Marantz ND8006 User manual

Network CD Player
ND8006
Quick Start Guide
ENGLISH
DEUTSCH
FRANÇAIS
ITALIANO
ESPAÑOL
NEDERLANDS
SVENSKA
РУССКИЙ
POLSKI
Kurzanleitung / Guide de démarrage rapide / Guida di Avvio Rapido /
Guía de inicio rápido / Snelhandleiding / Snabbstartsguide /
Краткое руководство пользователя / Skrócona instrukcja obsługi
Bitte zuerst lesen... / Lisez-moi en premier.... / Nota preliminare.... /
Lea esto primero.... / Lees mij eerst... / Läs detta först... /
Прочитайте в первую очередь... / Przeczytaj to najpierw....
Read Me First....
1.ND8006N_ENG_QSG_1012.indd 1 2017/10/16 10:25:04
PrintingColor:Black

1
Thank you for choosing a Marantz network
CD player. This guide provides step-by-step
instructions for setting up your network CD
player.
Please do not return this unit to the store –
call for assistance.
If you need help… :
If you need additional help in solving problems,
contact Marantz customer service in your area.
www.marantz.com
Welcome Before You Begin
What’s In the Box
Quick Start Guide Power cord
CD-ROM
(Owner’s Manual)
Remote control unit
(RC001PMND)
Safety
Instructions
R03/AAA batteries
Cautions on Using
Batteries
Audio cable
Notes on radio Remote connector
cable
Network CD
Player
External antennas for
Bluetooth/wireless
connectivity
Required for Setup
Amplifier Speaker systems Speaker cables Router
1.ND8006N_ENG_QSG_1012.indd 1 2017/10/16 10:25:07
PrintingColor:Black

2
Optional
Computer USB cable iOS device
Router with WPS LAN cable
• These drawings are for illustrative purposes only and may not represent
the actual product(s).
Important: External Antennas
The removable external antennas are required for both
Bluetooth and Wireless network connectivity. Please make
sure to connect the antennas before attempting to use the
Bluetooth or Wi-Fi features of the ND8006.
nConnecting the external antennas for
Bluetooth/Wireless connectivity
For each of the two antennas:
qPlace the antenna evenly over the antenna terminal
located at the upper left or right corner of the rear
panel.
wTurn the antenna clockwise until it is fully connected.
Do not over tighten.
eRotate the antenna upwards for the best possible
reception.
qwe
1.ND8006N_ENG_QSG_1012.indd 2 2017/10/16 10:25:09
PrintingColor:Black

3
There are seven steps to the setup
process.
1Installing batteries in the remote control unit
2Connect to the amplifier
3Plug the power cord into a power outlet
4Connect to the network
5Enjoying your music!
6Download the HEOS App
7Listen to computer audio
1) Installing the Windows driver software
2) Connect to PC or Mac
3) Listen to PC or Mac Audio
Setup 1Installing batteries in the
remote control unit
Batteries
1.ND8006N_ENG_QSG_1012.indd 3 2017/10/16 10:25:11
PrintingColor:Black

4
2Connect to the amplifier
RL
RL
AUDIO
LR
IN
Amplifier
3Plug the power cord into a
power outlet
Power cord
(supplied)
Connect to household
power outlet
(AC 230 V, 50/60 Hz)
1.ND8006N_ENG_QSG_1012.indd 4 2017/10/16 10:25:12
PrintingColor:Black

5
Choose from one of the following options.
4Connect to the network
Wireless
Select “WPS Router”.
WPS router
Wi-Fi router
Select “Wi-Fi - scan” and wait as
your ND8006 looks for available
networks.
No WPS router
Wi-Fi router
Power on. Select language.
(Please wait as starting the network
settings can take a few minutes.)
WPS
iOS
English
Select Language
:
enter
ENTER
Wi-Fi - scan
Select Connection Method
:
cancel
:
enter
ENTER BACK
iOS device
iOS version 7 or later
WPS
iOS
Make sure your iOS device
is connected to your
Wi-Fi Network. Select the
network named “Marantz
ND8006” from the
Settings/Wi-Fi screen on
your device.
Marantz ND8006
Marantz ND8006
1
1 2
3
3
3
Wired
WPS
iOS
WPS Router
Select Connection Method
:
cancel
:
enter
ENTER BACK
1.ND8006N_ENG_QSG_1012.indd 5 2017/10/16 10:25:29
PrintingColor:Black

6
Select language.
Please wait as completing
the connection can take a
few minutes.
(The front panel of the ND8006 will
show the status of the connection.)
Press the WPS button on
your router. Within 2 minutes,
press the ENTER button.
Connect a network cable
between your ND8006 and
your router.
(cable not included)
Power on.
Please wait while your ND8006
connects to your wired network.
Select your network name.
(If your network name is not listed,
select “Rescan”.)
Enter your network
password using the
number keys on the
remote control.
Network name
Select Network
:
back
:
enter
ENTER BACK
Enter Wi-Fi Password
:
a
:
character type
＋10 １～９
Please wait as completing...
Quick Setup
Wired
Follow the instructions
and tap Next.
Marantz ND8006
Marantz ND8006
Please wait as completing the connection
can take a few minutes.
(The front panel of the ND8006 will show the status of
the connection.)
Sharing the network...
Quick Setup
3
21
4
4
4
4
5
5
5
NETWORK
WPS
iOS
Press the WPS button...
Quick Setup
:
back
:
connect
ENTER BACK
Press the ENTER button.
Access Point 1
Wi-Fi Connected
:
back
:
next
ENTER BACK
If the signal strength
of your wireless
network is weak, to
improve reception,
please turn the
antenna on the back
of your ND8006 or
move your router to
the ND8006.
Wi-Fi
Connected!
Connected!
1.ND8006N_ENG_QSG_1012.indd 6 2017/10/16 10:25:33
PrintingColor:Black

7
Auto-Update
Setting
Usage Data
Setting
Setup
Complete!
Turns on Auto-Update so
that future updates are
automatically downloaded
and installed when your
ND8006 is in standby mode.
On
Auto-Update
Feature updates are automatically do...
1
Select “On” to turn on
Auto-Update.
Off
Auto-Update
Feature updates are not automatically...
Select “O” to turn o
Auto-Update.
Sets the time zone that matches
the area where you live.
Central European Tim...
Select your time zone
:
back
:
enter
ENTER BACK
2
To help us improve our products
and customer service, Marantz
collects anonymous information
about how you use your ND8006.
Marantz will never provide any
information we collect to third
parties.
Yes
Send usage data
To help us improve our products and...
Select “Yes” to provide
information on the operating
status of this unit.
No
Send usage data
To help us improve our products and...
Select “No” to not provide
information on the operating
status of this unit.
Network Control
Setting
On
Network Control
:
back
:
enter
ENTER BACK
Off
Network Control
:
back
:
enter
ENTER BACK
Select Network Control ON
to control ND8006 from your
smartphone, use Bluetooth/
Apple AirPlay®/HEOS App and
maintain constant network
access. Power Consumption
during standby power will be
slightly higher.
Select Network Control OFF
to reduce power consumption
during standby. You can not
turn on your ND8006 from
your smartphone or use
Bluetooth/Apple AirPlay/
HEOS App until your ND8006
is powerd on manually and
connects to your network.
1.ND8006N_ENG_QSG_1012.indd 7 2017/10/16 10:25:34
PrintingColor:Black

8
nEnjoying Internet Radio
Press INTERNET RADIO.
Select the station you
want to play, then press
ENTER.
Select “Play Now”, then
press ENTER.
1
2
3
nEnjoying music using Apple AirPlay
Open Control Center
(iOS 7 and later) by
swiping up from the
bottom of your screen,
then tap AirPlay.
【Example】iOS 11
【Example】iOS 9
AirPlay
D
rop:
ryon
e
Select the “Marantz
ND8006” from the
AirPlay Device list.
Marantz ND8006
Play the song on your iPhone, iPod
touch or iPad.
1
2
5Enjoying your music!
3
1.ND8006N_ENG_QSG_1012.indd 8 2017/10/16 10:25:36
PrintingColor:Black

9
nEnjoying music using Bluetooth
Press Bluetooth to select
Bluetooth.
When using for the first time,
the unit will go into the pairing
mode automatically and
“Bluetooth Pairing Mode” will
appear on the display of the unit.
Turn on Bluetooth fr...
Bluetooth Pairing Mode
:
cancel
BACK
Activate Bluetooth on
your mobile device. Bluetooth ON
Marantz NA6005
Bluetooth
1
2
Select “Marantz
ND8006” from the
Bluetooth device list on
your mobile device.
Bluetooth ON
Marantz ND8006
Bluetooth
Play music using any
app on your device.
Bluetooth ON
Marantz NA6005
Bluetooth
• To pair with other Bluetooth devices, press and hold Bluetooth on the
remote control until “Bluetooth Pairing Mode” is displayed on the unit.
3
4
1.ND8006N_ENG_QSG_1012.indd 9 2017/10/16 10:25:39
PrintingColor:Black

10
6Download the HEOS App
The HEOS App lets you control your
ND8006 from anywhere in your home.
Use HEOS to explore, browse, and play
music from many online streaming services
or from your own music library.
1.ND8006N_ENG_QSG_1012.indd 10 2017/10/16 10:25:41
PrintingColor:Black

11
7Listen to computer audio
Download the dedicated driver from the
“Download” section of the ND8006 page of
the Marantz website (http://www.marantz.
com/pages/home.aspx) onto your PC.
Unzip the downloaded  le, and double-
click the exe  le.
1
2
Install the driver.
qSelect the language to use for the installation.
wClick “OK”.
q
w
eThe wizard menu is displayed. Follow the
instructions on the screen.
rWhen the wizard is completed, click “Yes”.
r
NOTE
• Please see the FAQ at www.marantz.com if you experience any issues
getting audio to play from your computer through the ND8006. You may
also want to check the support pages for your audio player application.
1) Installing the Windows driver
software
NOTE
• The installation of the driver software is not necessary in the following
cases.
• When you do not play back the music from a PC using USB-DAC of this
unit.
• When using a Mac OS.
• The driver software cannot be installed correctly if your PC is connected
to the unit by a USB cable.
• If the unit and your computer are connected by a USB cable and the
computer is switched on before installation, disconnect the USB and
restart the computer.
Windows OS
System requirements：Windows 7, Windows 8,
Windows 8.1 or Windows 10
3
1.ND8006N_ENG_QSG_1012.indd 11 2017/10/16 10:25:41
PrintingColor:Black

12
3) Listen to PC or Mac Audio
Power on.
Press USB-DAC to
switch the input source
to “USB-DAC”.
Set the audio signal destination to this
unit on the computer.
Windows OS
qClick the “Start” button and click “Control
Panel” on the PC.
• The control panel setting list is displayed.
wClick the “Sound” icon.
• The sound menu window is displayed.
1
2
3
Computer on
which the driver
software and audio
player software are
installed
Type A
USB 2.0 cable
(Sold separately)
Type B
2) Connect to PC or Mac
1.ND8006N_ENG_QSG_1012.indd 12 2017/10/16 10:25:41
PrintingColor:Black

13
tClick the “Advanced” tab.
ySelect the sampling rate and bit rate to be applied
to the D/A converter.
• It is recommended that “2 channel, 24 bit,
192000 Hz (Studio Quality)” is selected.
(Windows 7)
• It is recommended that “2 channel, 32 bit,
192000 Hz (Studio Quality)” is selected.
(Windows 8/Windows 8.1/Windows 10)
uClick “Apply”.
iClick “Test”.
• Check that audio from this unit is output from the
PC.
t
i
y
u
eCheck that there is a checkmark next to “Default
Device” under in “ND8006” of the “Playback”
tab.
• When there is a checkmark for a dierent device,
click “ND8006” and “Set Default”.
rSelect “ND8006” and click “Properties”.
• The ND8006 Properties window is displayed.
ND8006
r
1.ND8006N_ENG_QSG_1012.indd 13 2017/10/16 10:25:42
PrintingColor:Black

14
Mac OS X macOS
System requirements: Mac OS X 10.10, 10.11 or macOS 10.12
qMove the cursor to “Go” on the computer
screen, and then click “Utilities”.
• The utility list is displayed.
wDouble-click “Audio MIDI Setup”.
• The “Audio Devices” window is displayed.
eCheck that “Use this device for sound output” is
checked in “ND8006”.
• If a dierent device is checked, select and
“Secondary click” on “ND8006”, and then
select “Use this device for sound output”.
ND8006
ND8006
e
rSelect the “ND8006” format.
• It is normally recommended to set the format to
“384000.0 Hz” and “2ch-32 bit Interger”.
ND8006
ND8006
tQuit Audio MIDI Setup.
Use your favorite music applications on your
PC/Mac to play audio through the ND8006.
• For high resolution audio playback you will need to
obtain an advanced audio player software such as
JRiver Media Center or Audirvana.
NOTE
• Additional settings to output audio to the ND8006 may have to be
selected in your advanced audio player application. Please refer to the
user’s manual for your application.
4
r
1.ND8006N_ENG_QSG_1012.indd 14 2017/10/16 10:25:42
PrintingColor:Black

15
nPrintable Version
Access the print version of the owner's manual from the
included CD-ROM or select the “PDF Download” link
from the Online Version.
Insert the disc into
your PC.
Follow the screen or double click on
the PDF le.
1
2
Owner’s Manual
nOnline Version
Enter the following URL into your web browser:
manuals.marantz.com/ND8006/EU/EN/
Please refer to the Owner's Manual for more details about the setup and operation of the network CD player and its features.
PDF
Overview
Connections
Playback
Settings
Tips
Appendix
PDF Download
Network CD Player
Network CD Player
WEB Manual
Copyright © 2017 D&M Holdings Inc. All Rights Reserved.
ND8006
Contents
English
Online Manual
1.ND8006N_ENG_QSG_1012.indd 15 2017/10/16 10:25:48
PrintingColor:Black

1.ND8006N_ENG_QSG_1012.indd 16 2017/10/16 10:25:48
PrintingColor:Black
