Planet Audio PNV9620I User manual

INSTRUCTIONS INSTRUCTIONS
Panel Introduction
87.5-108MHz
87.5-107.9MHz
55dB
30dB
20-30dBuv
1.5%
522-1620KHz
530-1710KHz
32dB
70dB
20Hz-20KHz
FM tuner
European frequency range
USA frequency range
Signal / Noise ratio
Stereo separation
Search station volt
Distortion rate
AM tuner
European frequency range
USA frequency range
Limit noise sensitivity
DVD player
Signal / Noise ratio
Frequency response
DC 12V
10.8-16.0V DC
15A
Negative ground
80 WattsX4 Channels
Power supply
Power range
Max operate current
Ground system
Amp Rating
SPECITICATIONS
1. VOL button
2. SD slot
3. AUX slot
4. GPS Card Socket
5. SEEK- button
6. SEEK+ button
7.
8.
9.
10. Disk load slot
11. / SRC
12. GPS
13. MENU
14. USB slot
15. IR
BASIC FUNCTION
1. VOL button
Press this button will turn on power, during working longer press this button will turn off
power, on any mode, shortly press will return main menu, rotate this button will adjust
volume level.
2.
3. Dual (front and rear) AUX
4.
Insert GPS card to read navigation map data.
SD
Insert SD card, the unit will play the files automatically.
To input external audio.
Warning :You can only use either front or rear AUX at a time. Never connect both front
and rear AUX at the same time.
GPS

INSTRUCTIONS INSTRUCTIONS
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
After ignition switch
off ,setting
information all lose
Reset information and save
Change battery or fuse
Cannot power on
Change fuse same as the old one
Some factors cause MPU
wrong operation
Press RES button on the panel by
penpoint, then, power on
Poor performance
of radio station
Cannot load disk There is a disk inside Remove disc before inserting another one
Weak signal Move the car to another place, then research
Cannot play disc
Disc is scratched Change new disc
Put wrong side of disc into
the unit Insert in the disk with sign side up
Clean lens by lens clean disc
Lens is dirty
Cannot switch
language/subtitle There is only one language/
subtitle in disc
If disc is not with multi-language/subtitle,
it cannot switch language/subtitle
No image Other factors cause MPU
wrong operation Press [RES] button on the panel by
penpoint, then, power on
Cannot watch
image during
driving
It’s not allowed to watch image
during driving
Park the car in a safe place, put the car stall
in “ P ” postion, pull up the hand brake,
parking brake wire must be grounded
Check fuse
WIRING DIAGRAM
This player is equipped with ISO standard connector, please follow below instruction:
● Yellow – 12 V Constant
● Black – Ground wire
● Blue - Power Antenna / Remote Amp Turn On
● Orange – Back-Up Camera Trigger (+) ● Parking Brake (-)
● White/White black - Left front speaker (+/-)
● Purple/Purple black - Right rear speaker (+/-)
● Green/Green black - Left rear speaker (+/-)
● Red - ACC ON (+12V) ● Grey/Grey black - Right front speaker (+/-)
After finished the calling, press this button to hang up the phone.
When this is a calling coning in, press this button to answer the phone.
EQ button
In a source mode, press the button to enter equalizer setup.
Press this button to back to the main menu.
Dual (front and rear)USB
Insert USB removable advice so as to read audio/video files.
Warning :You can only use either front or rear USB at a time. Never connect both front
and rear USB at the same time! This could cause malfunctions.
IR
To receive infrared signal from the remote control.
5. SEEK- button
At radio state, short press this button to manual seek radio frequency to backward
direction; long press this button to automatically seek radio frequency to backward
direction; At voice playing state, short press this button to select the previous song;
In the playback, press rewind function can be realized.
6. SEEK+ button
At radio state, short press this button to manual seek radio frequency to backward
direction; long press this button to automatically seek radio frequency to backward
direction; At voice playing state, short press this button to select the next song; In the
playback, press fast forward function can be realized.
7.
8.
9.
Press this button can eject the disc.
10. Disk load slot
Opening for disks to enter or retreat.
11. / SRC
12.
13. MENU button
14.
15.
Press this button shortly to power on, press this button longer to power off.
In normal situation, press SOURCE button can return to the main menu.

INSTRUCTIONS INSTRUCTIONS
Step 1: Press the mode button in the unit to switch to DVD mode.
POWER ON/OFF
MUTE
SOURCE
EQ
SEEK+ / SEEK-
VOL+ / VOL-
SEL
LOUD
BAND / P / N
LOC / RDM
STOP
PLAY / PAUSE
ST / PROG
O-10+
AMS / RPT
TITLE
AUDIO
SET PLAYING TIME
SUBTITLE
PBC
UP / DOWN / L / R ENTER
SLOW
ANGLE
SETUP
OSD
ZOOM
MENU
NAVI
28
3. SOURCE Button
Press this button to choose audio sources.
4. EQ Button
Press this button to choose POP、ROCK、
CLASSIC、EQ off.
5. SEEK+ ( )/ SEEK-( ) Button
In normal playback MP3、USB、SD songs,
Press this button to previous song or next
song.
6. VOL+ ( ) / VOL- ( )
Press this button to increase or decrease
volume level.
7. SEL Button
Press this button to choose sound feature.
8. LOUD Button
Press this button to startup LOUD function.
9. BAND-P/N Button
In radio mode, press this button to choose
band.
In VCD、DVD mode, press this button to
choose PAL 、AUTO or NTSC system.
10. LOC/RDM Button
In radio mode, press this button to switch
between local and direction.
In VCD、CD mode,press this key to randomly
play.
11. STOP Button
Press this button to stop playing.
12. PLAY/PAUSE Button
Press this button to switch between play and
pause.
In stop mode, press this button to play.
13. ST/PROG Button
In radio mode, press this button to choose
stereo or mono station.
In audio mode, it can help STOP button to
programmed play.
REMOTE CONTROL FUNCTION
1.POWER
Press once to switch on, press again to
switch off.
2. MUTE Button
Press once to turn off audio output,
press again to resume volume level.

INSTRUCTIONS INSTRUCTIONS
General Settings
into the General set interface.
(Password: 888888).
General settings have been set at the
factory.
In the set interface click [GENERAL] icon,
Regional radio
In the General Settings screen click
[RADIO] icon to enter the Radio setting
interface, as shown below:
Select your desired area.
Version Information
In the General Settings screen click [VERSION]
icon to enter the Version Information interface,
as shown below:
The version information is displayed please
prevail in kind.
System setting
In the General Settings screen click [SYSTEM]
icon to enter the System setting interface,
as shown below:
You can choose the system settings interface
has the feature is turned on or off.
Protocol settings
In the General Settings screen click [Car Set]
icon to enter the agreement setting interface,
as shown below:
You will need to set protocol, click the icon
to confirm the save the settings.
T-V standard
In the General Settings screen click [T-V]
icon to enter the T-V setting interface,
as shown below:
You can choose to have the T-V set is
turned on or off.
Slide up and down to select your preferred
language mode.
Language setting
In the General Settings screen click
[LANGUAGE] icon to enter the Language
setting interface, as shown below:
14. 0-10+ Button
Press this button to choose desired song、
section、preset stations.
Decimal numbers, for example the 19th
song, press 10+ and 9 button.
15. AMS / RPT Button
In radio mode, press this button to browse
stored stations.
In audio mode, press this button to play
repeatedly.
16. TITLE Button
In DVD mode, press this button to play
back to the top menu of disc.
17. AUDIO Button
In DVD mode, press this button to switch
language of dialogue.
In VCD mode, press this button to choose
left track、right track and stereo.
18. SET playing time
In DVD mode, press this button, you can
define playing time.
19. SUBTITLE Button
In DVD mode, press this button to switch
language of subtitle.
20. PBC Button
In VCD mode, press this button to display
all song menus, work with number button
to choose songs.
21. UP、DOWN、LEFT、 RIGHT、ENTER
Button
In DVD mode, press this button to move
cursor up, down, left, right to choose item
in menu, press the enter button to confirm
choice.
22. SLOW Button
In audio mode, press this button to slow
backward and slow forward.
In DVD mode, press this button to change
play angle.
24. SETUP Button
In audio mode, press this button to choose
different set items.
25. OSD Display
Press this button to display the title chapter
and the left time.
26. ZOOM Button
In DVD/VCD mode, press this button to
ZOOM in.
27. MENU Button
Press button to back to the main menu.
28. NAVI Button
Press the button to enter/exit the
navigation interface.
BATTERY CHANGE
When control distance of remote control
becomes shorter or no function, please
change battery. Please confirm polarity
before change.
23. ANGLE Button
One hand press stopper, then pull out
battery.
Put battery into controller.
Insert battery holder into controller.

INSTRUCTIONS INSTRUCTIONS
Turn on/off Host
When the ignition switch is put in ACC or ON position, Press [ ] button on the front panel
to turn on the unit. After the host starts, hold [ ] button for 3 seconds , the host will turn
off.
Access main interface
In boot-up state, press [ ] button on the panel to switch to main interface, as shown in
below picture:
1.
2.
Touch in different interface style to switch between.
Press and hold the hide icon hold to the left and right drag, you can hide the location
of the icon to the left or right.
3. Click the icon or gently with a touch pen or finger to the left and sliding screen to
toggle the main menu page.
4. To reset the shortcuts with a touch pen or finger to hold down the icon to drag the icon
to drag the icon to the shortcut bar to the
bottom of the screen, move over the icon will replace the old icon. If you want to delete the
shortcut icon, first press and hold the icon until the trash can icon and then drag to the trash.
5. The icon at the touch on the main interface to switch between day, night and
off-screen three modes.
6. Touch the function icons so as to access the corresponding function operations.
7. Double-click the watch icon to enter the clock setting interface:
Click the icon to select your favorite type of clock.
Click the icon unlock unlocked drag minutes
to set the time, set up and click again to icon
to lock the clock.
Wallpaper and Logo Setup
Click on the main interface [wallpaper] icon into the wallpaper and boot screen settings
interface, you can choose your favorite wallpaper and boot screen.
Note: The start-up screen has been set at the factory.
Navigation setting
Navigation path has been set at the
factory, please do not enter the navigation
setup interface to change the path freely,
otherwise the procedure many lead to
abnormal navigation.
Audio setting
In the set interface click [AUDIO] icon,
into the Audio set interface.
Click into sound effect default interface.
Press into loudspeaker interface,
click to adjust the
channel of loudspeaker, touch to get
back to initial setting.
BEEP: click that icon to switch on/off that.
LOUD: click that icon to switch on/off that.
GPS. MIX: click that icon to switch on/off that.
EQ: click that icon to switch different mode.
Basic operation setup menu
Click on the main screen [Setup] icon,
enter the setting interface.
With a finger or touching pen to gently
sliding screen can be set about switching
interface.
Access setup interface
Video setting
In the set interface click [VIDEO] icon, into
the video set interface.
Brightness: Drag icon can adjust video
the screen brightness.
Forbid play on run: Driving ban and click
on play icon can open/close the
function.
Time setting
Click the Settings interface Time setting
icon, enter the Time settings screen,
12h/24h interchangeable, as shown below:
In the year, month, day, hour, sub-office
slide up and down to the relevant settings.
Zone is set to enter the time zone settings
interface when clicked.
Choose the time zone, click the icon
to save your settings and exit the time
setting interface.
SET COMM setting
In the set interface click [SET COMM] icon,
into the Serial port set interface.
Choose good then click the icon to
save your settings and exit the serial port
settings interface.
Touch calibration
If touch calibration error occurs, you can
adjust the touch coordinate by “Touch
calibration”. Click [CALIBRATION] icon on
setup interface, click OK to pop up a [Do
you want to calibration?] as shown below,
click OK to confirm to access touch
calibration interface:
Touching methods
Use touch pen to click the center of”+” icon,
and move along with center of “+” icon so
as to calibrate the screen, It shall
automatically save data and exit after
screen calibration. Please accurately click
all positions on screen, or the accuracy of
touch calibration shall be affected.

INSTRUCTIONS INSTRUCTIONS
Radio Function Operation
In tune Among tall buildings At the boulevard The antenna is sheltered Underground parking Overpass or viaduct
GPS Navigation Function Operation
1. Navigation Function Operation
For detailed operation of navigation function, see “Navigation Operation Manual”.
2. Receiving signal error
When the satellite signals can be normally received, the error of standard GPS shall
be about 7 meters. Driving on parallel sections, there shall be error even the product
has auto-correct function. The normal receiving of satellite signals shall be affected
and cause error in following environment:
3. Satellite receiver
Navigation system can keep receiving eight satellite signals.
As a general rule, the navigation system can figure out your
accurate location after received 3-4 satellite signals.
But sometimes, weather and tall buildings in the city shall
affect the signal receiving effect, as is shown in following figure:
1. Enter/exit
Touch [Radio] icon in the main interface to enter into the radio interface.
2. Operation stored radio
Each band can be stored six radio stations, radio stations can be stored directly click
(P1-P6) choice, and will be displayed on the screen.
3. How to save radio stations
Select a band, and then select a radio station. Press and hold button (P1-P6) to select
the preset number will appear in the corresponding number button on the screen.
Touch [
5. Search/Save radio stations
Short touch the [ ] button, browse 1-6 sets of bits stored on the radio, Long touch
the [ ] button to long-automatic station search, and the strongest radio signals P1-P6
are stored in the display position on the table.
6. Play radio station selection
Touch [ ] icon pop-up selection sets the keyboard input radio frequency selectable
radio frequency spectrum or you can drag directly touch the icon to select a stored radio
station.
Touch [ ] can enter icon spectrum interface.
Double-click the spectrum can switch over the spectrum style.
Touch the
corresponding icon had no effect
Touch [ ] icon to return to main interface, and then touch other function icons so
as to exit radio mode.
4. Band selection
] icon so as to switch among FM1, FM2, FM3, AM1, AM2 bands.
7. Other Functions
Touch [ ] icon to access sound setting interface.
Touch [ ] icon so as to turn on/off loudness function.
Touch [ ] icon so as to turn on/off Long/Short-Range function.
Touch [ ] icon to turn on/off stereo.
8. RDS Function
RDS function provides series information (such as traffice information, name of station) ,
and can automatically switch to the station with stronger signal and carries the same
program.
AF: touch the button to turn on/off AF mode.
TA: touch the button to turn on/off TA mode.
PTY: touch the button the screen displays program types, users can search station
according to program type.
NOTE: If the unit does not have RDS function, it has no AF/TA/PTY function,
.
Sliding around
Scope for receiving satellite signals
Angle of
elvevation
Angle of
elvevation
Other function operation
Rear view function
In any running state, the video signal can switch to reverse video state when reversing
the car, and the system shall return to its initial running state after reversing the car.
Do not rely on CCD system completely, please make sure your car is safe by your eyes
during driving.Back rearview system only assists in driving. As the distance range of
rearview system is limited, completely relying on the rearview system during driving may
cause accidents.
Reverse field simulation Rearview backup image
Warning

INSTRUCTIONS INSTRUCTIONS
00:00:09 00:04:48
Disc Function Operation
Play disc
Insert the disc into the disc slot with the printing surface up, system will detect the disc and
automatically take it in to read and play.
Eject disc
(1) Click button on the panel to eject the disc.
(2) If a disc has not been took away 15 seconds after it is ejected, system will automatically
take in the disc but not play.
Do not insert two discs or more.
2. DVD/VCD disc playback
During playback of disc, touch the middle lower area of the screen to pop up the touch
menu, operate the touch menu to perform various playback controls.
After a CD is inserted, system shall access disk reading state immediately.
When there is a disk in the device, click [Disk] at the main interface so as to access disk
reading state.
After the disk being read out, system shall automatically play in sequence.
4. MP3/JPEG/MPEG4 disk playing
When the disk contains readable files, such as MP3/JPEG/MPEG4 files, it shall be
automatically read out and played after slipping into DVD player.
During playing, touch the screen area and the touch menu shall pop up. Operate the
touch menu for playing.
1. Play/eject disc
3. CD Disc Playback
5. Touch Menu Function Description
The disc read, touch area of the screen, pop-up touch menu. Operate a variety of playback
controls the touch menu.
MUSIC function operation
Connect to Music first, touch [Music] icon on main interface to access Music interface,
as shown in below diagram.
Click icon return to a interface
Short press next Song
Long press fast forward playback/rewind playback
previous Song/
Sound settings
Play/Pause
Loudness on/off
Back to the previous directory Page up/down
Number Button
Random play
cycle play
External input operation
Connect the video input plug with external video input jack, and connect the audio input
plug with external audio input jack.
Touch [AV-IN] icon on main interface to access
external input interface.
Click icon into the sound settings screen.
Loudness on / off.
COMPASS
COUNTER function operation
In the main interface touch [COUNTER] icon, into the counter interface.
function operation
In the main interface touch [COMPASS] icon, into a compass interface.
Steering wheel setting
Click the settings interface [STEER] icon into the steering wheel settings interface.
Steering steps:
The original line of control of the vehicle side, the positive,
the negative and machine side control line cathode, anode
connection after connection:
① Touch [Reset] and press
above the steering wheel buttons one by one, and record the
appropriate sequence and function, touch [allocation].
The steering wheel buttons
② Touch the desired distribution voltage value (such as: 2.00V).
③ select the appropriate settings (such as: volume +).
④ completed the steering wheel buttons will display the corresponding function.
⑤ After completing the settings, touch [OK] to save the settings.
⑥ For the reset function, can touch [Reset] (the original settings
will all be cleared), and repeat Step ② ~ Step ④ for resetting.
⑦ You can also choose to set a good model of the steering wheel.
Click the models select] icon pop-up model selection interface,
select your car type click OK icon to save the settings.

INSTRUCTIONS INSTRUCTIONS
PIC 2PIC 1PIC 3
PIC 4
Previous song
PLAY/PAUSE
next song
Forward/Backward play
Click the button, forward/backward play.
The previous/next song
The previous/next songClick the button, .
Channel conversion
Click Switchable channel the button, .
Back to Root Menu
Click the button the DVD state can return to
the root menu of the disc, VCD state can
enter the PBC menu and playback.
Access title menu
Press this button to return to title menu of the
disk. Directly click menu bar at title menu
interface for playing.
During VCD playing, this function only works when PBC is off.
Repeat play
In playing state, touch this button to start repeat play function:
Chapter repeat → Title repeat → Entire disc repeat →Off.
Language Selection
Touch the button, can switch subtitle language.
Note: the need to support the subtitle language discs have this feature
Number Button
Click the button, pop-up numeric keypad. By click the numeric keypad for direct selections
played.
U Disc/SD Card function operation
When there is a USB device/SD card connected, the unit can conduct the playback of
audio/video/image files in the USB device/SD card.
Insert/Eject USB storage device
1. Connect a U disc recorded with media information to the unit by a USB connecting
cable.
2. When there is a need to eject the USB device, exit the USB device playback screen
first, and then take out the device.
Insert/eject SD card
1. Insert a SD card recorded with media information into the SD card slot in the unit
correctly until it is locked.
2.
Enter/exit
Insert a USB storage device or SD card to automatically play data contained in it. If the
unit has connected with a USB device or SD card, touch [USB] icon in the multimedia
interface to enter into the external storage playback interface; Touch [SD] icon to enter
into the SD card playback interface. During playback, touch the top center area of the
screen to pop up the touch menu, operate touch menu to perform various playback
controls.
When pulling out the SD card, exit SD card playing state first, then press the SD card
and it shall pop up after unlocking.
Play
After SD card/USB removable device being read out, the operation methods are similar
to disk operation methods.
Random play
Scanning
Forward/Backward play
The next page menu
Play/Pause
Stop
The previous/next song
Volume button
Number Button
Repeat play
Back to Root Menu
Access title menu
Zoom in/out
Channel conversion Language Selection
BT Function Operation
1. Enter/exit
Touch [BT] icon in the main interface to enter the BT interface,
Touch icon to exit BT interface.
2. Pair/link
BT BT
BT
BT BT BT
BT
BT
BT
as PIC 1:
In the BT interface of click to access call records interface as PIC 2:
5. Phone book
After the cellphone gets connected to the unit, you can read records in the phonebook of
your cellphone and store information in the phonebook of the unit. In the BT interface of
click to access Phonebook interface as PIC 3:
Touch icon in the phonebook interface, the unit will automatically download phone
numbers and put them in order.
6. BT Music
In the BT interface of click to access BT music interface as PIC 4:
To use hand-free function, make connection first, i.e. match the host with the
mobile phone.
Operation methods:
Set the host to be matching state, and open the of your mobile phone and use the
mobile phone to search device, the mobile phone shall prompt to match password with
the when it has searched the device. Input password (0000) to the mobile phone
and confirm. The mobile phone shall prompt whether authorize to this device, please select
[Yes]. Phone and shall automatically connect within 20 seconds. Under any working
mode, the host shall convert to state if there is an incoming call. And the host shall
restore to current mode after hanging up.
When the device matches with this device, the connection status shall display ,
otherwise, it shall display .
3. Dialing
You can dial on mobile phone directly or input phone number through the number buttons
on the screen, click to delete if there is input error. After input the phone number, click
to make a call.
4. Call records
Dialed numbers: Touch this button to check all the dialed phone numbers.
Received calls: Touch this button to check all the phone numbers of received calls.
Missed calls: Touch this button to check all the phone numbers of missed calls.
Delete: Touch the button to delete a selected record.
All Delete: Touch the button to delete all information in phone book.
SPEAKER SYSTEMS
PLANET AUDIO SPEAKERS
