MAN USER MANUAL (LJ14 LLJ)
Getting in- using the thinnest key to unlock and lock the coach whilst also
twisting the black dial located on the door. Twist clockwise for unlock and anti-
clockwise for lock, then pushing the small round button near the key lock to
open an close the door top for front door bottom for middle door.
Power- No power switch on this coach.
Heat/Aircon- Three large dials control the main functions dial 38 controls air
flow direction 39 controls heating and 40 controls fan speed. 48 controls
passenger temperature controls.
Microphones- Two fitted one in the dash and one to the right of the drivers
seat. Dash one controlled by having radio on and driver mic with a switch on
the dash.
Boiler- fill the container up in the locker. Then on the coach open the locker
near the middle stairs ensure the switch is on the dash and then make sure 51
is on (pump for water) 52 to heat the water up 53 to turn on the water and
then use 55 to select hot water 54 for cold water.
Adblue- below the fuel gauge there is a small silver button push this to see the
gauge light up blue for AdBlue level push again for fuel.
Toilet- toilet drop is located under the sink in the toilet (square key needed)
Here you will find a black lever twist to open the drop wait until finished then
twist back to shut or toilet flush will not work. Topping up the waters using the
hose connectors in the middle offside locker.
Batteries- Rear offside locker.
Oil/water/coolant- in the main locker.
Fuses- Above the driver in the overhead locker
Bulbs-
Belts-
Triangle-

1. Front door 5. Locker door lock/unlock
2. Middle door 6. Drivers window
3. Driver overhead fan 7. Dash info button i.e air/oil
4. Locker door lock/unlock 8. Nav screen

9. Tachograph 14. Assistance/stop
10. Radio/DVD 15. Toilet on/off
11. Reading lights 16. Air horn on/off
12. Interior lights 17. Engine check
13. Mic on/off

18. Regeneration 25. electronic stability program
19. Manual Regeneration 26. Tag axle lift
20. Assistance/stop 27. Reverse Beep on/off
21. Spotlight 28. Rear axle lift
22. Light cycle check 29. Front axle lift
23. 30. Hazard’s
24. Kneel 31. Main Lights

32. Mirror Adjustments 35. Spotlight
33. Mirror demister 36. Sun blinds
34. Window demister 37. Driver window

38. Driver air flow direction 44. Step heater
39. Driver temp control 45. Passenger aircon
40. Driver Fan speed 46. webasto
41. Quick defrost 47. Passenger fan speed
42. Air recycle 48. Passenger temperature control
43. 49. Heater timer

51. Pump use this to pump the water through
52. fill the urns
53. Water heat
54. select cold water
55. select hot w

ater.
