MallinCam SKYRAIDER DS16C TEC User manual

MALLINCAM
SkyRaider DS16CTEC
User
Manual
Volume
1
[Version 6.0]
Michael Burns
Rock Mallin

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
1
C1: The MallincamSky DS16CTEC User
Manual
Use this User Manual to obtain a deep understanding of all the
features of both the MallincamSky and the SkyRaider
DS16CTEC camera. See the Quick Guide for an expeditious
look at getting up and running with the camera and software.
o save time for those of you who are familiar with Mallincam imaging cameras, this
User Guide will provide a Table of Contents to allow you to quickly locate the
commands and controls you need in controlling the DS16CTEC camera. It will include
instructions on how to install the Software and Drivers and how connect the SkyRaider
DS16CTEC Camera to your computer. This manual will provide explanations of all the camera’s
settings so you can get up and running quickly and can experience the wonders of video
imaging.
The ICONS at the left are quick indications of what that section performs.
Chapter
1
T
I C O N K E Y
Take Note
Hardware connection
Download
Running Software
Commands
Camera Controls

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
2
C1: The MallincamSky DS16CTEC User Manual........................................................1
Introduction ..............................................................................................................9
The Contents of the DS16C TEC ..............................................................................10
Specifications:................................................................................................................. 10
In the Box ....................................................................................................................... 11
System Requirements: ................................................................................................... 11
Dimensions..................................................................................................................... 11
Download and Install MallincamSky.......................................................................12
Connecting the DS16CTEC to your computer.........................................................15
Running MallincamSky............................................................................................17
C2: The MallincamSky Window.............................................................................18
Quick Work-Flow Procedures .................................................................................19
Quick Workflow for Starting MallincamSky.................................................................... 19
Detailed Work-Flow Procedures.............................................................................22
Detailed Workflow of Video Imaging Planetary Objects ................................................ 22
Detailed Workflow of Video Imaging Deep Sky Objects................................................. 28
C3: Quick Overview of the Left Sidebar.................................................................37
C4: Detailed Description of MallincamSky Controls ...............................................42
Top Line Menu ........................................................................................................43
File .................................................................................................................................. 43
Open Image...............................................................................................................................43
Open Video ..............................................................................................................................44
Save..........................................................................................................................................45
JPEG....................................................................................................................................................46
PNG ....................................................................................................................................................46
TIFF.....................................................................................................................................................47
JPEG 2000...........................................................................................................................................47
TFT......................................................................................................................................................47
Batch Save….............................................................................................................................48
Directory:............................................................................................................................................48
Name Format:.....................................................................................................................................48
File Prefix:...........................................................................................................................................48
File Type: ............................................................................................................................................48
Sample:...............................................................................................................................................48
Paste as New File .....................................................................................................................49
Recent Files ..............................................................................................................................49
Exit ...........................................................................................................................................50
Edit ................................................................................................................................. 51
Cut............................................................................................................................................51
Copy .........................................................................................................................................51
Paste.........................................................................................................................................51
Paste Shortcut..........................................................................................................................51
Image Select.............................................................................................................................52
Select All...................................................................................................................................52
Select None..............................................................................................................................52

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
3
View................................................................................................................................ 52
Browse .....................................................................................................................................53
Thumbnail ................................................................................................................................54
Sidebar .....................................................................................................................................54
Histogram.................................................................................................................................55
Grids.........................................................................................................................................55
No Grids..............................................................................................................................................56
Auto Grids...........................................................................................................................................56
Manual Grids ......................................................................................................................................57
Divide..................................................................................................................................................57
Remove All Grids ................................................................................................................................58
Add Preset..........................................................................................................................................58
Preset Management...........................................................................................................................58
Preset .................................................................................................................................................58
Best Fit................................................................................................................................................58
Actual Size ..........................................................................................................................................58
Full Screen ..........................................................................................................................................58
Pipette................................................................................................................................................59
Track...................................................................................................................................................59
Video Frame .......................................................................................................................................59
Reticles ...............................................................................................................................................59
Browse............................................................................................................................ 60
Sort...........................................................................................................................................60
Icons.........................................................................................................................................60
Refresh.....................................................................................................................................60
Properties.................................................................................................................................60
Open Record Folder .................................................................................................................61
Open Image Folder...................................................................................................................61
Setup .............................................................................................................................. 61
ST4 Test… .................................................................................................................................61
Capture........................................................................................................................... 61
Capture Image..........................................................................................................................62
Auto Capture............................................................................................................................62
Start Record…...........................................................................................................................62
Batch Record............................................................................................................................63
Image.............................................................................................................................. 65
Mode........................................................................................................................................65
Adjust.......................................................................................................................................66
Adjust Brightness/Contrast.................................................................................................................66
Color...................................................................................................................................................66
RGB .................................................................................................................................................................. 67
CMYK................................................................................................................................................................ 67
HIS.................................................................................................................................................................... 67
HSI.................................................................................................................................................................... 68
HMS....................................................................................................................................................68
Curve ..................................................................................................................................................68
Filter Color..........................................................................................................................................69
Extract Color.......................................................................................................................................69
Invert..................................................................................................................................................69
Edge Preserving Smooth.....................................................................................................................69
Detail Enhance....................................................................................................................................70
Rotate.......................................................................................................................................70
Flip......................................................................................................................................................71
Crop..........................................................................................................................................71

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
4
Image Scale ..............................................................................................................................71
Width and Height: ..............................................................................................................................72
Reset:..................................................................................................................................................72
Constrain Proportions: .......................................................................................................................72
Scale method:.....................................................................................................................................72
Histogram.................................................................................................................................72
Pixels: .................................................................................................................................................74
Level: ..................................................................................................................................................74
Count:.................................................................................................................................................74
Percentile: ..........................................................................................................................................74
Process ........................................................................................................................... 75
Stitch: .......................................................................................................................................75
Image Stacking .........................................................................................................................78
Options........................................................................................................................... 80
Record......................................................................................................................................80
Directory:............................................................................................................................................80
File:.....................................................................................................................................................80
Limit:...................................................................................................................................................81
Batch Record............................................................................................................................81
Auto Capture............................................................................................................................82
Directory:............................................................................................................................................82
File:.....................................................................................................................................................82
Capture Mode: ...................................................................................................................................83
Capture every frame: ....................................................................................................................................... 83
Time Slot: ......................................................................................................................................................... 83
Total Images:......................................................................................................................................83
File............................................................................................................................................83
Target.......................................................................................................................................84
Grids.........................................................................................................................................84
Grid Style:...........................................................................................................................................84
Grid Line Style:....................................................................................................................................84
Grid Line Color:...................................................................................................................................84
Reticle Color: ......................................................................................................................................84
Video........................................................................................................................................85
Metadata..................................................................................................................................85
Misc..........................................................................................................................................85
Window .......................................................................................................................... 86
Close All....................................................................................................................................86
Reset Window Layout ..............................................................................................................86
Windows ..................................................................................................................................87
About.............................................................................................................................. 87
MallincamSky Toolbar.............................................................................................88
Open............................................................................................................................... 88
Save ................................................................................................................................ 89
Browse............................................................................................................................ 90
Thumbnail....................................................................................................................... 91
Target ............................................................................................................................. 91
Image Type ..................................................................................................................... 91
Auto Capture .................................................................................................................. 91
Batch Record .................................................................................................................. 92
Pause Video Capture ...................................................................................................... 92
Open Video Folder.......................................................................................................... 92

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
5
Zoom............................................................................................................................... 92
Track............................................................................................................................... 93
Histogram....................................................................................................................... 93
Reticle............................................................................................................................. 94
ST4 Test ...................................................................................................................... 94
Advance/Reverse............................................................................................................ 94
Stitch .......................................................................................................................... 95
Automated ...............................................................................................................................95
Manual.....................................................................................................................................96
Panorama Straighten:.........................................................................................................................97
Projection Type:..................................................................................................................................97
Seam Finder:.......................................................................................................................................97
Exposure Compensation:....................................................................................................................97
Bundle Adjust: ....................................................................................................................................97
Preferences .................................................................................................................... 99
Customize..................................................................................................................... 100
Toolbar...................................................................................................................................100
Customize...............................................................................................................................100
Controlling the SkyRaider with Left Side Bar ........................................................101
Camera List................................................................................................................... 102
Capture and Resolution................................................................................................ 102
Resolution.........................................................................................................................................103
Snap..................................................................................................................................................103
Record ..............................................................................................................................................104
If in Video Mode ...............................................................................................................................104
If in Trigger Mode.............................................................................................................................104
Gain ..................................................................................................................................................105
Video Mode.................................................................................................................. 105
Exposure Target................................................................................................................................ 106
Exposure Time..................................................................................................................................106
Trigger Mode................................................................................................................ 107
Options............................................................................................................................................. 108
Number in Sequence ........................................................................................................................109
Sequence.......................................................................................................................................... 109
Bit Depth....................................................................................................................... 109
White Balance .............................................................................................................. 109
White Balance .................................................................................................................................. 110
Color Adjustment ......................................................................................................... 110
Hue...................................................................................................................................................110
Saturation......................................................................................................................................... 111
Brightness.........................................................................................................................................111
Contrast............................................................................................................................................111
Gamma............................................................................................................................................. 111
Frame Rate ................................................................................................................... 112
Color/Gray.................................................................................................................... 112
Flip................................................................................................................................ 112
Rotate........................................................................................................................... 113
Sampling....................................................................................................................... 113
ROI................................................................................................................................ 113

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
6
Digital Binning .............................................................................................................. 115
Method.............................................................................................................................................115
Number ............................................................................................................................................116
Usage suggestion in digital binning...................................................................................................116
Dark Field subtraction in Digital Binning........................................................................................... 117
Histogram..................................................................................................................... 117
Dark Field Correction.................................................................................................... 119
Flat Field Correction ..................................................................................................... 121
Introduction:..................................................................................................................................... 121
Optical Path Noise: ...........................................................................................................................121
Taking Flats:......................................................................................................................................121
Black Level.................................................................................................................... 123
Live Stack...................................................................................................................... 124
Conversion Gain ........................................................................................................... 127
Cooling.......................................................................................................................... 129
Sharpen ........................................................................................................................ 131
Misc .............................................................................................................................. 131
Preset ........................................................................................................................... 131
C5: Installing Optional Software .........................................................................134
Installing MallincamSky and its Driver.......................................................................... 135
Installing DirectShow Driver......................................................................................... 137
Installing Mallincam ASCOM Driver ............................................................................. 138
C6: Using Third Party Software ...........................................................................141
Imaging in SharpCap.............................................................................................141
Imaging in MaximDL.............................................................................................146
Sequence Generator Pro and SkyRaider DS16CCTEC..............................................148
The SkyX and the SkyRaider DS16CCTEC .............................................................150
C7: First Aid .......................................................................................................152
How do I................................................................................................................152
How do I get rid of the Green Exposure Rectangle? .................................................... 152
How do I Select a part of the Image and Zoom in? ...................................................... 152
How do I automatically save 1 image every 30 seconds? ............................................ 153
How do I adjust the brightness in my monochrome SkyRaider?.................................. 153
How do I Broadcast my image onto Night Skies Network (NSN)?................................ 153
Can I Use MallincamSky with One SkyRaider and Auto-Guide with another? ............. 153
How Do I Pause the Video? .......................................................................................... 153
How do I Undo an Operation?...................................................................................... 154
How do I make my ROI the whole Image Again? ......................................................... 154
How do I Turn Off Dark Field correction?..................................................................... 154
How Do I take Another Dark Field?.............................................................................. 154
My ROI Window is Black?............................................................................................. 154

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
7
Upgrading my SkyRaider Camera Software.........................................................155
Uninstall SkyRaider Software ....................................................................................... 155
Uninstall SkyRaider DirectShow Drivers....................................................................... 156
Uninstall SkyRaider ASCOM Drivers ............................................................................. 158
Finish the Uninstalling Procedure ................................................................................ 158
First Aid for the SkyRaider Series.........................................................................159
When I click on the SkyRaider camera from the Camera list, a message pops up saying
Failed to Start: SkyRaider ............................................................................................. 159
When I try to connect I receiver message “Catastrophic failure (Exception from
HRESULT:0x8000FFF (E_UNEXPECTED))” ..................................................................... 159
All I see is a White image.............................................................................................. 159
The computer keeps beeping when I plug in the USB 3.0 cable .................................. 159
MallincamSky acts Strange After Update..................................................................... 160
How do I Optimize my Computer? ............................................................................... 160
Stacking is going terribly slow or Stops completely? ................................................... 161
I see a Pink Floyd Kaleidoscope effect on my Screen................................................... 164
Explanations .........................................................................................................165
Dark Field Explanation.................................................................................................. 165
Dark Frame Subtraction............................................................................................................165
Dark Field Correction................................................................................................................165
Histogram Explanation ................................................................................................. 167
Electronic Assisted Astronomy vs Live Video Imaging ................................................. 169
Electronic Assisted Astronomy..................................................................................................169
Live Video Imaging ...................................................................................................................169
Can the Mallincam SkyRaider Camera do EAA ...........................................................................169
Process .............................................................................................................................................169
Lossless File Formats used by MallincamSky..............................................................................170
FITS (Flexible Image Transport System)............................................................................................ 170
TIFF (Tagged Image File Format).......................................................................................................170
An Introduction to the Stacking Algorithm .........................................................171
Historic Review............................................................................................................. 171
CCD (Charge Coupled Device) ...................................................................................... 171
CMOS (Complementary Metal Oxide Semiconductor)................................................. 172
CMOS Imaging .............................................................................................................. 172
What is happening when you Live Stack .............................................................173
Average......................................................................................................................... 173
Additive ........................................................................................................................ 174
Setting up to Broadcast on LiveSkies...................................................................176
Introduction.................................................................................................................. 176
Obtaining a Broadcast Account.................................................................................... 177
Logging into Liveskies ................................................................................................... 178
This section explains how to Capture and Broadcast Using either SplitCam or OBS ... 180

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
8
Live Chat....................................................................................................................... 182
Finished ........................................................................................................................ 182
Using OBS (Open Broadcast Software) –This is a more challenging process to initially
setup............................................................................................................................. 183
Viewing a Live Skies Channel........................................................................................ 189
If you want to participate in the Live Chat ................................................................... 189
To Live Chat .................................................................................................................. 191
To exit........................................................................................................................... 191
One Page Broadcast Summary ..................................................................................... 192
Customizing the Screen........................................................................................193
Focal Reducers......................................................................................................194
MFR-10 Focal Reducer.................................................................................................. 194
Universe .5X focal reducer ........................................................................................... 194
User Notes ............................................................................................................195

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
9
Introduction
MallinCam Introduces the new MallinCam DS16CTEC - designed from the ground up to
Introducing the new MallinCam DS16cTEC / DS16mTEC - designed from the ground up to
accommodate the most demanding wide field astronomical video imaging applications. Since
most CMOS sensors cannot be directly cooled via a cold finger without causing damage and
delamination with time which will ultimately shorten their life, a new cooling system had to be
developed. MallinCam developed a unique cooling system that provides no direct physical
contact between the Peltier cooler and the sensor. Instead, the Peltier cooler creates
a convection system “refrigerator-like” environment that cools the sensor without actually
contacting it. This cooling system is unique to MallinCam and not found on other
astronomical imaging cameras.
Since the Panasonic 16MP class 1 CMOS sensor of the MallinCam DS16cTEC / DS16mTEC is
cooled via convection, thermal shock to it and its associated circuitry is reduced. CMOS
sensors have other components mounted on the same wafer with the imaging section which
do not requires or can be adversely affected by cooling. This includes the digital logic circuitry
(interface, timing, processing, output amplifiers, pad rings and associated oscillators), clocks
and timing controls, analog signal processing, analog-to-digital converter (which when under
cooling from direct cold finger and Peltier results in instability). These parts of the CMOS
sensor do not need to be direct cooled from a cold finger application.
MallinCam has successfully design a working alternative - a cooling chamber called
refrigeration cooling - which subjects the CMOS sensor to cooling inside a triple sealed
vacuumed sensor chamber controlled with a heating element mounted around the internal
optical window to control and avoid dew formation on the optical window and surroundings.
A vacuumed sealed chamber is used to eliminate the use of desiccant material and keep dew
free environment permanently.
The result of this new technology, the SkyRaider DS16cTEC / DS16mTEC, is design for live
visual application or video imaging. It is built to laboratory specifications, where CNC
machining is used throughout to provide the rigid tolerances needed to provide precise
component matching. The chamber has six stainless steel screws securing the chamber cover
under 100 pounds of pressure to avoid possible air leaks into the chamber.
The internal electronics use Grade 1 components with tolerance of 0.5%, a military and
aerospace standard in some cases. The camera contains 4Gb DDR3 internal memory to insure
the smooth flow of data to the computer. The DS16cTEC also has a built-in USB2 hub that can
support a guider or a USB type focuser or filter wheel.
So, thank you for your purchase, and let the adventure begin.

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
10
The Contents of the DS16C TEC
Specifications:
•Convection Linear Cooling
•PC Win XP, Win7, Win 8, Win 10. Mac.
•Convection Cooling
•Refrigeration Chamber
•Vacuumed Sealed Chamber
•Linear Cooling
•Built-in Heater for Optical Window Dew Removal and Chamber Temperature Control
•100 Pound Chamber Plate Pressure Held with 6- Stainless Steel Screws
•Built-In USB2 hub for Guider, Focuser, filter wheel etc.
•Four Blue LED Status Indicators (power, system, cooler, fan)
•High velocity Ultra Quiet Fan With Dual Air Output
•High Grade Carrying Case
•Live Stacking on the Fly
•Live Star Registration, Ideal for all Motorized Alt-Az mounted telescopes
•Built-in Memories
•CDS (Correlated Double Sampling)
•16.3 Mega Pixels CMOS ceramic color sensor
•22 mm diagonal
•Number of effective pixels 4656 X 3518 (16,379,808 pixels)
•Progressive Scan
•Full HD Support
•Hand Selected sensor class 1 Scientific grade
•Sealed Multi-Coated No IR Optical Window
•Pixel (μm): 3.80 X 3.80 square
•Connectivity USB 3.0 (USB2 compatible)
•Sensor Gain: Variable to 20x
•Sensor G Sensitivity: 2413mv @ 1/30s
•Binning Resolution: : 4640 X 3506, 2304 X 1750, 1536 X 1168
•Sensor: Panasonic v Maicovicon Series Super High Performance
•Size (mm) 4/3", 17.6472 X 13.3228 mm
•4K2K Support
•Aspect Ratio: 4:3
•Total Number of Pixels: 16,845,920
•All Aluminum construction, precision CNC machining
•Hand crafted electronics assembly.
•One USB 3 cable operation
•Weight : 430 Grams (15.16oz)
•Dimension: 3.1 inch diameter, 3-1/4 inch long (78.74 mm, 82.55mm)


M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
11
In the Box
The SkyRaider DS16CTEC includes the following standard equipment:
•MALLINCAM SkyRaider-DS16CTEC Camera
•High Precision T-mount to 2” mount Eyepiece Adapter
•5-metre (15 ft) USB 3.0 cable.
•12 volts dc, AC power supply.
•High Grade Carrying Case.
•MallinCam Software MallinCam SKY
System Requirements:
•Equal to Intel Core2 2.8GHz or Higher
•Memory: 4GB or More
•USB port: USB 3.0 Port (Recommended)
•Display: 17" or Larger Recommended
•200MB Free HDD
Updated Software and Drivers can be downloaded at the Software Downloads Window
located in the Support Tab at www.mallincam.net
Dimensions

M42 x 0.75

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
12
Download and Install MallincamSky
Visit the following website: www.mallincam.net. Select the Support Tab, then Software
Downloads. Select and download the latest required software and drivers for your system.
Ensure DS16CTEC is not connected.
Oncedownloaded,placeyourmouseonthezippedfile,Right-Clicktopop-upanActionWindow,and
choose Extract All …
Just Click on the Extract button when the next Window pops-up. Windows should now open
the actual folder that contains the software to install.
Un-Zip the folder, then Double-Click on it to open it up, revealing the 5 programs it contains
(or 1 program if just downloading MallincamSky).

Step 1


M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
13
The ASCOM DRIVER folders contain the ASCOM Drivers for the camera
The DIRECTSHOW DRIVER folder contains the Direct Show Drivers for the camera
The WINDOWS APPLICATION folder contains the camera control software.
Double-Click on the WINDOWS APPLICATION folder to open it up.
Double-Click on the MALLINCAMSKYSetup file and follow instructions to install the
MallincamSKy software and drivers onto your computer:
The following MallincamSky Setup Screen will then appear:
Click on Next to start the installation process.
The installation program now wants to know where you would like to install the software.
Either choose your own location or select the default.
Click on Install to proceed.
Step 4
Step 5
Step 2
Step 3

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
14
Windows may again ask for permission to install the device software.
Click on Install to accept.
The MallincamSky Software will take about a minute to be installed. When completed, the
following screen will appear:
Click on Finish, and the MallincamSky Icon will appear on your screen.
MallincamSky and its drivers are typically all you need to install to control the DS16C camera,
but if you would like to have other image programs control of the DS16C then you can install
two other optional drivers: ASCOM and DIRECTSHOW
Optionally (see Installing the ASCOM Driver for more in-depth details), Double-Click on
ASCOM DRIVER folder, then Double-Click on the ASCOMMallincamSetup program and follow
the instructions to install the ASCOM driver.
Step 6
Step 7
Uncheck the Run
MALLINCAMSKY 3.7
checkbox
Step 8


M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
15
Optionally, (see Installing the DIRECTSHOW Driver for more in-depth details), Double-Click
on the DIRECTSHOW DRIVER Folder to open it up, then Double-Click on the
MALLINCAMDshowSetup program and follow the instructions to install the Directshow
drivers onto your computer.
Windows may display a warning asking for permission to run the program, if it does, select
YES.
Connecting the DS16CTEC to your
computer
Un-screw the plastic dust cover from the front of the SkyRaider-DS16CTEC camera (place it
back in the box for safe keeping) and Screw in the 2-inch eyepiece adapter (M42 x 0.75mm) to
the front of the DS16CTEC and inset camera into a 2” eyepiece adapter on your Telescope.
Depending upon the telescope, you may need extenders so that you can reach focus with your
telescope. It is recommended that you set this up in the daytime, so you can see what you are
doing (plus can aim at an easy to find tree or telephone pole).
The T2 (M 42 x 0.75 mm) female thread on the SkyRaider-DS16CTEC is a standard size, and
numerous adapters are available to connect your camera to various devices such as filter
wheels, camera lenses, filters, etc…

Step 9

432

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
16
Now connect the 12V AC adapter to a power source and attach the other end to the camera.
Attach the 5 metre USB 3.0 cable from the back of the to the SkyRaider DS16CTEC to a free
USB 3.0 (or USB 2.0) port on your computer.
The SkyRaider DS16CTEC has some strict power and thru-put requirements, and not all
computers are created equal. If you find you are having difficulties with the following steps, it
maybe the USB 3.0 port on your computer. If that is the case, one option to try is: connected a
Powered USB 3.0 Hub to your USB 3.0 port on your computer. This simple step can improve,
both thru-put, power and distance between your computer and the SkyRaider DS16CTEC
camera.
Power on the DS16C
The first time the DS16C camera is powered on and
connected to the computer, Windows will finish installing
its drivers will recognize the camera. You will hear and a
beep should be heard acknowledging the connection.
Using the USB 2.0 Ports on the SkyRaider DS16CTEC
The USB 2.0 HUB on the SkyRaider-DS16CTEC can be used to connect with various
accessories, such as a guide camera, filter wheel, or electronic focuser. This will allow you
better management of your cables. The integrated USB 2.0 hub on the SkyRaider-DS16CTEC is
powered by the 12V external power source.



M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
17
Running MallincamSky
Locate and double-click on the MallincamSky icon located on your Desktop to start
MallincamSky. When the software loads, you will be able to locate under the
Camera Tab the DS16CTEC camera name. Click on this name to activate the camera
and thus display in the Video window what the telescope is pointing at.
FIGURE 1.0 -MallincamSky’s opening screen. Note: the SkyRaider camera is not yet activated
If the driver has been successfully loaded, you will see the name of the SkyRaiderDS16CTEC
Camera in the MallincamSky Camera List on the upper left of the Window. You can install
more than one SkyRaider Camera to your computer, but the software can only control one
SkyRaider Camera at a time.
You can run multiple instances of MallincamSky at the same time, this way you can have one
instance control one Mallincam camera and the other instance control the other Mallincam
camera.
If you notice that the SkyRaiderDS16CTEC has a (USB2.0) behind it, then you are either using a
USB 2.0 port, or the distance is too great for the USB 3.0 cable, and the system has entered
USB 2.0 speeds. Remember USB 2.0 utilizes slower speeds but gives you greater distances.




M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
18
C2: The MallincamSky Window
The MallincamSky Software Window is segmented into a few regions to make viewing and
adjusting the SkyRaider camera easy and intuitive.
①The Top Menu Line provides dropdown menus and icons to allow you to make major
settings of the software
② The MallincamSky Left SideBar provides the simple click activation and selection
capabilities to control all aspects of the image and camera.
③The Left SideBar Base provides selection options for Camera, Folders, or Undo. Left
Clicking on the selection choice will fill the Left SideBar with its options.
④The Video Window will contain the display image from the SkyRaider Camera. It is here
that you will see the live video, or images.
⑤The Information Line will indicate the current camera, current frame rate, number of
frames displayed, resolution, information about captures, etc.
Chapter
2

M A L L I N C A M S K Y D S 1 6 C T E C U S E R M A N U A L
19
Quick Work-Flow Procedures
Quick Workflow for Starting MallincamSky
So, you do not like to read manuals, and you just want to just jump right into imaging. Then
this section gives you a Quick and Dirty method to get going. Then, I follow this section with
an even more detailed section on Planetary Imaging Workflow, and finally a more detailed
section on Workflow on Imaging Deep Sky Objects.
Double Click on the MallincamSky Icon to start the program.
Select the SkyRaiderDS16C TEC from the Camera List in the Camera Tab.
With the Camera Tab selected on the Left SideBar; Left-Click on the
SkyRaiderDS16C TEC (between lines in Camera Heading).
Once the SkyRaider is selected, a black rectangle (with
SkyRaider Camera name) will appear in the Video Window
of the MallincamSky Software along with the Horizontal and
Vertical Rulers, and the fan on the SkyRaider DS16C TEC may start
running.
Activate TEC from the Cooling tab to cool camera (set about 30obelow ambient temperature).
The current temperature of your camera is displayed on the bottom right corner of the
MallincamSky Window.
You can also turn On or OFF the fan via the Slider in the Cooling Tab
The Mallincam SkyRaider DS16C TEC Camera provides a processing technique called Dark
Field and Flat Field Corrections (see Detailed Sections below for techniques and explanations
on using both Dark Fields and Flat Fields).
Step 2
Step 3
Step 1

