Mango Mirror MM1 User manual

General'Installation'Instructions'
Model:'MM1'
'
WARNING:
If used in a bathroom Mango Mirror must be plugged into a Ground-Fault Circuit-Interrupters
(GFCI) outlet.
Mango Mirror should not be used in an environment with consistent high humidity.
RISK OF ELECTRIC SHOCK. DRY LOCATION USE ONLY.
Failure to follow this warning could result in serious injury and electrocution from electrical shock.

Preparation*
*
Tools'required'for'assembly:'(Not'Included)'
•'Pencil'' ' •'Screwdriver'' ' •'Level''
• Tape measure • Safety glasses
Important: When choosing your location, please ensure that the power adaptor cable will
reach your power outlet when installed.
'
General'Installation'Instructions'
Model:'MM1'
'
Package*Contents:*
'
(1)' Mango'Mirror''(Glass'mirror'with'attached'metal'frame'and'power'chord)'
'
'
Wall'mounting'Hardware'pouch'containing:'
(1)'Wall'-Hook'
(2)' Drywall'Anchors''
(2)'Screws'
'
(1)' General'Installation'Instruction'document'
'
CAUTION:
Anchors are for drywall surfaces only. Use tile anchors for tile surfaces. (not included)
Two people are required to safely install this mirror. The mirror will break if dropped. Take
extra precautionary measures to ensure a secure grip on the parts.
For'online'version'of'installation'document'and'
video'please'visit:'
www.mangomirror.com/pages/installation'

General'Installation'Instructions'
Model:'MM1'
'
Installation*Steps:*
'
1.'Once'the'location'and'height'of'the'mirror'has'been'determined,'place'the'wall-hook'on'the'
wall'as'shown'below.'Position'it'over'wall'studs'when'possible'for'the'most'secure'installation.'
Use'a'level'(not'included)'to'ensure'the'wall-hook'is'level.'Mark'the'position'for'the'screws'
holes'with'a'pencil'through'the'center'of'the'two'holes.''
2.'Put'aside'wall-hook.''If'no'studs'are'found'on'marked'positions,'use'the'screwdriver'to'install'
self-drilling'drywall'anchors'on'all'marked'positions.''For'your'safety'please'ensure'that'anchors'
are'installed'correctly.'If'damaged,'please'replace'with'appropriate'wall'anchors'rated'for'at'
least'50'lbs,'before'continuing.'
3.'Place'the'wall-hook'against'the'wall;'line'up'the'holes'
against'the'anchors'against'the'wall.'Insert'the'screws'
into'the'wall-hook'holes'and'the'wall'anchors'(or'
directly'into'wall'studs'if'applicable)'and'then'tighten'
firmly'with'a'screwdriver.''For'your'safety'please'
ensure'that'the'wall-hook'is'firmly'secured'and'
tightened'against'the'wall.'
'
'
''
'
'
Wall-hook''
Side'view'
Wall-hook''
Front'view'
Wall''

'
General'Installation'Instructions'
Model:'MM1'
'
4.''Mirror'is'heavy;'two'people'should'carry'the'mirror.''Based'on'your'power'outlet'placement,'
decide'on'which'side'to'hold'the'power'plug'as'you'carry'the'mirror.'
'
Ensure'that'the'motion'sensor'ring'is'to'the'bottom'right'facing'out'towards'you.''Then'place'the'
mirror'back'metal'brace'against'the'wall'and'lift'it'up'so'that'the'wall-hook'is'inserted'in'the'slot'in'
the'back'metal'brace.'The'back'metal'brace'must'be'flush'against'the'wall.'Then'gently'lower'the'
mirror'so'that'the'metal'brace'slot'top'sits'into'the'wall'hook,'holding'the'mirror'in'place.'
'
Once'complete.'Check'to'confirm'that'the'mirror'is'correctly'and'completely'flush'against'the'wall,'is'
hanging'on'the'wall-hook'and'being'held'securely'in'place,'before'letting'go'of'the'mirror.'
'
5.''Plug'the'power'adaptor'into'the'power'outlet'and'follow'the'instructions'on'the'mirror'display'
and'use'your'mobile'app'as'instructed,'to'setup'Mango'Mirror.'
'
Thank'you'for'choosing'Mango'Mirror!'
Back'Metal'Brace'
Slot'for'Wall-Hook'
Wall-Hook'
Motion'sensor'
