MAJORITY D80 User manual

HOME AUDIO • CAMBRIDGE
D80
Bookshelf
Speakers
User Manual

EN
2
3
4
7
7
8
9
10
11
12
13
14
15
What’s In the Box?..............................................................................................................
Controls And Functions…………………………..…………………………………………......................
Instructions Guide……………………………………………………………………………........................
Setting up your Majority D80 Speakers…………………………………………………
Basic Operation…………………………………………………………………………………….
Cable Connections – Optical, RCA, HDMI ARC………………………………………
Bluetooth Mode……………………………………………………………………………………
USB Playback Mode………………………………………………………………………........
Troubleshooting………………………………………………………………………………........................
Specification and Warranty…………………………………………………………………………………..
Warranty……………………………………………………………………………………………………………….
Safety Information…………………………………………………………………………….......................
Contents

EN
3
What’s in the Box?
Box Contents
A. Majority D80 Bookshelf Speakers
B. Speakers connecting Cable
C. RCA Cable to AUX cable 3.5 mm
D. Instructions Guide
E. Remote Control
F. Power Adaptor
A
C
D
E
B
F

EN
4
LED Indicators and Button Introduction
Controls & Functions
1. Active speakers
2. Infrared Receiver
3. LED Indicators
1
3
State Indicator Lights
Power off Red
Optical mode White
USB Purple
Line in mode Light Blue
Bluetooth connected Blue
ARC Green
2

EN
5
Back View of the primary speaker
Controls & Functions
456
7
8
9
10
11
12
13
14
15
4. Power switch
5. Input button (change speakers
mode)
6. EQ (Movie, Music & Dialogue)
7. Volume control
8. Treble control
9. USB playback input port
10. Bass control
11. DC IN Power cable port
12. ’Line in’ input port
13. Optical input port
14. ARC input port
15. Speaker output (connect with
the left speaker using
connecting cable)

EN
6
Remote Control
Note: ‘Movie,’ ‘Music’ and ‘Dialogue’ arepre-defined equaliser sound effects which
can be used while watching amovie, listening tomusic ornews (dialogue).
Alternatively, set the ‘Bass’ and ‘Treble’ as per your preferences.
Controls & Functions
1. Power button
2. Volume up
3. Previous track
4. Volume down
5. Optical mode
6. USB playback mode
7. Movie EQ
8. Mute button
9. Play/Pause
10. Next/ Forward
11. ARC mode
12. BT mode
13. Line-in mode
14. Dialog EQ
15. Music EQ
4
9
5
6
7
15
13
14
12
10
8
3
2
1
11

EN
7
Setting up your Majority D80 Speakers
Please note that the instructions within this user manual will refer to the D80’s
button number on themain speaker e.g. (Ref. ’number’) and to theremote-control
buttons e.g. (Rem. ‘number’), in accordance with thediagrams from pages 4-6.
Remove all packaging and prepare the D80’s for your set-up. Connect both speakers
together using the connecting cable, insert one end on the left speaker back into the’
Speaker in’ port and the other end into the ‘Speaker output port’ (Ref.12) on the back
of the main speaker. Position the speakers on the left and right hand-side of the
device you are about to connect with.
Using the power cord provided, plug one end into the DC IN power cable port which
can be found at the back of the primary speaker (Ref.11) and plug the other end into a
mains socket.
Prepare your remote for use. Remove the battery cover of the remote control. Insert
2 x AAA batteries (not included).
Ensure all cables are properly connected before switching the Majority D80 on, using
either the ‘Power’ button on the main speaker (Ref.4) or using the ‘Power’ button on
the remote control (Rem.1).
Instructions Guide

EN
8
Basic Operation
Power ON/OFF: Use the button on remote control (Rem.1) or the Power button which
can be found on the back of the primary speaker (Ref.4) to switch the unit on/off.
Change D80’s speaker modes in between: Bluetooth, USB, Line in (RCA), Optical or
HDMI/ARC using the corresponding mode buttons on remote control: BT, OPT, ARC,
USB or LINE. Alternatively, use the Input button which can be found on the back of the
primary speaker (Ref.2).
The mode selected is indicated by the sensor LED light colour positioned on the front
of the main speaker, such as:
•Bluetooth -Blue
•Optical -White
•Line In/RCA -Light Blue
•HDMI Arc -Green
•USB -Purple
Volume, treble and bass can be changed/controlled as per your preferences in all
modes. Alternatively, use the pre-defined equalisers (Movie, Music & Dialogue) by
pressing the corresponding buttons on remote control, or use the ‘EQ’ button (Ref.6)
on the back of the main speaker.
Instructions Guide

EN
9
Cable Connections
The Majority D80 speakers have multiple ports which can be used to connect with a
TV, PC/laptop, phone, MP3 player, CD player, or any other devices which have an
audio output port: Optical, AUX, HDMI ARC. Alternatively, The Majority D80 can be
paired via Bluetooth.
Connecting D80s with your device using a cable type:
Instructions Guide
Optical digital cable (supplied)
(White indicator light)
RCA to 3.5mm audio cable (supplied)
(Light Blue indicator light)
High speed ARC cable (not supplied)
(Green indicator light)
A
B
C
Active Speaker
TV

EN
10
Using Optical digital cable (not included)
•Insert an optical digital cable into the main speaker port (Ref.10) and the other
end to your TV optical output port or other similar device that you are about to
connect the speakers with.
•Change the mode to Optical, by pressing the ‘OPT’ button on the remote control
or use the ‘Input’ button on the back of the main speaker (Ref.5). The LED light
sensor will turn white, indicating that the speakers are in Optical Mode.
•If you are connecting the speakers with a TV using an optical cable, make sure
that your TV audio settings are set to ‘Optical out’ or ‘PCM.’
Using the RCA to AUX 3.5 mm cable
•Insert the RCA cable provided into the main speaker port L/R ‘LINE IN’ (Ref.12)
and the other end of the cable, AUX (3.5 mm) into an AUX or headphone jack port
of your device.
•Change the mode to ‘LINE IN’, by pressing the ‘LINE’ button on the remote control
(Rem.13) or use the ‘Input’ button on the back of the main speaker (Ref.5). The
LED light sensor will turn light blue, indicating that the speakers are in ‘LINE IN’
Mode.
•If you are connecting the speakers with a TV using this cable, make sure your TV
audio settings are set to PCM or Analogue.
Using a high-speed HDMI ARC cable (not included)
•Insert an HDMI ARC cable, into the main speaker port ‘ARC’ port and the other
end of the cable to your TV or other device-HDMI ARC port that you are about to
connect the speakers with.
•Change the mode to ‘ARC’, by pressing the ‘ARC’ button on the remote control
(Rem.11). The LED light sensor will turn green, indicating that the speakers are in
ARC Mode.
•If you are connecting the speakers with a TV using HDMI cable, make sure your
TV audio settings are set to HDMI out or PCM.
Instructions Guide

EN
11
Bluetooth Mode –Pairing with a device
The Majority D80 can be paired with a device via Bluetooth such as a phone, a tablet,
or any other Bluetooth-enabled device.
•To pair the Majority D80 with your device via Bluetooth, change the mode to
Bluetooth by pressing the ‘BT’ button on the remote control (Rem.12).
Alternatively, use the ‘Input button on the back of the main speaker (Ref.3).The
speaker’s sensor LED light will flash dark blue, indicating that the speakers are
ready to be paired.
•Switch Bluetooth on your device, and search for the Majority D80. On your
devices list you will see ‘Majority D80’. Select and connect.
•When successfully connected, you will hear an audible sound from the Majority
D80 confirming that the devices are now paired. The sensor LED light indicator
will stop flashing and now show a steady dark blue light. You can now play audio
from your paired device via the Majority D80.
•To disconnect the Majority D80 while in Bluetooth mode from your device, simply
remove the speakers from your list of devices. Once disconnected you will then
hear an audible sound, indicating that the devices have been disconnected. The
sensor LED light will then start flashing dark blue.
•While playing audio from your device, you can use the buttons on the remote
control including the Next/Forward’ (Rem.10) or ‘Previous’ (Rem.3) buttons on
remote control to skip audio tracks.
Note: The Majority D80 Speakers arenot compatible with Bluetooth earbuds.
Instructions Guide

EN
12
USB Playback Mode
•To use the Majority D80 in USB mode, press the ‘USB’ button on the remote
control to change the speaker's mode. Alternatively, press the ‘Input’ button
(Ref.5) on the main speaker to change the mode.
•The sensor LED light will turn purple, indicating that the Majority D80 is in the
USB Playback Mode.
•Insert a USB stick into the USB port which can be found at the back of the main
speaker (Ref.6) and use the remote-control functions to play, pause and navigate
through the files.
Note: The Majority D80s’ are compatible with USB sticks of up to 128GB. The
supported audio files are MP3, WMA, FLAC, MAV, APE.
The USB port cannot be used as a connection port with other devices as this is just
for playback only.
Instructions Guide

EN
13
Support
If you require further assistance with your Majority product, please contact our
support team on the Majority website: www.majority.co.uk/support
Troubleshooting
Observation Potential Cause/Solution
No power/function
Check whether the power is switched
on or off at the wall socket.
Check if all cables are properly inserted.
No sound
Check whether the unit is set to MUTE.
Check whether MODE is correctly
selected. Turn up the volume on the
speakers and on your external device.
If connected with a TV, make sure the
audio settings are adjusted as instructed
in the user manual.
Check if the audio port on your
TV/device is an audio ‘output’ port not
‘input.’
Any functionality issues
Switch off and unplug the speakers.
Leave it for 2 minutes, re-connect and
switch these on again.
Bluetooth not connecting
Ensure that the Majority D80 is in
Bluetooth mode. Make sure these are
not paired with other devices.

EN
14
Specification
Specification & Warranty
Power Supply 100-240V/50-60Hz
Mode
Bluetooth
Line in ARC
USB Playback (reader)
Optical
Power consumption 0.5W (Standby Mode)
Dimensions 230 x 155 x 155 mm
Weight 2.45 kg
Speakers 2x4” full range + 2x1” tweeter
Bluetooth Version 5.0
Bluetooth Range Up to 10 metres
Compatible file types MP3, WMA, FLAC, MAV, APE
Maximum compatible USB storage 128GB
Warranty
All products come with a standard 12 month warranty. All items must be registered on
www.majority.co.uk for the warranty to be valid. Once on the web page, use the
menu to find ‘Register Your Product’. You will also be given the chance to extend your
warranty for an additional 24 months, free of charge.

EN
15
Safety Information
1. Read these instructions.
2. Keep these instructions. Instructions are also
available for download at www.majority.co.uk.
3. Heed all warnings.
4. Follow all instructions.
5. Do no clean the apparatus near or with water.
6. Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus that produce heat.
9. Protect the power from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
10. Only use accessories specified by the
manufacturer.
11. Unplug this apparatus during light storms or
when unused for long periods of time.
12. Refer all servicing to qualified service
personnel.
13. No naked flame sources, such as a lit candle
should be placed on the apparatus.
14. Dispose of used electrical products and
batteries safely according to your local
authority and regulations.
ADDITIONAL WARNINGS
The apparatus shall not be exposed to dripping,
splashing or objects filled with water.
The main plug is used to disconnect the device. In
order to disconnect the apparatus from the main
mains completely, the mains plug should be
disconnected from the main socket outlet
completely.
Battery shall not be exposed to excessive heat.
RECYCLING ELECTRICAL
PRODUCTS
You should now recycle your waste electrical
goods and in doing so help the environment.
This symbol means an
electrical product should not be
disposed of with normal
household waste. Please
ensure it is taken to a
suitable facility for disposal
when finished.
IMPORTANT: Please read all instructions
carefully before use and keep for future
reference.
Risk of electric shock.
Do not open.
Read all instructions carefully
before use and keep for future
reference.
When servicing, use only identical
replacement parts.
CAUTION
RISQUE D’ELECTROCUTION NE
PAS OUVRIR
ATTENTION
RISK OF ELECTRIC SHOCK DO
NOT OPEN
IMPORTANT: Please read all instructions carefully
before use and keep for future reference

EN
16
