Magus MCBIR280A User manual

Specification
Model
MCBIR280A
Pick up Element
Color 1/3" HDIS
Effective Picture
976H)×496V)
Elements (H×V)
Horizontal Resolution
Color 800TV & B/W 850TVL
Minimum Illumination
01Lux-IR ON
S/N Ratio
More than 48dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
Auto
Gama Characteristic
0.45
IR Distance
10~20Meters
IR Status
Under 10Lux by CDS
IR Power On
CDS AUTO Control
Video Output
1Vpp, 75Ω
Auto Gain Control
Auto
Power/Current
350mA
Lens
Board Lens 3.6mm
Dimension (mm)
185(W)x74(H)x55(D)mm
Weight (g)
380gm
Storage Temperature
-10~+50℃RH95% MAX
Operating Temperature
-10~+45℃RH95% MAX
MCBIR280A
10~20 Meter IR Bullet
Notes: Before providing power for the
camera, please read this User Guide in
detail!
Packing List
No
Name
Model
Number
1.
Weatherproof IR Color Cameras
MCBIR280A
1
2.
User Guide
MCBIR280A
1
Do not attempt to disassemble the camera. If
the camera cannot work, please contact local
franchiser or our company.

BRIEF OF PRODUCT
CONNECTING
INTRODUCTION
*Sensor (CCD)
Adopt CMOS 1/3" CCD Sensor.
*Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The color camera
can get high definition picture in low Lux condition.
*Auto Electronic Shutter (AES)
Built-in auto electronic shutter function. The color
camera’s AES speed can reach 1/100,000s.
*Gama Characteristic
Camera Gama characteristic is 0.45.
*Scanning Mode
NTSC or PAL mode.
*Water resistance:
IP65
Monitor Video
DC12V
MCBIR280A
DC12V Power Supply
Link wire rule：
Video
Power
Congratulations on your purchase of this product.
This User Guide suits MCBIR280A product. We adopt the
latest CMOS technical of sensor and driver. The most
attractive characteristics are small and easy hidden, suits
the elevator and corridor. In addition, it owns the
characters of high definition and stability, strong anti-
jamming, rich and real color. Fixing and using this model
are convenient too. It is very good for you to apply to your
CCTV system.
Please read this instruction manual carefully to
ensure proper use of the product.
To prevent fire or shock hazarded. Do not expose the unit
to rain or moisture.
The symbol is intended to alert the user to the presence of
important operating and maintenance (servicing)
Instructions in the literature accompanying the appliance.
The symbol is intended to alert the user to the presence of
uninsulated ‘dangerous voltage’ within the product’s
enclosure that may be of sufficient Magnitude to constitute a
risk of electric shock to persons.
CAUTION:
RISK OF ELECTRIC. DO NOT OPEN
Notes：
●The power supply must through safe attestation. Its output voltage,
current, voltage polarity and operating temperature must match the
camera’s requirement.
●When using the camera in the thunderbolt condition, please note to mount
Anti-thunder device or put off the power supply plug and cable.
●In order to capture high quality pictures, the power supply’s cable and
video output cable should not be too long.
TROUBLE AND SOLUTION
1. No Picture after providing power
. May be the power supply voltage abnormity, please check the power
supply voltage and pole whether exactitude.
. Please check all the connecting cable and monitors whether be connected
correctly or not.
2. The picture level direction has flowing interference ripples
. May be caused by the power supply AC ripples, it need filter the wave of the
power supply.
. Check the monitor and peripheral equipment used.
3. The picture background color changes continuously
. The fluorescent lamp’s electromagnetic field cause color roll. This is proper
phenomenon of the cameras.
. Reduce the fluorescent lamp numbers or increase the distance between the
camera and the fluorescent lamps can improve it.
. Use power supply external sync. camera can solve it.
4. The picture smear too mass
. The power supply’s voltage unstable.
. Connecting cables not connect correctly or have high impedance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT REMOVE COVER OR BACK NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
OUALIFIED SERVICE PERSONNEL.
CAUTION: TO PREVENT ELECTRIC SHOCKS AND RISK OF FIRE
HAZARDS, DO NOT USE OTHER THAN SPECIFIED
POWER SOURCE.
Note:
●Please note the camera’s operating temperature and its using
environment requirement. Avoid using the camera at too high or
too low temperatures. The operating temperature is -10~+50℃.
(Recommendatory operating temperature is -10~+45℃.)
●Never make the camera face the sun or bright object.
Otherwise, it will damage the CCD.
●Do not mount the camera near by the radiator or heater.
