Markant MAX 2.5 User manual

MAX 2.5 INSTALLATION MANUAL

INDEX
Chapter
HARDWARE
RANGE
FRAME
1 - Rectangular
2 - Wing
ADJUSTABILITY
1 - HI-Tech
2 - E-Drive
T-Range
3 - F-Drive
T-Range
Wing
ELBOW
SCREEN
TABLE TOP
1 - Rectangular
2 - Wing
page 1
page 2
page 3-4
page 5
page 6
page 7
page 8-10
page 11-12
page 13-16
page 17
page 18-19
page 20
page 20
Page

1
MAX 2.5 INSTALLATION
Cap screw M6 x 30mm
Power tool
Allenkey
Cap screw M6 x 40mm
Leveler Wood Screw
Button cap screw M8 x25mm
Self tapping screw
HARDWARE
120 deg
120 deg
120 deg
NEED A LEVELER NEED A LEVELER
*POWER TOOL, ALLEN KEY & LEVELER ARE NOT INCLUDED

MAX 2.5 INSTALLATION
2
Panel Range Screen RangeT - Range
M6 x 40mm
Cap Screw
x 8
Allen Key
5mm
M6 x 40mm
Cap Screw
x 4
M6 x 30mm
Cap Screw
x 4
Allen Key
5mm
Allen Key
5mm
M6 x 40mm
Cap Screw
x 8
Allen Key
5mm
RANGE
LEGS
25005005xx
25005010xx
25001040xx
Max single end foot
Max single middle foot
25001050xx
25001055xx
OPTION:
25001035xx

MAX 2.5 INSTALLATION
3
FRAME (RECTANGULAR)
ab
completed
T AND PANEL RANGE
T AND PANEL RANGE , SCREEN RANGE
NEED A LEVELER
NEED A LEVELER
Max2 system frame 140x72
Max2 system frame 160x72
25007525xx
Max2 system frame 180x72
Max2 system frame 200x72
25007535xx
25007545xx
25007555xx

MAX 2.5 INSTALLATION
4
SCREEN RANGE
completed
*Complete look for MAX SCREEN RANGE frame
NEED A LEVELER

MAX 2.5 INSTALLATION
5
a
b
c
FRAME (WING)
*Complete look for MAX SCREEN RANGE frame
NEED A LEVELER
2500515xx
25007515xx

MAX 2.5 INSTALLATION
6
E-Drive F-Drive
HI-Tech
TOPSUPPORT
ADJUSTABILITY
*Place the plastic slider wheels on the upper and bottom section of top supports

MAX 2.5 INSTALLATION
7
ADJUSTABILITY (HI-TECH)
M8 x 25mm
Button Cap
Screw x 2
Allen Key
5 mm
NEED A LEVELER
Max2 lid for worktop 140
Max2 lid for worktop 160
25005061xx
25005066xx
Max2 lid for worktop 180
Max2 lid for worktop 200
25005071xx
25005076xx

MAX 2.5 INSTALLATION
8
ADJUSTABILITY (E-DRIVE)
T- RANGE
Max2 E-drive 140
Max2 E-drive 160
25005061
25005066
Max2 E-drive 180
Max2 E-drive 200
25005071
25005076

MAX 2.5 INSTALLATION
9
d
BACK
Slot in to the
groove
ab
c
BACK
Tension steel wire rope
and slot in top support
to aluminium prole

MAX 2.5 INSTALLATION
10

MAX 2.5 INSTALLATION
11
Step 1 Step 2
ADJUSTABILITY (F-DRIVE)
T- RANGE
Max2 F-drive 140
Max2 F-drive 160
25005125
25005130
Max2 F-drive 180
Max2 F-drive 200
25005135
25005140

MAX 2.5 INSTALLATION
12
d
BACK
Slot in to the
groove
ab
c
BACK
Tension steel wire rope
and slot in top support
to aluminium prole

MAX 2.5 INSTALLATION
13
WING (ONLY F-DRIVE)
*steel wire rope
*steel wire rope
*steel wire rope
*bowden cable
25005145

MAX 2.5 INSTALLATION
14
*Measure the height of left & right
sides of top supports.
WING (ONLY E-DRIVE)
25005111

MAX 2.5 INSTALLATION
15
a.
b.
c.
d.
25005080xx

MAX 2.5 INSTALLATION
16

MAX 2.5 INSTALLATION
17
ELBOW
*Bend End after
insert in
Step 1 : Adjust 2
glides at outside
Step 2 : Adjust 2 glides
at middle to touch to
ground
25005150xx
