MasterChef 085-3259-6 Quick setup guide

TF2047903-MC-00-ENG Page 1 of 21 20161205 V.2
Outdoor Propane Burner
Assembly, Use and Care For Outdoor Use Only
Model: 085-3259-6 (TF2047903-MC-00)
Tools required:
Crosshead screwdriver / Adjustable wrench
To installer or person assembling this
appliance: Leave this manual with this
appliance for future reference.
This instruction manual contains important
information necessary for the proper
assembly and safe use of the appliance.
Read and follow all warnings and instructions
before assembling and using the appliance.
Follow all warnings and instructions when
using the appliance.
Keep this manual for future reference.
This appliance is not for frying turkeys.

TF2047903-MC-00-ENG Page 2 of 21 20161205 V.2
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, keep away from the
appliance and immediately call your fire
department.
Failure to follow these instructions could result
in fire or explosion which could cause property
damage, personal injury or death.
DANGER
1. Never operate this appliance unattended.
2. Never operate this appliance within 10’(3
m) of any other gas cylinder.
3. Never operate this appliance within 25’(7.5
m) of any flammable liquid.
4. Never allow oil/grease to get hotter than
400°F (200°C). If the temperature exceeds
400°F (200°C) or if oil begins to smoke,
immediately turn the burner or gas supply
OFF.
5. Heated liquids remain at scalding
temperatures long after the cooking
process. Never touch cooking appliance
until liquids have cooled to 115°F (45°C) or
less.

TF2047903-MC-00-ENG Page 3 of 21 20161205 V.2
6. If a fire should occur, keep away from the
appliance and immediately call your fire
department. Do not attempt to extinguish an
oil or grease fire with water.
Failure to follow these instructions could result
in fire, explosion or burn hazard which could
cause property damage, personal injury or
death.
WARNING
Combustion by-products when using this product contain chemicals known to cause
cancer, birth defects, or other reproductive harm.
WARNING
This appliance is not intended for commercial use.
Safety Symbols
The symbols and boxes shown below explain what each heading means. Read and follow
all of the messages found throughout the manual.
DANGER
Danger: Indicates an imminently hazardous situation which, if not avoided, could result
in death or serious injury.
WARNING
Warning: Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.

TF2047903-MC-00-ENG Page 4 of 21 20161205 V.2
CAUTION
CAUTION: Indicates a potentially hazardous situation or unsafe practice which, if not
avoided, may result in minor or moderate injury.
WARNING
1. Never leave the appliance unattended. Keep children and pets away from
the appliance at all times.
2. The use of alcohol, prescription or non-prescription drugs may impair the
consumer’s ability to properly assemble or safely operate the appliance.
3. This appliance is for OUTDOOR USE ONLY.DO NOT use in a building,
garage or any other enclosed area. This appliance is not intended to be
installed in or on a recreational vehicle and/or boat. This appliance is not
intended for and should never be used as a heater.
4. This appliance must not be used on or under any apartment or
condominium balcony or deck.
5. When cooking, the fryer/boiler must be on a level, stable noncombustible
surface in an area clear of combustible material. As asphalt surface
(blacktop) may not be acceptable for this purpose.
6. When cooking with oil or grease, the thermometer provided MUST be
used. Follow instructions in this manual for proper installation and use of
the thermometer. If the thermometer supplied with this fryer has been lost
or damaged, a replacement thermometer must be one specified by the
appliance manufacturer.
7. If the temperature exceeds 400°F (200°C) or if oil begins to smoke,
immediately turn the burner or gas supply OFF and wait for the
temperature to decrease to less than 350°F (175°C) before relighting
burner according to the manufacturer’s instructions. If there is a lid
(cover), do not remove the lid.
8. When cooking with oil or grease, have a type BC or ABC fire extinguisher
readily available. In the event of an oil or grease fire do not attempt to
extinguish with water. Immediately call the fire department. A Type BC or
ABC fire extinguisher may in some circumstances contain the fire.
9. Never overfill the cooking vessel with oil, grease or water. If the vessel
doesn’t indicate the maximum fill line, please refer to following instructions
for determining the maximum fill level.
Determining the maximum fill level when using a vessel without a
maximum line:
(1) Place the food product in the basket.
(2) Place the food product and holder into the empty vessel.
(3) Fill the vessel with water just until the food product is completely

TF2047903-MC-00-ENG Page 5 of 21 20161205 V.2
submerged. There must be a minimum of 3”(7.6 cm) between the water
level and top of the vessel.
(4) Remove the food product from the vessel and either mark the water
level on the side of the vessel or measure the amount of water in the
vessel.
(5) Remove the water and completely dry the vessel and the food product.
(6) This is the amount of cooking oil the vessel is to be filled with to cook
the food product.
10. Introduction of water or ice from any source into the oil/grease may cause
overflow and severe burns from hot oil and water splatter. When frying
with oil/grease, all food products MUST be completely thawed and
towel-dried before being immersed in the fryer.
11. Do not place an empty cooking vessel on the appliance while in operation.
Use caution when placing anything in cooking vessel while the appliance
is in operation.
12. In the event of rain, snow, hail, sleet or other forms of precipitation while
cooking with oil or grease, cover the cooking vessel immediately and turn
off appliance burners and gas supply. Do not attempt to move the
appliance or cooking vessel.
13. Do not move the appliance when in use. Allow the cooking vessel to cool
to 115°F (45°C) before moving or storing.
14. Do not leave the appliance unattended; keep children and pets away from
the appliance at all times.
WARNING
Installation Safety Precautions.
Use appliance only with LP (propane) gas and the regulator/valve assembly
supplied.
Installation must conform with local codes or, in the absence of local codes, with
the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Storage and Handling of
Liquefied Petroleum Gases, ANSI/NFPA 58; or Natural Gas and Propane
Installation Code, CSA B1 49.1.
This appliance must be used only outdoors, and must not be used in a building,
garage or any other enclosed area.
Use appliance at least 10’(3 m) from any wall or surface. Maintain 10’(3 m)
clearance to objects that can catch fire or sources of ignition such as pilot lights on
water heaters, live electrical appliances, etc. Never use under balconies made of
wood or ANY overhead construction.
Apartment dwellers: Check with management to learn the requirements and fire
codes for using an LP Gas appliance at an apartment. If allowed, use outside on
the ground floor with a 10’(3 m) clearance from walls or rails.
Before opening LP tank valve, check the coupling nut for tightness. When
appliance is not in use, turn off control knob and LP tank valve.
Never move appliance while in operation or still hot.

TF2047903-MC-00-ENG Page 6 of 21 20161205 V.2
24”
If you notice grease or other hot
material dripping from appliance
onto valve, hose or regulator, turn
off gas supply at once. Determine
the cause, then correct, clean and
inspect valve, hose and regulator
before continuing. Perform a leak
test.
The regulator may make a
humming or whistling noise during
operation. This will not affect safety
or use of appliance.
Clean and inspect the hose before each use of the appliance. If there is evidence
of abrasion, wear, cuts or leaks, the hose must be replaced prior to the appliance
being put into operation.
WARNING
Never use a cooking vessel larger than 76 qt (66 L), with a diameter greater than
18 3/4”(48 cm) and taller than 16 1/2”(42 cm).
Never fill pot above upper fill line. Oil can splatter causing staining or
discolouration to ground surface.
Never place empty cooking vessel on the appliance while in operation. Use
caution when placing anything in the cooking vessel while the appliance is in
operation.
Never move the appliance when in use. Allow the cooking vessel to cool before
moving or storing.
Never leave the appliance unattended. Keep children and pets away from the
appliance at all times.
This appliance is not intended for and should never be used as a heater.
Never operate appliance with LP tanks out of correct position specified in
assembly instructions.
Keep the fuel supply hose away from any heated surface
10’
(3 m)
10’
(3 m)
(61 cm)

TF2047903-MC-00-ENG Page 7 of 21 20161205 V.2
Always close LP tank valve and remove coupling nut before moving LP tank from
specified operating position.
Appliance must not be used for commercial cooking.
This appliance will be hot during and after use. Use insulated oven mitts or gloves
for protection from hot surfaces or splatter from cooking liquids.
Avoid bumping or otherwise impacting the appliance to prevent spillage or
splashing of hot cooking liquid.
Never drop food or accessories into hot cooking liquid. Lower food and
accessories slowly into the cooking liquid in order to prevent splashing or
overflow. When removing food from the appliance care should be taken to avoid
burns from hot cooking liquids.
DANGER
The safety relief valve on the LP tank could activate releasing gas and cause an
intense fire with risk of death or serious injury. Therefore, follow instructions below
exactly.
Do not store a spare LP-gas cylinder under or near this appliance.
Never fill the cylinder beyond 80 percent full.
If you see, smell, or hear escaping gas, immediately get away from the LP
tank/appliance and call your fire department.
LP Tank Removal, Transport and Storage
Turn OFF all control knobs and LP tank valve. Turn coupling nut counter-clockwise by
hand only –do not use tools to disconnect. Failure to install safety cap as directed
may result in serious personal injury and/or property damage.
A disconnected LP tank in storage or being transported
must have a safety cap installed (as shown). Do not
store an LP tank in enclosed spaces such as a carport,
garage, porch, covered patio or other building. Never
leave an LP tank inside a vehicle which may become
overheated by the sun.
Do not store LP tanks in an area where children play.
Turn off gas at supply cylinder when not in use.
LP Tank
The LP tank used with your appliance must meet the following requirements:
Purchase LP tanks only with these required measurements: 12”(30.5 cm) width x 18”
(45.7 cm) height with 20 lb (9 kg) maximum capacity.
The LP-gas supply cylinder to be used must be constructed and marked in
accordance with the specifications for LP-gas cylinders of the US Department of
Transportation (DOT) or the Canadian standard, CAN/CSA-B339, Cylinders, Spheres
and Tubes for the Transportation of Dangerous Goods.

TF2047903-MC-00-ENG Page 8 of 21 20161205 V.2
LP tank valve must have:
Type 1 outlet compatible with regulator or appliance.
Safety relief valve.
UL-listed overfill protection device (OPD). This OPD safety
feature is identified by a unique triangular hand-wheel. Use only
tanks equipped with this type of valve.
LP tank must be arranged for vapour withdrawal and include collar to
protect LP tank valve.
LP (Liquefied Petroleum Gas)
LP gas is nontoxic, odourless and colourless when produced. For your safety, LP gas
has been an odour (similar to rotten cabbage) so that it can be smelled.
LP gas is highly flammable and may ignite unexpectedly when mixed with air.
LP Tank Filling
Use only licensed and experienced dealers.
LP dealer must purge tanks before filling.
Dealer should NEVER fill LP tank more than 80% of LP tank volume. Volume of
propane in tanks will vary by temperature.
A frosty regulator indicates gas overfill. Immediately close LP tank valve and call LP
gas dealer for assistance.
Do not release liquid propane (LP) gas into the atmosphere. This is a hazardous
practice.
To remove gas from LP tank, contact an LP dealer or call a local fire department for
assistance. Check the telephone directory under “Gas Companies”for nearest certified LP
dealers.
LP Tank Exchange
Many retailers that sell appliances offer you the option of replacing your empty LP
tanks through an exchange service. Use only those reputable exchange companies
that inspect, precision fill, test and certify their cylinders. Exchange your tank only for
an OPD safety feature-equipped tank as described in the “LP Tank”section of this
manual.
Always keep new and exchanged LP tanks in upright position during use, transit or
storage.
Leak-test new and exchanged LP tanks BEFORE connecting to appliance.
LP Tank Leak Test
For your safety
Leak test must be repeated each time LP tank is exchanged or
refilled.
Do not smoke during leak test.
Do not use an open flame to check for gas leaks.
Appliance must be leak-checked outdoors in well-ventilated area,
away from open flames or sparks.

TF2047903-MC-00-ENG Page 9 of 21 20161205 V.2
Use a clean paint brush and 50/50 soap and water solution.
Use mild soap and water. Do not use household cleaning agents. Damage to gas train
components can result.
Brush soapy solution onto all weld seams and entire valve area.
WARNING
If “growing”bubbles appear, do not use or move the LP tank. Contact an LP gas supplier
or your fire department.
Connecting Regulator to the LP Tank
1. Place LP tank on a secure, level, and stable surface.
2. Turn control knob to the OFF position.
3. Turn LP tank OFF by turning hand-wheel clockwise to a full
stop.
4. Remove the protective cap from the LP tank valve.Always
use cap and strap supplied with valve.
5. Hold regulator, insert nipple (B) into LP tank valve. Hand-tighten coupling nut, holding
regulator in a straight line (c) with LP tank valve so as not to cross-thread the
connection.
6. Turn the coupling nut clockwise to
tighten to a full solid stop. The
regulator will seal on the back-check
feature in the LP tank valve, resulting
in some resistance. An additional
one-half to three-quarters turn is
required to complete connection.
Tighten by hand only –do not use
tools.
NOTE: If you cannot complete connection,
disconnect regulator and repeat steps 5
and 6. If you are still unable to complete the connection, do not use this regulator!
Do not use a POL transport plug (A)
(plastic part with external threads)! It
will defeat the safety feature of the
valve.

TF2047903-MC-00-ENG Page 10 of 21 20161205 V.2
A
B
WARNING
Do not insert any tool or foreign object into the valve outlet or safety relief valve.
You may damage the valve and cause a leak. Leaking propane may result in
explosion, fire, severe personal injury, or death.
Never attempt to attach this appliance to the self-contained LP gas system of a
camper or trailer or motor home.
The pressure regulator and hose assembly supplied with the appliance must be
used. Replacement pressure regulator and hose assemblies must be those
specified by the appliance manufacturer.
WARNING
Do not use appliance until leak-checked.
If leak is detected at any time, STOP.
If you cannot stop a gas leak, immediately close LP tank valve, leave area of
appliance, and call LP gas supplier or your fire department!
Leak-testing Valves, Hoses and Regulator
1. Turn all control knob(s) to OFF.
2. Be sure regulator is tightly connected to LP tanks.
3. Completely open LP tank valve by turning hand-wheel
counter-clockwise. If you hear a rushing sound, turn gas off
immediately: there is a major leak at the connection. Correct
before proceeding.
4. Brush soapy solution onto indicated connections
shown at right in (A) and (B).
5. If “growing”bubbles appear, there is a leak. Close
LP tank valve immediately and retighten connections.
If leaks cannot be stopped, do not try to repair. Use
only replacement parts specified by manufacturer.
6. Always close LP tank valve after performing tank test
by turning hand-wheel clockwise.

TF2047903-MC-00-ENG Page 11 of 21 20161205 V.2
WARNING
When lighting the appliance, beware that body, head and hands should
be kept away from the burner top opening to avoid any fire hazard.
A long wooden match should be used for lighting. A match that is too short
may burn your hand.
Lighting Instructions
1. Read all instructions before lighting.
2. Turn regulator control valve to OFF position.
3. Remove the rain cover.
4. Fully open LP bottle valve.
5. DO NOT stand with head or arms over cooker. Slowly turn ON the regulator
control valve in 1 turn. Light a long wooden match and place it over burner.
Fully open the regulator control valve while the burner is being lit.
6. If ignition does not occur in 5 seconds, turn the burner control off, wait and
repeat the lighting procedure.
Note: Place the vessel on the stand after the burner is lit.
Regulator
control valve
Long wooden match
Counter-clockwise
to OPEN the gas
supply
Turn the valve clockwise, the gas is “ON”
Turn the valve counter-clockwise, the gas is “OFF”
Regulator control valve

TF2047903-MC-00-ENG Page 12 of 21 20161205 V.2
CAUTION
If burner does not light OR if burner flame is accidentally extinguished, turn knob to OFF,
wait 5 minutes and try again. If the burner does not ignite with valve open OR if burner
flame is accidentally extinguished after lighting, gas will continue to flow out of the
burner and could ignite with risk of injury.
Burner Flame Check
Light burner, rotate
knob from HIGH to
LOW. You should
see a smaller
flame in LOW
position than seen
on HIGH. Always
check flame prior
to each use. The air damper (D) mounted on the back of your burner helps to control the
amount of primary air that mixes with the LP gas. A blue flame with little or no yellow
flame provides the best heat.Adjust the air damper by turning it clockwise or
counter-clockwise until the desired flame is achieved.
Turning LP Cooker Off
Turn all knobs to OFF position. Turn LP tank OFF by turning hand-wheel clockwise to
a full stop.
Regulator Hose Assembly Check
Before each use, check to see if there is evidence of abrasion, wear, cuts or leaks. The
regulator hose assembly must be replaced prior to the appliance being put into operation.
The replacement hose assembly must be that specified by the manufacturer.
Cleaning and inspection of pressure regulator and hose assembly prior to use
Cleaning the Burner
CAUTION
Check and clean burner/venture tubes to eliminate insect nests. A clogged tube can
lead to fire beneath the appliance.
Spiders’nests or wasps’mud inside the burner may cause fire at the air damper. If a
fire occurs, immediately turn off gas supply at LP tank valve.
Note:
Spiders and small insects can spin webs and build nests inside the burner. This especially
occurs in late summer and fall before frost when spiders are most active. These nests can
obstruct gas flow and cause a fire in and around the burner and orifice. Such a fire can
cause operator injury and serious damage to the appliance.
Air Damper

TF2047903-MC-00-ENG Page 13 of 21 20161205 V.2
To help prevent a blockage and ensure full heat output, clean and inspect burner tube often
(once or twice a month). NOTE: Water or air pressure will not normally clear a spider web.
Steps for Cleaning the Burner:
1. Remove orifice/hose from the burner.
2. Look inside the burner tube for nests, webs, or
mud.
3. To remove the above obstructions, use an
accessory flexible venture brush or bend a
small hook on one end of a long flexible wire
such as the one shown in illustration.
4. Inspect and clean the burner if needed.
5. Reattach orifice/hose to burner.
Cleaning and Maintenance
Keep appliance area clear and free from combustible materials, gasoline and other
flammable vapours and liquids.
Do not block holes in bottom or sides of appliance.
Check burner flames regularly.
Use appliance only in well-ventilated space. NEVER use in enclosed space such as
carport, garage, porch, covered patio, or under ANY overhead construction.
Completely thaw food prior to placing in hot oil.
To minimize splattering, dry surfaces of food prior to placing in hot oil.
When LP tank is connected to the appliance, store outdoors in well-ventilated space
and out of reach of children.
Store appliance indoors ONLY if LP tank is turned off, disconnected, removed from
appliance and stored outdoors.
Keep the appliance clear and free from gasoline and other flammable vapours and
liquids.
Do not obstruct the flow of combustion and ventilation air.
Keep the ventilation opening(s) of the cylinder free of debris.

TF2047903-MC-00-ENG Page 14 of 21 20161205 V.2
CAUTION
All cleaning and maintenance should only be done when the appliance is cool and
with the fuel supply turned off at the LP tank. DO NOT clean any part in a
self-cleaning oven. The extreme heat will damage the finish.
Correct care and maintenance will keep your appliance operating smoothly. Clean regularly
as determined by the amount of use. NOTE: Clean the entire appliance each year and
tighten all hardware on a regular basis (1—2 times a year or more depending on usage).
Cleaning should be done where detergents won’t harm patio, lawn or the like.
Suggested Cleaning Materials:
Mild dish-washing liquid detergent
Hot water
Wire brush
Paper clip
Nylon cleaning pad
Soft brass-bristled brush
Component Cleaning:
Burner: Wire-brush loose corrosion from burner exterior. Clean clogged gas port holes with
an opened paper clip. Replace corroded or damaged burners that would emit excess gas.
Cooking surfaces, pots and pans. Clean with soapy water and a nylon cleaning pad.

TF2047903-MC-00-ENG Page 15 of 21 20161205 V.2
Product Diagram
1
2
3
4
5
6
7
8

TF2047903-MC-00-ENG Page 16 of 21 20161205 V.2
Component List
1. Steel stand
2. Burner
3. Burner bracket
4. Regulator
hose assembly
1 pc
1 pc
1 pc
1 pc
5. Air vent
6. Rain cover
7. Regulator hook
8. Leg foot
1 pc
1 pc
1 pc
4 pcs
Hardware List
Item
No.
Item name
Diagram
Qty.
A
BOLT M6 x 12
4
B
NUT M6
1

TF2047903-MC-00-ENG Page 17 of 21 20161205 V.2
Assembly Procedures:
Step 1: Insert the leg foot (8) into the stand leg.
Step 2: Attach the burner bracket (3) to burner (2) by using 2 M6x12 blot (A).
2
3
A
1
8

TF2047903-MC-00-ENG Page 18 of 21 20161205 V.2
Step 3: Attach burner (2) to the steel stand (1) as shown in Fig. A. Fasten the
burner inlet first by using 1 M6x12 bolt (A). For the side of burner head, attach both
the burner and the chain of the rain cover (6). Put the M6x12 bolt (A) through the
chain hole of rain cover (6), the hole of burner bracket (3) and the mounting hole of
steel stand (1). Fasten the bolt by using 1 M6 nut (B).
Step 4:Attach the air vent (5) to the inlet of the burner (2). Insert the brass fitting of regulator
hose assembly (4) into the burner and tighten. Be sure not to strip threads on brass fitting.
DO NOT OVERTIGHTEN. Proper connection is critical for correct operation of unit.
Figure A
A
B
A
Figure B
A
4
5

TF2047903-MC-00-ENG Page 19 of 21 20161205 V.2
Step 5: Attach the regulator hook (7) to the regulator hose assembly (4). When transporting
or storing the appliance without tank attached, hook regulator onto steel stand as shown.
Step 6: The appliance is equipped with a rain cover (6). When storing the appliance, place
the rain cover (6) on the burner.
7
4
4
6

TF2047903-MC-00-ENG Page 20 of 21 20161205 V.2
DANGER
An oil overflow may occur resulting in a fire which could cause property damage,
personal injury or death. Follow directions above to prevent this.
WARNING
Avoid bumping or otherwise impacting the appliance to prevent spillage or splashing of
hot cooking liquid. Introduction of water or ice from any source into the oil/grease may
cause overflow and severe burns from hot oil and water splatter. When frying with
oil/grease, all food products MUST be completely thawed and towel dried before being
immersed in the fryer.
