Matsui MUF987W User manual

Instruction Book
Freezer
Model MUF987W/MUF987S

Introducing Your New Freezer Install Your New Freezer
Location
When selecting a position for your Freezer you should make sure the floor is flat and firm,
and the room is well ventilated with an average room temperature of between 16°C and
32°C. Avoid locating your Freezer near a heat source, eg. cooker, boiler or radiator. Also
avoid direct sunlight in lean-to’s or sun lounges. If you are placing your Freezer in an out-
building such as a garage or annex ensure that the Freezer is placed above the damp course,
otherwise condensation will occur on the Freezer cabinet. Never place the Freezer in a wall
recess or into fitted cabinets or furniture.
Levelling the Freezer
Unscrew the packaging support from the base of the Freezer and
replace with the 2 Levelling Feet. Make sure the Freezer is level. Use
the Levelling Feet at the front. If the Freezer is not level, the doors
and magnetic seal alignments will be affected.
Cleaning before use
Wipe the inside of the Freezer with a weak solution of bicarbonate soda. Then rinse with
warm water using a ‘wrung-out’ sponge or cloth. Wash the baskets and shelves in warm
soapy water and dry completely before replacing in the Freezer. The external parts of the
Freezer can be cleaned with wax polish. If you require more information refer to Cleaning on
page 6.
Before plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the Freezer. If
not, please consult a qualified person to correct.
Before switching on!
DO NOT SWITCH ON UNTIL TWO HOURS AFTER MOVING THE FREEZER.
The coolant fluid needs time to settle.
Before use
Please read these instructions carefully before using your new Matsui Freezer.
The Freezer is for indoor, domestic use only.
2
hot (hidden condenser models )When your appliance is working, the condenser at the back (exposed models) may become
hot or alternatively the sides may become hot (hidden condenser models )
External Handle
Freezer baskets
Thermostat Control Dial
Adjustable feet

Getting Started 3
Switching on your Freezer
1 Before connecting the Freezer to the mains supply make sure
2 Turn the thermostat knob clockwise to set it to the desired
the temperature.
3 To ensure that the Freezer is cool enough to sufficiently freeze
your food wait 24 hours before filling with food.
Adjusting the temperature
Fast Freezing
Fresh food should be frozen as quickly as possible. Setting MAX
makes your Freezer operate continually and get colder (approx
minus 28°C). It will therefore freeze quicker and retain more of the
goodness in food. Freezing will be complete after 24 hours. Turn
the thermostat control dial back to position 2-3, to allow the
freezer to return to its normal temperature (-18°C). Never freeze
large quantities of fresh food at one time.
Noises inside the Freezer!
If you have not owned a fridge or freezer before, you may notice
that it makes some rather unusual noises.
Most of these are perfectly normal, but you should be aware of
them!
GURGLING, WHOOSHING
These noises are caused by the circulation of the refrigerant liquid
in the cooling system. It has become more pronounced since the
introduction of CFC free gases. This is not a fault and will not
affect the performance of your Freezer.
HUMMING, PURRING OR PULSATING
This is the compressor motor working, as it pumps the refrigerant
around the system.
Shopping for frozen foods
Your Freezer is 4 star ★★★★
When you are buying frozen food, look at the Storage Guidelines
on the packaging. You will be able to store each item of frozen
food for the period shown against the 4 star rating. This is usually
Check the freezer temperature
Check the temperature of the frozen food cabinet in the shop
where you buy your frozen foods. It should show a temperature
lower than -18°C.
Choose packs carefully
Take a quick look at the frozen food package and make sure it is
in perfect condition.
Purchase frozen food last
Always buy frozen products last on your shopping trip or visit to
the supermarket. Try to keep frozen food together whilst shopping
and on the journey home as this will help to keep the food cooler.
Store food straight away
Don’t buy frozen food unless you can freeze it straight away.
Special insulated bags can be bought from most supermarkets and
hardware shops. These keep frozen food cold for longer.
that the thermostat control dial is set at position in the MIN
of MAX and MIN which is Off.
position, bear in mind that the higher the number position,
the colder
The internal temperature of your appliance is controlled by a n or for prolonged periods.
thermostat. Max Position makes the appliance colder and is
used for fast freezing (see fast freezing section). The recommended
position is between Min and Max but should be adjusted according
to its environment. The appliance may not operate correctly if it is
in a particularly hot or cold room or if the door is opened often or
for prolonged periods.
Thermostat
control dial
Is the Freezer cold enough?
If you are at all concerned that you Freezer is not being kept cold
enough, or you occasionally wish to check the temperature, you
can purchase a Fridge/Freezer thermometer. These are available
from most supermarkets and hardware shops. Place the
thermometer in the Freezer where it can be easily read. Leave
overnight, the correct temperature should be between -18°Cor
lower. See ‘Adjusting the temperature ’.
FRIDGE/FREEZER THERMOMETER …C
FRIDGE
FRIDGE
FREEZER
-30…- 20…-10…0…+10…+20
+20
…+30
+30
…+40…
the period stated as ‘Best Before’, on the front of the packaging.
The maximumfreezing capacity of this appliance is 5kg in 24 hours.
Please do not place fresh food into the freezer compartment
exceeding this weight.

In Use
Tips for keeping food perfect in the
Freezer
Shut the door!
To prevent cold air escaping, try to limit the number of times you
open the door. When returning from shopping, sort foods to be
kept in your Freezer while the door is closed and only open it to
put food in or take food out.
Freezing fresh foods
Useful tips
Use quality food and handle it as little as possible. Freeze food in
small quantities, it freezes faster, takes less time to thaw and
enables you to eat it in the quantity you need.
What not to freeze
NOTE: DO NOT STORE INFLAMMABLE GASES OR LIQUIDS.
Preparations for freezing
• Leave cooked food to cool completely.
• Chill food in a Fridge before freezing if possible.
• Consider how you will want to cook the food before freezing
it.
• Don’t freeze food in metal containers if you may want to
microwave it straight from the Freezer.
• Use special freezer bags available from
supermarkets, freezer film, polythene bags,
plastic containers, aluminium foil (heavy
grade only, if in doubt, double wrap).
Don’t use aluminium foil for acidic
foods (such as citrus fruits). Don’t use
thin cling film or glass. Don’t use used
food containers (unless cleaned
thoroughly first).
• Exclude as much air from the
container as possible. You could
buy a special vacuum pump
which sucks excessive air out of
the packaging.
• Leave a small amount of ‘air space’
when freezing liquids, to allow for
expansion.
• You can use the space in the freezer
most efficiently if you freeze liquids (or solids with liquids, such
as stew) in square blocks. This is known as ‘preforming’. Pour
the liquid into a polythene bag which is inside a square sided
container. Freeze it like this, then remove it from the container
and seal the bag.
Label everything
• Many foods look the same when frozen, so careful labelling
will help avoid forgetting what an item is. Storage times being
exceeded could cause food poisoning.
• You can buy special freezer tape for use in low temperatures.
This tape is available in white, why not use it to write the items
contents on. You can buy special freezer labels and pens.
Labels come in different colours which can help you use your
Freezer effectively. For instance you could colour code meat
red and vegetables green. Using a different colour label for
each quarter of the year will help you rotate your frozen food
more efficiently.
• Write the contents and date. If you are really organised add
the weight and notes on cooking such as ‘thaw first’, or ‘cook
from frozen’ and keep a separate ‘log-book’ of what is in
each drawer. This will save opening the door and searching
around unnecessarily, ensuring the Freezer stays cold enough.
4
Fruit, Fresh Vegetables, Bottled Liquids, carbonated liquids" to
be checked.

In Use
5
Recommended storage periods
For recommended food storage times, refer to your food
packaging.
In Use
Thawing frozen food
For some foods, thawing before cooking is unnecessary. Vegetables
and pasta can be added directly to boiling water or steam cooked.
Frozen sauces and soups can be put into a saucepan and heated
gently until thawed.
To Thaw frozen foods
1 Cover food loosely.
2 Thaw at room temperature. Don’t forget that thawing in a
warm area encourages the growth of bacteria.
3 Always make sure there are no ice crystals in the food before
cooking, particularly with meat. These crystals indicate that the
food is not fully thawed. They result in lower temperatures
when cooking. Lower cooking temperatures may not destroy
dangerous bacteria.
4 Cook food as soon as possible after thawing.
5 Drain off and throw away any liquid lost during thawing.
Oven Thawing frozen foods
Many microwaves and ovens have thaw settings.
To avoid bacterial build up, only use these if you intend to cook the
food immediately afterwards.
Safety Tips
• Never re-freeze anything that has thawed out unless you cook
it again, to kill off harmful bacteria.
• Never re-freeze thawed shellfish.
Useful Tips
• Re-seal packs properly after removing items. This prevents
drying or ‘freezer burn’ and a build up of frost on any
remaining food

NOTES
6
Reverse the door swing
Remove the blanking plates covering the handle
screws using a flat bladed screw driver. remove
the screws and then remove the handle.
Slide the Freezer door back on to the top hinge,
making sure it’s the right way up.
Screw the bottom hinge into place on the new
side.
Check that door is
aligned horizontally and
vertically and that the
seals are closed on all
sides before finally
tightening the bottom
hinge.
Re-adjust the levelling
feet.
• Ensure the Freezer is unplugged and empty.
• Adjust the two levelling feet to their highest
position.
• We recommend you have someone to assist
you.
Tools required
• Phillips style screwdriver
• Flat bladed screwdriver
Note: to take the door off it is necessary to tilt the
Freezer backward. You should rest the Freezer on
something solid and place something under the
rollers so that it will not slip during the door
change process.
DO NOT lay the Freezer completely flat as this
may damage the coolant system.
Remove the blanking plates from the opposite
side of the door and screw the handle into
place. Replace all the blanking plates.
1. 2.
3. 4. 6.
7.
8.
Undo the screws and remove the hinge bracket
from the base. A spanner may be required to
loosen the bolts first.
Remove the screws and bracket from the opposite
side and fit back to where the hinge bracket was
located.
Slide the door down and off the top hinge pin and
lift away from the appliance.
Remove screws and hinge bracket and refit on opposite
side.
5.

7
Cleaning Maintenance
Moving your Freezer
Care when handling
Hold the Freezer around its sides or base when moving it. Under
no circumstance should it be lifted by holding the edges of the top
surface.
Location
Do not place your Freezer near a heat source, eg. cooker, boiler
or radiator. Also avoid direct sunlight in lean-to’s or sun lounges.
Levelling the Freezer
Make sure the Freezer is level. Use the rotating levelling feet at the
front. If the Freezer is not level, the doors and magnetic seal
alignments will be affected.
Do Not Turn on the Freezer for 2 hours
After the Freezer is in place it needs to be left for 2 hours. The
coolant fluid needs time to settle.
Installation
Warning - do not cover or block vents or grilles of your appliance.
Servicing
Repairs and maintenance of the appliance should only be
performed by an authorised, qualified technician.
Defrosting
After a period of time frost will build up in the Freezer. As a
temporary measure, this frost should be scraped away using a
plastic scraper or other plastic kitchen implement.
NOTE Don’t use a metal or sharp instrument and do not use any
electrical appliances to aid defrosting.
Complete defrosting will however become necessary approximately
once per year, or if the frost layer exceeds 5cm (2”) to maintain the
efficiency of the Freezer. This should be carried out if the frost build
up cannot be scraped away, or if it begins to interfere with the
food storage. Choose a time when the stock of frozen food is low
and proceed as follows:
1 Take out the frozen food, turn the Freezer off at the mains
supply and leave the door open. Ideally the frozen food should
be put into another freezer or refrigerator. If this is not possible
wrap the food, firstly in several sheets of newspaper or large
towels and then a thick rug or blanket and keep it in a cool
place.
2 Place a shallow bowl or pan below the Freezer. Scrape away
as much frost build up as possible using the plastic scraper.
Thawing of the remainder can be speeded up by placing bowls
of hot water inside the freezer cabinet and closing the door. As
the solid frost loosens, prize it away with the plastic scraper and
remove.
3 When defrosting is completed, clean your Freezer as described
in ‘CLEANING’.
Cleaning inside the Freezer
You should clean the Freezer internally with a weak solution of
bicarbonate of soda. Then rinse with warm water using a ‘wrung-
out’ sponge or cloth. Wipe the Freezer dry before replacing the
baskets.
Plug in and switch on the mains supply.
Cleaning the outside of the Freezer
Use standard furniture polish to clean the Freezer exterior. Make
sure that the door is closed, to prevent polish getting on the
magnetic door seal or inside the cabinet.
The grille of the condenser at the back of the Freezer and the
adjacent components can be vacuumed using a soft brush
attachment.
Cleaning tips
•Defrost when food stocks are low.
NOTE Do not use harsh cleaners, scouring pads or solvents to
clean any part of the Larder Fridge.

8
Troubleshooting Safety
Safety tips
Do not use electrical appliances such as a hair dryer or heaters to
defrost your Freezer.
Do not store inflammable gases or liquids inside your Freezer.
Disposal
Old appliances still have some residual value. An environmentally
friendly method of disposal will ensure that valuable raw materials
can be recovered and used again. The refrigerant used in your
appliance and insulation materials require special disposal
procedures. Ensure that none of the pipes on the back of the
appliance are damaged prior to disposal. Up to date information
concerning options for disposing of your old appliance and
packaging from the new one can be obtained from your local
council office.
Locks
If your Freezer is fitted with a lock, to prevent children being
entrapped keep the key out of reach and not in the vicinity of the
appliance.
If disposing of an old Freezer break off any old locks or latches as a
safeguard.
WARNING!
It is hazardous for anyone other than authorised
service personnel to carry out servicing or
repairs which involves the removal of covers.
To avoid the risk of an electric shock do not
attempt to repair this appliance yourself.
Power cut
If you have a Freezer thermometer, place it in the Freezer where
you can get easy access to it to read when the power returns. If
the internal temperature is -9°C or less when the power returns,
your food is safe. The food in your Freezer will remain frozen for
approx 16 hours with the door closed. If you know the power is
going to be cut, 24 hours before, turn the Thermostat Control Dial
to SUPER, this will make the Freezer colder than normal. If there is
no warning, turn the Thermostat Control Dial to SUPER after the
power cut. Don’t open the door more than necessary.
The Freezer is particularly cold
You may have accidentally left the Thermostat Control Dial on MAX.
The Freezer is particularly warm
The compressor may not be working. Turn the Thermostat Control
local store where you purchased your freezer.
The Freezer is not working
Check it is plugged in and switched on. Check that the fuse in the
plug has not blown. Plug in another appliance, such as a lamp, to
see if the socket is working.
Condensation appears on the outside of the
Freezer
This may be due to a change in the room temperature. Wipe off
any residue of moisture. If the problem continues contact the local
store where you purchased your freezer.
Noises
You may hear some unusual noises from time to time. See ‘Noises
inside the Freezer’ on page 4.
If you are not able to identify and eliminate the faults according to
the above recommendations, contact your Authorised Service
Agent, advising of model number of the appliance which is shown
on the back of the rating plate.
Do not attempt to repair your Freezer yourself as it might
endanger you and others.
Dial to MAX. If there is no humming noise, it is not working. Contact
the

TECHNICAL SPECIFICATIONS
Model
MUF987W/MUF987S
Rated Voltage 230
(V)
Rated Frequency 50
(Hz)
Input Current 0.37
(A)
Input power 60
(W)
Net Capacity (Litres)
(Cubic Feet) 3.5
Weight 34
(kg)
Product Dimension h/w/d 845 x 545 x 555
(mm)
Refrigerant 44g
(weight)
Weight and Dimensions are approximate. Because we continually
strive to improve our products we may change specifications and
designs without prior notice.
9
Freezer Volume
98
★★★★

This symbol on the product or in the instructions means that your electrical and electronic equipment
should be disposed at the end of its life separately from your household waste. There are separate
collection systems for recycling in the EU.
For more information, please contact the local authority or your retailer where you purchased the
product.
Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories.
With over 50,000 products in stock we can deliver direct to your door the very next day.
Visit www.partmaster.co.uk
or call
0870 6001 338
(UK customers only)
Calls charged at National Rate.
