MAJORITY D80 User manual

D 8 0
U S E R M A N U A L
H O M E A U D I O • C A M B R I D G E

CONTE NTS
EN
2
Contents ........................................................................................................................... 2
Box Contents .................................................................................................................... 3
Controls & Functions ........................................................................................................ 4
Setting up your Majority D80 Speakers ........................................................................... 7
Basic Operation................................................................................................................ 8
Bluetooth, USB Controls .................................................................................................... 9
RCA and Optical Modes.................................................................................................. 10
Bluetooth Mode.............................................................................................................. 11
USB Mode .................................................................................................................... 12
Troubleshooting.............................................................................................................. 14
Spec & Warranty............................................................................................................. 15
Safety Information .......................................................................................................... 16
Register your product online for a FREE 3 year
extended warranty at: www.majority.co.uk

BOX CONTE NTS
EN
3
WHAT’S IN THE BOX
A. Majority D80 Bookshelf Speakers
B. 3.5mm to 3.5mm AUX Cable
C. 3.5mm to RCA Cable
D. Instructions Guide
E. Remote Control
F. Power Adapter
G. Digital Optical cable

CONTROLS & FUNCTIONS
EN
4
FRONT VIEW
1.Remote Sensor 2.Speakers
BACK VIEW
8.Digital Optical cable
9.USB
10.High speed ARC cable
13.Power adapter
11.Stereo RCA to 3.5mm audio
12.RCA to RCA audio cable
1
LEFT
2
RIGHT

CONTROLS & FUNCTIONS
EN
5
REMOTE CONTROL
1 Power
2 Volume up
3 Previous track
4 Volume down
5 Optical mode
6 USB mode
7 Music mode
8 Mute
9 Play/pause
10 Next track
11 ARC mode
12 BT mode
13 line mode
14 Dialog mode
15 Movie mode

SETTING UP YOUR MAJORITY D80 SPEAK ERS
EN
7
Connecting and powering the unit
Using the power cord provided, plug one end into the back of the primary speaker
and plug the other end into a mains socket. Switch the unit on at the back of the
primary speaker .
Connect the two speakers together via the speaker connector cable. To do this, plug the
left speaker connector cable plug into the right (primary) speaker connector.
Switch on your Majority D80 Speakers
Press the ฀button to switch on the speakers. Press the ฀button to switch the
speakers off.
Remote Power
Remove the battery cover of the remote control. Insert 2 x AAA batteries (excluded).
Replace battery cover.
Note: when using the remote control, ensure that you are pointing at the remote sensor
otherwise the unit may not respond to key presses.

BASIC OPERATION
EN
8
Basic controls
Volume, treble and bass can be changed on all speaker modes.
On the remote control, use the Vol+ & Vol- buttons to control the volume. Press
MUTE to mute the audio.
Alternatively on the rear of the main speaker, use the Volume dial to increase
and decrease volume.
Use the Treble & Bass dials on the rear of the main speaker to control the bass and
treble settings of the sound
In Bluetooth or USB mode, use the ⏴⏵buttons to skip tracks and rewind or fast
forward.
Switching mode
Select the correct mode using the Mode option buttons on the remote control, or press
the ‘input’ button on the rear of the main speaker.
The mode selected is indicated by LED light colour on the front of the main speaker:
Dark Blue –Bluetooth
White –Optical
Light Blue –Line In/RCA
Purple –USB
Green –HDMI Arc

CONNCTING WITH A TV
EN
9
A. Set the TV’s audio output to optical or PCM.
B. Set Connecting using a RCA to 3.5mm audio cable. Select RCA mode.
C. Set the TV’s audio output to HDMI or PCM.

BLUETOOTH MODE
EN
11
To connect an external device to the D80 speakers, ensure that the speakers are
in ‘Bluetooth’ mode. Select ‘Bluetooth’ mode manually by using the ‘BT’ button on
the remote control, or pressing the ‘input’ button on the main speaker.
The corresponding mode indicator light lights up dark blue and will flash.
Switch Bluetooth on for your external device. Select ‘Majority D80’ from the list of
devices. When your external device is connected, you will hear an audible sound to
indicate successful connection. The indicator light will remain static. You can now play
audio through the speakers.
When Bluetooth is disconnected, you will hear an audible sound to indicate successful
disconnection, plus the indicator light will resume flashing.

USB & SD CARD MODE
EN
12
USB
To use USB mode, ensure that the speakers are in ‘USB’ mode. Select ‘USB’ mode
manually by using the ‘USB’ button on the remote control, or pressing the ‘input’ button on
the main speaker.
The corresponding mode indicator light lights up green.
Insert a USB drive into the USB port and use the remote control functions to play, pause
and navigate through files.

CONNECTING HEA DPHONES
EN
14
Observation
Potential Cause/Solution
No power/function
Check whether the power is switched on or off
at the wall.
Check that the power adaptor is properly
connected to the power outlet.
No sound
Check whether unit is set to MUTE.
Check whether MODE is correctly selected.
Turn up the volume on the speakers or on your
external device.
Check that cables are properly installed.
Function disturbance
Switch off and unplug the unit. Leave it for 2
minutes and switch it on again.
Bluetooth not connecting
Ensure that you are on Bluetooth mode on the
speaker and the Bluetooth on your device is
switched on. Select the Bluetooth device ‘D40’
and you should now be able to play audio.
SUPPORT
If you require further assistance with your new soundbar, please contact our support
team on the Majority website: www.majority.co.uk/support

SPEC & WARRANTY
EN
15
SPECIFICATION
Power Supply
100-240V/50-60Hz
Mode:
Bluetooth
Line in
ARC
USB reader
Optical
Power consumption
0.5W (standby mode)
Dimensions
230 x 155 x 155 mm
Weight
2.45 kg
Speakers
2*4” full range + 2 * 1” tweeter
Bluetooth Version
5.0
Bluetooth range
up to 10 meters
Compatible file types
MP3, WMA, FLAC, MAV, APE
Maximum compatible USB storage
128GB
WARRANTY
All products come with a standard 12 month warranty. All items must be registered
on www.majority.co.uk for the warranty to be valid. Once on the web page, use the
menu to find “Register Your Product”. You will also be given the chance to extend your
warranty for an additional 24 months, free of charge.

SAFETY INFORMATION
EN
16
1. Read these instructions.
2. Keep these instructions. Instructions are also availa-
ble for download at www.majority.co.uk
3. Heed all Warnings
4. Follow all instructions
5. Do not clean the apparatus near or with water
6. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions
7. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
8. Protect the power from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
9. Only use attachments/accessories specified by the
manufacturer.
10. Unplug this apparatus during light storms or when
unused for long periods of time.
11. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in a way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to the rain or moisture, does not operate
normally or has been dropped.
12. No naked flame sources, such as lit candles, should
be placed on the apparatus.
13. Dispose of used electrical products and batteries
safely according to your local authority and
regulations.
ADDITIONAL WARNINGS
The apparatus shall not be exposed to dripping or splash-
ing and no objects filled with liquid, such as vases, shall
be places on the apparatus.
Main plug is used to disconnect device and it should
remain readily operable during intended use. In order to
disconnect the apparatus from the main mains complete-
ly, the mains plug should be disconnected from the main
socket outlet completely.
Battery shall not be exposed to excessive heat such as
sunshine, fire or the like.
RECYCLING ELEC TRICAL PRODUCTS
You should now recycle your waste electrical
goods and in doing so help the environment.
This symbol means an electrical product should
not be disposed of with normal household waste.
Please ensure it is taken to a suitable facility for disposal
when finished with.
IMPORTANT: Please read all instructions carefully before
use and keep for future reference.
Risk of electric shock.
Do not open
Read all instructions carefully before use
and keep for future reference
When servicing, use only identical
replacement parts
CAUTION
ATTENTION
IMPORTANT: Please read all instructions carefully before use and

WWW.MAJORITY .CO.UK
