MAXHUB ViewPro Series User manual

MAXHUBV6
ViewPro Series
Quick Start Guide
All the pictures in this manual are for reference only, subject to our available products.

Thank you for choosing MAXHUB product.
To ensure that you are able to fully utilize the capabilities of the product, we ask that you
please read this user manual carefully and thoroughly before using the device. Should you
have any questions or require assistance, please do not hesitate to contact our technical
support team for guidance.
Safety Warnings
Placement
(1) Please do NOT place the product on a slope, mount on an unstable stand or an insuiciently
robust wall, a table nor a shelf.
(2) Please do NOT expose the product to direct sunlight or any other heat source.
(3) Please do NOT put the product near devices that generate strong magnetic fields.
(4) Please do NOT place the product in a humid environment for it is NOT water-proof. Keep it
from water splashes.
(5) Please do NOT place any other heavy objects on the product.
Power Supply
(1) Please check the product’s operating voltage and frequency matches the local power
configuration.
(2) Please unplug the device during storming or thundering weather.
(3) Please unplug the power should the product is left unused for long time.
(4) Please keep the power cable from physical or mechanical damage.
(5) Please use the original power cable from the accessory bag, don't modify or lengthen it.
(6) Please make sure the AC is grounded.
(7) This power cable comes with the device exclusively for this device only.
LCD Screen
(1) Do NOT use hard nor sharp objects on the screen other than MAXHUB stylus.
(2) Please unplug the power before cleaning the product.
Please clean the screen with a soft, dustless and dry cloth.
(3) Please do NOT use water or liquid detergent to clean the product.
(4) Please contact the authorised reseller for thorough cleaning.
(5) Please do NOT display a high-brightness image on the screen for too long time.
Viewing Distance
For optimal viewing experience, it is recommended to position the interactive flat panel at a
distance that is 3-4 times the diagonal length of the screen.
Temperature & Humidity
(1) Please do NOT put the product near a heater nor a radioactive source.
(2) If the product is moved from a cold place to a warm one, please unplug the power cable
and allow the product to gradually warm up for at least two hours to reduce the moisture.
(3) Operating temperature of the product is 0°C-40°C, operating humidity is between
0%-90%RH.
(4) avoid exposing the unit to rain or placing it in high humidity areas. Additionally, it is
crucial to keep the unit in a dry and cool indoor environment.

Ventilation
Please ensure that the interactive flat panel is placed in an area with adequate ventilation
to allow for proper heat dissipation. It is recommended to leave a minimum of 10cm of space
on the left, right, and back of the device, and 20cm of space above it to ensure proper airflow
and optimal performance.
Earphone
When using the earphones, it is important to be aware that prolonged listening at high
volumes may cause temporary or permanent hearing loss. To prevent this, we strongly
recommend turning down the volume before inserting the earphones into your ears.
Energy Saving
Please note that pressing the power button briefly will not fully shut down the interactive flat
panel. Instead, it will enter standby mode, with only the screen turning o. To properly shut
down the device, press and hold the power button for approximately 3 seconds and confirm
the shut down command that appears on the center of the screen.
Notes for Cleaning
Please do not block or cover the heat vents on the back panel and do not spray liquids on the
device.
Power Switch Status Signs
“I” means power on, “O” means power o.
Maintenance
Please contact authorised reseller for maintenance or repairing.
Warranty Exclusions
MAXHUB does not warranty Products that match any one or few of the following descriptions:
(1) Product damages caused by violating the user manual.
(2) Hardware damages caused by improper setup.
(3) Product damages caused by unauthorised modification or maintenance.
(4) Product damages caused by using in an unsuitable environment.
(5) Product damages caused by abnormal external force.
(6) Product damages caused by natural disasters or other force majeure.
(7) Damaged Warranty Sticker.
(8) Unable to provide eective purchase certificate.
I. Unboxing Checklist
Wall Mounting Bracket ×1 Quick Star Guide×1 Interactive Flat Panel ×1
User Manual
Interactive Flat Panel

II. Installation Guide
1.Confirm the panel installation position.
Align the wall-mounted screw holes with the studs on the back panel and fasten with 2 wall-mounted
strips.
First, fasten the screws on the top side, then fasten the screws on the bottom side. A total of four
screws are required.
Refer to the table below for the position of the lock hole.
(The picture is for reference only)
1
23
9
11
12
4
8
10
13
5
67
SizeSeries
ViewPro
Bracket and holes
WIB9060G- hole #11
WIB9060G- hole # 1
65
86
Step 2:fasten the screws
on the bottom
Step 1:fasten the screws
on the top
Power Cord*
Type-C Cable (1.8M)×1
The Wireless Module×1
Note:【*】Power cord could be dierent for dierent regions , pls refer to the actual product.
HDMI Cable (1.5M)×1 Passive Stylus×2

3 Take 8 pcs of expansion rubber plug b
and screw it into the wall. It is recommended
to use 10 mm impact drill bit.
4Fix the wall bracket on 8pcs expansion
plug b with a combination of 8 pcs screw C
and gasket d.
Ø 10
b×8
c×8d×8
Take the panel out of the box and place it on a soft surface, such as a mat, to protect it
during installation.
2
wall wall
2.Steps to install the wall mount
Take out the wall mount plate accessory package from the accessory box.
b-8pcs c-8pcs d-8pcs
a-1pcs
1

3.Reference On Wall Mount
When planning for wall mounting, it is important to take into consideration the physical
dimensions of the panel. To ensure ease of use, it is recommended to maintain a proper
distance between the wall and the back of the panel.
w
4-M8×25
Please mind the junction
12mm
L
L1
L2
NOTE: The table and diagram are only for reference.
Series
L
L1
L2
H
W
Dimension
ViewPro
1500 mm 1969 mm
925 mm 1188 mm
117 mm 126 mm
305 mm 522 mm
440 mm 486 mm
65" 86"
5Tighten the safety screw counter-clockwise
to make the top of screw reach the second
screw hole.
6Hang the panel vertically on the bracket
and then finish installation.
Tilt the Device Mounting arms
& Screen
Wall Plate
Note: This step is especially important for
installation on the mobile stand. Tightening
the safety screws will make device more stable.
Note: Please keep the panel in the center of
the bracket.

III. Installing the Wireless Module
Please make sure that the following items are ready before setting up the wireless module.
1×Interactive Flat Panel
1×Wireless Module
2×Screws (CM3×6mm)
Please make sure the power cord of the Interactive Flat Panel is disconnected before
installation.
Step1: Remove the Mylar on the bottom of the interactive flat panel. Use a Phillips screwdriver
toloosen two screws and remove the cover.
Step2: Insert the wireless module into the wireless module slot and screw it up.
Note: This Wireless Module only works for the Interactive Flat Panel by plugging it into
the above slot.
Mylar from the bottom
Wireless Module
Wireless Module
Screws

IV. Installing the PC module/Android Module
Please make sure the power cord of the Interactive Flat Panel is disconnected before
installation.
Step1: Unscrew and remove the cover. Step 2: Prepare the PC module/
Android Module.
cover
PC module Android Module
Step4: Installation of PC module/Android module..
Rail up
Insert the module
Step3: Unscrew and remove the cover.
Slot
Bottom
Up

Plug the power cable into the power socket of the product.
Plug the power cable into the power supply.
flip the rocker switch and press the power button. The indicator light will turn white when the product
is powered on.
V. Removing the PC module/Android Module
Please make sure the power is o before proceeding with the removal.
VI.Power On/0
To remove the module, press up on the module
and release the lock.

88
9
121467
5
3
910
VII. Control Panel
To ensure the proper functioning of the product, it is important to keep it free of dust and
moisture. Regular cleaning with a soft, dust-free, and dry cloth is recommended. Remember
to unplug the product before cleaning.
Number
Function description
1 Magnetic zone Area for placing the absorptive magnetic pen
2 Wireless module
3Tap to enter energy saving function press at least 2 seconds to enter
standby mode
4 Remote control signal receiver Receive the remote signal
5 Light sensor Identify the brightness of ambient light
6
USB Type-C Supportcharging, data transmission, extension for
audio and video output interface, etc.
Note The maximum rated power of the USB Type-C port of this
product is 'XX'W. When using this port to charge electronic devices, the
charging power of the electronic device cannot exceed the rated power
of this port. If the charging power of the electronic device exceeds the
rated charging power of this port, please Do not directly use this port
for charging.
：
：
：
：
：
