Maserati N145BT User manual

Multi Media System

2
The vehicle is equipped with the IT Maserati Multi Media System which includes
the vehicle radio system with AUDIO CD player/CD ROM drive/MP3 CD player,
GSM Dual Band mobile telephone (also available in USA version), navigator, on-
board computer and MP3 jukebox.
The system is installed in an ergonomic position for both the driver and the
passenger, and the user-friendly graphics on the front panel allows quickly
identifying the controls.
In the following pages you will find the instructions for its use. We advise you
to read them carefully and thoroughly and to keep them within reach at all
times (e.g. in the glove compartment).
Warning: Only use the the maps provided, which are stored on the hard disk of
the system for the Maserati Multi Media System
USA and Canada versions
Contains transmitter FCC ID: 09EQ24AU001
Contains transmitter IC ID: 3651C-Q24AU001

1
2
3
4
5
6
7
8
9
10
3
Contents
Controls and general information
Audio functions
Mobile phone
Navigator
Traffic information
On-board computer (TRIP)
System configuration
Voice controls
Appendix Japanese version
Table of contents

4

1
5
Controls and general information
Control description 7
Advice 13
General information 16
Switching-on / off 17
Adjusting the volume 17

22
1 2 3 4 6 7 8
9
10
11
5
21 20 16 15 14 12131819 17
Fig. 1
1
6

1
7
Control description
Some controls have multiple functions, depending on the system current operating conditions. In some cases, the
activation of the function selected is controlled by the pressure on the button (short or prolonged press) as listed in the
table below.
Pos. Symbol Button pressed briefly Button pressed at length Ref. page
1CD eject 28
2 SOURCE Mode selection: radio, CD or Jukebox.
3 BAND Radio mode: Frequency band selection: FM1 – FM2
– FMAST – AM
Radio mode: Automatic storage
of radio stations in FMAST
(Autostore).
23
4Telephone mode activation.
Send call.
Accept incoming call.
42
5 RPT Activates the navigation message repetition.
6 ESC Exits a selection list or goes to the previous menu level.
7Radio mode: radio frequency shift to the next station
in preset steps, starting from the station currently
tuned.
MP3 CD and Jukebox mode: previous album selection.
Menu: scrolls through the menus.
23
30
8With Basic Hi-Fi system:
Radio, CD and Jukebox mode: audio adjustment (music
ambience, bass, treble,Fr-rr balance, L-R balance,
loudness, automatic volume adjustment).
With Bose Hi-Fi system (optional):
Radio, CD and Jukebox mode: audio adjustment (bass,
treble, Fr-rr balance, L-R balance, Center Point ).
20
20

1
8
Pos. Symbol Button pressed briefly Button pressed at length Ref. page
9SIM card adapter eject button. 40
10 SIM card adapter 40
11 Radio mode: auto store of the next radio station.
CD and Jukebox mode: go to next track.
Menu: scrolls through the menus.
CD audio mode: track fast
forward
23
28
12 LIST Radio mode: displays the list of stations receivable in
alphabetical order.
AUDIO CD mode: displays the list of tracks.
MP3 CD and Jukebox mode displays the list of albums
and tracks.
Radio mode: updates the list of
stations
27
30
32
13 Telephone mode, Navigation, Audio (Radio, audio
CD and MP3, Jukebox) and Trip: opens the function-
related menu.
Menu: turn to select the function, the item and the
value, which are then confirmed by pressing the knob
itself.
14 Radio mode: radio frequency shift to the previous
station in fixed steps, starting from the station
currently tuned.
MP3 CD and Jukebox mode: next album selection.
Menu: scrolls through the menus.
23
30
15 MENU Access to main menu Access to Help menu.

1
9
Pos. Symbol Button pressed briefly Button pressed at length Ref. page
16 Radio mode: auto store of the previous radio station.
CD and Jukebox mode: goes to previous track if
selected within the first 3 seconds of track playing,
otherwise the track is played again from the
beginning.
Menu: scrolls through the menus.
CD audio mode: track fast
rewind
23
28
17 Radio mode: recalls the stations stored (1– 6)
Telephone mode: dial phone number: (1 – 12) or input
text. Quick selection of a name in the directory and on
the SIM card that starts with the selected letter.
Storage of current station (1 – 6). 23
40
18 Telephone mode: Reject incoming call.
Drop call.
43
19 TA/PTY TA (Traffic Announcements): Activation of
automatic reception of traffic information.
Functions availableonly in the countries where RDS is
available.
PTY (Type Program): Activation
of the search filter in relation
to the broadcasting station
category.
24-25
20 With the key in position MAR or the engine on: Audio
OFF/ON
With the key in position STOP or the gearshift lever in
PARK: system activation / deactivation
Rotation: to adjust the volumes. 17
21 DARK 1st pulse: partial display darkening.
2nd pulse: total display darkening.
3rd pulse: back to normal display brightness.
System reinitialisation.
22 MODE Changes current display on the right-hand side of
the screen (Radio, Map, Onboard Computer (TRIP),
Telephone).
23 + Increases the sound system volume. 17

2423
32 33 28 27
25 26
29
30
31
29
30
31
Fig. 2
1
10

1
11
Pos. Symbol Button pressed briefly Button pressed at length Ref. page
24 - Decreases the sound system volume. 17
25 Radio mode: Search for the first
tuneable station with
higher frequency;
CD and Jukebox mode: next track selection.
CD audio mode: track fast
forward.
23
28
26 Radio mode: Search for the first
tuneable station with
lower frequency;
CD and Jukebox mode: goes to previous track if
selected within the first 3 seconds of track playing,
otherwise the track is played again from the
beginning.
CD audio mode: track fast
rewind
23
28
27 SRC Mode selection: radio, CD or Jukebox.
28 Mute function on/off.
29 Radio mode: radio frequency shift to the next station
in preset steps, starting from the station currently
tuned.
MP3 CD and Jukebox mode: selects next folder.
Menu: scrolls through the menus.
23
30
30 Radio mode: radio frequency shift to the previous
station in fixed steps, starting from the station
currently tuned.
MP3 CD and Jukebox mode: selects the previous folder.
Menu: scrolls through the menus.
23
30
31 Confirms the function, item or value selected.

1
12
Pos. Symbol Button pressed briefly Button pressed at length Ref. page
32 Voice control function activation/deactivation.
Navigator Mode: Enables the guiding voice during the
trip guidance and also displays information pertaining
to the guidance session.
33 Telephone mode activation.
Send telephone call.
Accept incoming call.
End telephone call
in progress.
Reject incoming telephone call. 42

1
13
Advice
Road safety
It is advisable to learn to use the
various functions of the Multi Media
System before setting off, especially
the radio (e.g. storing the stations).
Setting a too high volume
may endanger the life of the
driver and other persons.
Therefore, always adjust the volume
to such a level that you can still hear
the surrounding ambient noises (e.g.
horns, ambulance and police sirens,
etc.).
Reception conditions
The reception conditions change
continuously while driving. The
reception may be disturbed in the
vicinity of mountains, buildings or
bridges, especially when you are far
from the transmitter of the station
you are listening to.
WARNING: Traffic information is
normally broadcast at a higher than
normal volume.
Care and maintenance
The Maserati Multi Media System has
been constructed to assure long-
lasting operation without requiring
any particular maintenance. In the
event of system failure contact the
Maserati Service Network.
Nevertheless, some care must be
taken to ensure full functional
efficiency of the Maserati Multi Media
System:
- The display is sensitive to scratches,
cleaning liquids and UV rays
- Should liquids penetrate the
system, it may be irreparably
damaged.
Clean the front panel and the
display using only a soft, clean, dry
and antistatic cloth. Cleaning and
polishing products might damage the
surface.
WARNING: Be careful not to knock
against the display with sharp or
rigid objects and avoid touching it
with your hands. When cleaning the
display, do not exercise any pressure.
WARNING: In the event of a
malfunction, the Maserati Multi
Media System may only be checked
and repaired by the Maserati Service
Network.
WARNING: If the ambient
temperature is very low, the display
will reach its optimal brightness only
after a certain period of operation.

Proper way to hold the
Compact Disc
Removing the disc
1
14
System software update
When new software versions for the
navigation module of the Maserati
Multi Media System become available,
the system can be upgraded to
enable you to benefit from the
function management improvements
introduced.
The software upgrade is performed
by specialists of the Maserati Service
Network.
Compact Disc
If using the Audio Compact Disc
player, remember that traces of
dirt or marks on the CD may cause
jumping and poor sound quality. The
same occurs when compact discs are
unintentionally bent.
For optimal playing conditions, you
are advised to:
- Use only compact discs that carry
the trademark:
- Thoroughly clean the compact
discs with a soft cloth to remove
fingermarks and dust. Hold the CD
by the edge and clean it starting
at the centre working towards the
edge.
- Never use chemical products to
clean CDs (e.g. spray cleaners,
antistatic spray or thinners) as they
may damage the surface.
- After listening to a CD, put it back
in its sleeve to protect it against
marks or scratches, which may
cause jumping when playing the
CD.
- Do not expose compact discs to
direct sunlight, high temperatures
or humidity to prevent them from
deforming.
- Do not stick labels or write on the
recording surface of compact discs.
To take the CD out of its sleeve, press
in the centre of the sleeve and lift out
the CD holding it by the edge.
Always hold compact discs by the
edge. Never touch the surface.
To remove fingerprints and dust use a
soft cloth starting at the centre of the
CD working towards the edge.

Ball-point pen
Roughness
No
No
No
No
1
15
New discs may be rough around the
edges. When playing these discs,
the CD player may not work or the
sound may jump. To smooth the edge
roughness use a ballpoint pen or
similar.
WARNING: Do not use the protective
film of commercial CDs or discs with
stabilizers, etc. since they might get
jammed in the internal mechanism
and damage the disc.
Notes on compact discs
Do not stick labels or write with
pencils and pens on the surface of
compact discs.
Do not use solvents, such as stain
removers, antistatic sprays or thinners
available on the market to clean
compact discs.
Do not use badly scratched, cracked,
deformed etc. compact discs. Using
such discs will lead to malfunctioning
or damage to the CD player.
Do not expose compact discs to direct
sunlight or any source of heat.

1
16
General information
Important warnings for use and
safety during road circulation
The Maserati Multi Media System
with Radio/Telephone/Navigator/
On-board computer permits user-
friendly control of the vehicle’s main
functions.
To avoid creating conditions that pose
a risk to you and other peole please
follow the below mentioned advice:
- The Maserati Multi Media System
must be used keeping full control
over the vehicle. If you have
any doubts about the use of the
functions, stop to perform the
various operations.
- It is prohibited to use the mobile
phone in the vicinity of explosive
substances.
The navigation system helps you reach
your destination, indicating every
change in the route on the maps
stored on the hard disk.
In fact, when working out the
route, the system takes account of
all the road information stored and
advises you on the best route to
take. Nonetheless, it cannot consider
the traffic conditions, sudden
interruptions or any other problems.
The navigation system
assists the driver while
driving, providing advice
and suggestions, by means of voice
guidance and graphic information,
for the best route to take for reaching
the set destination The suggestions
provided by the navigation system
do not relieve the driver from full
responsibility for the manoeuvres
made through traffic while driving,
or from compliance with road
regulations and other provisions
regarding road traffic. The person
driving the vehicle is always and in
any case responsible for safe driving
on the road.
In any manoeuvre you perform,
always comply with the road
regulations whatever the advice
the navigation system provides.
Should you decide to go off the
recommended route, the navigation
system will work out a new route and
suggest it to you.

1
17
Switching-on / off
With the key in position MAR you can
turn the audio section on and off by
pressing the knob (20). The navigation
messages will nonetheless remain
active.
Adjusting the volume
For safety reasons, if the
volume of any audio source
is higher than 20 when
turning off the system, the volume
will automatically be set to 20 when
turning on again.
The volume of all the sources in the
system can be set using the volume
adjustment knob. Turn the volume
adjustment knob (20) clockwise to
increase the volume and anticlockwise
to decrease it.
The volume control is specific for each
sound source and remains stored until
the next adjustment.
It is also possible to preset the
minimum volumes for the telephone
operation, the traffic news and the
navigation guide’s voice. For more
information, please refer to the
paragraph “Adjusting the volume“ in
the “Configuration“ chapter.
The warning tone (beep) volume can
be modified only for some warnings.

18

2
19
Audio functions
Audio adjustments 20
Radio mode 23
CD / Jukebox mode 28
Jukebox Mode 30
Audio mode menu 33

Fig. 3 Fig. 4
2
20
Audio adjustments
With the key in position MAR you can
turn the audio section on and off by
pressing the knob (20), (see Fig. 3).
Depending on the system installed,
the audio adjustments may be:
- Base: Radio, CD and Jukebox mode:
audio adjustment (music ambience,
bass, treble, Fr-Rr balance, L-R
Balance, loudness, automatic
volume adjustment).
- Bose: Radio, CD and Jukebox mode:
audio adjustment (bass, treble,
FR-Rr balance, L-R balance, Center
Point ).
To perform an audio adjustment,
repeatedly press the AUDIO button
(8) to access adjustment of the
bass tones (BASS), treble tones (TREB),
loudness (LOUD), fader (FAD), balance
(BAL), automatic volume and sound
type (musical ambience). The system
stores the data and deactivates audio
adjustment when the button ESC (6)
is pressed or after a few seconds if no
adjustment is made.
WARNING: Bass and treble tone
adjustment is specific to each source,
and they can therefore be adjusted
differently in the RADIO, CD or
JUKEBOX modes.
Bass adjustment (BASS)
When “BASS” is shown on the display
(see Fig. 4), turn the knob (13) to
adjust within the following audio
levels:
- “BASS -9” to adjust the bass to the
minimum value
- “BASS 0” to adjust the bass to the
medium value
- “BASS +9” to adjust the bass to the
maximum value.
