Mathieu Azura MC210 User manual

USER MANUAL
2010717-0

User manual -AZURA –AZURA Flex
1
Foreword
Thank you for the confidence you have shown Mathieu by purchasing an Azura - Azura Flex vehicle.
We invite you to carefully read this manual and keep in handy in the vehicle's cabin.
Regular maintenance is required for the correct operation and long life of your vehicle.
Ensure that this manual is always available in the driver's cabin during general and cleaning operations, it is essential for its
correct use.
11/04/2016
Vehicle serial No.: _ _ _ _ _
No.: 2010717 rev: 0
Translated manual (original in French)

User manual -AZURA –AZURA Flex
2
A. GENERALITIES........................................................................................................................................................................................ 7
1. DECLARATION OF CONFORMITY (EXTRACT)................................................................................................................................... 7
2. SAFETY INSTRUCTIONS FORUSE .................................................................................................................................................... 8
3. SCR SYSTEM (EURO 6MODEL ONLY)............................................................................................................................................... 9
4.TECHNICAL SPECIFICATIONS OF THE VEHICLE............................................................................................................................. 10
a. Azura weight and dimensions (in functional order)......................................................................................................................... 10
b. Azura Flex weight and dimensions................................................................................................................................................. 10
c. Noise level..................................................................................................................................................................................... 11
d. Vibrations ...................................................................................................................................................................................... 12
e. Inclines.......................................................................................................................................................................................... 12
f. Tyres.............................................................................................................................................................................................. 12
g. Fuel............................................................................................................................................................................................... 12
h. AdBlue ®....................................................................................................................................................................................... 12
i. Engines .......................................................................................................................................................................................... 13
j. Brakes............................................................................................................................................................................................ 13
k. Steering......................................................................................................................................................................................... 13
5. VEHICLE IDENTIFICATION................................................................................................................................................................ 14
6. SAFETY STICKERS ........................................................................................................................................................................... 16
7. VEHICLE OPERATINGPRINCIPLE.................................................................................................................................................... 19
8. TECHNICAL SPECIFICATIONS OF VEHICLEWORK ........................................................................................................................ 20
B. DISCOVERING THE VEHICLE............................................................................................................................................................... 23
1. EXTERNAL VIEWS............................................................................................................................................................................. 24
2. DRIVING POSITION........................................................................................................................................................................... 26
a. Seat adjustment............................................................................................................................................................................. 26
b. Seatbelts ....................................................................................................................................................................................... 26
c. Adjusting the angle and height of the steering column ................................................................................................................... 28
3. CONTROLS ANDEQUIPMENT.......................................................................................................................................................... 30
a. Pedals........................................................................................................................................................................................... 30
b. Steering column............................................................................................................................................................................. 32
I- Left control stalk........................................................................................................................................................................ 32
II-Right control stalk: ................................................................................................................................................................... 34
III-Parking brake: ........................................................................................................................................................................ 34
IV-Hazard lights:.......................................................................................................................................................................... 34
V- Emergency stop button:........................................................................................................................................................... 36
c. Driver's door armrest ..................................................................................................................................................................... 38

User manual -AZURA –AZURA Flex
3
d. Central console.............................................................................................................................................................................. 42
I-AZURA model............................................................................................................................................................................ 42
II-AZURA FLEX model................................................................................................................................................................ 44
e. Front upper console....................................................................................................................................................................... 48
f. Control display................................................................................................................................................................................ 52
I- Main menu................................................................................................................................................................................ 52
II-Meaning of indicator lights ....................................................................................................................................................... 54
III-Secondary menu..................................................................................................................................................................... 60
IV-Information and settings related to your vehicle's display........................................................................................................ 64
g. Driving assistance cameras control screen.................................................................................................................................... 76
h. Hour meter display ........................................................................................................................................................................ 78
i. Air conditioning/heating controls ................................................................................................................................................... 800
j. AZURA floor ................................................................................................................................................................................. 822
k. AZURA/AZURA FLEX floor.......................................................................................................................................................... 866
l. Rear trunk..................................................................................................................................................................................... 888
4. ON BOARDEQUIPMENT................................................................................................................................................................. 900
C. STARTING-UP AND DRIVING.............................................................................................................................................................. 911
1. DRIVING SAFETY INSTRUCTIONS ................................................................................................................................................. 922
2. FILLINGTHE FUEL TANK ................................................................................................................................................................ 944
3. FILLINGTHE ADBLUE ®TANK (EURO 6ENGINE ONLY) ............................................................................................................... 966
4.STARTING-UP AND STOPPING THE ENGINE................................................................................................................................... 98
a. How to start the vehicle ................................................................................................................................................................. 98
b. How to stop the vehicle.................................................................................................................................................................. 98
5. DRIVING..........................................................................................................................................................................................1000
a. Driving generalities.....................................................................................................................................................................1000
b. Braking.......................................................................................................................................................................................1022
c. Changing gear ratios...................................................................................................................................................................1022
d. Particulate filter regeneration......................................................................................................................................................1044
6. DRIVING ASSISTANCE CAMERA...................................................................................................................................................1066
D. WORK MODE OPERATION ..............................................................................................................................................................10909
1. WORKING SAFETY PRECAUTIONS...............................................................................................................................................1100
2. FILLINGWATER TANKS.................................................................................................................................................................1122
3. STARTINGWORK MODE................................................................................................................................................................1144
a. Selecting work speed..................................................................................................................................................................1144
b. Switching to 2-wheel steering during work mode. .......................................................................................................................1144
4. STARTINGSWEEPING MODE........................................................................................................................................................1166

User manual -AZURA –AZURA Flex
4
5. STOPPINGWORK MODE.............................................................................................................................................................11818
6. CONTROL DISPLAY IN SWEEPING MODE ....................................................................................................................................1200
7. ADJUSTING THE COMBUSTION ENGINE SPEED (DEFAULT START-UP INECOMODE).............................................................1222
8. ADJUSTING THE BRUSH ROTATIONSPEED................................................................................................................................1244
9. ADJUSTING THE CONTACT PRESSURE OF THE BRUSHES ON THE GROUND .........................................................................1266
10. SELECTINGTHE BRUSH POSITION..........................................................................................................................................12828
a. Selecting brushes to adjust.......................................................................................................................................................12828
b. Adjusting the spacing of the brushes with the joystick.................................................................................................................1300
c. Adjusting the lateral tilt of the brushes with the joystick...............................................................................................................1300
11. STARTING UP AND STOPPING THE DAMPENING FUNCTION...................................................................................................1322
12. ADJUSTINGTHE BRUSH AND NOZZLE DAMPENING SPRINKLER FLOW .................................................................................1344
13. RAISING/LOWERING THE SUCTION NOZZLE.............................................................................................................................1366
14. OPENING/CLOSING THE NOZZLE HATCH................................................................................................................................13838
15. RAPID RAISING OF BRUSHSYSTEM...........................................................................................................................................1400
16. MANUAL DECANTATION..............................................................................................................................................................1422
17. USING THE DIRECTION REVERSING PEDAL..............................................................................................................................1444
18. EMPTYING THEWASTE TANK.....................................................................................................................................................1466
E. AFTER USE.......................................................................................................................................................................................14949
1. CLEANING THE VEHICLE...............................................................................................................................................................1511
a. Cleaning the suction tube, the nozzle and the brushes...............................................................................................................1522
b. Cleaning the decantation system................................................................................................................................................1522
c. Cleaning the turbine, the air exhaust duct and the tank...............................................................................................................1544
d. After cleaning .............................................................................................................................................................................1566
2. VERIFYING THE CORRECT OPERATION OF SPECIFIC COMPONENTS....................................................................................15858
a. Spray nozzle flow .....................................................................................................................................................................15858
b. Brushes....................................................................................................................................................................................15858
c. Lights........................................................................................................................................................................................15858
F. TOWING...............................................................................................................................................................................................1611
1. FREEWHEELPROCEDURE............................................................................................................................................................ 162
2. PARKINGBRAKE DISABLING PROCEDURE.................................................................................................................................1644
a. Your battery is working: ..............................................................................................................................................................1644
b. Your battery is not functioning:....................................................................................................................................................1666
G. STOWING..........................................................................................................................................................................................16969
H. OPTIONS...........................................................................................................................................................................................17373
1. USING THE HP SPRAY ARM...........................................................................................................................................................1744
2. USING THE LEAF SUCTION TUBE (LST)........................................................................................................................................1766

User manual -AZURA –AZURA Flex
5
a. Description .................................................................................................................................................................................1766
b. Recommendations....................................................................................................................................................................17878
c. Using the LST...........................................................................................................................................................................17878
d. LST storage and emptying the tank using the LST option...........................................................................................................1800
3. AUTOMATIC DECANTATION VIA THE NOZZLE (DEPENDING ON MODEL)..................................................................................1822

User manual -AZURA –AZURA Flex
6

User manual -AZURA –AZURA Flex
7
A. GENERALITIES
1. DECLARATION OF CONFORMITY (EXTRACT)
The manufacturer MATHIEU S.A. declares that the new equipment designated below:
Azura MC210, road cleaning equipment, complies with the essential safety and health requirements of the following
European directives.
- Directive 2006/42/EC: machines.
- Directive 2000/14/EC: environmental noise levels.
- NF EN 13019+A1 (2008): Road cleaning machines - Safety requirements.
Serge Chaure
Director

User manual -AZURA –AZURA Flex
8
2. SAFETY INSTRUCTIONS FOR USE
The use of this vehicle requires training or a license (refer to the legislation in force in your country).
Drivers must know the Highway Code in force.
This vehicle must be used exclusively for the purpose for which it was designed.
Do not slide under the vehicle when the key is still in the ignition.
No not approach any part of the moving brush section or sweeping system.
Only tip the tank if the vehicle is on firm, flat ground.
Set up the safety prop before any work under the tank when it is raised.
Do not use the vehicle in a poorly ventilated area to void the risk of asphyxiation from exhaust gases.
Use the Personal Protective Equipment (PPE) that is adapted to your work.
WARNING:
If a rear axle component fails the parking brake is no longer effective, in this case the driver must not stop the
engine so that the foot brake continues to hold.

User manual -AZURA –AZURA Flex
9
3. SCR SYSTEM (EURO 6MODEL ONLY)
The EURO 6 engine uses the SCR (Selective Catalytic Reduction) pollution control system, which consists of treating the
exhaust gas with an "AdBlue ®" additive, (AUS 32, urea solution DIN 70070) for converting the nitrogen oxide (NOx) into
nitrogen and water.
WARNING:
During the evaporation process, the AdBlue ® crystallises and the crystals that are created are corrosive.
It is therefore important to avoid accidental diffusion of AdBlue ® over the rest of the vehicle and on the road. As long as
the solution is liquid it is easy to remove.
Request the safety data sheet from your AdBlue ® supplier.
INFORMATION:
AdBlue ® starts to crystallise at –11°.
It is therefore necessary to wait at least 6 minutes after switching off the ignition before stopping the general circuit
breaker (depending on the model) to allow the AdBlue ® pipes to empty and prevent them freezing.

User manual -AZURA –AZURA Flex
10
4. TECHNICAL SPECIFICATIONS OF THE VEHICLE
a. Azura weight and dimensions (in functional order)
Length _________________ : 3845 mm
Width__________________ : 1293 mm
Height _________________ : 2096 mm (without rotating beacon)
Wheelbase______________ : 2150 mm
Ground clearance ________ : 180 mm
Weight when empty_______ : 3600kg (depending on engine and options!)
PTAC/maximum load per axle: see manufacturer's plate in cabin
b. Azura Flex weight and dimensions
Length _________________ : 3965 mm
Width__________________ : 1293 mm
Height _________________ : 2096 mm (without rotating beacon)
Wheelbase______________ : 2150 mm
Ground clearance ________ : 180 mm
Weight when empty_______ : 3600 kg (depending on engine and options!)
PTAC/maximum load per axle: see manufacturer's plate in cabin

User manual -AZURA –AZURA Flex
11
c. Noise level
Reference engine speed = 1400rpm
As per directive 2000/14/EC
EURO 6 engine
STAGE IIIB engine
measured noise level (LWA)
102.5 dB(a)
103.5 dB(a)
declared noise level (LWA)
105 dB(a)
106 dB(a)
As per directive 2006/42/EC
EURO 6 engine
STAGE IIIB engine
acoustic pressure in cabin (LPA)
less than 80 dB(a)
less than 80 dB(a)

User manual -AZURA –AZURA Flex
12
d. Vibrations
Electro-pneumatically suspended seat.
Vibration emission
Uncertainty k = 0.5
Whole component (seat)
aWZS= 0.39 m/s²
Upper components (steering wheel)
Ahv = 1.01 m/s²
e. Slope
Maximum slope _________ : 25 %
f. Pneumatics
Type __________________ : Tubeless 225/65 R16 112/110 R
Inflation pressure_________ : 5.6 bars (~ 84 PSI)
Note: a tyre pressure error has a serious incidence on the tyre's service life.
g. Fuel
Type __________________ : Diesel in accordance with EN 590.
WARNING:
If fuel with a sulphur content higher than 0.5% is used, the frequency of replacing the specified engine oil should be
halved.
Fuel tank capacity ________ : 70L
h. AdBlue ®
Tank capacity ___________ : 14L

User manual -AZURA –AZURA Flex
13
i. Engines
EURO 6 engine
STAGE IIIB engine (LEVEL
IV)
Make
VM R754 EU6
KUBOTA V3800 CR T E4
Displacement
2970 cc
3800 cc
No. of cylinders
4
4
Power
62 kW(83hp) at 2300 rpm
55.4 kW (74hp) at 2200 rpm
Torque
270 Nm at 1350 rpm
310 Nm at 1500 rpm
Idling speed
950 rpm
950 rpm
Estimated consumption
5 L/h
5.5 L/h
j. Brakes
Front disc brakes with double hydraulic circuit on front axle (assisted by hydraulic accumulator).
Hydrostatic restraint on the rear axle depending on the driving mode.
Brake drums on the rear axle (depending on the country's legislation).
Parking brakes on rear axle.
k. Steering system
2 or 4-wheel steering modes with hydraulic assistance.
Turning circle
Between walls
Between footpaths
4-wheel steering mode (two brushes)
~7.40 M
~6.30 M
4-wheel steering mode (three brushes)
~8.44 M
~6.30 M

User manual -AZURA –AZURA Flex
14
5. VEHICLE IDENTIFICATION
The identification plate is located at the base of the driver’s seat.
Indications given:
- Platform.
- Type of vehicle.
- Year of manufacture.
- Approval.
- Chassis number.
- Serial No.
- Total load weight allowed.
- Maximum load at the front and rear.
The complete vehicle number is engraved on the chassis at the front right wheel. The number consists of 17 characters:
Example: VF9ABBC0EFT607ZZZ
- VF9: iso constructor code (Part 1).
- A: Project Code.
- BB: Engine Code.
- C: Driving position side (R: right/L: left).
- 0: Neutral character.
- E: Development stage.
- F: Year of manufacture. (Iso code)
- T: Production factory. (T= Toul)
- 607: Iso manufacturer code (part 2).
- ZZZ: Three last numbers of the vehicle serial number.
INFORMATION: Always indicate the serial number of your vehicle when communicating or making inquiries with
our after sales service. The guarantee and the general terms of sale are provided on the rear of your vehicle
purchase confirmation form.

User manual -AZURA –AZURA Flex
15

User manual -AZURA –AZURA Flex
16
6. SAFETY STICKERS
# 1: Danger of cutting fingers or hand.
- Wait until all vehicle components have completely stopped before touching.
#2: Danger of falling.
- Do not climb on top of the vehicle.
#3: General warning.
- Read the instruction manual before any handling or work on the vehicle.
# 4: Danger of items thrown from sweeping system.
- Stay clear and keep other people at a safe distance.
#5: Fuel (diesel);
- Do not smoke nearby.
# 6: Danger of burns.
- Keep at safe distance.
#7: Crushing risk.
- Set up the safety prop before any work under the tank.
#8: Danger.
- Remove the key from the ignition and read the user manual before any mechanical intervention.

User manual -AZURA –AZURA Flex
17
STOP DIESEL
#1
#2
#3
#4
#5
#6
#7 #8

User manual -AZURA –AZURA Flex
18
