Mooreco Basic Desk User manual

Modular Teacher Desk - Basic Desk
UPDATED AS OF: 09/04/2019
Part Numbers: 90455-XXXX-XX / 90456-XXXX-XX
1 of 8
INSTRUCCIONES DE ENSEMBLAJE
NO LA TIRE
INSTRUCTIONS DE MONTAGE
NE PAS JETER
ASSEMBLY INSTRUCTIONS
DO NOT THROW AWAY!

INSTRUCCIONES DE ENSEMBLAJE
NO LA TIRE
INSTRUCTIONS DE MONTAGE
NE PAS JETER
ASSEMBLY INSTRUCTIONS
DO NOT THROW AWAY!
Parts
UPDATED AS OF: 09/04/2019 2 of 8
90390 - 1 Side Leg
58590 - Support Tube
58259 (72”)/ 58258 (60”)
- Modesty Panel
Table Top (Custom)
x2
x1
x1
x1

INSTRUCCIONES DE ENSEMBLAJE
NO LA TIRE
INSTRUCTIONS DE MONTAGE
NE PAS JETER
ASSEMBLY INSTRUCTIONS
DO NOT THROW AWAY!
Hardware
UPDATED AS OF: 09/04/2019 3 of 8
P1 - Adjustable Leg
P2 - V Bracket: Inner
A - M6 x 42mm
B - M6 x 12mm
E - Non-Locking Caster
F - Locking Caster
G - Lock Washer
Tool(s):
-Allen Wrench
-Caster Wrench
x1
x1
x2
x3
x1
x1
x2
90390 - 1 Sided Leg x2
P1 - Support Tube
P2 - U Clamp
A - M6 x 12mm
C - Set Screw
D - Wood Screw
Tool(s):
-Allen Wrench
x1
x2
x4
x2
x4
58590 - Support Tube

For full product warranty details, please visit:
Para obtener información sobre la garantía del producto, consulte este sitio (ingles):
Pour plus d’informations sur la garantie du produit, consultez ce site (anglais):
For questions on assembly or missing/damaged parts, please contact us using the
following information.
Para preguntas sobre el ensamblaje o piezas faltantes o dañadas, por favor
contáctenos usando la siguiente información.
Pour toute question sur le montage l-assamblage manquantes ou endommagées,
veuillez nous contacter en utilisant les l’information ci-dessous.
To register your product for warranty, please visit:
Para registrar la garantía del producto, vea este sitio (en ingles):
Pour enregistrer la garantie de votre produit, consultez ce site (en anglais):
Review full assembly instructions and
check that all parts are present before
beginning assembly. Heavy or large
furniture may require multiple persons in
order to properly assemble. If you have
questions regarding assembly, contact
the manufacturer before continuing.
Damage due to incorrect assembly may
not be covered by warranty. Do not use
product unless all screws are tight. Check
all screws for tightness at least every
six months. If parts are broken, missing,
damaged, or worn, stop use of the product
until repairs are made by your dealer using
factory authorized parts.
WARNINGS AND DISCLAIMERS
WARRANTY
CARE & MAINTENANCE
PRODUCT REGISTRATION
UPDATED AS OF: 09/04/2019 4 of 8
Phone:
1.800.749.2258
(Monday – Friday, 8AM – 5PM
Central Time)
http://moorecoinc.com/warranty
https://moorecoinc.com/register
Email:
[e-mail]
Previo a comenzar el proceso de
ensamblaje favor de revisar las
instruccionesyasegurarsequecuentacon
todas las partes y materiales necesarios.
Es posible que los muebles grandes o
pesados, requieran mas de una persona
para ensamblarlos correctamente. Por
favor contacte al fabricante directamente
si tiene alguna duda o pregunta antes de
continuar con el proceso de armado del
producto. La garantía no cubrirá daños
que ocurrieron por errores cometidos
durante el proceso de ensamblaje. Todos
los tornillos deben estar ajustados previo
el uso del producto. Debe revisar los
tornillos periódicamente, por lo menos
cada seis meses y asegurarse de que
estén bien ajustados. Por favor detenga
el uso del producto si partes del producto
se pierden, rompen, se deterioran por uso
o se rompen. Favor de contactar a su
distribuidor para que le envíen las partes
necesarias o realice las reparaciones
necesarias con partes autorizadas por el
fabricante.
Avant de commencer l’ assamblage
veuillez consulter les instructions
complètes et vérier si vous avez toutes
les pièces nécessaires. Ill est possible que
plusieurs personnes soient nécessaires
pour assemble des meubles grand ou
lourds. En cas de doute sur l assamblage
contactez le fabricant avant de continuer.
Les dommages encourus pendant
l’assamblage ne seront pas couvert par
la garantie. Ne pas utiliser le produit sans
vérier que tous les vis soient serrées.
Vériez que les vis sont serrées au moins
tous le 6 mois. Si aucune pièce se casse,
manque, est endommagée ou usée,
arrêtez d’ utiliser de produit jusqu’à ce
que le vendeur le repaire a l’aide de pièces
autorisées par la fabricant.
ADVERTENCIAS Y RENUNCIAS AVERTISSEMENTS

STEP 1
UPDATED AS OF: 09/04/2019 5 of 8
STEP 2
Hardware Required:
-Adjustable Leg x2
90390 - P1
-Non-locking Caster
90390 - E
-Locking Caster
90390 - F
-Lock Washer x2
90390 - G
Tool(s) Required:
-Caster Wrench
Attach two casters (E,F) to Adjustable Leg (P1) with Caster
Wrench included. Be sure to include Lock Washer (G) on each.
Locking Caster installed in front. Do this for both Legs.
Connect V-bracket Inners (P2) to Modesty Panel with two screws
each (B). Keep top screw 3 holes or less from edge of panel to
use desk at lowest setting. Circular holes at bottom of brackets
should face down.
Hardware Required:
-V-Bracket: Inner x2
90390 (1) - P2
90390 (2) - P2
-M6 x12mm x4
90390 (1) - B x2
90390 (2) - B x2
Tool(s) Required:
-Allen Wrench

STEP 3
UPDATED AS OF: 09/04/2019 6 of 8
STEP 4
Slide modesty panel V-bracket Inners into outer brackets
on both legs. Secure modesty panel in place with
two screws (B) inserted through bottom of brackets.
Hardware Required:
-M6 x 12mm x2
90390 (1) - B
90390 (2) - B
Tool(s) Required:
-Allen Wrench
After removing all four screws from each leg, raise to preferred height
setting. Replace all screws after. Legs must be at equal heights.
Tool(s) Required:
-Allen Wrench

STEP 5
UPDATED AS OF: 09/04/2019 7 of 8
STEP 6
Loosen set screws (C) on sliding outer members of Support
Tube (P1). Fasten one side of tube to side of leg with screws (A)
then after adjusting tube to appropriate length, fasten opposite
side of tube to other leg with same screws. Retighten set screws
on Support Tube when finished.
Hardware Required:
-Support Tube
58590 - P1
-M6 x 12mm x4
58590 - A
Tool(s) Required
-Allen Wrench
Set Table Top into place by aligning threaded inserts on underside
of table with holes in both Adjustable Legs. Insert screws (A) up
through holes and hand tighten all before tightening further with
allen wrench. Be sure grommet holes are positioned correctly.
Hardware Required:
-M6 x 42mm x4
90390 (1) - A x2
90369 (2) - A x2
Tool(s) Required:
-Allen Wrench

STEP 7
UPDATED AS OF: 09/04/2019 8 of 8
Hardware Required:
-U-Clamp x2
58590 - P2
-Wood Screw x4
58590 - D
Tool(s) Used
-Electric Drill (recommended)
Install U-Clamps by sliding over Support Tube and securing
with two wood screws each (D). Screws are driven directly
into underside of table. Position clamps approximately half-
way along each sliding tube.
THIS COMPLETES ASSEMBLY INSTRUCTION
