Marani CLP-260 User manual

19"
482mm
DIGITAL USB

Index
Index........................................................................P age 1
Safety Instructions................................... ..................Page 2
Controls and Parameters......................... ...................Page 3
CLP260 Processes Notes.......................... .................Page 4
RMS Compressor............................ ..........Page 4
A.G.C............................................... ....... Page 5
PEAK Limiter................................... .........Page 6
Sub Harmonic Synthesizer.........................P age 7
Input and Output Level Considerations........................P age 8-10
Getting Started..........................................................P age 11
Encoders and ENTER/QUIT buttons............................P age 12
Load/Save Preset......................................................P age 12-14
Utility Function..........................................................P age 15
Edit Parameters........................................................ Page 16
Routing....................................................P age 16
Input Gain................................................ Page 16
Noise Gate...............................................P age 16
A.G.C.......................................................P age 17-20
Filters 1-7.................................................P age 21
Sub Harmony............................................P age 22
Drive........................................................P age 23
RMS Compressor......................................P age 24-25
Make Up.................................................. Page 25
PEAK Limiter............................................P age 26
Mute........................................................ Page 26
Appendix 1............................................................... Page 27
Input Level Meters Ref. Table.....................P age 27
Comprressor/Limiter Activity......................P age 28-29
Meters Ref. Table......................................P age 29
CLP260 Processes Block Scheme...............................P age 30
1

IMPORTANT SAFETY INSTRUCTIONS
Ventilation
1
Overload
5
Heat sources
3
Power cord proctecion
4
2
Maintenance
8
7Humidity
Cleaning
Note: inordertoensuresafety,pleasereadtheseinstructionscarefully
Attention:To reduce the riskoffireorelectricshock,donotexpose this apparatus
torainormoisture!
All safety and operating instructions should be read before the
product is operated.
6
Objects or liquid entry
inside the unit
Refer all servicing to
qualified service
personnel. To
prevent the risk of
shock, do not
attempt to service
this equipment
yourself because
opening or removing
covers may expose
you to
dangerous voltage
or other hazards.
The unit should far
away form water.
Be careful that no
objects fall or liquid is
spilled inside the unit
thr ou gh ve nt ila ti on
openings.
Do not block any
ventilation openings.
Clean only with dry
cloth.
Do not install near
any heat sources
such as radiators,
stoves, or other
apparatus that
produce heat.
Protect the power
cord from being
walked on or pinched
particularly at plugs.
Power plug should
not overload.
2

1
3
CLP-260
RMS StereoCompressor
CONTROLS
Enc Variation Adjust Parameters Value
Key Enter Access to Editing Pages and Par Values Confirm
Key Quit Exit from Editing Pages
Led Clip Input/Process Overflow
Enc Navigation Compressor's Ratio and Knee selection
Button Process On/Off RMS Compressor Active/Bypass
Pot Input Level Analog Input Gain Left/Right
Pot Output Level Analog Output Volume Left/Right
TECHNICAL DATA
Inputs Balanced 2 TRS/2 XLR
Outputs Balanced 2 TRS/2 XLR
Input Max Level +15dBu
Output Max Level +10dBu
THD+N <0.01% @ -6dBFS (Bypass)
S/N Ratio >100dBu (Processes in Bypass)
Frequency Response 20Hz – 20kHz +/-0.5dB
A/D and D/A Resolution 24bit
Process Resolution 24x48 bit
Processes RMS Stereo Compressor
Power Supply 110V/220V (Switchable)
2x20 characters LCD display for the Parameters Editing
Fully remotely controllable by USB or MIDI interfaces

4
The CLP260 is a Stereo RMS Compressor and Peak Limiter with the
addition of a Noise Gate, an AGC, a 7 bands Eq and a Sub Harmonic
Synthesizer.
W i t h r e f e r e n c e t o t h e f o l l o w i n g R M S C o m p r e s s i o n p r o c e s s
representation
The CLP260 is implementing a REAL RMS Compressor, so compressing
at the same threshold a pure sinusoidal signal as a squared wave.
Particularly, the RMS Compressor is a Compression process applied with
fast slow Attack and Release times to the INPUT signal of a Unit, in order
to maintain the amplitude of the OUTPUT signal at a defined level, when
input level is exceeding a defined intervention Threshold.
The Compressor implemented in the CLP260 is acting on the evaluation
of an input signal which is an averaged one on a 50ms time frame, and
representing actually the RMS value of the input signal itself, so to make
more “Musical” the Compressors action. The RMS Compressor, it is so
maintaining constant the output energy and not the Output peak, so to
have for the different inputs, independently from their harmonic content,
a constant output RMS level.
More, for the CLP260 Compressor is also available a Ratio and a
Hard/Soft Knee parameters. The Ratio parameter is allowing to get a
compressed output maintaining a constant dB ratio with the input.
This feature is got in the CLP260 with a precise Look Up Table Log
Computation process, allowing int the ratio maintenance a precision of
0.1dBu.

5
The Hard and Soft knee feature is allowing the user to select between a
sudden compression intervention when the input signal it is just above
the Threshold (Hard Knee) or a smoother one starting the compression
smoothly before the Threshold.,
Together with the RMS Compressor, the CLP260 is making available also
other 2 very useful Dynamic Processes: an AGC and a Peak limiter.
In order to understand how the CLP260 AGC is working, need to refer to
the following picture
The AGC is an Expansion/Compression process applied with pretty slow
Attack and Release times to the INPUT signal of a Unit, in order to
maintain the average amplitude of the OUTPUT signal at a defined level,
independently from the averaged amplitude of the input sources.
For this purpose, the AGC has to be able to expand the input signal, there
where the average of the related output signal is below a defined
Threshold (Exp Thr), and to maintain the expanded signal at a constant
expansion level when the averaged signal is beyond a defined Threshold
(Thr Hold).
The AGC implemented in the CLP260 is acting on the evaluation of an
input signal which is an averaged one on a 50ms time frame, and
representing actually the RMS value of the input signal itself, so to make
more “Musical” the AGC action.
If the output signal of the AGC process will exceed then a defined
Threshold (Cmp Thr), so becoming too loud, a compression process is
occurring.

6
The Speed and the amount of the Expansion can be defined through the
“Exp Time' and “Exp Ratio” parameters, so as the Speed and the amount
of the Compression can be defined through the “Cmp Time” and “Cmp
Ratio” parameters.
When the Signal coming out from the AGC process (Output), applied to
the AGC input, is above the “Exp Thr” and below the “Thr Hold”, it is
expanded up to the max expansion coefficient defined by the Exp Ratio.
When the Signal coming out from the AGC process (Output), applied to
the AGC input, is above the “Cmp Thr”, it is compressed up to the min
compression coefficient defined by the “Cmp Ratio”.
When the AGC output is comprised within the “Thr Hold” and the “Cmp
Thr” Thresholds, no further expansion or compression actions will be
taken and the expansion/compression coefficient, will be maintained with
its current value.
Particularly, if the averaged AGC output level is “entering” the signal
“hold” area coming from the expansion area, then the Coefficient
computed by the AGC for multiplying the input level in order to get the
proper output signal, will be higher than one (if the “Exp Ratio” will be set
at 1:2), so as the coefficient will be lower than one (if the “Cm Ratio” will
be set between 2:1 and 16:1) if the averaged AGC output level is
“entering” the signal “hold” area coming from the compression area.
The last dynamic process available with the CLP260, is a Peak Limiter,
useful when the CLP260 is used before an amplifier and need to limit the
signal for avoiding the amplifier to overload and break cabinets.
This kind of Limiter is acting on the Signal Peak detection and therefore
the limitation is on the output Peak value.

7
In addition to the Dynamic Processes, in the CLP260 is also available a
powerful Sub Harmonic synthesizer.
The Sub Harmonic Synthesizer is working generating sub Harmonics on
the base on the Harmonic content of the original signal.
Particularly, the amplitude distribution of the generated Sub Harmonics is
following the shape of a band pass filter set on the low part of the band.
The peak of this “band pass” filter, is centered on 2 possible frequencies,
60Hz and 90Hz.; this means that when selected the frequency range
setting the Sub Harmonics Amplitude Peak on 60Hz (24-36Hz), the
Harmonics added to the original sound will bring a “deep” and very low
extra body to the original sound.
When selected the frequency range setting the Sub Harmonics Amplitude
Peak on 90Hz (36-56Hz), the Harmonics added to the original sound will
bring a “lighter and more booming” extra body to the original sound.
Finally, in order to “adjust” harmonically the Input signal, a 7 bands Eq. is
available, where the first of the 7 filters can be chosen to be 1st/2nd ord.
HP or Low Shelving, the seventh one can be chosen to be 1st/2nd ord. LP
or High Shelving and the other 5, from the second to the sixth, can be
chosen to be 1st/2nd ord. High Shelving or Peaking.
The CLP260 has a bypass control in the analog domain.

8
Input and Output Level Considerations
The Input and Output levels of the CLP260 can be adjusted by a couple of
Analog Potentiometers.
Due to the fact that the potentiometers are operating in the analog
domain, before the A/D converter ( Input Level) and after the D/A
converter (Output Level) there is not an absolute and fixed relation
between the Input and Output Levels and the levels in front of the A/D and
after the D/A converters.
Need therefore to provide the user some “Absolute” reference in terms on
Input level and Output level, in order to clarify first what are the Max
Absolute Input level, which cannot be exceeded without getting an Op-
Amp clip, no longer recoverable by any Digital operation.
In order to help the user in understanding clearly the following
paragraphs, need to refer to the “Input Level” and “Output Level” pictures,
replicating the Input and Output Potentiometers' grids with a more
precise detail:
Fig A Fig B
The figures A/B are showing in details the possible positions of the
potentiometers controlling the Analog Input and Output Level.
Referring then to the above precise divisions of the available range
between the MIN and MAX position of the potentiometers, the Max Analog
Input/Output levels can be understood, so as the can be found the proper
setting for the best use of the RMS Compressor.

9
In order to verify the Input/Output Max Levels of the CLP260, need first to
make sure that NO process is active.
Max Analog Input: in order to understand what can be the maximum
Analog Input level to the unit, which is the one before the clipping of the
Op-Amps in front of the A/D converters, need to make sure that no Digital
clip (DSP process) is occurring.
The output will never clip unless the clip is coming from the digital
process.
This means that if the D/A output isn't clipped, then no clipping will come
from the Analog Op-Amp output section.
From this point of view, any position of the Output potentiometer for
evaluating the Max Input level, can be set.
Let's consider to set the output potentiometer to the position 5 of the grid
in Fig B.
Now, to define what is the Max Analog Input level, need to set the Input
Level potentiometer to a position granting enough attenuation of the
signal before the A/D, so to make sure no clip is occurring on the A/D side.
Let's set the Input potentiometer to the position 3 of the grid of Fig. A.
Done this, we can increase progressively the Input signal level until the
output will start to clip or the Input Level displayed on the LCD will not
show the “>” symbol.
In this way, can be found that the Max Input level, before to get the Input
Op amps clipping is +15dBu.
Max Analog Output: once set the Max Input Level to +15dBu, in order to
identify the Maximum Output Level, need to move the Input Level
Potentiometer from the position 3, up to the position that is clipping the
A/D converter.
With +15dBu Input, the position of the Input Level Potentiometer at the
limit of the Input Clipping, is the position 6 of the Input Level grid of Fig A.
Once set, then, the Input Level Potentiometer to the position 6, in order to
find out the Max Output Level achievable with the CLP260, need to set
the Output Level Potentiometer to the position Max
The Max output Level that can be found is +10dBu, if measured with an
Audio Precision or similar measurement tools.
CLP260 Signal to Noise Ratio (S/N): from the condition got for the Max
Analog Output verification, can be go the S/N of the CLP260.
If, with the Max Output Level of +10dBu, the Input Signal Is removed,
measuring the output can be seen that the residual Ground Floor Noise
drops to -92.7dBu, which let us say that the S/N=(Max Output) – (GND
Floor Noise) = 10dBu - (-92.7dBu) = 102.7dBu

1 0
Analog Bypass: de-pressing the “On/Off Process” button, the Analog
Bypass can be activated.
In this condition the CLP260 is bypassing the Digital section and
connecting the Analog Input to the Analog Output.
Here the Max Output is reaching the +10.4dBu with a GND Floor Noise of
-92.3dBu, bringing the S/N of the unit to 102.7dBu
Set Input and Output Potentiometers for a 0dBu Input/Output path: in
order to evaluate the performances of the CLP260 RMS Compressor,
we'll set a 0dBu path, and to that one we'll refer the all measurement we'll
show for making understanding the Unit's way of working.
What anyway will be shown, will remain valid for any input level value
there where with the Input Level Potentiometer, the signal to the A/D will
be adjusted so to be close to the Clipping (notified by the RED CLIP Led
or by the symbol “>” Input Level page on the LCD).
In order to be on a 0dBu Input/Output path, when the Unit is in “Process
Bypass”, need from the previous condition to set the external Analog
Input Signal to 0dBu.
In order to get in Output also 0dBu, being at the maximum A/D Input level,
need to set the Input Level Potentiometer to 7 of the Grid of Fig A and the
Output Level Potentiometer to the position 7 of the Grid of Fig B.
The Input Level page on the LCD will just stop a step before the showing
of the “>” symbol.
To the 0dB path condition are referred the AGC, RMS Compressor and
Peak Limiter's Thresholds that when set to 0dB are meaning that the
processes are not active being the Threshold set at the maximum input
level to the unit...which cannot be exceeded, impeding therefore any
compressing/limiting process.
This means the the 0dB threshold of the AGC, RMS Compressor and
Peak Limiter processes are related to the max Input level and therefrom
has to be evaluated the threshold set when using a threshold different
from 0dBu: in example a -10dBu Threshold on the RMS Compressor
means that starting from an input reaching the max input level, this input
will be limited at 10dBu lower RMS level.

1 1
Getting Started
As soon as the CLP260 is turned ON the device model name will appear
in the LCD screen:
And after showing quickly the “Firmware Version 2.212”, the LCD will
show the “Input Level Page, by default, where is possible see thanks to
graphic meters, the Input level
When the Input Level is in clipping, the symbol”>” will appear (as for the
channel B in the example)
From this initial condition, and if an RMS Compressor or a Peak Limiter
(or both) are set to be active, their compression/limiting activity can be
seen thanks to a the “Compressor Activity” and “Limiter Activity” windows,
accessible from the Input Level one just rotating the NAVIGATION
encoder clock/counter-clock wise.
If in example from the Input level window the user want to see the RMS
Compressor's activity, it is enough to rotate the NAVIGATION Encoder
clockwise twice, so accessing the following screen:
Where the compression activity is shown from right to left, matching the
depth of the compression on the base of the Compression Coefficient
Value: if the coefficient is equal 1, then no compression is occurring and
no bars are displayed, if the coefficient is <1, then as more the coefficient
is far from 1 as more from right to left bars will appear.
F o r t h e r e l a t i o n b e t w e e n t h e b a r s i n t h e I n p u t L e v e l ,
Compression/Limiting Activity windows and the Input signal level and
compression depth, refer to the Appendix 1 tables.
CLP260
Compressor Limiter

1 2
Encoders and ENTER, QUIT buttons
The CLP260 is equipped with 2 Relative Encoders, “VARIATION” and
“NAVIGATION”, These encoders allow to navigate the user interface and
edit sections of the processor. They allow the user to navigate within the
screen for the selection of sub-menus, pages and parameters and to
select the values to be assigned during the editing operations.
The “ENTER” and “QUIT” buttons allow the user to confirm or NOT
confirm the operations performed by the encoders.
Particularly, the “ENTER” button is also allowing to enter the editing
pages from the initial Input Level and Compressor/Limiter Activity
screens.
The “QUIT” button is allowing to get back from any editing page to those
screens.
From anyone of the Initial windows, the editing menus and pages can be
accessed pressing the “ENTER” button.
Once left the Input Level and Compressor/Limiter Activity windows, the
screen will show on the top row the currently running preset and it's
nam e, and on th e lo wer row, the sub- menu for th e CL P260
functions/parameters access and editing.
Once left the Input Level and Compressor/Limiter Activity windows, if the
currently running preset is the number 16 called “DeepCmp”, the screen
will then appear as follow:
And to access the all sub-menus need just to rotate clock/counter-clock
wise the NAVIGATION Encoder.
The all available Sub-menus are:
Load Preset: Loading one of the 32 available presets (16 factory
and 16 users)
Save Preset: Store up to 16 user presets
Utility Function: Communication Interface setting (USB or MIDI)
Edit Parameters: Access to the parameters' editing of the all
CLP260 processes
Preset 16: DeepCmp
Load Preset

1 3
Load Preset: this page allows the Loading of a preset program from one
of the 16factory presets (1-16) or from one of the 16 user presets:
By pressing ENTER and rotating the “VARIATION” encoder, it is possible
to scroll through all current available user presets.
If the Preset 21 is chosen (AGC_Fat), then pressing the “ENTER” button,
the current temporary window will appear
and the AGC_Fat preset number 21 will be loaded and the sub-menu
page will be left going back to the previous level, updated:
Save Preset: this page allows you to store a new preset, and up to 16, in
the CLP260's memory from the location 17 up to the location 32, skipping
the locations from 1 to 16 reserved to the Factory presets:
By pressing the ENTER button and rotating the “VARIATION” encoder, it
is possible to scroll through the previously saved presets and the
available empty locations (identified by “Empty”).
If no user presets are stored, the “Save a Program” screen will show
empty memory locations for all 17-32 presets as shown in the example
below for location 30:
Preset 16: DeepCmp
Load Preset
Load Preset
<Preset:21 AGC_Fat >
Preset 21: AGC_Fat
Load Preset
Wait : Loading …...
<Preset:21 AGC_Fat >
Preset 21: AGC_Fat
Save Preset

1 4
When storing an edited configuration for the CLP260, select the location
for a preset from the 16 available by using the “VARIATION” encoder.
Once the desired location appears on the screen press ENTER again to
reach the “Edit Name Preset” page.
If the location number 30 is ok, in example, then the screen will be the
following:
In this page the User can enter a Preset Name (up to 16 Characters) by
using the “VARIATION” encoder to choose a character and the
“NAVIGATION” encoder to move between the 16 available locations for
the character's positioning.
The current position of the cursor is shown by a “blinking underscore”.
To store the Preset Name press the “ENTER” button again.
The above action will take you to the “Enter to Save” page showing the
selected location for the preset and the final edited name, in example
LightCmp:
Pressing “ENTER” again, will store the preset in the selected location
with the chosen name and the following transitory screen will appear on
the LCD:
Once saved the preset, the CLP260 will go back to the previous level
Wait : Saving …...
30: LightCmp
[Enter] to Save
30: LightCmp
Save Preset
<Preset:30 EMPTY >
Edit Name Preset
30: _preset name
Preset 30: LightCmp
Save Preset

1 5
Utility Function: this sub-menu allows to define the remote control
interface [USB or MIDI] to be used for controlling the CLP260 :
From “Interface Utilities”, press “ENTER” to access the “Config
Communication” page, allowing to choose the remote control protocol for
the CLP260.
By pressing “ENTER” and then using the VARIATION encoder, can
chosen between the two possible interfaces (USB or MIDI) for the
CLP260.
Particularly, a MIDI channel from 01 to 15 can be selected, or the USB
interfaces
Once selected the desired interface, a double click on the “QUIT” button
is allowing to go back to the original menu.
NOTE: the “QUIT” button, once pressed as many time as necessary, will
bring back to the top LCD level which is the one displaying the Input Level
or the Compressor/Limiter Activity.
Preset 30: LightCmp
Utility Function
Utility Function
Config Communication
Config Communication
Device <MIDI Ch=12>

1 6
Edit Parameters: in this sub-menu, the all parameters related to the
signal processes of the CLP260 are available for editing.
Pressing the “ENTER” button, the all processes can be accessed for
editing.
With the “NAVIGATION” Encoder, the all processes can be scrolled and
from the “Edit Parameters” Sub Menu, the CLP260 channel can be
selected for editing simply rotating clock/counter-clock wise the
“VARIATION” encoder.
Once entered the Edit Parameter Sub Menu, the screen will show the
following:
In the case above, editing the all parameters edited are referred to the
Channel A (ChA); for editing the processes referring to the Channel B
(ChB), it is enough to rotate the VARIATION encoder and the screen will
show the following:
Indicating that the Parameters will be edited will refer to the ChB process
and Output.
It is also possible select the Ch.A+B, and in this case the all edited
parameters will be assigned with the same value to the Channel A and B
..linked.
In the Editing Parameters Sub-menu, the all available processes are:
Routing: is allowing to assign the the currently edited channel
processes the Input A, B or the Sum (A+B)/2
Input Gain: Digital control of the Input level
Noise Gate
A.G.C.
Filter 1 – Filter 7: Eq where the filter 1 is selectable as 1st/2nd
Ord. HP OR Low Shelving and the filters from 2 to 7 as 1st/2nd
Ord. High Shelving OR Peaking
Sub Harmony: Sub Harmonic Synthesizer centered around 65Hz
or 90Hz
Drive: Signal Control before the RMS Compressor
RMS Compressor
Volume: Make Up Volume after the RMS Compressor and before
the Peak Limiter
Peak Limiter
Mute: Output Channel Muting.
Ch.A Edit Param
Routing
Ch.B
Edit Param
Routing

1 7
In order to edit the parameters of any single process, it is enough to enter
the process editing page by pressing the “ENTER” button and leaving it,
once finished the editing, by pressing the “QUIT” button for going back to
the Editing Parameters sub-menu and selecting the new process to edit,
scrolling the all processes with the NAVIGATION encoder.
Routing: from this page it is possible to assign anyone of the 2 inputs of
the CLP260 to the currently edited Channel's processes and Output.
So, it is possible to assign to the processes of the Channel A and its
Output, the Input A, B or (A+B)/2.
The selection can be operated using the VARIATION encoder.
Input Gain: from this page it is possible to adjust the Input Level digitally
(after the A/D converters) ranging from -12dBu up to +6dBu, by steps of
0.5dBu.
The adjustment can be operated using the VARIATION encoder.
Noise Gate: from this page it is possible to set the parameters of a Noise
Gate placed at the beginning of the all dynamic and Eq. Processes
Threshold: the Noise Gate Threshold can be set as -80dBu, -85dBu, -
90dBu or as OFF; when OFF the Noise Gate is just bypassed
Release Time: it is the time taken by un-muting the output once detected
again an input signal over the set threshold; can range from 5ms to
100ms, by steps of 1ms up to 10ms and of 10ms from 10ms up to 100ms.
Attack time: is the time taken by the Noise Gate to enter the Output Mute
condition once the input signal is detected to be below the Threshold; can
range from 0.5 seconds up to 2 seconds by steps of 0.1 seconds.
The adjustment of the parameters can be operated using the VARIATION
encoder.
Ch.A Noise Gate
< Attack = 0.5s >

Note: for the all Dynamic Processes as the AGC, RMS Compressor and
Peak Limiter, it is necessary, in order to make them working properly, to
be in a condition similar to the one described before for the 0dBu path.
Any different condition on the Input Signal, can bring to the same output
results if the Input Level Potentiometer will be Adjusted in order to be
close to the Input Clipping condition, which means that if the Input Signal
will be lower/higher than 0dBu, the potentiometer will have to adjust the
input to the A/D converter so to go back to a “0dBu” condition as the one
used as reference.
A.G.C.:from this page it is possible to set the parameters of the Automatic
Gain Controller.
AGC Bypass: from this screen it is possible to set the AGC On or OFF, so
to activate it or not without resetting the all parameters; use the
“VARIATION” encoder for toggling the AGC Bypass On/Off.
The following is an example screen for the “AGC Bypass” page where the
AGC is set Active
AGC Exp Time:from this screen it is possible to set the AGC Expansion
time from 0.057 seconds up to 14.4 seconds; use the “VARIATION”
encoder to set the value.
The following is an example screen for the “AGC Exp time” page where
the Expansion Time is set to 1.5S
AGC Cmp Time: from this screen it is possible to set the AGC
Compression time from 0.014 seconds up to 6 seconds; use the
“VARIATION” encoder to set the value.
The following is an example screen for the “AGC Cmp time” page where
the Compression Time is set to 0.5S
Ch.A A.G.C.
< Bypass = ON >
1 8

AGC Exp Thr: from this screen it is possible to set the AGC Expansion
Threshold from -70 dBu up to the Hold Threshold Value; use the
“VARIATION” encoder to set the value.
The following is an example screen for the “AGC Exp Thr” page where the
Expansion Threshold is set to -50dBu
AGC Cmp Thr: from this screen it is possible to set the AGC Compression
Threshold from Hold Threshold Value up to 0dBu; use the “VARIATION”
encoder to set the value.
The following is an example screen for the “AGC Cmp Thr” page where
the Compression Threshold is set to -3dBu
AGC Thr Hold: from this screen it is possible to set the AGC Threshold of
the AGC Signal “Hold” area, from -69 dBu up to -1dBu; use the
“VARIATION” encoder to set the value.
The following is an example screen for the “AGC Thr Hold” page where
the Threshold of the Signal “Hold” area is set to -40dBu
Ch.A A.G.C.
< Exp Thr = -50dB >
1 9
