Makita CW003GZ01 User manual

EN
Cordless Cooler & Warmer Box INSTRUCTION MANUAL 4
FR
MANUEL D’INSTRUCTION
13
DE
Akku-Kühl- und Warmhaltebox GEBRAUCHSANLEITUNG
22
IT
Frigorifero e Scaldavivande portatile MANUALE D'USO
31
NL
Draadloze Koeler en Warmerbox GEBRUIKSAANWIJZING
40
ES
Caja Enfriadora & Térmica Inalámbrica MANUAL DE INSTRUCCIONES
49
PT
Refrigerador e aquecedor a Bateria MANUAL DE INSTRUÇÕES
58
DA
Ledningsfri køle- og opvarmningsboks INSTRUKTIONSVEJLEDNING
67
EL 76
TR 85
SV
Sladdlös kylar- och värmarbox BRUKSANVISNING
94
NO
Batteridrevet kjøle- og varmeboks BRUKSANVISNING
103
FI
Kannettava kylmä- ja kuumalaukku OHJEKIRJA
112
LV 121
LT
Belaidis kilnojamasis maisto šaldytuvas-šildytuvas NAUDOJIMO INSTRUKCIJA
130
ET
Juhtmevaba jahutus- ja soojenduskast KASUTUSJUHEND
139
PL 148
HU
HASZNÁLATI ÚTMUTATÓ
157
SK
Bezdrôtový chladiaci a ohrievací box
166
CS 175
SL
NAVODILA ZA UPORABO
184
SQ
MANUALI I UDHËZIMEVE
193
BG 202
HR
UPUTE ZA UPORABU
211
MK 220
SR 229
RO 238
UK 247
RU 256
KK 265
ZHTW 274
CW003G

2

3

ENGLISH4
ENGLISH (Original instructions)
WARNING
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
SPECIFICATIONS
Model: CW003G
Capacity 7 L
Input Battery cartridge D.C. 18 V / D.C. 36 V
AC adapter
(Optional accessory)
Refer the indication on the AC adapter.
(Input voltage varies depending on the country.)
Cigarette lighter adapter D.C. 12 V / D.C. 24 V
Anti-shock protection class III
Climate type SN / N / ST / T
Insulation material / Foaming material Polyurethane foam / Cyclopentane (C5H10)
Refrigerant R-1234yf (24 g)
Operating power cooling power 65 W, heating power 31 W
Dimensions
( L × W × H )
External dimensions 456 mm × 245 mm × 308 mm (not including the carrying handle)
Inside of the chamber 210 mm × 150 mm × 230 mm
Net weight 9.4 kg (with BL4080F) / 7.5 kg (without battery)
Protection degree IPX4 (only powered by battery pack)
Selectable control
temperature
Cooling mode -18 °C, -15 °C, -10 °C, -5 °C, 0 °C, 5 °C, 10 °C
(0 °F, 5 °F, 15 °F, 25 °F, 30 °F, 40 °F, 50 °F)
Heating mode 30 °C, 35 °C, 40 °C, 45 °C, 50 °C, 55 °C , 60 °C
(85 °F, 95 °F, 105 °F, 115 °F, 120 °F, 130 °F, 140 °F)
USB power supply port Type A / Output voltage D.C. 5 V / Output current D.C. 2.4 A
• Due to our continuing program of research and development, the specifications herein are subject to change
without notice.
• Specifications may differ from country to country.
Applicable battery cartridge and charger
D.C.18 V Model Battery cartridge BL1815N / BL1820B / BL1830B / BL1840B / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF / DC18SH / DC18WC
D.C.36 V Model Battery cartridge BL4020 / BL4025 / BL4040 / BL4050F / BL4080F
Charger DC40RA / DC40RB / DC40RC
• Some of the battery cartridges and chargers listed above may not be available depending on your region of
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
and chargers may cause injury and/or fire.

5 ENGLISH
Operating time
NOTE: Operating times are approximate and may differ depending on battery type, charging status, and usage
condition.
Voltage Battery cartridge
Operating time for each control temperature (hours)
Ambient temperature is 30 °C (85 °F) Ambient temperature is 0 °C (30 °F)
-18 °C
(0 °F)
-10 °C
(15 °F)
0 °C
(30 °F)
5 °C
(40 °F)
10 °C
(50 °F)
30 °C
(85 °F)
40 °C
(105 °F)
50 °C
(120 °F)
60 °C
(140 °F)
18 V
BL1815N 0.5 1.0 1.5 2.0 2.5 1.5 1.5 1.0 1.0
BL1820B 1.0 1.5 2.0 2.5 3.0 2.5 2.0 1.5 1.5
BL1830B 1.5 2.0 2.5 3.5 4.5 3.5 2.5 2.5 2.0
BL1840B 2.5 3.5 4.0 5.5 6.5 5.0 3.5 3.5 3.0
BL1850B 3.0 4.5 5.0 7.0 8.5 6.5 4.5 4.5 4.0
BL1860B 3.5 5.0 6.0 8.5 10.0 7.5 6.0 5.0 4.5
36 V
BL4020 2.5 3.0 5.5 6.5 7.5 5.0 4.0 3.0 2.5
BL4025 3.5 4.0 7.0 8.5 10.0 6.5 5.0 3.5 3.5
BL4040 5.5 7.0 11.5 13.5 16.0 10.5 8.0 6.0 5.5
BL4050F 7.0 8.5 14.0 16.5 20.0 13.5 10.0 7.5 7.0
BL4080F 11.5 14.0 23.0 27.0 32.0 21.5 16.5 12.0 11.5
Symbols
The followings show the symbols which may be used
for the equipment. Be sure that you understand their
meaning before use.
Read instruction manual.
Only for EU countries
Due to the presence of hazardous
components in the equipment, waste
electrical and electronic equipment,
accumulators and batteries may have a
negative impact on the environment and
human health.
Do not dispose of electrical and electronic
appliances or batteries with household
waste!
In accordance with the European Directive
on waste electrical and electronic
equipment and on accumulators and
batteries and waste accumulators and
batteries, as well as their adaptation to
national law, waste electrical equipment,
batteries and accumulators should be
stored separately and delivered to a
separate collection point for municipal
waste, operating in accordance with the
regulations on environmental protection.
This is indicated by the symbol of the
crossed-out wheeled bin placed on the
equipment.
Caution: risk of fire.
Do not fill the water directly in the chamber.
Do not immerse the appliance in water. Do
not pour water on the appliance. Otherwise
electric shock or malfunction may occur.
SAFETY WARNINGS
1. The device is suitable for:
- Operation in vehicles.
- Cooling and deep-freezing food.
- Camping use only when the appliance powered
by battery pack.
2. This appliance uses FLAMMABLE
REFRIGERANTS. Read and follow this
instructions for handling. Ask our service
center for servicing. When disposing the
appliance, follow your local regulations
relating to disposal of FLAMMABLE
REFRIGERANTS.
3. WARNING: Keep ventilation openings in the
appliance enclosure clear of obstruction.
4. WARNING: Do not use mechanical devices
or other means to accelerate the defrosting
process, other than those recommended by
the manufacturer.
5. WARNING: Do not damage the refrigerant
circuit.
6. WARNING: Do not use electrical appliances
inside the food storage compartments of
the appliance, unless they are of the type
recommended by the manufacturer.
7. This appliance contains flammable insulation
blowing gases inside. When disposing the
appliance, follow your local regulations
relating to disposal of flammable insulation
blowing gases.
8. Do not store explosive substances such as
aerosol cans with a flammable propellant in
this appliance.

6 ENGLISH
9. This appliance is intended to be used in
household and similar applications such as
- staff kitchen areas in shops, offices and other
working environments;
- farm houses and by clients in hotels, motels
and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
10. If the SUPPLY CORD is damaged, it must
be replaced by a special cord or assembly
available from the manufacturer or its service
agent.
11. WARNING: Risk of child entrapment. Before
you throw away your old refrigerator or
freezer:
* Take off the doors.
12. The installation clearance around and above
the unit shall be no less than 15 mm.
13. When positioning the appliance, ensure the
power cord is not tapped or damaged.
14. Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the
appliance.
15. Disposal of the appliance.
This marking indicates that this product
should not be disposed with other
household wastes throughout the EU. To
prevent possible harm to the environment
or human health from uncontrolled waste
disposal, recycle it responsibly to promote
the sustainable reuse of material resource.
The insulation blowing gas are flammable.
When disposing of the appliance, do so
only at an authorized waste disposal
centre. Do not expose to flame.
IMPORTANT NOTICES
1. Read the instruction manual carefully before
use.
2. Check if the voltage range used is the same
as that marked on the nameplate, whether
the power cord plug is match the socket, and
ensure that the socket is well grounded.
3. Even if the appliance is not in use, do not place
the appliance upside down, or tilt it above 15°.
Otherwise malfunction may occur.
4. When carrying the appliance, keep the
appliance with the upper cover facing up. Do
not carry the appliance with upside down.
Otherwise malfunction may occur.
5. Do not immerse the appliance in water or other
liquid to prevent electric shock. Do not expose
to rain.
6. When cleaning or not in use, remove the
battery and unplug the power plug.
7. Any accessories not recommended by the
manufacturer may not be used.
8. Do not place the appliance in hot places such
as in a car under the sun or near heating
materials. Cooling performance may be reduced,
or a gas leak may cause a fire.
9. Do not place the appliance near gas
appliances. Cooling performance may be
reduced, or a gas leak may cause a fire.
10. Do not start the power button frequently (at
least 5 minutes each time) to avoid damage to
the compressor.
11. Do not insert metal foil or other conductive
materials into the appliance to prevent fire or
short circuit.
12. Do not use chemical washing liquids and hard
tools to clean the product.
13. Insert the plug completely into the “DC IN”
inlet. Failure to do so may deform the plug or
cause a fire.
14. Do not operate the appliance while driving.
Doing so may cause an accident.
15. When the remaining automobile battery
capacity gets small, use the appliance with
the engine running. After using the appliance,
unplug the cigarette lighter socket to prevent
the loading on the automobile battery.
16. Do not use the AC adapter outdoors. Otherwise
electric shock may occur.
17. Do not abuse the AC adapter and cigarette
lighter adapter.
18. Clean the plug of the AC adapter and cigarette
lighter adapter. Dirt such as water or salt
adhering to the plug may cause rust and result
poor conductivity, deformation or fire.
19. Do not touch the plug of the AC adapter and
cigarette lighter adapter immediately after
operation. They may be extremely hot and could
burn your skin.
20. Do not disassemble the appliance.
21. Do not charge the car battery while using the
appliance. Unacceptable voltage may be applied
to the product, resulting in failure or fire.
22. Do not use flammable sprayer near the
appliance. Otherwise it may cause fire.
23. During operation, do not touch the contents,
especially those made of metal, inside the
appliance with wet hands. Doing so may cause
frostbite.
24. Do not handle the plug with wet or greasy
hand. Doing so may cause electric shock.
25. Do not put such as medicines or academic
materials in the appliance. This appliance
cannot storage the materials that require strict
temperature control.
26. Do not use this product as a stepstool or chair.
It may cause falls and injuries.
27. Do not allow small children and pets to play
with this appliance. Keep the appliance out of
reach of children when storing.

7 ENGLISH
28. Do not overfill food and drink in the appliance.
Cooling performance may be reduced, causing
food and drink to rot.
29. Be careful not to run out of battery power while
keeping food and drink cool or warm. Do not
store opened foods for a long time. Food and
drink may rot.
30. Do not use a knife or a screwdriver to remove
ice or frost from the appliance. Doing so may
damage the inside of the appliance and cause a
malfunction, or the enclosed gas or oil may squirt.
31. Do not use the DC output (DC) of the engine
generator as the power supply. Doing so may
cause a failure.
32. Do not put water etc. directly in the appliance.
Water may get inside the appliance and cause
a malfunction. If water has accumulated in the
chamber, wipe it off with a soft cloth.
33. Be careful not to pinch your finger when
closing and opening the upper cover.
34. Do not put things that are easily perishable in
the chamber. The food or drink may rot.
35. When operating heating mode, do not touch
the inside of the appliance with your hand for a
long time. Risk of low-temperature burns.
36. When putting food or drink in the appliance,
keep the inside of the chamber clean. Risk of
food poisoning etc.
37. Do not use this appliance in the refrigerator
vehicle or refrigerator chamber. Dew
condensation easily occurs in the refrigerator
vehicle and refrigerator chamber, causing water
droplets to fall on the appliance and result in
malfunctions.
38. Do not put creatures such as pets in the
appliance. This appliance cannot save creatures.
39. Do not put a cold agent in a broken bag. If the
cold agent leak in the appliance, the metal part of
the appliance may be corroded. If the cold agent
leaks, wipe it off with a damp soft cloth and then
wipe dry with a soft cloth.
40. Attach the shoulder band securely so that
it does not drop off due to the weight of the
appliance. Otherwise the appliance may fall and
cause injury.
41. When putting food and drink in the appliance,
put a cold or hot thing in advance. This
appliance cannot cool or heat in a short time.
42. When using the appliance in a car, be sure to
install the appliance in a stable place such as
the luggage space or the feet of the rear seats,
and fix it. Do not place the appliance on the
seat in an unstable state. If the car suddenly
starts or stops during driving, the appliance may
fall over and move, causing injury.
43. Hold the appliance firmly when carrying.
Otherwise the appliance may fall and cause a
malfunction, or falling on your feet may cause
injury.
44. When using in dusty environment, clean the
sponge filter more often. Dusty environment
causes sponge filter clogging easily and fire.
SAFETY WARNINGS for
BATTERY-OPERATED
APPLIANCE
Battery-operated appliance use and
care
1. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to battery pack, picking up or carrying the
appliance. Carrying the appliance with your finger
on the switch or energizing appliance that have
the switch on invites accidents.
2. Disconnect the battery pack from the
appliance before making any adjustments,
changing accessories, or storing appliance.
Such preventive safety measures reduce the risk
of starting the appliance accidentally.
3. Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of fire
when used with another battery pack.
4. Use appliances only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
5. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
6. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause
irritation or burns.
7. Do not use a battery pack or appliance that
is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
8. Do not expose a battery pack or appliance
to fire or excessive temperature. Exposure
to fire or temperature above 130 °C may cause
explosion.
9. Follow all charging instructions and do
not charge the battery pack or appliance
outside the temperature range specified in
the instructions. Charging improperly or at
temperatures outside the specified range may
damage the battery and increase the risk of fire.
10. Have servicing performed by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the product is
maintained.
11. Do not modify or attempt to repair the
appliance or the battery pack except as
indicated in the instructions for use and care.

8 ENGLISH
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all
instructions and cautionary markings on
(1) battery charger, (2) battery, and (3) product
using battery.
2. Do not disassemble or tamper with the battery
cartridge. It may result in a fire, excessive heat,
or explosion.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical attention
right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any
conductive material.
(2) Avoid storing battery cartridge in a
container with other metal objects such
as nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
flow, overheating, possible burns and even a
breakdown.
6. Do not store and use the appliance and battery
cartridge in locations where the temperature
may reach or exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a fire.
8. Do not nail, cut, crush, throw, drop the battery
cartridge, or hit against a hard object to the
battery cartridge. Such conduct may result in a
fire, excessive heat, or explosion.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are
subject to the Dangerous Goods Legislation
requirements.
For commercial transports e.g. by third parties,
forwarding agents, special requirement on
packaging and labeling must be observed.
For preparation of the item being shipped,
consulting an expert for hazardous material is
required. Please also observe possibly more
detailed national regulations.
Tape or mask off open contacts and pack up the
battery in such a manner that it cannot move
around in the packaging.
11. When disposing the battery cartridge, remove
it from the appliance and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
specified by Makita. Installing the batteries
to non-compliant products may result in a fire,
excessive heat, explosion, or leak of electrolyte.
13. If the appliance is not used for a long period
of time, the battery must be removed from the
appliance.
14. During and after use, the battery cartridge
may take on heat which can cause burns or
low temperature burns. Pay attention to the
handling of hot battery cartridges.
15. Do not touch the terminal of the appliance
immediately after use as it may get hot enough
to cause burns.
16. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge. It may result in poor performance or
breakdown of the appliance or battery cartridge.
17. Unless the appliance supports the use near
high-voltage electrical power lines, do not
use the battery cartridge near high-voltage
electrical power lines. It may result in a
malfunction or breakdown of the appliance or
battery cartridge.
18. Keep the battery away from children.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery bursting
causing fires, personal injury and damage. It will also
void the Makita warranty for the Makita appliance and
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop appliance operation
and charge the battery cartridge when you
notice less appliance power.
2. Never recharge a fully charged battery
cartridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room
temperature at 10 °C - 40 °C (50 °F - 104 °F).
Let a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the appliance or the charger.
5. Charge the battery cartridge if you do not use
it for a long period (more than six months).

9 ENGLISH
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
it may accidentally fall out of the appliance, causing
injury to you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.
B) AC adapter
Optional accessory
When using the appliance with AC power, use the AC
adapter supplied with the appliance. Insert the plug to
“DC IN” inlet of the appliance and then insert the other
end to an outlet.
When the appliance is operating with power from AC
adapter, the lamp of “DC IN” lights up.
C) Cigarette lighter adapter
When using the appliance with the cigarette lighter
socket, use the cigarette lighter adapter supplied with
the appliance. Insert the plug to “DC IN” inlet of the
appliance and then insert the other end to the cigarette
lighter socket.
When the appliance is operating with power from
cigarette lighter adapter, the lamp of “DC IN” lights up.
CAUTION: Insert the plug completely into the
“DC IN” inlet. Failure to do so may deform the plug
or cause a fire.
CAUTION: Always close the “DC IN” socket
cover firmly when the power cord is not plugged.
Otherwise foreign matter may enter the appliance and
cause a malfunction.
NOTE: When the appliance shifts power supply, the
compressor will stop for about 3 minutes to protect the
compressor.
NOTE: After turning off the appliance, it takes about 3
minutes to restart the compressor because of the pro-
tection of the compressor.
NOTE: If the appliance stops by any means other than
pressing the power button, the appliance turns on
automatically when the power supply of the AC adapter
or the cigarette lighter adapter is regained.
PARTS DESCRIPTION
Fig.1
1 Control panel 2 Battery cover
3 LED light 4 Upper cover
5 Upper cover hook 6 Opener
7 Carrying handle 8 "DC IN" socket
9 Filter cover 10 USB power supply port
11 Power button 12 Cool / heat switch button
13 Temperature display 14 Battery indicator
15 Temperature reduction button 16 Temperature plus button
17 Lamp of "DC IN" 18 Unit of temperature
19 Lamp of heating mode 20 Lamp of cooling mode
OPERATION
CAUTION: Do not put things that are easily
perishable in the chamber. The food or drink may
rot.
NOTE: When operating the appliance in high humid
environment, dew condensation may occur on the
appliance. This is not malfunction of the appliance.
Use a dry cloth to wipe the dew condensation off the
appliance.
1. Connecting the power supply
A) Battery
CAUTION: Always switch off the appliance
before installing or removing the battery
cartridge.
CAUTION: Hold the appliance and the battery
cartridge firmly when installing or removing
battery cartridge. Failure to hold the appliance and
the battery cartridge firmly may cause them to slip off
your hands and result in damage to the appliance and
battery cartridge and a personal injury.
CAUTION: Be careful not to pinch your finger
when opening or closing the battery cover.
CAUTION: Be careful not to pinch your
fingers between the battery cartridge and the
terminals. It may cause slash injury.
To install the battery cartridge, open the battery cover.
Align the tongue on the battery cartridge with the groove
in the housing and slip it into place. Insert it all the way
until it locks in place with a little click.
Then close the battery cover.
To remove the battery cartridge, slide it from the
appliance while sliding the button on the front of the
cartridge.
Fig.2
1. Red indicator 2. Button 3. Battery cartridge

10 ENGLISH
2. Turning on the appliance
Press the power button to turn on the appliance. Press
the power button again to turn off the appliance.
3. Switching cooling / heating mode
Press the cool / heat switch button to switch the
operating mode.
• When the appliance operates in cooling mode, the
lamp of cooling mode lights up.
• When the appliance operates in heating mode, the
lamp of heating mode lights up.
The temperature display flashes the control temperature.
4. Selecting the control temperature
Press the temperature plus button or the temperature
reduction button to select the control temperature. Refer
the chapter “SPECIFICATIONS” for the selectable
control temperature.
The appliance starts cooling / heating 5 seconds after
without any operation, then the control temperature stop
flashing and the temperature display shows the current
temperature.
The appliance stops cooling / heating when the current
temperature reaches the control temperature.
Tips for efficient cooling
• Opening the upper cover for long periods can
cause significant increase of the temperature in
the chamber.
• Regularly clean surfaces that can come in contact
with food and accessible drainage systems.
• Store raw meat and fish in suitable containers in
the chamber, so that it is not in contact with or drip
onto other food.
• If the chamber is left empty for long periods:
- Switch off the appliance.
- Defrost the chamber.
- Clean and dry the chamber.
- Leave the upper cover open to prevent mold
developing within the chamber.
FUNCTION
Indicating the remaining battery
capacity
The battery indicator shows the remaining battery
capacity. The remaining battery capacity is shown as
the following table.
Battery indicator status Remaining
capacity
Lighted Off
50% to 100%
20% to 50%
0% to 20%
(Blinking)
Charge the
battery.
(Only for battery cartridges with
the indicator)
Press the check button on the battery cartridge to
indicate the remaining battery capacity. The indicator
lamps light up for a few seconds.
Fig.3 1. Indicator lamps 2. Check button
Indicator lamps Remaining
capacity
Lighted Off Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
The battery
may have
malfunctioned.

11 ENGLISH
NOTE: Depending on the conditions of use and the
ambient temperature, the indication may differ slightly
from the actual capacity.
NOTE: The first (far left) indicator lamp will blink when
the battery protection system works.
Appliance / battery protection
system
The appliance is equipped with the protection
system. This system automatically cuts off power to
extend appliance and battery life. The appliance will
automatically stop during operation if the appliance or
battery is placed under one of the following conditions.
• Battery over discharge protection
When the battery capacity becomes low, the
appliance stops automatically. The battery
indicator prompts that the battery should be
charged. Remove the batteries from the appliance
and charge the batteries.
• Overcurrent protection
When the appliance / battery is operated in a
manner that causes it to draw an abnormally high
current, the appliance automatically stops. In this
situation, stop the application that caused the
appliance to become overloaded. Then turn the
appliance on to restart.
• Low-voltage protection
When the car input voltage is lower than the
rated voltage, this protection system turns off the
appliance and the temperature display shows “F3”
with beep sound.
• Over-voltage protection
When the input voltage is higher than the rated
voltage, this protection system turns off the
appliance and the temperature display shows “F4”
with beep sound.
• Short circuit protection
The circuit has short circuit protection function
in case of short circuit. In this situation, take the
appliance to Makita Authorized or Factory Service
Centers.
• Tilt protection function
The appliance is equipped with the tilt protection
function. When operating the appliance in cooling
mode, the appliance will automatically shuts
down if the appliance is placed under one of the
following angles.
When the appliance get equal to or greater than
30° from level angle as shown A, B, C, or D in
the figure, the appliance shuts down and the
temperature display shows "F1" for a while. It
takes 3 minutes to restart after the appliance back
in level position.
Fig.4
Protections against other causes
Protection system is also designed for other causes that
could damage the appliance and allows the appliance to
stop automatically. Take all the following steps to clear
the causes, when the appliance has been brought to a
temporary halt or stop in operation.
1. Turn the appliance off, and then turn it on again to
restart.
2. Charge the battery(ies) or replace it/them with
recharged battery(ies).
3. Let the appliance and battery(ies) cool down.
If no improvement can be found by restoring protection
system, then contact your local Makita Service Center.
USB charging
There is the USB port in the battery compartment. The
USB port continuously outputs 5 V voltage in operation
state.
NOTICE: Connect only devices which are
compatible with the USB power supply port.
Otherwise it may cause malfunction to the appliance.
NOTICE: Do not connect the USB power supply
port of this appliance to the USB terminal of your
computer. It may cause malfunction.
NOTICE: Before connecting USB device to the
appliance, always backup your data of USB
device. Otherwise your data may be lost by any
possibility.
NOTICE: When not using or after charging,
remove the USB cable and close the cover.
NOTE: The appliance may not supply power to some
USB devices.
Memory function
After setting the control temperature, if the user does
not operate within 5 seconds, the current setting will be
memorized. Next time, the appliance starts in the same
setting.
Switching the unit of temperature
You can switch the unit of temperature °C (degree
Celsius) or °F (degree Fahrenheit) by following
procedure.
1. Turn on the appliance.
2. Press the cool / heat switch button until the unit
(°C or °F) starts flashing.
3. Press the temperature plus button or the
temperature reduction button to select unit.
4. Press the cool / heat switch button, or leave the
appliance 5 seconds without any operation. The unit
selection is completed.

12 ENGLISH
Shoulder belt
CAUTION: Make sure the shoulder belt
securely attached properly. Otherwise falling
accident may occur.
CAUTION: When carrying the appliance,
keep holding the appliance even if when using
the shoulder belt. Carrying the appliance using only
the shoulder belt makes it unstable. The shoulder belt
may come off or the appliance hit other objects and
cause injury.
1. Put the belt through the carrying handle.
2. Buckle the belt.
Fig.5
Error code
For the specific errors, the temperature display shows
following code.
Error code Matter
F1 Tilt protection is active. Refer the section for
the tilt protection function.
F2 Running out of battery.
F3 Input voltage is low. Refer the paragraph for
the low-voltage protection.
F4 Input voltage is high. Refer the paragraph for
the over-voltage protection.
Error codes
other than
the above
Turn off and restart the appliance. If the error
still does not improve, take the appliance to
Makita Authorized or Factory Service Centers.
MAINTENANCE
CAUTION: Always be sure that the appliance
is switched off, unplugged, and the battery
cartridge is removed before attempting to perform
inspection or maintenance.
CAUTION: Do not spray or pour water on
the appliance when cleaning. Do not wash with a
hose; avoid getting water inside of the appliance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
To maintain product SAFETY and RELIABILITY,
repairs, any other maintenance or adjustment should
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
Cleaning
• Clean the oil stain in the chamber regularly.
• Clean around the interior of the chamber to
prevent odor.
• Clean the dust on the sponge filter regularly to
improve the refrigeration efficiency.
• The sealing strip of the upper cover is easy to get
dirty, clean it in time.
Defrosting
To defrost, turn off the power and wait until the frost has
melted. Then wipe off the water.
Cleaning the sponge filter
CAUTION: After cleaning the sponge filter,
be sure to install it on the appliance. Operating
the appliance without the sponge filter may cause
malfunction.
1. Slide the filter cover in the direction of the arrow
shown in the figure, and then take the filter cover
off.
2. Take off the sponge filter, clean the sponge filter.
Fig.6
3. Install the sponge filter and the filter cover back.
Fig.7
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specified in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or attachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• AC adapter
• Makita genuine battery and charger
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may

CW003G-31L(CE)-2206
WLI/CRE
Makita Europe N.V.
Makita Corporation
Jan-Baptist Vinkstraat 2,
3070 Kortenberg, Belgium
3-11-8, Sumiyoshi-cho,
Anjo, Aichi 446-8502 Japan
www.makita.com
