MASSA-K ?K-TP(FP) Use and care manual

“MASSA-K”
Printing scales МK-TP(FP)
MF Modification
Administrator manual
LITE
PROFESSIONAL
TPS

2 Administrator manual MK-TP(FP) MF (Edition 3) 2011

Administrator manual MK-TP(FP) MF (Edition 3) 2011 3
Table of contents
Introduction............................................................................................................................................6
Part 1. Design of scales.......................................................................................................................7
1.1 Description of scales. ................................................................................................................7
1.2 Scheme......................................................................................................................................7
1.2.1 Purpose of keyboard buttons. ............................................................................................8
1.3 Preparation for work .................................................................................................................9
1.3.1 Assembly ...........................................................................................................................9
1.3.2 Installation and powering on .............................................................................................9
1.3.3 Inserting paper ...................................................................................................................9
1.3.4 Setting up modes of scales...............................................................................................12
Part 2. LITE mode............................................................................................................................13
2.1 Purpose and specificity of use.................................................................................................13
2.1.1 Labels examples...............................................................................................................13
2.1.2 Algorithm of scales’ work in LITE mode........................................................................13
2.1.3 Setting up LITE mode .....................................................................................................14
2.2 Label programming.................................................................................................................14
2.2.1 Label Programming from keyboard.................................................................................15
2.2.2 Rules for text information input ......................................................................................15
2.2.3 Label programming from PC...........................................................................................15
2.3 Enter of items database ...........................................................................................................16
2.3.1 Enter of items database from keyboard of scales ............................................................17
2.3.2 Enter of items database from computer ...........................................................................17
2.4 Setting parameters of scales....................................................................................................17
2.4.1 Clock’s setting .................................................................................................................18
2.4.2 Printer’s parameters setting .............................................................................................19
2.4.3 Configuring ports of scales..............................................................................................19
2.4.4 On-line mode ...................................................................................................................20
2.4.5 Work with memory card..................................................................................................20
2.4.6 Language setting..............................................................................................................20
2.4.7 Price Format.....................................................................................................................20
2.4.8 Sound ...............................................................................................................................20
2.4.9 Adjusting the display .......................................................................................................21
2.4.10 Price autoreset................................................................................................................21
2.4.11 Access of operations ......................................................................................................21
2.5 Operator’s work ......................................................................................................................21
2.5.1 Turn scales on ..................................................................................................................21
2.5.2 Setting parameters of item...............................................................................................21
2.5.3 Weighting of item............................................................................................................22
2.5.4 Work with piece item.......................................................................................................22
2.5.5 Label printing...................................................................................................................22
2.6 Operator’s menu......................................................................................................................23
2.6.1 Labeling ...........................................................................................................................23
2.6.2 Viewing the totals ............................................................................................................24
2.6.3 Price changing .................................................................................................................24
2.6.4 Memorize PLU ................................................................................................................24
Part 3. PROFESSIONAL mode ......................................................................................................25
3.1 Purpose and specificity of use.................................................................................................25
3.1.1 Labels examples...............................................................................................................25

4 Administrator manual MK-TP(FP) MF (Edition 3) 2011
3.1.2 Algorithm of work of scales in PRO mode .....................................................................25
3.1.3 PRO mode setting ............................................................................................................26
3.2 Label programming.................................................................................................................26
3.2.1 Installation of “Data manager PRO” ...............................................................................29
3.3 Enter of items database ...........................................................................................................29
3.4 Setting parameters of scales....................................................................................................29
3.5 Operator’s work ......................................................................................................................29
3.5.1 Turn scales on ..................................................................................................................29
3.5.2 Setting parameters of item...............................................................................................29
3.5.3 Weighing of item .............................................................................................................30
3.5.4 Article label printing........................................................................................................30
3.5.5 Total label printing ..........................................................................................................31
3.6 Operator’s menu......................................................................................................................31
Part 4. TPS mode..............................................................................................................................32
4.1 Purpose and specificity of use.................................................................................................32
4.1.1 Examples of tickets and reports.......................................................................................33
4.1.2 Algorithm of work in TPS mode .....................................................................................33
4.1.3 TPS mode setting.............................................................................................................34
4.2 Ticket’s programming.............................................................................................................35
4.2.1 Structure of ticket ............................................................................................................35
4.2.2 Ticket’s programming from keyboard.............................................................................35
4.2.3 Ticket’s programming from computer.............................................................................36
4.3 Enter data of sellers and administrator....................................................................................36
4.3.1 Sellers list.........................................................................................................................36
4.3.2 Seller work modes ...........................................................................................................37
4.3.3 Administrator password...................................................................................................37
4.3.4 Enter data of sellers from keyboard.................................................................................37
4.3.5 Enter data from computer ................................................................................................37
4.4 Enter of items database ...........................................................................................................37
4.4.1 Enter of items database by keyboard ...............................................................................38
4.4.2 Item database input from computer .................................................................................38
4.5 Setting parameters of scales....................................................................................................39
4.5.1 Clock’s setting .................................................................................................................39
4.5.2 Printer’s parameters setting .............................................................................................39
4.5.3 Configuring ports of scales..............................................................................................40
4.5.4 On-line mode ...................................................................................................................40
4.5.5 Work with memory card..................................................................................................41
4.5.6 Language setting..............................................................................................................41
4.5.7 Price Format.....................................................................................................................41
4.5.8 Sound ...............................................................................................................................41
4.5.9 Adjusting the display .......................................................................................................41
4.6 Seller’s work ...........................................................................................................................41
4.6.1 Turn scales on ..................................................................................................................41
4.6.2 Password input.................................................................................................................41
4.6.3 Setting parameters of item...............................................................................................41
4.6.4 Calculation cost of item ...................................................................................................42
4.6.5 Purchase registration........................................................................................................43
4.6.6 Change calculation...........................................................................................................43
4.6.7 Close of ticket ..................................................................................................................43
4.6.8 Example of work..............................................................................................................44
4.7 Operator’s menu......................................................................................................................45
4.7.1 Cancel purchase ...............................................................................................................46

Administrator manual MK-TP(FP) MF (Edition 3) 2011 5
4.7.2 Refund..............................................................................................................................46
4.7.3 Report on sold goods .......................................................................................................46
4.7.4 Z - report ..........................................................................................................................46
4.7.5 Last 10 Z - reports............................................................................................................47
4.7.6 X - report..........................................................................................................................47
Annex 1. Symbol codes ........................................................................................................................48
Annex 2. Trouble shooting ..................................................................................................................49

6 Administrator manual MK-TP(FP) MF (Edition 3) 2011
Introduction
Scales MK-TP (modification MF) provides several important functions that are used in commercial
and accounting operations.
MK-TP scales are the multifunctional device. For changing functions of scales you need to set up
appropriate mode of work (Fig. 1).
Fig. 1. Modes of work for MK-TP scales
* There is no TPS mode in packing scales.
Work in all modes consists of two phases: programming the scales and the work itself directly with
the items (Fig 2).
N o t e - To use the scales modification MF, instead of earlier versions, you must set the
PROFESSIONAL.
Scales work
(for operator)
Fig 2 Basic steps for operating MK-TP scales
Start of operations
Work with items
Scales programming
(for administrator)
Label (ticket) pro-
gramming
Input
base of
items
Parameters
setting
Printing scales
MK-TP
Purpose – calculation with buyers.
•Create your own label
designs.
•Large library of standard
labels.
•Print logo, certification
mark, graphics.
•10 print font for text data
•Building networks of
scales having different for-
mat of labels.
•Printing the total labels.
•Automatic setting
label format.
•Ability to enter the
base of items from
scales’ keyboard.
•Easy scales pro-
gramming.
•Calculation the cost of weight
and piece items
•Calculation of the total sum,
change calculation.
•Creation and printing of tickets.
•Creation and printing reporting
documents:
- report on the sold items per day,
per month;
- intermediate report on revenue(X
- report);
- total report on revenue (Z - re-
port).
•Separate accounting for 8 Sell-
ers
Purpose – Item’s marking.
PROFESSIONAL mode
(Professional labels printing)
LITE mode
(Simple labels printing)
TPS* mode
(ticket printing mode: payment
with customer, ticket printing)

Administrator manual MK-TP(FP) MF (Edition 3) 2011 7
Part 1. Design of scales
1.1 Description of scales.
Example of designation of scales
1.2 Scheme
Scheme of scales shown for trade scales MK-TP-U10 (Fig. 3).
Fig. 3. Scheme of MK-TP-U10
Trade scales have 2 indicators, one for seller, and one for buyer. Scales have 33 shortcut buttons.
Packing scales have one indicator for the operator. Scales have 25 shortcut buttons.
Maximum
capacity
6 6 kg
15 15 kg
32 32 kg
Type of scales
FP Packing
TP Trade
Underwinding
UYes
No
MK - 15 - TP U
Pan
Underwinding
device
Stand
Printing
device
Transportation wedges
(4 pcs.)
Transportation
stop screw
Indicator
Pa
p
er holder fla
g

8 Administrator manual MK-TP(FP) MF (Edition 3) 2011
1.2.1 Purpose of keyboard buttons.
1.2.1.1 Functions of buttons in label printing mode.
…Typing digital information.
…Shortcut buttons. ( …- for packing scales)
Reset
Packing weight sampling
Setting zero of the scales
Item number
Name browsing
Enter menu
Enter / Save
Sorting the data or menu items
Enter to piece-item
Article label printing
Total label printing
1.2.1.2 Changing button functions when typing
… … …
Text entry keyboard
(… … … - for packing scales)
Switching the keyboard between Latin and Russia alphabets
Switching the keyboard between small and capital letter
Moving along a row
Go to the next line
Erasing symbols
1.2.1.3 Changing the buttons in TPS mode
Purchase registration
… Purchase registration with simultaneous operation sellers
Ticket printing

Administrator manual MK-TP(FP) MF (Edition 3) 2011 9
1.3 Preparation for work
1.3.1 Assembly
Remove scales from packing.
Remove the scale pan. Remove transportation wedges from the scale platform (Fig. 3).
Connect the scale platform cable to the indicator (Fig. 4 a).
Pointing the cable inside the frame connect frame mounting apertures and scale platform arm. Se-
cure frame to arm connection with the screws (М5×10) (Fig. 4 b, c).
Screw out the conveying stop screw (Fig. 3), rotating it only counter-clockwise.
Connect the adapter plug to the scales.
Fig. 4. Assembly
1.3.2 Installation and powering on
Place the scales on a firm surface (table) that is not subject to vibrations. Screw the adjustable legs
into the base of the scale platform, so that the stand stop (Fig. 4 c), that serves as a stability purpose of the
scales, touches the table surface. Without breaking contact between the frame stop and the table, adjust
the legs so that the air bubble in level tube stays in the middle.
Place the scale pan on the cross-piece. Before powering ensures that the scales are not loaded and the
platform doesn’t touch any obstacles.
Connect adapter to the mains. Turn on the scales.
When the scales are powered on you should see the indicator test mode which appears as consecu-
tive figures change. After that scales are ready for operation.
1.3.3 Inserting paper
The scales could work with 2 types of rolls:
- label rolls with dimensions 30x58, 40x58, 60x58 or 90x58, when you use scales for label printing;
- ticket rolls with width 57mm, when you use scales for ticket printing.
1.3.3.1 Scales without underwinding
R
otating the conveying stop screw clockwise can lead to load cell deformation and scales
m
alfunction.
!
Take care when connecting the cable. When connecting be sure to match the plu
g
pins with the connecter sockets in order to avoid scales malfunction.
!
b
Adjustable legs (4 pcs.)
Stand stop
c
a
Pan
Corbel
Cable
Stand
Switch on/off
!Only the adapter supplied with the scales should be used. Usin
g
an
y
other adapter can
lead to scales malfunction.

10 Administrator manual MK-TP(FP) MF (Edition 3) 2011
!Remove the tape from printer only in its printing moving direction, previously cut off a
part of the tape in front of printer inlet.
•Easy-jerk lift the lid printer (Fig. 5a).
•Raise the paper flag clip (Fig. 3).
•Remove the tape leftover.
•Put on a roll at the appropriate holder (* in packaging scales ticket roll holder is not installed
(Fig. 5 b).
•Stretch the tape through the printer in direction pointed by arrows.
•Put on print cover.
•Drop the paper flag clip.
1.3.3.2 Scales with underwinding
Scales are used for automatic underwinding labels from the roll. To install the roll into scales with
winding, before lowering the flag:
•draw a hand on the latch belt in the direction of the arrow (Fig. 6 c), remove the clamp from the
reel, along with the spent tape (if available);
•wrap the end of the tape (stretched across the printer) around the reel. Direct retainer in the guide
spool and insert so that the end of the tape was jammed between the reel and lock;
•crank the reel with the tape at 360° hand counterclockwise. Edge of the label separated from the
substrate is divisible;
•drop the paper flag clip.
*Using scales with underwinding in the mode of ticket roll (modification of TPS) is not effective
because underwinding in this case makes no sense and is automatically disabled.
1.3.3.3 Manual label separate
In the scales provides the possibility of effective separation of labels from the roll in the scales with-
out underwinding. To do this:
•After printing edge labels will stop over separating plate (Fig. 7 а);
•With a touch index finger reject the label down with tape (Fig. 7 b). Edge of the label separates
from the tape;
•Remove the label from the tape, hold the upper edge by the thumb and forefinger (Fig. 7 c).
Notes
1 Released labels of the tape can freely fall down in the prepared container.
2 If the tape begins interfere with work, it could easily break off the edge of a separable with respect
to the plate.
3 If edge labels are not removed when you or a detachable edge is too small, then it is necessary to
correct stopping place labels. The recommended place to stay when the edge labels do not reach the end
of the separating plate 1 ÷ 2 mm (Fig. 7 a).
The order changing the place of the stop labels described in point 2.4.2.3.
4 First label after power weights or after filling the roll is of the control and in print from the printer
is empty.

Administrator manual MK-TP(FP) MF (Edition 3) 2011 11
* In the packing scales, checking roll holder is not installed.
Fig. 5. Printing device
Fig. 6. Inserting paper
a - inserting label roll in scales without underwinding;
b - inserting ticket roll in scales without underwinding;
c - inserting label roll in scales with underwinding.
Cover
a
Holder* of
paper roll
Holder of
label roll
bCase
Printer
c
Ticket roll
a
Paper roll
Printing moving direction
S
p
indle
Locking
tape
b
Direction of faster of
locking tape

12 Administrator manual MK-TP(FP) MF (Edition 3) 2011
Fig. 7. Label detaching for scales without underwinding (MK-FP10, MK-TP10 scales)
1.3.4 Setting up modes of scales
Turn scales on. During the indication’s test press and hold button at least 3 seconds. Scales
will set to setup menu mode (Fig. 8).
By , buttons set one of the mode and press button.
Fig. 8 . Menu of setting up scale modes
After indication test scales will display name of the mode. After that indicator displays clock.
1 7 / 1 2 / 1 0 1 2 : 5 2
Press button, scales enter to operating mode.
a
Separating plate
b c
L≈1÷ 2mm
LITE mode /Scales with printing “simple” label/
PROFESSIONAL mode /Scales with printing professional label/
TPS mode /Ticket-printing scales/
Using the keys:
- sorting menu items
- choose menu item
- exit menu
Turning scales on
Indication test

Administrator manual MK-TP(FP) MF (Edition 3) 2011 13
Part 2. LITE mode
2.1 Purpose and specificity of use
Scales in LITE mode could print labels with size 58 х30 mm and 58 х40 mm, for weight and count
items.
The labels may display: item name, its weight, price, total price, shelf life, barcode EAN 13 and the
advertising information.
Simple programming of label and item’s database makes the scales easy for beginner.
Label format and items database are installed from computer or from the keyboard of scales.
2.1.1 Labels examples
Fig. 9. Examples of simple labels
2.1.2 Algorithm of scales’ work in LITE mode
After turning scales on and passing indication test, scales will go to the operating mode (Fig. 10).
To enter in Administrator’s menu press and hold button during the test.
To enter in Operator’s menu, press button in operating mode.
Name
Shelf date
Barcode
Advertising
Weight
Price
Total price

14 Administrator manual MK-TP(FP) MF (Edition 3) 2011
Before using, administrator programs the label, enters items database, and also sets the parameters of
scales.
2.1.3 Setting up LITE mode
How to install LITE mode is described in point 1.3.4.
2.2 Label programming
In LITE mode label format is generated automatically, depending on the parameters of labels, which
was set by administrator (Table 1).
In fact, programming labels, is consisted of choosing length of the label, type of barcode, and if nec-
essary, input of advertising information.
Indication test
Turn scales on
Operators menu
Labeling
Totals
Change price
Memorize PLU
Administrator’s
menu
Data input
Parameters of scales
Calibration
Tests
Item search
Setting
quantity of
pieces
Operating mode
Item
weighing
Label programming
Barcode t
yp
e
Len
g
th
Item database input
Delete ite
m
New ite
m
Scales parameters setting
Connections
Cloc
k
Label
printing
Fig. 10. Algorithm for work in LITE mode

Administrator manual MK-TP(FP) MF (Edition 3) 2011 15
Table 1. Parameters of label setting in LITE mode
Parameter Values Notes
Length of label L =30mm, L=40mm
Advertising Text rows
Text up to 2 rows. Printing on labels
L=40mm. Rule for entering text see
point 2.2.2.
Barcode prefix
EAN13* Numeric value Range 00 … 99
Barcode type
EAN 13
no,
PPТТТТССССССК,
…… ,
PPТТТТТСССССК,
PPТТТТТТWWWWК
Where:
- РР - prefix,
- Т..Т– PLU number digits,
- С…С–item’s cost digits,
- W..W – weight digits,
- К– checksum of EAN13.
Prefix (РР) is set for weighting item. When you print count item, prefix value will be increased by
one (РР+1).
2.2.1 Label Programming from keyboard
Enter to administrator’s menu, choose “Data input” by , buttons, press button.
Choose “Label” and input parameters, like shown on scheme (Fig. 11).
2.2.2 Rules for text information input
Text information can be input by one of the following ways.
1. By the keyboard ……….
Text symbols printed on the keys. Switch registers by pressing button (ENG-RUS), switch
capital letters by (Caps Lock), navigate to the next row by button.
2. By the symbol codes.
Press button, then on the keyboard you need to enter 3 digits of code (Annex 1).
Navigation of cursor is made by , buttons, erasing by button, stop entering by
button.
*In practice, often used a mixed set. The main text is entered from keyboard, and missing symbols,
e.g. “+”, “%”, enter by symbol code.
2.2.3 Label programming from PC
It’s easy to enter label’s parameters from PC. To do it please connect scales to computer, install
“Data manager LITE”, supplied with scales.
Computer could connect to the scales via RS232, or Ethernet. Cable for connection to the RS232
interface is supplied.
The procedure of programming is described directly in the “Data manager LITE” program.

16 Administrator manual MK-TP(FP) MF (Edition 3) 2011
Fig. 11. Enter data of label and items
2.3 Enter of items database
Each item is set by its parameters. In LITE mode you could use from 3 to 6 parameters of item
(Table 2). Quantity of items in scales is up to 20 000 pcs.
Table 2. Parameters of items setting in LITE mode
Item data Note
PLU (number of item) Number up to 8 digits. Unique number.
Name Text up to 36 symbols. Enter in accordance with point 2.2.2
Item type Weight or piece item.
Price (optional) Number up to 6 digits. Enter from keyboard.
Shelf time (optional) Measured in days. From 1 to 360. Date printed on the label,
determined by adding shelf time to the date of printing.
Shortcut (optional)
Set up correspondence between shortcut button and item. Pro-
gramming correspondence is given by pushing the appropriate
shortcut button.
Using the keys:
- sorting menu items
- select a menu item
- return on a higher level
- exit menu
Item name (Table 2)
Price (Table 2)
Item type (Table 2)
Shortcut button (Table 2)
Shelf life (Table 2)
New item
Edit item
Delete item
00 .. 99
Data input
Label
Goods
Length (Table 1)
Advertising (Table 1)
Barcode prefix (Table 1)
Barcode type (Table 1)
L=30mm
L=40mm
no,
РРТТТТССССССК,
…… ,
РРТТТТСССССК,
РРТТТТТТWWWWК.
PLU (Table 2)
Item name (Table 2)
Price (Table 2)
Item type (Table 2)
Shortcut button (Table 2)
Shelf life (Table 2)
Search by PLU (2.3.1)
Search
by
name
(
2.3.1
)
Delete
Search by PLU (2.3.1)
Search by name (2.3.1)
By-weight
By-count
By-weight
By-count
Administrator’s menu

Administrator manual MK-TP(FP) MF (Edition 3) 2011 17
2.3.1 Enter of items database from keyboard of scales
Enter to administrator’s menu, then by , buttons select menu “Data input”, enter to menu
by button. Select “Goods” and enter parameters, like shown in scheme (Fig. 11).
Enter the items database product includes three main procedures:
- enter new item;
- correction of previously entered item;
- delete item.
New item begins with the setting PLU and name of the item. If these two parameters are not set, the
program does not allow to set others parameters of item.
Operations “Edit item” and “Delete” start with the search item which you want to edit/delete.
2.3.1.1 Search by PLU
Enter PLU number by keyboard, press button. Scales will select item from the memory of
scales and go to edit/delete item parameters.
2.3.1.2 Search by name.
By , buttons select the name of item, press button. Scales will select the item from
the memory and go to edit/delete item parameters.
*During item’s parameters setting you can press button to print a test label with this item.
2.3.2 Enter of items database from computer
It’s suitable to enter database from PC. To do it please connect scales to computer, install “Data
manager LITE”, supplied with scales.
Computer could connect to the scales via RS232, or Ethernet. Cable for connection to the RS232 in-
terface is supplied.
The procedure of programming is described directly in the “Data manager LITE” program.
2.4 Setting parameters of scales
Enter to administrator’s menu, then by buttons , select point “Parameters”, enter by
button. Set required parameters as shown on scheme (Fig. 12).

18 Administrator manual MK-TP(FP) MF (Edition 3) 2011
2.4.1 Clock’s setting
Enter to “Clock”, by , buttons set lighting symbol to place that you need to change. By
keyboard please make changing of clock, press button.
Printing mode (2.4.2.1)
Contrast (2.4.2.2)
Label stoppage (2.4.2.3)
Print displacem. (2.4.2.4)
Underwinding (2.4.2.5)
Using the keys:
- sorting menu items
- select a menu item
- return on a higher level
- exit menu
Default parameters are underlined
ON
OFF
Clock (2.4.1)
Printer
Read from card
Save to card
Memory card (2.4.5)
0.00
0.000
0
0.0
ON
OFF
Sound (2.4.8)
Price format (2.4.7)
Display
Fig. 12. Parameters setting menu
Price autoreset (2.4.10)
Русский
English
- - - - - - - - -
Language (2.4.6)
IP-address
Subnet mask
Port
Connections
Ethernet (2.4.3.1)
RS-232 (2.4.3.2)
Granted
Denied
Granted
Denied
Price changing
PLU memorizing
Totals erasing
Operation
access
(2.4.11)
Granted
Denied
Backlight (2.4.9.1)
Contrast (2.4.9.2)
Administrator’s mode
ON
OFF
On-line mode (2.4.4)
Auto
Manual
0
- - -
5
- - -
9
0
- - -
5
- - -
9
0
- - -
5
- - -
9
0
- - -
5
- - -
9
0
- - -
5
- - -
9
Parameters
ON
OFF
1 7 / 1 2 / 1 0 1 2 : 5 2
Da
y
Month Yea
r
Hou
r
Minutes

Administrator manual MK-TP(FP) MF (Edition 3) 2011 19
2.4.2 Printer’s parameters setting
2.4.2.1 Printing modes
Establishes the procedure for printing labels:
Auto – printing just after weighting.
Manual – by pressing button.
2.4.2.2 Contrast
Setting the print contrast.
2.4.2.3 Label stoppage
This parameter is important for scales’ models with label detached by hand (without underwinding
mode). Optimal distance L between the label end and the separating plate is 1÷2 mm (Fig. 7 а). Changing
of L is achieved by buttons , , in this case, you can see moving label on the printing device.
2.4.2.4 Print displacement
The print displacement is a shift of a printed text along the label, e.g. to combine text and image al-
ready printed on the label.
2.4.2.5 Underwinding
Turn ribbon underwinding drive on or off (only for scales MK_FP-U10, MK_TP-U10).
2.4.3 Configuring ports of scales
2.4.3.1 Configuring of Ethernet
Setting when you want to connect scales via Ethernet. Structure of number of scales: IP- address;
subnet mask; network port.
IP-address is a unique identifier of the scales in TCP/IP network, comprising four groups of num-
bers each not to exceed the value of 225, separated with dots. The address is required to register the scales
from the customer’s software end and to communicate date between them.
As the scales are connected to network, system administrator must assign the respective address to
all scales based on the network settings.
Enter IP address via keypad: nnn.nnn.nnn.nnn, where nnn - is any number from 000 to 255. Press
button.
N o t e - several scales shall not have same IP-addresses.
Subnet mask. In TCP/IP networks context, subnet mask or net mask is a bit mask to determine
which part of the network unit’s IP address shall be referred to network address, and which shall be re-
ferred to unit address within the same network. Subnet mask comprises four groups of numbers each not
to exceed the value of 225, separated with dots, assigned by system administrator and set in the scales’
settings.
By keyboard set subnet mask: mmm.mmm.mmm.mmm, where mmm - any digit from 000 to 255.
Press button.
Network port - Network port is a TCP and UDP protocols’ parameter (used in TCP/IP networks) to
make for designation of data packages in IP format, as are communicated to computer via network. This
is a conventional number from 0 to 65535 enabling independent data obtaining for various programs run
on one computer.

20 Administrator manual MK-TP(FP) MF (Edition 3) 2011
By keyboard set port number from 0 to 65535. Press button.
Recommended port for scales - 5001.
2.4.3.2 Configuring RS-232
RS-232 port in label printing mode set for computer connection only.
2.4.4 On-line mode
In the on-line mode, scales transfer parameters for each transaction (the result of weighing, time of
weighing, PLU, etc.), immediately after its completion. Parameters are passed via interface RS232,
Ethernet, also on the flash memory card (if it’s inserted in the scales). The results of transactions records
can be used for systematic analysis of turnover.
Data format is described on the CD, included in the delivery.
2.4.5 Work with memory card
Memory card is used when you want to transfer:
- user data from PC to scales;
- user data from one to another scales;
- totals from scales to PC.
How to download user data from memory card to scales:
- insert card to scales' socket (Fig. 13) until it slightly clicks, which means fixation of card in the
socket, then;
- in operator’s menu select “Memory card”. By , buttons select “Read from card”, press
button.
- push the memory card slightly into the scales’ socket, and then abruptly let it to take the card out of
the socket.
Procedure for transfer of the database and the totals from scales to memory card is similar to de-
scribed above, only instead of typing “Read from card” should set the “Save to card”:
Fig. 13. Inserting card into scales
2.4.6 Language setting
By , buttons select language, press button.
2.4.7 Price Format
Depending on the accepted currency in the country scales have the ability to display the price and
cost in four formats, e.g. 3.20; 0.320; 32.0; 320.
By , buttons select 0.00; 0.000; 0 or 0.0. Press button.
2.4.8 Sound
Parameter allow or disallow sound some operations by beep.
Socket
Memory card
