Marlow Wentworth Windsor Deluxe Square Cube Table User manual

Deluxe Square Cube Table
Assembly Instructions
 1 / 6

Product size:
L125*W125*H75 cm
IMPORTANT, RETAIN FOR FUTURE REFERENCE
READ CAREFULLY

Deluxe Square Cube Table
Assembly Instructions
 2 / 6
Before you start
Warnings
IMPORTANT, RETAIN FOR FUTURE
REFERENCE
READ CAREFULLY
See enclosed instructions for assembly, safety and care
information.
Failure to follow the warnings could result in serious injury.
Handle heavy parts with care.
Ensure that this product is fully assembled as illustrated before
use.
This product should only be used on firm, level ground.
Keep small parts out of reach of children.
Do not stand or climb onto this product.
This product is intended for Domestic Use only.
Furniture can be dangerous if incorrectly used. No liability will be
accepted for damage or injury caused by incorrect use of this
product.
Dos
When you are ready to start, make sure that you have the right
tools, plenty of space and a clean, dry area for assembly.
Removing all packaging and banding and place the components
carefully on suitable surfaces to prevent damaging or scratching
them.
Check the pack and make sure you have all parts listed.
Check all screws and bolts are tightened and inspect regularly.
We recommend the use of furniture covers to protect your product
when not in use.
This product is suitable for all year outdoor use.
However to prolong its life we recommend that during severely
bad weather and during the winter months, it is stored in a cool,
dry place.
Before storage, ensure that the product is clean and dry.
To clean, wipe down with a sponge and warm soapy water and
wipe with a clean, dry cloth.
Don’ts
Do not use scourers, abrasives, washing powders, chemical cleaners
or any other substances containing abrasives since these substances
can damage the product, including the glass panel.
Do not place very hot or very cold items on the glass surface
unless adequately thick table-mats are used to prevent such
items from coming into contact with the glass.
Do not use the glass as a chopping surface. Do not strike glass
with hard or pointed items.
Do not strike the glass with hard or pointed items.
Do not use power tools to construct this product.
Do not use this product if parts are missing, damaged or worn.
Do not sit or lean on this product.
Do not stand or climb onto the product and do not use it as a ladder,
as this could lead to it unbalancing and overturning.
Never drag furniture when moving it, always lift it.
Number of people required for assembly
Two people
Time to assemble
30 Minutes
Tools required
Tips:
Do NOT fully tighten bolts before
all components are connected.
Only fully tighten once you are
satisfied with the alignment of all
components.
Do not over-tighten the bolts.

Deluxe Square Cube Table
Assembly Instructions
 3 / 6

Components, fixtures & fittings (not actual size)
Table Parts List
Part
No. Diagram Qty Part No. Diagram Qty
A
Table Top Frame
1 PC B
Upper Cross Leg
1 PC
C
Bottom Cross Leg
1 PC D
Glass Top
1 PC
E
Connecting Panel
1 PC F 
ParasolHoleCap
1 PC
F2
Bolt Head Cap
12 PCS F63
M6*20mm Bolt
12 PCS
F3
Washer
12 PCS S1
Socket Wrench
1 PC

Deluxe Square Cube Table
Assembly Instructions
 4 / 6

Step by step assembly instructions
Step One
Open the packaging, take out the contents and carefully leave the glass on the carton until the
rest of the table is fully assembled.
With the help of another person, place the Table Top Frame (A) upside down on a flat,
non-abrasive surface to avoid scratching the table surface or rim.
Do NOT assemble the Legs (B&C) to the Table Top Frame (A) while it is still resting on the
Glass Top (D).
Step Two
With the help of another person, stand two legs upside down.
Place the Bottom Cross Leg (C) onto the Upper Cross Leg (B), align the assembly holes,
using Connecting Panel (E), Bolts (F63) and Washers (F3) to connect them.
DO NOT fully tighten the bolts.

Deluxe Square Cube Table
Assembly Instructions
 5 / 6
Step Three
Place the Assembled Legs onto the Table Top Frame (A), align the assembly holes, using Bolts
(F63) and Washers (F3) to connect them.
At this stage, please don't fully tighten the bolts; just assemble all bolts into place so that they
still turn freely.
Step Four
With the help of another person, carefully lift the partly-assembled table in upright position.
Level the table with adjustable feet screws.
Once you are satisfied with the alignment of all components, carefully tighten all bolts
using Socket Wrench (S1), cover all Bolt Heads with Bolt Head Caps (F2).
During this step (Levelling step and Bolts-tightening step), you may have to turn around the
table upside down for several times.
Adjustable Foot Screw

Deluxe Square Cube Table
Assembly Instructions
 6 / 6
Step Five
With the help of another person, carefully lift the Glass Top (D) and place it onto
the Table Top Frame (A).
The glass top should be securely inlaid into the Table Top Frame (A).
Make sure the glass top is evenly rested on the Table Top Frame (A).
Insert the Parasol Hole Cap (F) into the middle hole in the Glass Top (D) and the
Table Top Frame (A).
.
Your table is now ready for use.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
