MAJORITY BARTON 2 Manual

EN Instructions Guide
DIGITAL RADIO & ALARM CLOCK
BARTON
2
BAR-DAB-WDN | WAL-2

What’s In The Box?���������������������������������������������������������������������������������������1
Controls And Functions������������������������������������������������������������������������������ 2
Support �������������������������������������������������������������������������������������������������������� 4
Instructions Guide �������������������������������������������������������������������������������������� 5
Basic Operation �����������������������������������������������������������������������������������������
DAB/DAB+ Radio����������������������������������������������������������������������������������������
DAB/DAB+ Presets�������������������������������������������������������������������������������������
FM Radio����������������������������������������������������������������������������������������������������
FM Radio Presets ��������������������������������������������������������������������������������������
Clock & Date Settings�������������������������������������������������������������������������������
Dual Alarm Settings����������������������������������������������������������������������������������
Alarm Functions����������������������������������������������������������������������������������������
Other Functions ����������������������������������������������������������������������������������������
Troubleshooting���������������������������������������������������������������������������������������� 20
Spectications��������������������������������������������������������������������������������������������21
Warranty �����������������������������������������������������������������������������������������������������21
Safety Information������������������������������������������������������������������������������������ 22
Register your product online for a FREE 3 year
extended warranty at: www.majority.co.uk
EN
Contents

1
EN What’s In The Box?
Box Contents
1� Majority Barton Radio
2� UK Power Supply
3� User Guide

2
EN
Controls And Functions
1� Info/Menu
2� Power/Mode
3� Scan
4� Dimmer
5� Alarm
6� Volume -/+
7� Speaker
8� Display Screen
9� Previous
10� Snooze/Sleep
11� Preset
12� Select
13� Next
MODE
SCAN
DIMMER
SNOOZE/SLEEP
PRESET
SELECT
INFO/MENU
ALARM
PREV
NEXT
VOL+VOL-
6
2
1
3
4
5
10
9
11
12
13
8
7
Front View

3
EN
14�
15� DC Power Input
16� Headphone Jack
17� Antenna
Controls And Functions
Back View
14 15 16
17

4
EN
Please note all (Ref.) refer to Page 1 Controls and Functions mapping guide.
Plug the connector into the back of the system labelled DC 5V (Ref.15)�
Ensure the antenna (Ref.17) is extended as far as possible so that
you can rotate it which will enable you to get the best possible signal�
Switch the button on the rear of the unit to “On” (Ref.14)� Press and
hold the ‘Power/Mode’ button to turn on the unit (Ref.2)� The unit will
automatically take you to either DAB radio mode or the previous mode
you were using�
To change the mode (DAB/FM), press the ‘Power/Mode’ button (Ref.2)�
The display screen will dim automatically after 10 seconds if left in
standby or working mode�
DAB
scanning and storing all stations that have a good signal� In DAB/DAB+
mode, the radio will synchronize with the time and date of the station�
If the radio does not automatically scan, or you would like to rescan for
available stations, press the ‘Scan’ button (Ref.3) and then release� Once
To scroll through the stored stations, use the ‘Prev’ (Ref.9) and ‘Next’
buttons (Ref.13) to browse through stations� Press ‘Select’ (Ref.12) to
listen to a station�
Instrucons Guide
Basic Operation: DAB

5
EN Instructions Guide
FM Scan Setting
be displayed on the screen� Choose between scanning strong and weak
signals (All) or only the strong stations (Only)�
Press and hold the ‘Info/Menu’ button (Ref.1)� Use the ‘Prev’ or ‘Next’
buttons (Ref.9/Ref.13) to scroll to “FM Scan Setting” and press the
‘Select’ button (Ref.12)� Press the ‘Prev’ (Ref.9) or ‘Next’ (Ref.13) buttons
to scroll between “All” or “Only”� Press the ‘Select’ button (Ref.12) to
Manual Tuning
button (Ref.13/Ref.9
individually to search slowly�
To scan for stations with good signal, press the ‘Scan’ button (Ref.3) for
station with good signal will then begin to play�
(Ref.3
for good signal�
The radio will display station information when you press the ‘Info/
Menu’ button (Ref.1), press multiple times to view all available
information (See page 13)�
Basic Operation: FM

6
EN
DAB/DAB+ Radio
When you are listening to a DAB/DAB+ radio station with good signal,
you can press the ‘Info/Menu’ button (Ref.1) repeatedly to show the
Bit Rate: Shows the data rate at which the signal is being transmitted�
Bit Error Rate (BER): Provides details of the signal error rate�
Channel and Frequency: Displays the station’s transmission channel
PTY (Programme Type): Shows the type and description of the
program provided by the DAB station�
Time and Date: Displays the time and date information provided by the
broadcaster�
Bit Rate: The data rate which the signal is being transmitted�
Dynamic Label Segment (DLS): Displays scrolling text information
supplied by the broadcaster�
Station Information for DAB Radio
Instructions Guide

7
EN
How to store a preset station
listening to a station, press and hold the ‘Preset’ button (Ref.11) for 2-3
seconds until Preset Store settings open, and “Preset Store <1: (Empty)”
displays� Release the ‘Preset’ button�
Press the ‘Prev’ (Ref.9) or ‘Next’ (Ref.13) buttons to change the number
you want to store the station as� Press the ‘Select’ button (Ref.12) to
save the preset� Once saved, the display will show “Preset (x) stored”�
How to play a preset radio station
To play your preset radio stations, press the ‘Preset’ (Ref.11) button to
open Preset Recall settings� Hold down the button to open Preset Store
settings�
Press the ‘Prev’ (Ref.9) or ‘Next’ (Ref.13) buttons to scroll through your
preset stations from 1-10�
Press the ‘Select’ button (Ref.12) to select your choice� The station will
now begin to play�
Instructions Guide
FM/DAB Radio Presets

8
EN
Instructions Guide
FM Radio
When you are listening to an FM radio station with good signal, you can
press the ‘Info/Menu’ button (Ref.1
programme information�
Signal Strength: Displays a signal bar with the strength of the current
station�
Time and Date: Displays the time and the date�
Frequency:
Audio Type: Displays the audio type of the station you are listening to�
It will either be Stereo or Mono�
Radio Text: Displays scrolling text information supplied by the
broadcaster�
Programme Type: Displays a description of the type of programme
provided by the broadcaster�
Station Information for FM Radio

9
EN Instructions Guide
Once the radio has been put into DAB/DAB+ mode, the time and date
should be automatically set� If this does not occur or you wish to alter
the time and date, follow the steps below:
Manually Setting the Date and Time
To enter the radio settings, press and hold the ‘Info/Menu’ button
(Ref.1)�
To make your selection, use the ‘Prev/Next’ buttons (Ref.9/Ref.13) to
your choice (Ref.12)�
hour by pressing the ‘Prev’ (Ref.9) or ‘Next’ (Ref.13) buttons�
Ref.12)�
above to change the minutes�
The time is now set and the next step will enable you to change the
date� Follow the same steps as above to change the day, month and
year�
Clock & Date Settings

10
EN
1. Press the ‘Alarm’ button (Ref.5) once for Alarm 1 or twice for Alarm 2�
Press the ‘Select’ button (Ref.12
2. Once alarm 1 or 2 is selected, the screen will display the word “OFF”�
To turn the alarm on, use the ‘Next’ (Ref.13
on the display� Press the ‘Select’ button (Ref.12
3.
the alarm to sound, press the ‘Prev’ or ‘Next’ buttons (Ref.9/Ref.13) to
change the hour and press ‘Select’ (Ref.12
4. Use the ‘Prev’ or ‘Next’ buttons (Ref.9/Ref.13) to edit the minutes and
press the ‘Select’ button (Ref.12
5.
to scroll through the alarm options: ‘Once/Daily/Weekends/Weekdays’�
6. Now set the alarm volume by pressing the ‘Prev’ or ‘Next’ buttons
(Ref.9/Ref.13)� Press the ‘Select’ button (Ref.12
7.
buttons (Ref.9/Ref.13) to select the alarm sound: Alarm, DAB or FM
Radio and press ‘Enter’ (Ref.12
Instructions Guide
Dual Alarm Settings

11
EN
To Cancel Alarm 1 or Alarm 2
To cancel the alarm, press the ‘Alarm’ button (Ref.5) once for Alarm 1 or
twice for Alarm 2� Press the ‘Select’ button (Ref.12
you wish to cancel�
Ref.13) so that the screen
Ref.12
Snooze/Switch o Alarm when Sounding
When the alarm sounds, press the ‘Snooze/Sleep’ button (Ref.10) to
snooze for 9 minutes� The radio will go on standby mode�
Mode’ button (Ref.2)�
Instructions Guide
Cancel/Snooze Alarm

12
EN
Instructions Guide
Sleep Setting
to 120 minutes from activation�
Press the ‘Snooze/Sleep’ button (Ref.10)�
Using the ‘Prev’ or ‘Next’ buttons (Ref.9/Ref.13), choose the sleep timer
length: OFF/5 mins/15mins/30mins/45mins/60mins/90mins or 120mins�
When your choice is displayed press the ‘Select’ button (Ref.12)� The
system will automatically start the timer�
“OFF”�
Once the timer has been set, the minutes will countdown on the
counting down to “S0”, then the radio will go into standby mode�
Other Functions

13
EN
System Reset
To erase all settings and preset options, perform a factory reset� This
would also be advisable if you are having any functionality issues with
your radio�
To perform a factory reset, press and hold the ‘Info/Menu’ button
(Ref.1)� Use the ‘Prev’ or ‘Next’ buttons (Ref.9/Ref.13) to select “Factory
reset” and press the ‘Select’ button (Ref.12
‘Next’ button (Ref.13Ref.12)
to initiate the factory reset�
SW Version – Software Version Display
To view the software version, press and hold the ‘Info/Menu’ button
(Ref.1)�
Use the ‘Prev’ or ‘Next’ buttons (Ref.9/Ref.13) to navigate to “SW
Version” and press ‘Select’ (Ref.12
be displayed�
Dimmer
Press the Dimmer button (Ref.4) repeatedly to switch between low,
medium and high brightness options� The dimmer button can be used
in either standby or working mode�
Instructions Guide
Other Functions

14
EN
Troubleshooting
Observation Potential Cause/Solution
No sound The station may not be tuned properly� Please perform a rescan
for available stations or manually scroll through available
stations�
Cannot preset stations Ensure that you are pressing and holding down the Preset
button for 2-3 seconds to open Preset Store settings� Press, do
not hold down, to open Preset Recall�
FM: Static sound
DAB: Burbling/
intermittent cut-out
Signal reception is low� Adjust the aerial or move the unit to a
stronger signal location� Perform a rescan�
Re-scan stations and/or a factory reset�
Cannot locate DAB/DAB+
mode
available DAB station name will display�
Desired station not
found
Weak signal� Use the manual tune function and try rescanning
Display shows “No
Service”
There is no DAB coverage in your area, or poor reception�
Adjust the position of the aerial, or move the unit to a stronger
signal location�
Display is blank This may occur if the broadcaster changes the label of a service
or removes a label while tuned� The radio will try to retune or
perform a scan�
Time and Date not
setting automatically
To automatically set the time and date, turn on the system and
switch to DAB radio�
Alternatively, you can edit these in radio settings�
Support
support team on the Majority website:
www�majority�co�uk/support

15
EN
All products come with a standard 12 month warranty� All items must
be registered on www�majority�co�uk for the warranty to be valid� Once
also be given the chance to extend your warranty for an additional 24
months, free of charge�
Power supply DC 5V 1A Power Input
Modes FM (87 5MHz – 108MHz)
DAB/DAB+ (174-240MHz)
Output Connector 3�5mm Earphone jack
Dimensions 19 x 12 x 12 cm
Net Weight 1kg
No-load power consumption 0�07W
Average active eciency 75�26%
Output 5�0V ⎓ 1�0A 5�0W
Input 100-240V~, 50-60Hz, 0�2A Max�
Model no� AD0600501000UK
Brand Adition
Manufacturer Shenzhen Adition Audio Science &
Technology Co�,Ltd
Specications
Warranty
Specications

16
EN
1� Read these instructions�
2� Keep these instructions� Instructions are also
available for download at www�majority�co�uk
3� Heed all Warnings
4� Follow all instructions
5� Do not clean the apparatus near or with water
6� Do not block any ventilation openings� Install in
accordance with the manufacturer’s instructions
7� Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
8� Protect the power from being walked on or pinched
particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus�
9�
manufacturer�
10� Unplug this apparatus during light storms or when
unused for long periods of time�
11�
damaged in a way, such as power-supply cord or
have fallen into the apparatus, the apparatus has
been exposed to the rain or moisture, does not
operate normally or has been dropped�
12�
be placed on the apparatus�
13� Dispose of used electrical products and batteries
safely according to your local authority and
regulations�
ADDITIONAL WARNINGS
The apparatus shall not be exposed to dripping or
vases, shall be places on the apparatus�
Main plug is used to disconnect device and it should
remain readily operable during intended use� In order
to disconnect the apparatus from the main mains
completely, the mains plug should be disconnected
from the main socket outlet completely�
Battery shall not be exposed to excessive heat such as
RECYCLING ELECTRICAL PRODUCTS
goods and in doing so help the environment�
This symbol means an electrical product should
not be disposed of with normal household waste�
Please ensure it is taken to a suitable facility for
IMPORTANT: Please read all instructions carefully
before use and keep for future reference�
Risk of electric shock�
Do not open
Read all instructions carefully before use
and keep for future reference
When servicing, use only identical
replacement parts
ATTENTION
RISQUE D’ELECTROCUTION
NE PAS OUVRIR !
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN !
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN !
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!
!
!
Safety Information
IMPORTANT: Please read all instructions carefully
before use and keep for future reference
!


www�majority�co�uk
Table of contents
Other MAJORITY Clock Radio manuals
