September 2022 Operating Instructions 1
MAURY MICROWAVE
Description
The Maury model A034B1 connector gage kit is designed to measure 3.5mm and 2.92mm (K) connectors with
either female or male interfaces.
CAUTION: Use your A034B1 for 3.5mm and 2.92mm (K) connectors only. Do not use for SMA connectors.
The Maury models A034B1 female and male connector gage assemblies simulate actual mating conditions al-
lowing high accuracy measurements. The connector gage assemblies are initially set to zero using master setting
gage, A027T1, permitting subsequent measurements to be read directly on the dial indicator. All machined parts
are made from non-magnetic stainless steel to assure long life and good stability. Gaging surfaces are lapped to
ensure a high degree of accuracy. A parts list is shown in Table 1.
General Information
Table 1. Parts List
Item Description Maury Part Number Quantity Per Assembly Notes
1Indicator Assembly,
Female A034S11 1
2Indicator Assembly, Male A034S12 1
3Master Gage A027T1 1
4Instrument Box A027T3 1

034-92 A
September 2022
2 Operating Instructions
MAURY MICROWAVE
Figure 1. The A034B1 Connector Gage Kit
Cap (Do Not use as Handle)
Dial Lock Release Screw.
Used when rotating Bezel for
Zero Setting the Connector Gage
Dial Indicator
CAUTION: Do Not use as Handle
Graduated Dial
- Readings indicate Recession
of Center Conductor
+ Readings indicate Protrusion
of Center Conductor
Grasp the Gage here for Maximum Stability
Master Gage
Female Setting Surface
Male Setting Surface

034-92 A
September 2022 Operating Instructions 3
MAURY MICROWAVE
The specications listed in Table 2 are the performance standards based on factory measurements traceable to the
U.S.A. National Institute of Standards and Technology (NIST).
To verify that your gage kit is performing to traceable specications, periodically send the kit to Maury Microwave
Corporation for calibration. The recommended calibration cycle is one year. The actual need may vary depending
on usage.
NOTES:
1Per ASME B89.1.10M-2001, C5.1.2.
2Per ASME B89.1.10M-2001, Table 2.
3Per manufacturer's specication.
4Operator skill has a great impact on repeatability. You can easily determine the repeatability of the connector
gages by multiple engagements of the master gages following the procedure outlined under Zero Setting on
page 5.
5Performance standards are in compliance with ANSI/NCSL Z540-1, MIL-STD-45662A and ISO 10012-1.
6Applies over the operating range for connector gaging +0.006/-0.003" from master gage zero setting.
Table 2
Connector Gage Specications
Characteristics Limits Comments
Gage Resolution ± 0.000050 1/5 Least dial graduation 1
Gage Calibration Accu-
racy 6± 0.000375 1 Least dial graduation 2 plus 0.000125 measurement
guardband
Gage Repeatability 4± 0.000050 1/5 Least dial graduation 2
Master Accuracy ± 0.000050 0.00010 Range 3
Total Uncertainty 5, 6
RSS
Worst Case
± 0.000385
± 0.000525
Root sum of the squares.
Add resolution, repeatability, gage and master accuracy limits.

034-92 A
September 2022
4 Operating Instructions
MAURY MICROWAVE
NOTES:
1Female contact pin location.
2Male contact pin location.
3Tighter tolerances can be used at user's discretion.
4In reference to the outline above, Plus (+) tolerances indicate a recessed condition from the outer conduc-
tor mating plane.
Minus (-) tolerances indicate a protruding condition above the outer conductor mating plane.
5 Other dimensions shown in this gure are shown since they affect the mating of the Gage Assemblies'
gaging mechanisms (bushing and pin). Deviation from these dimensions may cause measurement errors
or improper t between the gaging mechanisms and the connectors being measured.
Consult our Customer Service Department on measuring connectors with interface dimensions other than
specied above.
Connector
Type d D "FP" 3 "MP" 3 Comment
APC3.5 .0598 .1378
+.003
.000
-.000
+.003
.000
-.000
Rated to 34 GHz
2.92mm (K) .0500 .1150
+.003
.000
-.000
+.003
.000
-.000
Rated to 40 GHz
Figure 2. Critical Contact Pin Location Dimensions of 3.5mm and 2.92mm (K) Precision Connectors

034-92 A
September 2022 Operating Instructions 5
MAURY MICROWAVE
Operation
Visual Inspection
Inspect all connectors carefully before each use. If a connector shows deep scratches, dents, uneven wear, or par-
ticles clinging to the mating plane surfaces, clean it and inspect again. Damaged connectors should be set aside
for repair. Also, try to determine the cause of the damage before making further connections.
Cleaning
Use dry compressed air of a very low velocity rst; then a solvent such as isopropyl alcohol. Clean the contacting
surfaces using a lint free swab. Then re-inspect the connector to make sure that no bers have been left around the
contact and mating surface.
CAUTION: For optimum measurements, never rotate parts against each other since this will yield faulty readings
and could damage the mating surfaces.
Verifying Zero Setting
The gage assemblies are pre-set at the factory for zero setting, however, the user should verify the zero setting prior
to each use as follows.
NOTE: The master setting gage is marked 'M' (male) and 'F' (female) to correspond to the 'M' and 'F' marked on
the indicator assemblies.
Procedure: Refer to Figure 3
Example for Zeroing Male Connector Shown (Applies Equally to Female Connector Gage)
1. Visually inspect the mating surfaces of your connector gage and master setting gage.
2. Clean both mating surfaces using the cleaning procedure above.
3. Align the connector gage and master setting gage. Carefully engage the master gage with the dial indicator
until the master gage seats securely. The dial hand should rotate clockwise and stop at zero after one or
more revolutions.
4. If resetting zero is required, engage the master gage, then while holding the dial indicator and master gage in
one hand, loosen the dial lock and rotate the bezel (outside rim on indicator) to the zero position indicated
by the hands on the indicator. Re-tighten the dial lock.

034-92 A
September 2022
6 Operating Instructions
MAURY MICROWAVE
Adjust Outside Bezel for
Proper Zero Reading.
Dial Lock
Zero Set the Connector Gage
using the Master Gage.
If Dial Hand Does NOT Read Zero,
Reset as Shown Below.
Figure 3. Zero Setting the Connector Gage
Align your Connector Gage and
the Master Gage

034-92 A
September 2022 Operating Instructions 7
MAURY MICROWAVE
Gaging 3.5mm and 2.92mm (K) Connectors
The critical mechanical specication in precision 3.5mm and 2.92mm (K) connectors is the recession (setback) of
the center conductor relative to the outer conductor mating plane. No protrusion of the center conductor in front
of the outer conductor mating plane is allowable.
Gaging Female & Male Connectors
Contact Pin Location: Dimension 1 & 2 , Figure 2.
1. Using the gage assembly with corresponding 'F' (female) or 'M' (male) master setting gage end, check the
zero setting of the connector.
2. For Female: Carefully engage the female connector to be gaged to the female gage assembly. The gage
assembly bushing will slip into the connector and bottom on the outer conductor mating plane.
For Male: Carefully align the center contact pin of the male connector to be gaged so that it will enter the
hole in the pin of the male gage assembly. Engage straight on until the gage bushing bottoms on the outer
conductor mating plane of the male connector.
3. The pointer of the dial indicator will then indicate the deviation from zero. A minus (-) reading of the dial
shows that the center contact is below the outer conductor mating plane and a plus (+) reading shows that
the center contact is protruding past the outer conductor mating plane, which is not acceptable.

034-92 A
September 2022
8 Operating Instructions
MAURY MICROWAVE
Figure 4. Example of Gaging the 3.5mm and 2.92mm (K) Connectors
Align your Connector Gage
and the Connector.
Zero Set the Connector Gage
using the Master Gage.
Gently Connect the Device.
0.0015 in.
0.0 in.

034-92 A
September 2022 Operating Instructions 9
MAURY MICROWAVE
Maintenance
These connector gage kits are relatively maintenance free if the components are handled with the same care that is
appropriate to all precision equipment. As with any precision component, proper care should be taken to assure
clean mating surfaces, proper alignment, and proper torquing. Repair and calibration should be referred to our
Customer Service Department.
Calibration
To verify that your connector gage kit is performing to traceable specications, periodically send it to Maury Mi-
crowave Corporation for calibration. The recommended calibration cycle is one year. The actual need may vary
depending on usage.
Should Additional Information or Service be Required, Address Inquiries To:
Maury Microwave Corporation
Attention: Customer Service
2900 Inland Empire Boulevard
Ontario, California 91764-4804
USA
Phone: [phone] Facsimile: [phone]
E-mail: [e-mail] Web site: http://www.maurymw.com
Please mention the model number and revision of the software and the date received in any correspondence.
Warranty
We warrant each instrument of our manufacture to be free from defects in material and workmanship. Our obligation
under this warranty is limited to servicing or adjusting any instrument returned to our factory for that purpose, and to
making good at our factory any part or parts thereof except fuses or batteries. This warranty period is limited to one
year from date of shipment to the original purchaser, and to equipment which is returned to us with transportation
charges prepaid and which, upon our examination, shall disclose to our satisfaction to have been defective. This
warranty does not cover wear from normal usage nor subsequent damage after shipment.
We reserve the right to make changes in design at any time without incurring any obligation to install such changes
on units previously sold by us.
This constitutes the only warranty extended by us, and is in lieu of any other obligations or liabilities on our part in
connection with the sale of our equipment.
Maintenance, Calibration & Warranty
