Martin FiberSource CMY150 User manual

FiberSource CMY150
user manual

Measurements are in millimeters.
280
110
197
134
398
195
© 2001-2006 Martin Professional A/S, Denmark.
All rights reserved. No part of this manual may be reproduced, in any form or by any means, with-
out permission in writing from Martin Professional A/S, Denmark.
Printed in Denmark.
P/N 35000102, Rev E

3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
AC power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Fiber optic cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Fixture orientation and location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Data link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Control address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Personality settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
General operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
General guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
The LEDs and fixture operating status. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Stand-alone operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Programming fixtures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Executing stand-alone scenes with an MC-X Controller . . . . . . . . . . . . . . 26
Controller operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Lamp control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Lamp replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Firmware updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Fuse replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
DMX protocol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
MP-2 control menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4 Introduction
I NTRODUCTION 1
Thank you for selecting the Martin FiberSource CMY150. The FiberSource
CMY150 is an automated 150-watt color-changing luminaire for illuminating fiber
optic cables in permanent installations. It has a weather-resistant IP rating of 44 that
enables it to be used in outdoor installations. It features seamless CMY color
mixing and full-range continuous dimming. The fixture may be operated with DMX
controllers, in synchronization with other units (with or without a controller), and in
stand-alone mode with programmable start and stop times, and/or light level
activation/deactivation.
UNPACKING
The FiberSource CMY150 comes with a user manual and a Philips MasterColor
CDM-SA/R 150W lamp (installed).
SAFETY INFORMATION
Warning! This product is not for household use.
This product presents risks of lethal or severe injury due to fire and heat, electric
shock, ultraviolet radiation, lamp explosion, and falls. Read this manual before
powering or installing the fixture, follow the safety precautions listed below and
observe all warnings in this manual and on the fixture. If you have questions about
how to operate the fixture safely, please contact your Martin dealer or call the
Martin 24-hour service hotline at [phone].
Guarding against electric shock
• Disconnect the fixture from AC power before removing or installing the lamp,
fuses, or any part.
• Always ground (earth) the fixture electrically.
• Use only a source of AC power that complies with local building and electrical
codes and has both overload and ground-fault protection.
• Refer all service to a Martin service technician.

Introduction 5
Preventing UV radiation and lamp explosion
• Never operate the fixture with missing or damaged lenses, without a fiber adaptor
installed, or with the housing removed.
• When replacing the lamp, allow the fixture to cool for at least 15 minutes before
opening the fixture.
• Do not stare directly into the light. Never look at an exposed lamp while it is lit.
• Replace the lamp if it becomes defective or worn out.
Guarding against burns and fire
• Never attempt to bypass the thermostatic switch or fuses. Always replace defective
fuses with ones of the specified type and rating.
• Keep at least 0.2 meter (8 in) clear around the air vent.
• Keep all combustible materials (for example fabric, wood, paper) at least 0.1 meter
(4 inches) away from the fixture. Keep flammable materials well away from the
fixture.
• Install the fixture in a well ventilated area.
• Never place filters or other materials over the lens.
• The exterior of the fixture becomes very hot, up to 70° C (158° F) during normal
operation. Do not locate the fixture in areas where accidental contact is likely.
• Do not modify the fixture or install other than genuine Martin parts.
• Do not operate the fixture if the ambient temperature (Ta) exceeds 40° C (104° F).
Preventing injury due to falls
• When suspending the fixture above ground level, verify that the structure can safely
hold the weight of all installed devices.
• Block access below the work area whenever installing or removing the fixture.

6 Installation
I NSTALLATION 2
This section describes in general terms how to mount the fixture and connect it to
data and AC power. The procedures in this chapter shall be performed by qualified
professionals:
1“ACpower”
2 “Fiber optic cable” on page 9
3 “Fixture orientation and location” on page 11
4 “Data link” on page 12
AC POWER
Do not connect the FiberSource CMY150 to an electrical dimmer system: doing so
can damage the electronics.
Warning! Disconnect the fixture from AC power before removing any
cover.
Important! Verify voltage and frequency settings before applying power.
POWER SUPPLY SETTINGS
The FiberSource CMY150 is factory-wired to one of the configurations shown in
Table 1. The model number and factory settings are printed on the serial number
label which can be found on the base of the fixture. If your local AC voltage or
frequency differ from the settings for your model, the fixture’s power supply must
be rewired by a qualified installer or technician.
Model No. Voltage Frequency
90523000 230 V 50 Hz
90523100 120 V 60 Hz
Table 1: Default Power Supply Settings

Installation 7
Rewiring the power supply
Always use the setting that most closely matches the local AC mains voltage and
frequency.
1 Verify that the FiberSource CMY150 is isolated from AC power.
2 Remove the fixture housing using a 5mm Allen wrench.
3 On the transformer, move the brown and blue wires (those with insulated spade
plugs) to the transformer taps shown for your mains voltage (see Table 2).
Important! Do not move the grey wire from terminal 9 or the black wire from
terminal 15.
Mains voltage Setting Brown wire on tap Blue wire on tap
95 - 109 V 100 V 12 10
110 - 130 V 120 V 12 9
200 - 219 V 210 V 15 10
219 - 239 V 230 V 15 9
240 - 260 V 250 V 16 9
Table 2: Transformer settings
Transformer
Ballast
10 11 12 13 14 15 169
23456781
orange (12 V)
orange (12 V)
grey
blue
black
brown
100 volts
10 11 12 13 14 15 169
23456781
orange (12 V)
orange (12 V)
grey
blue
black
brown
120 volts
purple (24 V)
purple (24 V) purple (24 V)
purple (24 V)

8 Installation
4 To set the frequency, move the brown wire on the ballast to the “230-50” (50 Hz) or
“230-60” (60 Hz) terminal as shown. The wire is released and locked by inserting a
small screwdriver in the square hole next to the terminal and prying back the spring.
5 Tug lightly on the brown wire to make sure that it is connected securely.
6 Replace the fixture housing before applying power.
MAINS CONNECTION
Warning! For protection from dangerous electric shock, the fixture must
be grounded (earthed). The AC mains supply shall be fitted with
a fuse or circuit breaker, ground-fault protection, and a means
to isolate the fixture from the mains during service or when not
in use.
10 11 12 13 14 15 169
23456781
orange (12 V)
orange (12 V)
grey
blue
black
brown
210 volts
10 11 12 13 14 15 169
23456781
orange (12 V)
orange (12 V)
grey
blue
black
brown
230 volts
purple (24 V)
purple (24 V) purple (24 V)
purple (24 V)
10 11 12 13 14 15 169
23456781
orange (12 V)
orange (12 V)
grey
blue
black
brown
250 volts
purple (24 V)
purple (24 V)
grey
brown
50 Hz 60 Hz
grey
brown

Installation 9
The FiberSource CMY150 is equipped with a 1.8-meter (5.9 ft.) length of 3-
conductor 0.75 mm2(~18 AWG) electrical cable for connection to the AC power
supply. The cable attaches with 1/4” female spade plugs on the live and neutral
wires and a ring terminal on the ground wire. Other cable can be installed as
follows.
Replacing the mains lead
1 Isolate the fixture from AC power.
2 Remove the fixture housing.
3 Disconnect the existing mains cable and pull it through the hole in the chassis.
4 Pass the new cable through the hole in the chassis and connect the leads. The live
wire connects to PL3, the neutral wire connects to PL1, and the ground wire connects
to the chassis screw terminal.
5 Draw up the slack in the AC and data cables and replace the fixture housing.
Installing a cord cap on the mains lead
A cord cap may be installed on the mains lead for testing, service, and temporary
applications.
Following the cord cap manufacturer’s instructions, connect the yellow and green
wire to ground (earth), the brown wire to live, and the blue wire to neutral. Table 3
shows some pin identification schemes; consult an electrician if you have any
doubts about proper installation.
FIBER OPTIC CABLE
Fiber optic cable is connected to the FiberSource CMY150 using one of the
available fiber adaptor kits:
• P/N 91611035, for 75-350 x Ø1mm fibers. This has a diameter of 30mm and is
supplied with an adaptor ring that increases the adaptor diameter to 38mm so that it
will fit in the port of the FiberSource CMY150 fixture.
• P/N 91611034, for 350-800 x Ø1mm fibers. This has a diameter of 38mm.
Wire (EU) Wire (US) Pin Marking Screw (US)
brown black live “L” yellow or brass
blue white neutral “N” silver
yellow/green green ground green
Table 3: Cord Cap Connections

10 Installation
The fiber adaptors are tapered to fit a varying number of fiber optic cables. The
adaptor often needs to be cut for proper fit and maximum light output.
Cable types
The following guidelines provide a starting point for estimating your needs. Light
transmission through fiber-optic cable depends on its quality and results will vary
depending on the type of cable used.
SIDE-EMITTING CABLE
With 1 fixture, best results are had when the fiber optic cable is 10 m (33 ft.) or
shorter. The length may be increased to 15 m (50 ft.) by looping the cable and
illuminating both ends. With 2 fixtures, one at each end of the cable, lengths up to
30 m (100 ft.) can be achieved.
END-EMITTING CABLE
Light output decreases with length: keep the cable as short as possible. The
maximum recommended length is 25 meters. Cut the light emitting end of the fibers
with a sharp knife for maximum output.
Installing fiber optic cable
1 Install the cable in the adaptor ferrule according to the instructions supplied with the
adaptor ferrule.
2 Insert the adaptor ferrule into the port of the FiberSource CMY150.
Warning If your adaptor ferrule is the smaller 30 mm diameter adaptor
(P/N 91611035), then you need to insert it into an adaptor ring to
increase the diameter to 38 mm. Place the adaptor ring onto the
adaptor ferrule so that the ends are flush. Screw the adaptor
ring fast using a 2mm Allen wrench. Do not push the adaptor
ferrule past the end of the adaptor ring as the fiber will be too
close to the light source and will be damaged.
3 Tighten the set screw with a 2 mm (5/64 in.) Allen wrench.
