Maxent 58" User manual

Owner’s Manual
l
e
n
a
P
t
a
l
F
a
m
s
a
l
P
58” Plasma TV

2
2
EN
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock, do not remove the front or back covers.
No user-serviceable parts inside. Refer servicing to qualified service personnel only.
The lightning flash with arrow-head
within a triangle is intended to inform
the user that parts inside the product
are a risk of electric shock.
The exclamation point within a triangle
is intended to tell the user that important
operating and servicing instructions are
explained.
Warnings & Precautions
To prevent damage which may result in fire or shock hazard, do not expose this product to rain or moisture.
To prevent electric shock, do not remove cover. No user serviceable parts are inside. Refer servicing to
qualified service personnel only.
Keep display away from excessive dust, high temperature, moisture or direct sunlight.
Use in a well-ventilated area and do not cover ventilation openings.
Unauthorized modifications to this equipment or usage of an unshielded connecting cable may cause
excessiveinterference.
When the display is not in use, disconnect it from the electric outlet.
If the picture displayed is in any way abnormal, turn off the unit and disconnect it from the electric outlet.
Verify your signal wire connections and reconnect the display to the electric outlet.
Do not place this product on an unstable cart, stand or table. The product may fall, causing serious
damage.
Do not place the unit on a bed, sofa, rug, or other similar surfaces.
Never place the unit near or over a radiator or heat source.
Do not install unit in an enclosed area unless proper ventilation is provided.
The unit should be operated from the type of power source indicated on the label. If the type of available
power is unknown, consult your dealer or local power company.
The unit is equipped with a 3-pin grounded plug. The plug will only fit into a grounded power outlet. This is a
safety feature. If you are unable to insert the plug into the outlet, contact your electrician. Do not alter this
plug as this will defeat the safety feature. Power cord not lighter than H05VV-F, 3G, 0.75mm2shall be used.
Do not rest objects on the power cord & avoid placing power cord near high traffic areas.
Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
Unplug the display from the electric outlet and disconnect the antenna/cable TV system during a lightning
storm or when left unused for long periods of time. This will prevent damage to the display caused by
lightning and power-line surges.
Avoid overhead power lines. An outdoor antenna system should not be placed in the vicinity of overhead
power lines, electric lights, or power circuits. When installing an outdoor antenna, be careful to not touch
any power lines or circuits as contact with these lines can be fatal.
Do not insert any foreign objects through the ventilation openings to the display. It may
touch dangerous voltage points or damage parts.
Special Notices
Certain programs may be copyrighted and any unauthorized recording in whole or in part may be in violation
of copyright laws in the U.S. and Canada.
FCC/CSA regulations state that any unauthorized modifications to this display may void user authority to
operate it.
Important Safety Instructions

3
3
EN
If an outdoor antenna or cable system is connected to the display, be sure the antenna or cable system is
grounded to provide some protection against voltage surges and static charge buildups. Section 810 of the
National Electrical Code,ANSI/NFPANo.70-1984, provides information about proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the
groundingelectrode.
If this display is equipped with separate speakers, please remove the speakers prior to moving the display.
Moving the display with the speakers attached may cause damage or injury.
Disconnect the unit from the main supply and refer servicing to qualified service personnel under the follow-
ing conditions:
-Power cord or plug is damaged or frayed.
-Liquid has been spilled into the product and/or the unit has been exposed to water or moisture.
-Unit does not operate normally when the operating instructions are not followed. Adjust only those
controls that are covered by the operating instructions, improper adjustment of other controls may result
in damage which often requires extensive work by a qualified technician to restore the unit to normal
operation.
-Unit has been dropped or the cabinet has been damaged.
-Unit exhibits a distinct change in performance, indicating a need for service.
Cleaning & Maintenance
Disconnect from the electric outlet before cleaning. Do not use liquid or aerosol cleaners. Use only a slightly
damp cloth for cleaning.
Special Warranty Information
Cell Defects
Although the display panels are produced with more than 99% percent active cells, there may be some cells
that do not produce light or remain lit. This is considered normal and not a manufacturer defect.
Important Safety Instructions
Note to CATV System Installer-This reminder is provided to call the CATV system install’s attention to
Section 820-93 of the National Electric Code which provide guidelines for proper grounding and in
particular, specify that the Coaxial cable shield shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.

4
4
EN
FCC Statement
The Federal Communications Commission Radio Frequency Interference Statement includes the following
warning:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television receptions, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
followingmeasures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Warning
User must use shielded signal interface cables to maintain FCC compliance for the product. Provided with this
display is a detachable power supply cord with IEC320 style terminations. It may be suitable for connection to
any UL Listed personal computer with similar configuration. Before making the connection, make sure the
voltage rating of the computer convenience outlet is the same as the monitor and that the ampere rating
of the computer convenience outlet is equal to or exceeds the monitor voltage rating. For 120 Volt applications,
use only UL Listed detachable power cord with NEMA configuration 5-15P type (parallel blades) plug cap. For
240 Volt applications use only UL ListedDetachable power supply cord with NEMAconfiguration 6015P type
(tandem blades) plug cap.
IC Compliance Notice
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regula-
tions of ICES-003.
Cet appareil Numerique de classe B respecte toutes les exigences du Reglemont NMB-03 sur les equipements
produisant des interferences au Canada.
Notice de Conformit IC
Cet appareil numerique de classe B respecte toutes les exigences du Reglement ICES-003 sur les equipements
produisant des interferences au Canada.
Regulatory Notice
Manufactured under license fromDolby Laboratories.
Dolby and the double-Dsymbol are trademarks ofDolby Laboratories.

5
5
EN
Important Safety Instructions ................................................................................................................... 2
SpecialNotices.................................................................................................................................2
Warnings & Precautions ................................................................................................................... 2
Cleaning & Maintenance ...................................................................................................................3
Special Warranty Info........................................................................................................................3
RegulatoryNotice.................................................................................................................................... 4
Getting to Know Your TV .........................................................................................................................7
Package Contents ............................................................................................................................8
Front Panel Controls .........................................................................................................................9
Rear Panel Connections ................................................................................................................... 10
RemoteControl.................................................................................................................................11
Display Connections ...............................................................................................................................13
Connecting TV, CATV or ATSC .......................................................................................................14
Connecting a VCR ............................................................................................................................14
Connecting a DVD ............................................................................................................................15
Connecting a Set-Top Box ................................................................................................................17
External Audio Connections.............................................................................................................18
Connecting a PC ..............................................................................................................................19
Basic Operations.....................................................................................................................................21
Powering On/Off...............................................................................................................................22
Changing Inputs ...............................................................................................................................22
VolumeAdjustment............................................................................................................................ 23
Channel Up/Down .............................................................................................................................23
On-ScreenDisplay Menu .................................................................................................................24
On-Screen StatusDisplay ................................................................................................................25
Understanding Widescreen Modes ...................................................................................................26
Change Aspect Ratios .....................................................................................................................27
Picture Controls ......................................................................................................................................29
Adjusting Picture Settings .................................................................................................................30
Picture-in-Picture .............................................................................................................................32
Noise Reduction ...............................................................................................................................33
Adjusting Screen Size ......................................................................................................................34
Fine Tuning PC Mode .......................................................................................................................35
Quick Access ...................................................................................................................................35
Picture Mode ....................................................................................................................................35
Audio Controls ........................................................................................................................................37
AdjustingAudio Settings ...................................................................................................................38
Using Surround Sound .....................................................................................................................40
Built-inAmplification (Speaker).........................................................................................................41
Fixed / Variable Audio Output ...........................................................................................................42
Advanced Functions................................................................................................................................43
SleepTimer ......................................................................................................................................44
OSDMenu Language ....................................................................................................................... 44
Power Save Mode ............................................................................................................................ 45
Image Shift .......................................................................................................................................46
TimeZone.........................................................................................................................................46
System PassCode ............................................................................................................................52
Table of contents

6
6
EN
Table of Contents
Daylight Saving ................................................................................................................................ 48
Full Screen Type .............................................................................................................................. 49
Full Screen Start ............................................................................................................................... 49
TV Function ............................................................................................................................................ 51
Memorizing Channels ....................................................................................................................... 52
On-Screen Status Display (TV/Digital TV Mode) ............................................................................... 54
Blue Back ......................................................................................................................................... 55
Changing Channel ............................................................................................................................ 55
Closed Captioning (Analog/Digital TV Modes)................................................................................... 56
Parental Block (V-Chip) .................................................................................................................... 58
Quick View ....................................................................................................................................... 61
Channel Lock ................................................................................................................................... 62
Program Guide ................................................................................................................................. 63
Understanding HDTV ........................................................................................................................ 64
Advanced ................................................................................................................................................ 67
Adjusting Advanced Settings ............................................................................................................. 68
Power Step ....................................................................................................................................... 69
Default Aspect .................................................................................................................................. 69
Input Skip ......................................................................................................................................... 70
Appendix ................................................................................................................................................. 71
Troubleshooting ................................................................................................................................ 72
Wall Mount Instructions .................................................................................................................... 73
Specifications for 58” TV .................................................................................................................. 75
How to program the Universal Remote Control .................................................................................. 77
Component Program Code ............................................................................................................... 78

7
7
EN
Getting to Know
Your TV
Getting to Know Your TV

8
8
EN
Package Contents
lortnoCetomeRVTlenaPtalF Batteries
draCytnarraWlaunaMresU Power Cord
Getting to Know Your TV
Quick Start Guide

9
9
EN
Infrared Receiver
Receive IR signal from the remote control.
Status LED
Orange - Standby (Power OFF) with AC
power detected
The LED will illuminate in orange color if the
TV is shut-off but the main power cord is
plugged into•the back of the unit.
Solid Green - Power ON
Receive IR signal from the remote control.
Power (Standby) Button
Turns power on or off from standby mode. There is
a wait period between on or off cycles.
Volume Adjustment Buttons
Use these buttons to adjust volume up and down.
These keys also serve as navigation and adjustment
keys when On Screen Display menu is engaged.
Channel Select Buttons
Use these buttons to select Channel up or down.
Menu Button
Use this button to engage the On Screen Display
menu.
Input Button
Use this button to switch between available inputs.
Getting to Know Your TV
Side Panel Controls

10
10
EN
Composite / S-Video Inputs
Connect Composite or S-Video signals from
external sources such as VCRs or DVD players.
Antenna Jack
Connect to an antenna, cable service for standard
NTSC service or digital cable for Digital TV.
Rear Panel Connections
Digital HDMI/DVI Inputs
Connects to the digital video signals from a DVD
player or Set-Top Box.
PC Input
Connect to another computer monitor for chaining
applications.
RS-232 Connector
Connect to a computer serial port.
Audio Output
Variable or fixed audio output jacks for connecting
to an external audio amplifer.
Component Video Inputs
Auto-detecting component video inputs (Y/Pb/Pr or
Y/Cb/Cr) for connecting to the component output
jacks of a DVD player or Set-Top Box.
Getting to Know Your TV
SPDIF Digital Audio Output
When the Digital TV input is selected for viewing,
the digital audio associated with Digital
programming will be available on this output for
connection to your home theatre system.
