OWNER’S GUIDE & SERVICE MANUAL
MARVEL UNDERCOUNTER REFRIGERATION
Model: MPWC424-IS31A

WELCOME
Welcome to the Marvel Experience!
Thank you for choosing our quality American-built product
to add to your home. We are thrilled to welcome you to
our growing community of Marvel owners, who trust in our
products and our support.
The information in this guide is intended to help you install
and maintain your new Marvel undercounter model to
protect and prolong its lifetime. We encourage you to
contact our Technical Support team at [phone] with
any questions.
Got a Marvelous Design?
We would love to see how your Marvel product looks in its
new home. You can send us photos of your installed
product at [email protected], and we
might feature your Marvel home design on our website and
social media!
Bonus Third-Year Warranty Free with Product
Registration
Your Marvel Professional
product qualies for a one-year
extension of the two-year
warranty coverage from your
date of purchase, free of
charge. To take advantage of
this third-year warranty, be sure
to register your product with
Marvel within 60 days from the
date of purchase at
marvelrefrigeration.com and
provide proof of purchase.
Thank you again for investing in Marvel for your home!
Warranty Registration
It is important you register your product warranty after
taking delivery of your appliance. You can register online at
www.marvelrefrigeration.com.
The following information will be
required when registering your
appliance:
Serial Number
Date of Purchase
Dealer’s name and address
The serial number can be found on the serial plate which is
located inside the cabinet on the left side near the top.
Online registration
available at
marvelrefrigeration.com

TABLE OF CONTENTS
Tip: Click on any section below to jump directly there
Installation
Integrated Panel Dimensions
Integrated Panel Installation
3

15⁄32"
(2.9 cm)
Hinge side of door
Top of door
INTEGRATED PANEL DIMENSIONS
Right Hand Hinged Door
24" (61 cm) wide appliance
Right Hand Hinged Door
24" (61 cm) wide appliance
Clearance
for hinge
at top and
bottom
Hinge side of door
Top of door
Left Hand Hinged Door
24" (61 cm) wide appliance
Left Hand Hinged Door
24" (61 cm) wide appliance
Clearance
for hinge
at top and
bottom
1/4"
[0.6cm]
4"
[10.1cm]
3-3/4"
[9.5cm]
2"
[5.1cm]
3-3/4" 4"
2"
3" 3"
2"
3-3/4" 4"
15-1/4"
3"
[7.6cm]
30-7/16"
[77.3cm]
30-7/16"
2"
[5.1cm]
4"
[10.1cm]
15-1/4"
[38.7cm]
3"
[7.6cm]
4

!CAUTION
Integrated door panel installation:
Step 1: Removing the Door
Open the door and loosen the screws holding the hinges to
the cabinet (2 at the top and 2 at the bottom hinge). Do not
remove the screws but loosen them enough so the hinges
󰀨
the side.
With a helper, and being careful not to scratch the cabinet
or the door, slide the door to the side about 12inch and
remove the hinges and door from the unit.
!WARNING
Integrated panel models are designed for use with
built-in installations only. Use in freestanding instal-
lations could result in personal injury.
If you purchased an integrated panel model, your unit is
equipped with articulated hinges to allow fully integrated
built-in installations. Custom panel thicknesses of 58" (15
mm) and 34" (18 mm) are accommodated.
It is important to use the factory provided grille that came

through the condenser. The use of a custom grille is not
recommended and will void the warranty.
!WARNING
The articulated hinges have many pinch points. Care-
fully close / collapse the hinges as soon as the door is
removed from the cabinet.
INTEGRATED PANEL INSTALLATION
5

INTEGRATED PANEL INSTALLATION
Integrated

with top and
side of door.
Magnetic Gasket
remove starting at a
corner, grasp and pull
away from the door.
Step 3: Cut and drill the integrated panel
Depending on your model cut the integrated door panel to
the dimensions shown in Figures 19 to 22. The window cut
out is for glass door models only. If your appliance has a
lock also drill the lock hole in the panel, see Figure 25.
Integrated panel
to be centered
on width of door.
Figure 24
Holes in
gasket
retainer.
Figure 24a
Step 2: Remove the door gasket

corner of the door remove the magnetic door gasket from
the interior side of the door, see Figure 17. Set the gasket


each side and 2 at the top and bottom which are used to
fasten the panel to the front of the door. The screws are
provided in the literature pack along with the door lock,
which is provided on certain models.
Loosen (do not remove ) these
2 phillips head screws on the
top and bottom hinges
!WARNING


to built-in installation. Do not remove the cabinet "Z"
bracket from the top of the cabinet.
Figure 23b
Bottom of
door
"P" clamp
and screw
Wire connector
see Figure 6
Figure 23
Figure 23a
Cabinet
"Z" Bracket
6

!CAUTION
INTEGRATED PANEL INSTALLATION
12"
screw
Step 4: Assemble the panel to the door
The preferred method of attaching the panel to the door
is to clamp the panel to the door so it cannot move while
drilling the screw pilot holes. Use bar clamps or "C" clamps
with pads on the clamping surfaces that will not mar the
panel or the door. The custom integrated panel should be

of the door. See Figure 16a. Drill holes through the gasket

size from the chart in Table "A", being careful not to drill
through the front surface of the panel. If the integrated
panel is thinner than 58" (16 mm) thick shorter screws will
have to be obtained. Fasten the panel to the door with
the 10 screws provided in the literature pack. (See Figure
25a). Remove the clamps and replace the gasket in the

required to seat the gasket into the channels. Be sure the
gasket corners are seated properly.
Material Type #10 Wood Screw
Hardwood ¹" (3.2 mm) Diameter. Pilot Hole
Softwood  (2.8 mm) Diameter. Pilot Hole
Table A
Weight of integrated door panel must not exceed 15
pounds (6.8 kg) for a solid door model or 10 pounds
(4.5 kg) for a glass door model.
A A
B B
C C
D D
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
PANEL-WOOD
DO NOT SCALE DRAWING
24 Panel
SHEET 1 OF 1
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:5
WEIGHT:
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH
BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
APPLICATION
USED ON
NEXT ASSY
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
Counter bore
lock hole
on back side.
Figure 25 - Back of Panel
12" (13 mm)
diameter drill through
door panel, from other
side 1316" (20.5 mm)
counter bore, 716" (11
mm) deep.
Hinge side of door
Figure 25a
7

Cabinet
"Z" bracket
34" black
screws
(3 places)
Figure 28
Step 7: Install the door
Carefully open the top and bottom hinges on the door being
careful as there are many pinch points. Place the hinges
over the 4 screws in the cabinet, 2 at the top and 2 at the
bottom and slide the door into position. Tighten the 4 hinge
screws with a phillips screwdriver. (See Figures 25 and
25a).
SECTION A-A
SCALE 1 : 1
LOCK
NUT
BRASS EXTENSION
CAM
PHILLIPS SCREW
13/16 COUNTER
BORE 7/16 DEEP
1/2 HOLE
3/4 INCH
WOOD PANEL
SPRING WASHER
INNER
DOOR
Step 8: Secure the cabinet
34" black screws from the literature pack to
secure the counter top to the cabinet top through the holes
in the cabinet "Z" bracket.
INTEGRATED PANEL INSTALLATION
Figure 27
Step 6: Install lock cam
Attach the lock cam to the back of the lock assembly with
the phillips head screw provided. Orient the lock cam verti-
cally when installing on the lock.
Cam stop
washer
Spring
washer
Cam
Set screw
Lock
Key
Retainer
nut
Screw
Brass

(2 lengths
provided)
Step 5: Assemble lock parts

34" thick integrated panels and the
shorter one for 58" thick integrated panels. Assemble the

screw to the lock as shown in Figure 26 and 27.
Install this lock assembly into the lock hole in the integrated
panel and secure with the retaining nut on the back side
with a 15 mm socket and ratchet. Make sure the key slot in
the front of the lock is vertical.
Figure 26
