SA-14S1
Super Audio CD Player
Reference Series - Super Audio CD/CD Player
Marantz Audio Advantage
nWide-range, high-speed sound with analog
audio circuits featuring exclusive Marantz
HDAM-SA2 and HDAM modules
nPlayback HD (High definition) content
-Native playback of DSD files via USB Type B
port: DoP (DSD over PCM)
nAsynchronous USB-B computer input
with LPCM and DSD support
(Sampling frequencies: 32/44.1/48/88.2/
96/176.4/192 kHz[PCM], 2.8224MHz[DSD])
nNew disc drive mechanism, to thoroughly
suppress vibration
nNew disc tray mechanism with Xyron FRP
(Fiber Reinforced Plastics).
nUSB-B “Ground/Signal” isolator for
reduced noise and high-quality sound from
connected computers
nClock jitter reducer generates a low-jitter
output clock from a jittery external clock
source
nFull discrete, high-quality headphone
amplifier, featuring HDAM-SA2 and HDAM
nSelectable Digital Filter
nDigital to analog converter function with
3 digital inputs (USB-B, Coaxial, Optical)
nTotal sound balance retuned with optimized
components
High quality sound
n192kHz/24bit high current audiophile
D/A converter
nOxygen Free Copper toroidal transformer
(50 VA)
nRigid chassis together with double layered
bottom plate, aluminum die-cast chassis feet
n
High purity gold plated copper RCA terminals
nLow noise LCD display
Useful functions
nFront panel USB-A port for iPhone®/iPod®
or USB device digital to analog conversion
and playback
nDown-mix stereo playback of multichannel
Super Audio CD discs
nSuper Audio CD, MP3/ WMA playback
nSystem remote unit, controls both SA-14S1
CD player and PM-14S1 amplifier
nAuto standby, low power consumption in
standby mode (less than 0.3W)
The SA-14S1 Super Audio CD/CD player has been designed to deliver the utmost fidelity from your favorite music discs, and features state-of-
the-art digital technologies to reproduce sound with superb musicality. In addition to playback of stereo and multi-channel Super Audio CDs,
the SA-14S1 features the ability to play music CDs including CD-R and CD-RW recordable types, and the player also features multiple digital
inputs so it can be used as a standalone D/A converter with other digital audio source components. It's equipped with a USB port on the
front panel that lets you connect an iPod or iPhone, and the USB-B port on the rear panel can be used with a computer to decode linear PCM
and DSD high definition audio files via DSD over PCM. The analog circuits feature our exclusive HDAM (Hyper Dynamic Amplifier Module)
technologies to deliver superior wide-range sound with expansive dynamic range. The SA-14S1 features a newly developed center-mounted
disc drive mechanism mounted on its own sub-chassis for the most reliable and stable playback, and the power supply features a high current
toroidal power transformer with Oxygen Free Copper secondary windings. The elegant remote control can also control the matching PM-14S1
reference grade integrated amplifier.

General
Power supply: AC 120 V, 60 Hz
Power consumption:
37 W
0.3 W (Standby mode)
Dimensions (W x H x D):
173/8” x 5” x 16.5”
440 x 123 x 419 mm
32 lbs, 14.5 kg
Port
Analog audio output
RCA (Unbalanced) 1 pair
Phones 1
Digital audio output
Optical 1
Coaxial 1
Digital audio input
Optical 1
Coaxial 1
USB-A (Front) 1
USB-B (Rear) 1
Contol
Remote control (IN/OUT) 1/1
Disc Formats Playability
• Super Audio CD
• Audio CD (Stereo)
• CD-R (Stereo), CD-RW (Stereo)
Supported audio formats of D/A converter
USB-B port Coaxial/ Optical
DSD (*1)
(2-channel) •-
Linear PCM (*2)
(2-channel) • •
(*1) DSD Sampling frequency: 2.8224 MHz
Bit length: 1 bit
(*2) Linear PCM
Sampling frequency :
32/44.1/48/88.2/96/176.4/192 kHz
Bit length: 16/24 bit
Analog Output
Super Audio CD CD
Disc capacity 1 1
Channels 2 channels 2 channels
Frequency range 2 Hz - 100 kHz 2 Hz - 20 kHz
Frequency response 2 Hz - 50 kHz 2 Hz - 20 kHz
Dynamic range 109 db 100 dB
Signal-to-noise ratio 109 db 110 dB
Total harmonic distortion 0.0009% 0.0015%
©2013 Marantz America, LLC.
For purposes of improvement, specifications and design are subject to change without notice.All specifications, dimensions and weights are subject to
change without notice. D&M Holdings, Marantz, Marantz America, LLC. or any of its subsidiaries will not assume any liability for errors in this spec sheet
which may result in consequential errors being made by dealers, designers, custom installers, cabinet makers or end users, etc., based upon information
contained within this document.
*Design and specifications are subject to change without notice. *Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. *“Made for iPod,” and “Made for iPhone,” mean that an electronic
accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please
note that the use of this accessory with iPod, or iPhone, may affect wireless performance. *AirPlay, the AirPlay logo, iPad, iPhone, iPod, iPod classic, iPod nano, iPod shuffle and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.
Call for Assistance: 9:00AM to 8:00PM M-F E.S.T.
For frequently asked questions please visit www.marantz.com
1-855-ONE-MARANTZ
1-855-663-6272
Specifications
20440713A
Can be used as a D/A converter with
3 digital inputs (coaxial, optical, USB type B)
Analog audio circuitry featuring Marantz’s
unique HDAM technology
Robust, high-speed power supply
Supported file types
Playable media
CD-R/-RW USB memory device
AAC -•
WMA • •
LPCM • • (.wav)
MP3 (MPEG1 Layer3) • •
*Some functions may not work for some discs or files,
even if indicated “•” on the table.
