2
SL3
Figure 2-11, Connecting the Parallel Stack Cables to the Router
2.7.2 Connecting the Parallel Stack Cables
To connect the parallel stack cables:
1. Connect a stack cable to the Stack/Accessories port on every inverter installed in parallel (see
Figures 2-1 & 2-10).
2. Route the inverter-connected stack cables from each inverter/charger to your router.
Depending on your particular setup, the cables may need to be routed through walls or the
MP panel enclosure system.
3. Connect each stack cable to its respective stack port on the router (MA, SL1, SL2, and SL3
ports for the appropriate number of inverters installed in parallel). See Figure 2-11.
Info: At least one stack cable must be plugged into the router’s MA port in order for the
router to operate any inverters.
Push front cover
down flush, and
install screws in
bottom tabs.
Place front
cover over
tabs at top.

Installation
© 2017 Sensata Technologies Page 11
2-wire dry
contact
terminal
Figure 2-13, Wiring the Auxiliary Relay
2.9 Wiring the Auxiliary (Aux) Relay
The router’s Aux Relay provides a 2-wire dry contact relay (i.e., no voltage provided) that is
either open or closed, and can be wired to any device requiring a contact closure to operate. For
example, it can be used as a signal relay to power a higher current relay.
Relay Information
• A single-pole, single-throw relay provided with the NO (Normally Open) and COM contacts.
• Contact rating: up to 30 VDC @ 1 amp, and from 31 VDC up to 60 VDC @ .25 amp.
• Opens if power to the router (provided through the inverter remote cable) is lost.
• Provides “dry contact” connections (it does not provide any voltage or current)—power for
any external device requiring voltage or current must be provided through the relay.
• This relay is not intended to directly provide power. Rather, this relay can be used to send a
signal to operate the coil of another higher amperage device that does the actual switching
of power.
CAUTION:
• Any voltage connected to the relay must be less than or equal to the relay’s contact
ratings (Contact ratings: ≤1A up to 30 VDC, ≤.25A from 31 VDC to 60 VDC).
• An in-line fuse rated up to 1 amp (up to 30 VDC) or .25 amp (from 31 VDC to 60
VDC) must be used to protect all power circuits connected to the router’s Aux Relay
(do not fuse ground connections). The fuse should be located as close as possible to
the power source. A fuse must be used, even if the circuit is providing only a “dry
contact” or “ground” connection—it prevents damage if the connection is miswired
or damaged. Ensure the fuse is correctly rated for the wire size used. Refer to
national and local codes for rating and type.
• The router’s Aux Relay circuit is not rated for AC volts (may cause damage if used).
• The warranty does not cover damage to this relay.
Relay Terminal Block
The router’s Aux Relay is wired through an Euro-style removable connector (Figure 2-13). The
connector provides a two-port screw-type terminal block for wiring. This terminal block is friction-
fit into the connector and can be removed by pulling it straight out. Each port on the terminal
block accepts a CU/AL single wire from #28 to #12 AWG (0.3 to 2.3 mm²).
Info: For information on setting the router’s Aux Relay, refer to the CTRL: 04 ARTR Aux
Relay menu.
