Marthon 041-FL100-C User manual

800.840.1228 /MARATHONHARDWARE.COM 800.840.1228 /MARATHONHARDWARE.COM
Bottom Mounted Pull-out
Technical Specifications & Assembly
Bottom Mounted Pull-out
 Required interior width of 270mm (10 5/8”)
for opening
 Door Mount not available
 Available for hinged door only
 Load capacity: 15kg (33lbs)
 Soft-Close
Product Features
Description Part#
W x H x D 267 x 423 x 484mm (10 ¹⁄ x 16 ¹¹⁄ x 19 ¹⁄”) 041-FL100-C
Bottom Mount Pull-out, complete kit
This Bottom Mounted Pullout with concealed
undermount soft-close slides is a good fit for undersink
or base cabinets. Cutting board holder included.
14260
42
234
min. 500
Unit: mm
Front
Back
Bottom Dimensions

800.840.1228 /MARATHONHARDWARE.COM
Technical Specifications & Assembly
Bottom Mounted Pull-out
What’s In The Box
1.2.
x1 x1
4.x2
3.
x1
5.6.
x8 x2
7.
x4
Minimum Interior Cabinet Dimensions
W x H x D 267 x 423 x 484mm (10 ¹⁄ x 16 ¹¹⁄ x 19 ¹⁄”)
x2
8.
W
D

800.840.1228 /MARATHONHARDWARE.COM 800.840.1228 /MARATHONHARDWARE.COM
Technical Specifications & Assembly
Bottom Mounted Pull-out
Frame Installation
Slide Installation
4
6
7
8
8

800.840.1228 /MARATHONHARDWARE.COM
Technical Specifications & Assembly
Bottom Mounted Pull-out
Board Holder Installation
Basket Installation
