UfiSpace S9705-48D Manual

Hardware Installation Guide
S9705-48D
Core/Edge Router
R1.0

S9705-48D Hardware Installation Guide | i
Table of Contents
1Overview............................................................................................................................... 1
2Preparation...........................................................................................................................2
Installation Tools......................................................................................................................2
Installation Environment Requirements .................................................................................3
Preparation Check List.............................................................................................................4
3Package Contents..................................................................................................................5
Accessory List...........................................................................................................................5
Component Physical Information............................................................................................6
4Identifying Your System ........................................................................................................7
S9705-48D Overview ...............................................................................................................7
PSU Overview...........................................................................................................................7
Fan Overview ...........................................................................................................................8
Port Overview ..........................................................................................................................9
5Rack Mounting.................................................................................................................... 10
6Installing Fan Modules ........................................................................................................ 13
7Installing Power Supply Units.............................................................................................. 14
8Grounding the Router ......................................................................................................... 16
9Connecting Power............................................................................................................... 18
DC Version .............................................................................................................................18
AC Version..............................................................................................................................20
10 Verifying System Operation ................................................................................................ 22
Front Panel LED....................................................................................................................22
PSU FRU LED ........................................................................................................................23
Fan FRU LED.........................................................................................................................23
11 Initial System Setup ............................................................................................................ 24
12 Cable Connections............................................................................................................... 25
Connecting the USB Extender Cable....................................................................................25
Connecting the Transceiver.................................................................................................25
13 Cautions and Regulatory Compliance Statements ............................................................... 27
Cautions and Regulatory Compliances................................................................................27

S9705-48D Hardware Installation Guide | 1
1Overview
The UfiSpace S9705-48D enables the disaggregated architecture required to fulfill the high
traffic loading in a 5G mobile Ethernet network. As part of UfiSpace’s S9700 Series, the
S9705-48D is a robust fabric switch that used to interconnect the S9710-76D, S9700-53DX
and/or S9700-23D routers into pay-as-you-grow cluster sizes. Suitable for core networking,
the S9705-48D is one of the essential building blocks to provide carriers with a better
solution in place of the traditional chassis.
With redundant power supplies and fans together with a high port density design, our
S9705-48D delivers high system reliability, switching performance and intelligence to the
network and helps reduce infrastructure and administrative costs.
This document describes the technical specifications designed for S9705-48D.

S9705-48D Hardware Installation Guide | 2
2Preparation
Installation Tools
Phillips #2 Screw Driver
6-AWG green-and-yellow wire for grounding
Crimping tool
Wire stripping tool
All illustrations within this document are for reference purposes only. Actual
objects may differ.
•PC with terminal emulation software. Refer to the "Initial System Setup" section for
details.
•Baud rate: 115200 bps
•Data bits: 8
•Parity: None
•Stop bits: 1
•Flow control: None

S9705-48D Hardware Installation Guide | 3
Installation Environment Requirements
•Power Reserve: The S9705-48D power supply is available with:
1. DC Version: 1+1 Redundant and hot swappable, active/active -48V voltage DC power supply
field replaceable unit or;
2. AC Version: 1+1 Redundant and hot swappable, active/active 200V to 240V AC power
supply field replaceable unit.
To ensure the redundant, active/active feed power design functions properly, a field with
dual power circuit is recommended with a reserve of at least 1500 watts on each power
circuit.
•Space Clearance: The S9705-48D chassis width is 17.16 inches (43.6cm) and is shipped with an
adjustable mounting rail kit suited for standard 19 inch (48.3cm) wide racks. The depth of the
S9705-48D chassis is 30 inches (76.2cm) without the field replaceable units (FRUs). The handle
of fan FRU is 1 inch (2.5cm) and the handle of the PSU FRU is 1.5 inches (3.8cm). Therefore, to
accommodate the fan, power supply handles, airflow and cabling, a minimum space
clearance of 6 inches (15.2cm) is needed at front and back of the S9705-48D. A total
minimum reserve depth of 42 inches (106.6cm) is required.
Figure 1.
• Cooling: The S9705-48D airflow direction is front-to-back. Make sure the equipment on
the same rack have the same airflow direction.
Figure 2.

S9705-48D Hardware Installation Guide | 4
Figure 3.
Preparation Check List
Task
Check
Date
Power voltage and electric current requirement
DC version: -40 to -72V DC, 60 to 33 x 2 ampere maximum or;
AC version: 200 to 240V AC, 12.5 x 2 ampere maximum
Installation spacing requirement
S9705-48D chassis spacing requires a height of 2RU (3.45”/8.8cm), a
width of 19” (48.3cm), and a depth of 42 inches (106.6cm)
Thermal requirement
S9705-48D working temperature is 0°C to 45°C (32°F to 113°F),
airflow direction is front-to-back
Installation tools required
#2 Philips screwdriver, wire-stripping tools for stripping 6-AWG,
crimping tool for ground lug
Accessories required
PC with USB ports and terminal emulation software

S9705-48D Hardware Installation Guide | 5
3Package Contents
Accessory List
Item
Description
Spec. & Dimensions
Qty.
Weight
1
Grounding Lug
DC Version:
1.54” x 1.47” x 0.49”
(# 6 AWG)
(39 x 37.5 x 12.5mm)
5 pcs
0.14lbs (63.6g)/5 pcs
AC Version:
1.54” x 1.47” x 0.49”
(# 6 AWG)
(39 x 37.5 x 12.5mm)
1 pcs
0.03lbs (15.3g)/1 pcs
2
Screw Kit (for
Grounding Lug)
2 x Screw M4*L8.0mm
2 x M4 Lock Washers
2 sets
0.01lbs (2.6g)/1 set
3
Micro USB Cable
3.28’ (1m)
1 pcs
0.05lbs (24.4g)/1 pcs
4
RJ45 to DB9 Female
Cable
8’ (2.4m)
1 pcs
0.23lbs (105g)/1 pcs
5
Adjustable Mounting
Rail (for 4 post)
30.4” x 1.7” x 0.9”
(771 x 44 x 22mm)
(22”~33” rack depth)
2 pcs
7.01lbs (3.2kg)/2 pcs
(3.5lbs (1.6kg)/1 pcs)
6
Screw Kit
(for Rack Mount Rail)
2 x Screw M4.0*L5.5mm
2 sets
0.004lbs (1.9g)/1 set

S9705-48D Hardware Installation Guide | 6
Component Physical Information
Specification
Item
Description
Weight
Total package contents
54.89lbs (24.9kg)
Chassis without FRU
45.19lbs (20.5kg)
Power Supply Unit (PSU)
DC PSU: 2.65lbs (1.2kg)
AC PSU: 2.65lbs (1.2kg)
Fan module
1.10lbs (498g)
Ground lug
0.15lbs (66.2g)
Adjustable mounting rail
7.05lbs (3.2kg)
Micro USB cable
0.05lbs (24.4g)
RJ45 to DB9 Female cable
0.23lbs (105g)
AC power cord (AC version only)
0.70lbs (318g)
Dimension
S9705-48D (W x D x H)
17.16” x 30” x 3.45” (436 x 762 x 87.7mm)
PSU (W x D x H)
1.99 x 14.17” x 1.58” (50.5 x 360 x 40mm)
Fan (W x D x H)
3.15” x 4.80” x 3.15” (80 x 122 x 80mm)

S9705-48D Hardware Installation Guide | 7
4Identifying Your System
S9705-48D Overview
Figure 4.
PSU Overview
Power supply unit (PSU) with 1+1 Redundancy. Hot swappable, field replaceable unit (FRU).
AC Version:
Figure 5.

S9705-48D Hardware Installation Guide | 8
DC Version:
Figure 6.
Fan Overview
3+1 Redundant, hot swappable, field replaceable unit (FRU).
Figure 7.

S9705-48D Hardware Installation Guide | 9
Port Overview
Port ID
Form Factor
Maximum Support Distance
Support Speed
0 ~ 47
QSFP-DD
328ft (100m)
400GE
The 400G fabric ports of the S9705-48D can only be used to interconnect the S9700 Series
routers.
Figure 8.

S9705-48D Hardware Installation Guide | 10
5Rack Mounting
It is recommended that installation be done by at least two trained professionals.
One individual should hold the router in position, while the other secures it in
place onto the rail slides.
1. Separate the adjustable mounting rail slides.
1.1 Pull apart the inner and outer rails until it is locked in place. An audible click can be heard
when the rails are locked in place.
1.2 Pull the white tab forward to unlock the rails in order to completely separate the inner rail
from the outer rail. The white tab is located on the inner rail.
1.3 Once the inner rail is separated, push the tab located on the outer rail to unlock and slide
the middle rail back.
Figure 9.
2Install the inner rails onto the chassis.
2.1 The inner rail has key-shaped holes where attachment pins on the chassis can be aligned.
The chassis has 5 attachment pins on each side, for a total of 10 pins. Fit the key-shaped
holes with the attachment pins and pull back to hold the inner rack in place.
Make sure the locking screw of the inner rail is positioned at the front of the
chassis.
2.2 After the attachment pins are secured to the inner rail, lock the inner rail to the chassis
using two M4 screws (one on each chassis side).

S9705-48D Hardware Installation Guide | 11
Figure 10.
3Fix the outer rails onto the rack.
3.1 The outer rails have two brackets on the front and rear. Pull back the clip of the rear
bracket to attach it onto the rack. An audible click can be hear when the bracket is secured
onto the rack.
3.2 Once the rear bracket is secured, pull back the clip of the front bracket attach it to the rack.
An audible click can be heard when the bracket is secured onto the rack.
Figure 11.
4Insert the Chassis to complete the installation.
4.1 Pull the middle rail fully extended into lock position, an audible click can be heard when the
middle rail is fully extended and locked into position.
4.2 Insert the chassis by lining up the inner rails into the slot of the middle rail.
4.3 Slide the chassis into the middle rail until it hits a stop.
4.4 Push the blue release tab on each rail to unlock the rails and slide the chassis all the way
into the rack.
4.5 Lock the chassis into place by using the screw on the front of the inner rail.

S9705-48D Hardware Installation Guide | 12
Figure 12.

S9705-48D Hardware Installation Guide | 13
6Installing Fan Modules
The fan modules are hot swappable field replaceable units (FRUs), which can be replaced while the
router is operating as long as all the remaining modules are installed and in operation. The fans
come pre-installed and the following steps are instructions on how to install a new fan module.
1. Locate the release tab on the fan module. Then press and hold the release tab to unlock the
fan module.
Figure 13.
2. While holding down the release tab, grip the fan handle and gently pull the fan module out of
the fan bay.
Figure 14.
3. Align the new fan module with the fan bay, ensuring that the fan module’s power connector is
in the correct position.
4. Carefully slide the new fan module into the fan bay and gently push until it is flush with the
case.
5. An audible click will be heard when the fan module is installed correctly. The fan module will
not go in all the way if it is installed in the wrong direction.
Figure 15.

S9705-48D Hardware Installation Guide | 14
7Installing Power Supply Units
The power supply unit (PSU) is a hot swappable field replaceable unit and can be replaced while
the router is operating as long as the remaining (second) PSU is installed and in operation (with 220V
power input). The AC and DC PSU follow the same steps for installation. The PSU comes pre-
installed and the following are instructions on how to install a new PSU.
If power input for AC power supply is only 110V, there will only be 1000 watts per power
supply and will not be enough power for the power supply to be changed while the router is
in operation. In order for AC power supply to be changed while the router is in operation,
ensure that 220V power is supplied.
Safety Notices
Caution! Shock hazard!
TO DISCONNECT POWER, REMOVE ALL POWER CORDS FROM UNIT.
DC:
AC:
Figure 16.
1. Locate the release tab on the PSU. Then press and hold down the release tab to unlock the
PSU.
2. While holding down the release tab, grip the PSU's handle and firmly pull it out of the power
bay.
DC Version:
AC Version:
Figure 17.

S9705-48D Hardware Installation Guide | 15
3. Align the new PSU with the power bay, ensuring the PSU’s power connector is in the correct
position.
4. Carefully slide the new PSU into the power bay and gently push until it is flush with the case.
5. An audible click will be heard when the PSU is installed correctly. The PSU will not go in all the
way if it is in the wrong direction.
Figure 18.

S9705-48D Hardware Installation Guide | 16
8Grounding the Router
It is recommended that equipment changes be done on a grounded rack system. This will reduce
or prevent the risk of shock hazards, equipment damage, and potential of data corruption.
The router can be grounded from the router's case and/or the power supply units (PSUs). When
grounding the PSUs, ensure that both PSUs are grounded at the same time in case one of them is
removed. A grounding lug and M4 screws and washers are provided with the package contents,
however, the grounding wire is not included. The location for securing the grounding lug is at the
rear of the case and is covered with a protective label.
The following instructions are for installing the grounding lug onto the case.
This equipment must be grounded. Do not defeat the ground conductor or
operate the equipment without correctly grounding the equipment. If there is any
uncertainty about the integrity of the equipment's grounding, please contact the
electrical inspection authority or a certified electrician.
1. Before grounding the router, ensure that the rack is properly grounded and in compliance with
local regulatory guidelines. Ensure that there is nothing that can obstruct the connection for
grounding and remove any paint or materials that may prevent good grounding contact.
2. Strip the insulation from a size #6 AWG grounding wire (not provided within the package
contents), leaving 1.125”+/-0.02” (28.6+/-0.5mm) of exposed grounding wire.
3. Insert the exposed grounding wire all the way into the hole of the grounding lug (provided with
package contents).
4. Using a crimping tool, firmly secure the grounding wire to the grounding lug.
Figure 19.

S9705-48D Hardware Installation Guide | 17
5. Locate the designated location for securing the grounding lug, which is located on the rear of
the router and remove the protective label.
Figure 20.
6. Using 2 M4 screws and 4 washers (provided with the package contents), firmly lock the
grounding lug to the designated grounding location on the router.
Figure 21.

S9705-48D Hardware Installation Guide | 18
9Connecting Power
DC Version
1. Ensure there is enough power to supply the system.
The maximum system power consumption is 1466 watts. It is recommended to ensure that
enough power is reserved from the power distribution system before installation. Also, please
ensure that both PSUs have been properly installed before powering up the equipment, as the
S9705-48D is designed to support 1 + 1 power redundancy.
2. Attach the DC power cables to the lugs.
The UL 1015, #6 AWG DC power cable (not provided) must be attached to a two-hole lug
before connecting to the PSU. The following instructions are for connecting the DC Power
Cable to the lug:
2.1 Strip the insulation from a DC Power Cable, leaving 0.5” +/-0.02” (12.7mm +/-0.5mm) of
exposed cable
2.2 Insert the exposed DC power cable into the heat shrink tubing, the length of heat shrink
tubing should not less than 38.5mm.
2.3 Insert the exposed DC power cable all the way into the hollow tube of the lug (provided
with the package contents).
2.4 Usinga crimping tool, firmly secure the DC power cable to the lug. It is recommended to not
crimp exceeding the lines indicated on the lug, which is also depicted as the cross-section area
in the picture on the below.
Figure 22.
2.5 Move the heat shrink tubing to cover any exposed metal on the DC power cable and lug.
