MaxComm M-150 User manual

4G LTE Industrial DTU Router
Model : M-150
MaxComm Co.,Ltd

目录
1 Summary...........................................................................................................................3
1.1 Brief of Overview....................................................................................................3
1.2 Reference standard................................................................................................3
2 Product photo....................................................................................................................4
3 Product main feature ........................................................................................................4
4 Hardware function.............................................................................................................5
4.1 Hardware interface introduction .............................................................................5
4.2 Indicator function introduction ................................................................................5
4.3 Hardware platform introduction..............................................................................6
4.4 Hardware watchdog function introduction..............................................................6
5 WIFI parameter introduction.............................................................................................6
6 Power supply ....................................................................................................................7
7 4G mobile telecommunication..........................................................................................8
8 Structure parameter and accessories...............................................................................8
9 Software............................................................................................................................8
10 Product working temperature requirement.....................................................................9

1 Summary
1.1 Brief of Overview
This document describes the electrical characteristics, RF performance,
size and application environment of M-150. Under the introduction of this
document, end users or developers can quickly understand the hardware
functions of M-150.
M-150 is an industrial DTU with 4G function, used for data transmission
services of industry users, supports transparent data transmission, access to
the Internet through 4G mobile communication dial-up or 100Mbps WAN port
dial-up, and then share the Internet network through wireless WiFi 4 and
100Mbps wired LAN .
1.2 Reference standard
Relevant standard specifications:
USB2.0 bus standard
Standard SIM/USIM interface standard
IEEE802.11n/g/b
IEEE802.3/802.3u
Mini PCI Express Card Electro mechanical Specification Revision 1.0-2003
4G mobile communication standard, which is determined by the selected 4G
mobile communication module

2 Product Photo:
3 Main features of the product:
Using MT7628DA solution, MIPS24KEc architecture CPU, the main frequency is up
to 580MHZ
MT7628DA chip integrates 2.4G WIFI function, the rate is up to 300Mbps
MT7628DA chip integrates 64MB DDR2, with 8MB Nor Flash
1WAN, 1LAN full 100M adaptive network ports, support auto flip (Auto MDI/MDIX)
Support one RS232, one RS485 serial communication interface, support anti-static
and anti-surge design
Support 9-32V power supply, meet industrial power requirements, support anti-static
and anti-surge design
Support "one-key flashing mode", that is, long press the reset button to turn on the
machine to enter the rescue flashing mode
Built-in mini-PCIE standard interface, which can be used to connect 4G mobile
communication module
External standard SIM card interface, support SIM/USIM card
External high-gain omnidirectional antenna, wireless signal 360 degrees without

dead angle
This product supports the hardware watchdog function, and the device will
automatically restart when the routing system or 4G module fails
4 Hardware function
4.1 Hardware interface introduction
Network
ports
1 WAN port, 100Mbps support auto flip (Auto MDI/MDIX)
Compliant with IEEE 802.3/802.3u
1 LAN port, 100Mbps supports auto flip (Auto MDI/MDIX)
Compliant with IEEE 802.3/802.3u
SIM card slot
SIM card interface 1 standard SIM card (large card) interface,
support SIM/USIM
Power port
DC5.0*2.1MM
Button
1* reset button
Antenna
2 external 2.4G antennas
2 external 4G mobile communication antennas, compatible with
3G/2G mobile data communication
Connector
6 PIN connector, this connector is RS232 and RS485
communication interface
4.2 Indicator function introduction
Power LED
always on when the power is turned on, and it is not on when the
power fails or is not connected to the power supply. The left LED
lights in the bottom row
2.4G WIFI LED
always on when the 2.4G WIFI function is turned on, flashes when
there is data communication, and it is not on when the 2.4G WIFI
is not turned on or when the 2.4G WIFI function is faulty, the right
LED lights in the lower row
Mobile 4G LED
This LED light is controlled by the routing system, it is recognized
that the 4G module is always on, the 4G module is faulty or there
is no 4G module, the LED light does not light up, the left LED light
in the upper row
External network
LED light
The device dials successfully through the 4G mobile
communication module or the WAN port. It is always on when it

4.3 Hardware platform introduction
Processor
MT7628DA MIPS24KEc architecture CPU, the main frequency is
up to 580MHZ
2.4G WIFI
Chip
MT7628DA integrates 2.4G WIFI function
IEEE 802.11n/g/b, maximum rate 300Mbps
RAM
DDR2 64MB, Does not support custom memory size
Flash
Nor Flash 16MB
Not support NAND Flash
4.4 Hardware watchdog function introduction
This hardware product is designed with a hardware watchdog function. After the hardware
watchdog is powered on, it will automatically turn on and detect the heartbeat level output
by the routing system that jumps once per second. If the routing system itself fails (such
as a crash), it will also Naturally, the heartbeat level can no longer be output. At this time, if
the hardware watchdog does not detect the heartbeat level within 120 seconds, it will shut
down itself for 15 seconds and then restart the entire system.
When the routing system is operating normally, but the 4G module dialing is abnormal, the
routing system will control the 4G module's power supply and let the 4G module
automatically restart to repair the 4G dialing abnormal problem.
5 WIFI Wireless parameter introduction
communicates with the Internet normally, and it does not turn on
when the device cannot access the Internet. The upper row of left
LED lights
Watchdog work table
Routing system is abnormal
4G module dialing is abnormal
Restart the whole system
Only restart the 4G module

Compatible with IEEE 802.11 b/g/n, support IEEE 802.11 d/h/k; support
20MHz, 40MHz, use 2T2R MIMO antenna technology, the highest connection
rate is up to 300Mbps. The following is an explanation of 2.4G WIFI's power
frequency, receiving sensitivity, and transmitting power.
Items
Max.
Rated
value
Mim.
Unit
Work
frequency
2484
2412
MHz
Receiving
sensitivity
11 Mbps CCK
-86
-87.5
-89
dBm
54 Mbps OFDM
-72
-74
-76
dBm
BW=20MHz MCS 7
-70
-72
-74
dBm
BW=40MHz MCS 7
-68
-70
-71
dBm
Transmit
power
11 Mbps CCK
19
18
17
dBm
54 Mbps OFDM
17
16
15
dBm
BW=20MHz MCS 7
17
16
15
dBm
BW=40MHz MCS 7
16
15
14
dBm
6 Power supply and power consumption description
Test Condition
Min.
Rated
value
Max.
Unit
Work voltage
T A = 25°C
6
12
32
V
Absolute working
voltage
T A = 25°C
5
36
V
Work current
VIN=12V，T A =
25°C
0.3
0.5
0.8
A
Please use the MaxComm standard power adapter to supply power to this
product. If the MaxComm standard power supply is not used, please supply
power to this product in strict accordance with the above power specifications,
otherwise the product will be damaged. If you use a battery or vehicle power

supply to supply

power, you must take anti-static and anti-surge countermeasures.
7 4G mobile communication function
This product has a built-in mini-PCIE interface, which can be used to
expand 4G mobile communication functions, and the built-in mini-PCIE
interface supports USB2.0 bus. The specific frequency band supported by 4G
mobile communication is determined by the selected 4G module.
8 Introduction to structural parameters and
accessories
Weight
（KG)
TBD
Shell size
TBD
Color
TBD
Accessories
Manual
1PCS
Certificate of
conformity
1PCS
Power
adapter
12V1A 1PCS
Network
cable
8P8C 1PCS
SIM card
adapter
1PCS
9 Software configuration information
Default IP
192.168.1.1
User name
Password
root/admin
2.4G SSID
WIFI-XXXXXX (X is the last 6 digits of MAC address), no password
by default
5.8G SSID
NA

The above is the general default configuration information of the product. The WIFI
SSID may be different when using our OS firmware or OPENWRT firmware, but the
default IP and WEB login name and password of this product remain unchanged. For
other detailed software functions, please refer to the product description.
10 Product working environment requirements
Work
temperature
0℃to 40℃
Storage
temperature
-40℃to 70℃
Working
humidity
10% to 90%RH Non-condensing
Storage
humidity
5% to 90%RH Non-condensing
