Marantz SA1/F1N User manual

SA-1 392K855010 MIT
3120 785 22320
First Issue 2000.12
Service
Manual
R
SA-1
Please use this service manual with referring to the user guide ( D.F.U. ) without fail.
SA1/F1N, /N1G, /U1G
Super Audio CD Player
SACD CD
PAUSESTOP
DISPLAY
SACD/CD
PLAY
SUPER AUDIO CD PLAYER SA-1
OPEN/CLOSE
POWER
REP 1
TRACK RND PROGRAM TOTAL PLAY
TABLE OF CONTENTS
SECTION PAGE
1. MAIN UNIT
1.1 TECHNICAL SPECIFICATIONS ......................................................................................................... 1-1
1.2 TEST MODE ........................................................................................................................................ 1-2
1.3 BLOCK DIAGRAM ............................................................................................................................... 1-3
1.4 WIRING DIAGRAM ............................................................................................................................. 1-5
1.5 SCHEMATIC DIAGRAM ...................................................................................................................... 1-7
1.6 PARTS LOCATION ........................................................................................................................... 1-15
1.7 EXPLODED VIEW AND PARTS LIST ............................................................................................... 1-21
1.8 ELECTRICAL PARTS LIST ............................................................................................................... 1-24
2. CDM-10M ( SACD MODULE )
2.1 REMOVING AND REINSTALLING THE MAIN PARTS ...................................................................... 2-2
2.2 BLOCK DIAGRAM ............................................................................................................................... 2-5
2.3 SCHEMATIC DIAGRAM ...................................................................................................................... 2-9
2.4 PARTS LOCATION ........................................................................................................................... 2-13
2.5 IC DATA ............................................................................................................................................ 2-17
2.3 EXPLODED VIEW AND PARTS LIST ............................................................................................... 2-36
2.4 ELECTRICAL PARTS LIST ............................................................................................................... 2-37

MARANTZ DESIGN AND SERVICE
Using superior design and selected high grade components, MARANTZ company has created the ultimate in stereo sound.
Only original MARANTZ parts can insure that your MARANTZ product will continue to perform to the specifications for which
it is famous.
Parts for your MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent.
ORDERING PARTS :
Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
The following information must be supplied to eliminate delays in processing your order :
1. Complete address
2. Complete part numbers and quantities required
3. Description of parts
4. Model number for which part is required
5. Way of shipment
6. Signature : any order form or Fax. must be signed, otherwise such part order will be considered as null and void.
SHOCK, FIRE HAZARD SERVICETEST :
CAUTION : After servicing this appliance and prior to returning to customer, measure the resistance between either primary AC
cord connector pins ( with unit NOT connected to AC mains and its Power switch ON ), and the face or Front Panel of product and
controls and chassis bottom.
Any resistance measurement less than 1 Megohms should cause unit to be repaired or corrected before AC power is applied, and
verified before it is return to the user/customer.
Ref. UL Standard No. 1492.
In case of difficulties, do not hesitate to contact the Technical
Department at above mentioned address.
001120MIT
USA
MARANTZ AMERICA, INC
MARANTZ AMERICA, INC.
440 MEDINAH ROAD
ROSELLE, ILLINOIS 60172
USA
PHONE : 630 - 307 - 3100
FAX : 630 - 307 - 2687
BRAZIL
PHILIPS DA AMAZONIA IND. ELET. ITDA
CENTRO DE INFORMACOES AO
CEP 04698-970
SAO PAULO, SP, BRAZIL
PHONE : 0800 - 123123
(Discagem Direta Gratuita)
FAX : [phone]
JAPAN Technical
MARANTZ JAPAN, INC.
35- 1, 7- CHOME, SAGAMIONO
SAGAMIHARA - SHI, KANAGAWA
JAPAN 228-8505
PHONE : [phone]
FAX : [phone]
EUROPE / TRADING
MARANTZ EUROPE B.V.
P.O.BOX 80002, BUILDING SFF2
5600 JB EINDHOVEN
THE NETHERLANDS
PHONE : +31 - 40 - 2732241
FAX : +31 - 40 - 2735578
TECHNICAL AUDIO GROUP PTY, LTD
558 DARLING STREET,
BALMAIN, NSW 2041,
AUSTRALIA
PHONE : 61 - 2 - 9810 - 5300
FAX : 61 - 2 - 9810 - 5355
CANADA
LENBROOK INDUSTRIES LIMITED
633 GRANITE COURT,
PICKERING, ONTARIO L1W 3K1
CANADA
PHONE : 905 - 831 - 6333
FAX : 905 - 831 - 6936
AUSTRALIA
QualiFi Pty Ltd,
24 LIONEL ROAD,
MT. WAVERLEY VIC 3149
AUSTRALIA
PHONE : +61 - (0)3 - 9543 - 1522
FAX : +61 - (0)3 - 9543 - 3677
NEW ZEALAND
WILDASH AUDIO SYSTEMS NZ
14 MALVERN ROAD MT ALBERT
AUCKLAND NEW ZEALAND
PHONE : +64 - 9 - 8451958
FAX : +64 - 9 - 8463554
THAILAND
MRZ STANDARD CO.,LTD
746 - 754 MAHACHAI ROAD.,
WANGBURAPAPIROM, PHRANAKORN,
BANGKOK, 10200 THAILAND
PHONE : +66 - 2 - 222 9181
FAX : +66 - 2 - 224 6795
TAIWAN
PAI- YUING CO., LTD.
6 TH FL NO, 148 SUNG KIANG ROAD,
TAIPEI, 10429, TAIWAN R.O.C.
PHONE : +886 - 2 - 25221304
FAX : +886 - 2 - 25630415
MALAYSIA
WO KEE HONG ELECTRONICS SDN. BHD.
SUITE 8.1, LEVEL 8, MENARA GENESIS,
NO. 33, JALAN SULTAN ISMAIL,
50250 KUALA LUMPUR, MALAYSIA
PHONE : +60 3 - 2457677
FAX : +60 3 - 2458180
AMERICAS
SUPERSCOPE TECHNOLOGIES, INC.
MARANTZ PROFESSIONAL PRODUCTS
2640 WHITE OAK CIRCLE, SUITE A
AURORA, ILLINOIS 60504 USA
PHONE : 630 - 820 - 4800
FAX : 630 - 820 - 8103
AUSTRALIA
KOREA
MK ENTERPRISES LTD.
ROOM 604/605, ELECTRO-OFFICETEL, 16-58,
3GA, HANGANG-RO, YONGSAN-KU, SEOUL
KOREA
PHONE : +822 - 3232 - 155
FAX : +822 - 3232 - 154
SINGAPORE
WO KEE HONG DISTRIBUTION PTE LTD
130 JOO SENG ROAD
#03-02 OLIVINE BUILDING
SINGAPORE 368357
PHONE : [phone]
FAX : [phone]

1-1
1.1 TECHNICAL SPECIFICATIONS
Power Supply
F version ............................................................................................................... AC 100 V 50/60 Hz
N version .................................................................................................................... AC 230 V 50 Hz
U version .................................................................................................................... AC 120 V 60 Hz
Power Consumption ...................................................................................................................... 33 W
Cabinet, etc.
Dimensions (Width x Height x Depth) ................................................................... 458 x133 x 365 mm
Net weight ................................................................................................................................. 17.7 kg
Operating temperatures ................................................................................................+5 °C ~ +35 °C
Operating humidity ....................................................................................... 5 % ~ 90 % (without dew)
Accessories
Remote control unit (RC-1SA) ............................................................................................................ 1
Dimensions (Width x Height x Depth) ............................................................... 44 x 17.5 x 239 mm
Net weight (without Batteries) .................................................................................................. 175 g
AAA (R03) Batteries ............................................................................................................................ 2
Stereo audio cable with cinch pins ...................................................................................................... 1
AC Power Cord ................................................................................................................................... 1
User’s Guide ....................................................................................................................................... 1
Specifications subject to change without prior notice.
Super Audio CD CD
Audio Characteristics
Channels 2channels 2channels
Frequency range 2 Hz - 100 kHz 2 Hz - 20 kHz
Frequency characteristics 2 Hz - 50 kHz (-3 dB) 2 Hz - 20 kHz
Dynamic range 109 dB 98 dB
THD (1 kHz) 0.0012 % 0.0015 %
wow & flutter Precision of quartz Precision of quartz
Analog output
output level (unbalanced) 2.2 V 2.4 V
output level (balanced) 4.4 V 4.8 V
Digital output
output level (cinch JACK) - 0.5 Vp-p (75 ohm)
output level (optical) - -19 dBm
Optical Readout System
Laser AlGaAs AlGaAs
Wave length 650 nm 780 nm
Sampling frequency 2.8224 MHz 44.1 kHz

1-2
1.2.TEST MODE
1. How to enter the initial test mode
Turn the power on, press the SACD/CD button and the
track down button more than two seconds.
Display: F 0 TEST
2.Version check mode
1 Press the SACD/CD button to enter this mode.
Display: 1 0 9 0 9 2 8
Year/Month/Day
2 Model number (Press the PLAY button in the step 1 .)
Display: 1 0 0 0 0 1 0
Model number
3 Version (Press the PLAY button in the step 2 .)
Display: 1 0 A 0 0 0 1
Version number
4 Then press the PLAY button to return to the initial test
mode.
Display: F 0 TEST
3. Laser test mode
1 Press the PAUSE button to enter this mode.
(In case of the no disc mode, eject the tray.)
Display: 3 0 0 0 0 0 0
2 Enter the laser test mode.
Display: 3 1 0 0 0 0 0
3 CD laser lit up (Press the STOP button in the step 2 or
4.)
Display: 3 1 0 0 0 0 0
4 SACD laser lit up (Press the PAUSE button in the step 2
or 3.)
Display: 3 1 0 0 0 0 0
5 Laser test mode completed (Press the PLAY button in
the step 2, 3 or 4.)
Display: F 0 TEST
4. FIP test
1 Press the PLAY button to enter this mode
Display: All lamps lit up.
2 Press the PLAY button again to return to the initial test
mode
Display: F 0 TEST
5. How to exit the test mode
In case of finish the test mode, press the mains switch
(POWER button)

1-3 1-4
