Mahindra XYLO mEagle 2010 User manual

©2010Mahindra&MahindraLtd.Allrightsreserved.Thisbookmaynotbereproducedorcopied,inwholeorinpart,without
thewrittenpermissionofMahindra&MahindraLtd.

WIRINGMANUAL

mEagle (Airbag)



  





RELEASEDBY‐

TECHNICALPUBLICATIONCELL
MAHINDRA&MAHINDRALTD.
Rev1–SEPTEMBER2010
All information contained in this manual is most up-to-date at the time of publication. However,
specifications and procedures are subject to change without notice. This manual is strictly
meant for restricted internal circulation within M&M Authorized dealer service centers.
MAN-00095
www.teknetmahindra.com




©2010Mahindra&MahindraLtd.Allrightsreserved.Thisbookmaynotbereproducedorcopied,inwholeorinpart,without
thewrittenpermissionofMahindra&MahindraLtd.

ABOUT THE WIRING MANUAL
The wiring manual outlines complete electrical network plan of the Mahindra XYLO mEagle vehicle,
fitted with AIRBAGS.
The wiring plan for XYLO mEagle (Airbag) version is different from the XYLO mEagle (non-airbag)
version in view of the extensive use of CAN in the Airbag version. Please ensure the correct wiring manual
is used while diagnosing XYLO mEagle vehicles fitted with Airbags
Wiring diagrams are technical drawings representing the electrical /electronic structure of the vehicle.
Understanding this manual is the quickest way to identify and repair a trouble, first time right. The manual
defines as to how the various systems are integrated and works, functions and operates. All the electrical
components are shown, including their locations, colors of connecting wires and connectors.
The manual is structured as below –
Component locations – Indicates schematically the location of the crucial components like fuses,
relays and controllers (ECUs)
In-vehicle communication network – Details the data communication network within various
controllers in the vehicle through LIN, K-Line and CAN.
Harness Layout – Indicates the physical layout of the wiring harness across the topography of the
vehicle. It also indicates the connectors and their codes/locations.
Inter-harness Connectors – Specifies the code, locations and pin-out view of the connectors in
between separate wiring harnesses.
Terminal Connectors –Specifies the code, locations and pin-out view of the major connectors which
terminate at controllers (ECUs)
Ground Points – Specifies the locations of the various grounding points across the vehicle body/chasis.
Circuit Plans – Specifies the circuit diagram of individual circuits, function wise.

©2010Mahindra&MahindraLtd.Allrightsreserved.Thisbookmaynotbereproducedorcopied,inwholeorinpart,without
thewrittenpermissionofMahindra&MahindraLtd.

Good electrical/electronic troubleshooting process
When troubleshooting any problem related to electrical/electronic system, follow the 5-step
process –
STEP 1 – Verify the customer complaint
•Turn on all the component/functions in the problem circuit to check accuracy of the
customer complaint.
•Replicate the customer complaint
•Note down the symptoms
•Do not begin disassembly or testing unless you have narrowed down the probable causes.
STEP 2 – Read and analyze the wiring diagrams
•Locate the specific circuit diagram of the problem circuit
•Understand how the circuit is supposed to work by tracing the circuit from power source
through components on to ground.
•Check other circuits which share components/fuse/ground/switch with this circuit.
•Isolate the circuit/component with problem.
STEP 3 - Inspect circuit/component with problem isolated
•Make a circuit test to check the diagnosis
•Narrow down the probable causes using troubleshooting charts/diagnosis charts
STEP 4 – Repair the problem
•Make necessary repairs as authorized
STEP 5 – Re-check the circuit
•Repeat the system check to ensure that the problem is eliminated
•Check related circuits
•Ensure that the customer symptom is eliminated

HOW TO READ THE WIRING MANUAL
Fuse with Rating
and direction of
flow
Inter-harness connector
IC1 – IC no
1 – Pin no
Pin No
Component
Signal type
Wire cross-section in mm2
Wire Colour
Signal Types
V - Voltage
I – Input
O - Output
G – Ground
Splice/Joint
Connector No
This is a sample circuit
7

CONTENTS
About the Wiring Manual
Good Electrical/Electronic Troubleshooting Process
How to read the wiring manual
1. CONTROLLERS/FUSES/RELAYS – LOCATION
MAIN FUSE /RELAY BOX- P31 09
AUX. FUSE / RELAY BOX – E4 10
ENGINE COMPARTMENT FUSE/RELAY BOX – EC21 11
2. IN-VEHICLE COMMUNICATION NETWORK
3. INDIVIDUAL CIRCUITS
CAN CIRCUIT 13
K – LINE CIRCUIT 14
ENGINE MANAGEMENT SYSTEM 15
ABS CIRCUIT 17
MAHINDRA BODY FUNCTION MODULE (MBFM) 18
IMMOBILISER
21
AIRBAG ECU 22
HVAC 23
REAR AC 24
FRONT WASH / WIPE 25
AUDIO 26
CENTRAL LOCKING SYSTEM
27
CHARGING CIRCUIT
28
DRIVER INFORMATION SYSTEM 29
CLOCK 30
FRONT AND REAR FOG LAMP 31
FUEL LID OPENER 32
HEAD LAMPS 33
4

HEADLAMP LEVELING CIRCUIT 34
HORN 35
INSTRUMENT CLUSTER 36
INTERIOR LAMPS CIRCUIT 37
OIL PRESSURE CIRCUIT 39
ORVM CIRCUIT 40
PARK /LIC LAMP CIRCUIT
41
CIGAR LIGHTER / POWER OUTLET 42
POWER WINDOW
43
REAR DEMISTER 45
REVERSE SWITCH 46
RPAS CIRCUIT 47
STARTING CIRCUIT 48
STOP LAMP CIRCUIT 49
TANK UNIT CIRCUIT
50
TURN SIGNAL & HAZARD
51
REAR WIPE/WASH 52
4. WIRING HARNESS LAYOUT
P- INSTRUMENT PANEL HARNESS 53
EC- ENGINE COMPARTMENT HARNESS 55
F- FLOOR HARNESS 57
E- ENGINE HARNESS 59
B - ABS HARNESS 61
RO- ROOF – FRONT HARNESS 63
RA- ROOF - REAR HARNESS 63
I - DIS HARNESS 65
S – RPAS HARNESS 65
D- DRIVER DOOR HARNESS 67
C- CO-DRIVER DOOR HARNESS 69
R- REAR DOOR - LEFT HARNESS 71
RR- REAR DOOR - RIGHT HARNESS 73
T- TAIL GATE HARNESS 75
H- HMSL HARNESS 75
A – ANTENNA/AMPLIFIER HARNESS 75
5

5. INTER-HARNESS CONNECTORS - LOCATION/PINS/VIEWS 77
6. TERMINAL CONNECTORS - MAJOR - LOCATION/PINS/VIEWS 84
7. INSTRUMENT CLUSTER
88
8. GROUND SCHEME 89
9. APPENDIX
Symbols and nomenclature 92
Wire Color coding chart 97
6

LOCATIONS – FUSEBOX/RELAYS/CONTROLLERS
P31 10 1311 12
57
9
EC21 E
4
8
6
4
6

ENGINE COMPARTMENT FUSE/RELAY BOX
LOCATION
LEFT FENDER
EC21
LOCATION
–
LEFT
FENDER
EC21
60A
1
HEAD LAMP
HORN
60A
2
60A
3
30A
4
1
HEAD LAMP
LOW BEAM
HEAD
LAMP
HIGH BEAM
20 A
100A
12
HORN
20 A
2
3
4
FRONT
FOG
LOW
BEAM
20 A
15A
625A
715A
9
15A
815A
10 11
30A
5
FOG
20 A

MAIN FUSE/RELAY BOX
LOCATION – RH SIDE OF INSTRUMENT PANEL (After opening driver door) P31
1
20A
PULLER
21
2
20A 3 5A 4 10A 5 20A 6 10A 7 5A 8 15A 9 15A 10 5A
22
REAR
DEFOGGER
20A
(BLACK)
REAR
BLOWER
20A
(BLACK)
PULLER
40A 40A
20
20A 19 10A 18 10A 17 20A 16 10A 15 10A 14 5A 13 10A 12 15A 11 15A
A/C
COMPRESSOR
20A
(YELLOW)

AUX. FUSE/RELAY BOX
LOCATION
BEHIND GLOVE BOX
E4
LOCATION
–
BEHIND
GLOVE
BOX
E4
FRONT
BLOWER
40 A
MAIN
RELAY
CRDe
30 A
CONDENSOR
FAN
40 A
10A
1
15A
2
15A
3
15A
4
10A
5
10A
6

Overview of the in-vehicle communication network
LEGEND
CAN
K-Line
LIN
MBFM
DIS
Diagnostic
Connector
(DLC)
IMMOBILIZER
(ICU)
CAN
LocalInterconnectNetwork
(MBFMtoDIS)
LocalInterconnect
Network
(EMSECUtoDIS–K‐line)
K‐Line
ABS
(EHCU)
Engine
(EMS ECU)
Instrument
cluster
(ECU)
Airbag
(ECU)
K‐Line
